Intermec Janus 2050 User manual

P/N 065716-001
User’s
Manual
JANUS
™
2050
Vehicle-Mount Computer (4MB)

P/N 065716-001
User’s
Manual
JANUS
™
2050
Vehicle-Mount Computer (4MB)

IntermecCorporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. service and technical support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian service and technical support: 1-800-688-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for the purpose of allowing
customers to operate and/or service Intermec manufactured equipment and is not to be released,
reproduced, or used for any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change without notice.
1997 by Intermec Corporation
All Rights Reserved
The word Intermec, the Intermec logo, JANUS, IRL, TRAKKER, Antares, Duratherm, Precision
Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or registered trademarks of
Intermec Corporation.
CardID™ and CardSoft™ are trademarks of SystemSoft Corporation. Some of the information in this
manual is based on copyrighted material contained in the CardSoft™ 3.1 Software User’s Guide,
published by SystemSoft Corporation, 1992-1994, Natick, Massachusetts.
Throughout this manual, trademarked names may be used. Rather than put a trademark (™ or )
symbol in every occurrence of a trademarked name, we state that we are using the names only in an
editorial fashion, and to the benefit of the trademark owner, with no intention of infringement.

code 39
nuggetnugget A
Contents
iii
Contents
Before You Begin xv
Warranty Information xv
Safety Summary xv
Warnings and Cautions xvi
Terms and Conventions xvii
Suggested Reading xix
Getting Started
Overview of the JANUS 2050 1-3
Starting the JANUS 2050 for the First Time 1-6
Unpacking the JANUS 2050 1-6
Mounting the JANUS 2050 on a Vehicle 1-6
Connecting the JANUS 2050 to the Vehicle Power Supply 1-9
Attaching the Antenna 1-10
Connecting a Scanning Device to the JANUS 2050 1-11
Turning On the JANUS 2050 for the First Time 1-13
Turning the JANUS 2050 On and Off 1-13
Setting the Time and Date 1-14
Entering Data 1-14
Using a Laser Scanner 1-15
Scanning Techniques 1-16
JANUS 2050 Accessories 1-17
Where Do You Go From Here? 1-17
Operating the JANUS 2050
Using the JANUS 2050 Features 2-3
The JANUS 2050 Keypad 2-5
How to Type the Characters Printed on the Keypad 2-6
Using the Keypad 2-6
Ctrl, Alt, and Shift Keys 2-6
Compound Function Key 2-7
Additional Keys 2-7
Cursor Keypad 2-7
Numeric Keypad 2-7
Entering ASCII Characters 2-8
1
2

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
iv
International Keypads 2-9
DOS Code Pages 2-9
Alpha Keys With Multiple Characters 2-9
Numeric Keys With Multiple Characters 2-9
Alt and Shift Keys 2-9
Special Characters 2-10
International Keypad Examples 2-10
Terminal Emulation (TE) Keypads 2-14
Accessing TE Commands on the Keypad 2-15
Shift Key 2-15
Ctrl and Alt Keys 2-15
Compound Function Key 2-15
Booting the JANUS 2050 2-16
Performing a Cold Boot 2-16
Performing a Warm Boot 2-16
Understanding the Status LEDs 2-17
Display Modes 2-19
Understanding Audio Signals and Beep Sequences 2-20
Estimating Power Usage 2-21
Recharging the Backup Battery 2-21
Defining JANUS 2050 Drives 2-22
Drive C 2-22
Drive D 2-22
Drive E 2-23
PC Card Drive (G) 2-23
Memory Management 2-24
Using the JANUS Software
Software Provided With the JANUS 2050 3-3
What Software Is Provided on the Companion Disks? 3-4
Using DOS Commands 3-5
Defining the Startup Files 3-6
AUTOEXEC.BAT File 3-6
CONFIG.SYS File 3-8
3

code 39
nuggetnugget A
Contents
v
MS-DOS Startup Menu 3-10
Learning How to Change the Contents of Drive C 3-10
Creating a RAM Drive 3-11
Changing Drive C and Configuring for International Languages 3-13
Using Auto-Loader to Change Drive C 3-14
Installing Auto-Loader 3-14
Creating and Loading an Image File 3-16
Creating an Image File 3-18
Loading an Existing Image File 3-20
Using MakeDisk and PutDisk to Change Drives C or D 3-21
Deciding Where to Run MakeDisk 3-21
Creating and Filling the Working Source Directory 3-22
Creating the New Image File 3-23
Loading the New Image File 3-23
Examples of Using MakeDisk and PutDisk 3-24
Using Reader Services 3-28
Understanding the Bar Code Wedge 3-29
Enabling Direct Hardware Wedge Functions 3-30
Using the Wedge Configuration Program 3-30
Configuring the JANUS 2050
Overview of Configuration Parameters 4-3
Configuring for Bar Code Symbologies 4-3
Defining Communications Parameters 4-4
Modifying Operations Parameters 4-5
Different Ways to Configure the JANUS 2050 4-6
Using the Configuration Application 4-7
Entering ASCII Control Characters 4-9
Communications Protocol Characters 4-9
Operation Preambles and Postambles 4-9
Using Multiple Configuration Files 4-10
Configuring the JANUS 2050 From the DOS Prompt 4-11
Loading a New Configuration File 4-11
Automatically Loading a Configuration File 4-11
Saving a New Configuration File 4-12
Loading the Factory Default Configuration 4-12
4

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
vi
Editing a Configuration File Using the Host Computer 4-13
Configuring With Bar Code Labels 4-14
Configuring Using IRL Z Commands 4-15
Configuring Through a User Application 4-15
Using PC Cards
Learning About PC Cards 5-3
What Is PCMCIA? 5-3
Supported PC Cards 5-3
Which Memory Cards Are Recommended? 5-4
Which Expansion Cards Are Recommended? 5-4
Accessing the PC Card Drive 5-5
Configuring, Formatting, and Using PC Cards 5-9
Preparing to Use ATA Cards 5-10
Initializing and Formatting an ATA Card 5-10
Using the ATA Card 5-11
Preparing to Use Flash Cards 5-12
Initializing and Formatting a Flash Card 5-12
Erasing a Previously Formatted Flash PC Card 5-14
Preparing to Use I/O Cards 5-15
Configuring the JANUS device to Use an I/O Card 5-15
Resetting the PC Card Drive for I/O Cards 5-16
Preparing to Use SRAM Cards 5-16
Formatting an SRAM PC card 5-17
Using the SRAM PC Card 5-17
Managing the Power on the PC Card Drive 5-17
Managing the PC Card Drivers in the Startup Files 5-18
Drivers in CONFIG.SYS 5-19
Drivers in AUTOEXEC.BAT 5-19
Tips for Enabling PC Card Drivers 5-20
Communicating With the JANUS 2050
Planning the Network Connection 6-3
Choosing a Communications Application 6-4
Choosing a Communications Protocol 6-4
Choosing a Protocol Handler 6-5
5
6

code 39
nuggetnugget A
Contents
vii
Setting Up the JANUS 2050 for Communications 6-7
Configuring the JANUS 2050 for Communications 6-7
Loading and Unloading Protocol Handlers 6-8
Loading/Unloading Protocol Handlers at the DOS Prompt 6-8
Loading/Unloading Protocol Handlers With a Batch File 6-9
Loading/Unloading Protocol Handlers With IRL Desktop or Communications
Manager 6-10
Specifying a Value for the FIFO Control Register 6-10
Different Ways to Communicate With the JANUS 2050 6-13
Communicating Using the Interlnk/Intersvr Utilities 6-13
Interlnk/Intersvr System Requirements 6-15
Installing Interlnk/Intersvr 6-15
Running Interlnk on the Host Computer 6-16
Running Interlnk on the JANUS 2050 6-17
Interlnk/Intersvr Status 6-18
Redirecting Drives 6-18
Exiting Interlnk/Intersvr 6-18
Restarting Interlnk/Intersvr 6-19
Communicating Using Communications Manager 6-19
Using the Communications Manager Menus 6-19
Using a Command Line 6-21
Downloading Applications Across the Network 6-22
Examples of Using BFT 6-23
Examining a Typical BFT Session 6-25
Preparing the Device and Host Computer for BFT 6-26
Differentiating Between Client and Server 6-27
Starting an Application When the FTA Terminates 6-29
Using FTA Commands on the Device 6-29
Typing FTA Commands on the Device 6-29
Learning the Syntax of FTA Commands 6-30
Editing the FTA Initialization File 6-32
Working With IRL
What Is IRL? 7-3
Using IRL on the JANUS 2050 7-4
Working With Files 7-4
Specifying Data and Program Paths 7-5
Using the Desktop 7-5
Using Commands in the IRL Desktop 7-8
Starting an IRL Program 7-8
7

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
viii
Exiting an IRL Program 7-9
Downloading an IRL Program 7-10
Transmitting IRL Files 7-10
Receiving IRL Files 7-11
Clearing IRL Files 7-11
Types of Error Messages 7-12
Resuming IRL Programs 7-13
Exiting a Program So You Can Resume It Later 7-13
Exiting Directly to DOS 7-14
Resuming a Program From the DOS Prompt 7-14
Resuming a Program From the IRL Desktop 7-14
Using the IRL Z Command 7-15
IRL File, Clear 7-16
IRL File, Receive 7-17
IRL File, Transmit 7-17
IRL Program, Download 7-18
IRL Program, Exit 7-18
IRL Program, Resume 7-19
IRL Program, Run 7-19
Troubleshooting
Troubleshooting the JANUS 2050 8-3
Powering Up or Booting the JANUS 2050 8-3
Operating the JANUS 2050 8-7
Running IRL 8-9
Using PC Cards 8-10
Using DOS 8-13
Using Configuration Manager 8-16
Using MakeDisk 8-17
8

code 39
nuggetnugget A
Contents
ix
Using PutDisk 8-19
Scanning Bar Code Labels 8-22
Resetting the JANUS 2050 8-23
Returning to the Default Configuration 8-23
Performing a Cold Boot 8-23
Forcing the JANUS 2050 to Turn Off 8-24
Saving Data and Loading Flash Memory 8-24
Saving JANUS 2050 Data 8-24
Loading Flash Memory 8-25
Command Reference
Using JANUS 2050 Commands 9-3
Enter/Exit Accumulate 9-4
Enter Accumulate 9-4
Exit Accumulate 9-5
Backspace, Destructive 9-5
Change Configuration 9-6
Clear 9-6
Command Override 9-7
Enter 9-8
Prepare for Reboot 9-8
Reboot 9-9
Configuration Commands
Using Configuration Commands 10-3
Variable Data 10-4
Address, Multi-Drop 10-5
AFF (Affirmative Acknowledge) 10-6
Baud Rate 10-7
9
10

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
x
Beep Duration 10-9
Beep Frequency 10-11
Beep Volume 10-13
Codabar 10-14
Code 11 10-16
Code 16K 10-17
Code 2 of 5 10-18
Code 39 10-20
Code 49 10-24
Code 93 10-26
Code 128 10-27
Command Processing 10-28
Communications Port, Select 10-33
Communications Port, Choosing Scanner or COM2 10-34
Communications Port, UART Restore 10-35
Communications Protocol 10-37
Configure 10-37
Activate 10-40
Multi-Drop, User-Defined 10-41
Data Bits 10-42
Decode Security 10-43
Display Mode, IRL 10-44
Display Setup 10-45
EOF (End of File) 10-47
EOM (End of Message) 10-48
EOR (End of Record) 10-50
Flow Control 10-51

code 39
nuggetnugget A
Contents
xi
Intercharacter Delay 10-52
Interleaved 2 of 5 10-54
IRL BAK (Bad Program Acknowledge) 10-56
IRL END Program Block 10-57
IRL EOP (End of Program) 10-58
IRL PAK (Program Acknowledge) 10-59
IRL PSS (Program Statement Separator) 10-60
IRL RUN 10-61
IRL SOP (Start of Program) 10-62
Key Code Lookup Table 10-63
Keypad Caps Lock 10-64
Keypad Clicker 10-65
Keypad Ctrl Key Functions 10-66
LRC 10-67
MSI 10-68
NEG (Negative Acknowledge) 10-70
Parity 10-71
Plessey 10-72
POL 10-73
Postamble 10-74
Preamble 10-75
Records Per Block 10-76
REQ (Request for Acknowledge) 10-78
RES (Reset) 10-79
Scan Ahead 10-80
Scanner Devices 10-81

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
xii
Scanner Mode 10-82
Scanner Redundancy 10-83
Scanner Timeout 10-84
Scanner Trigger 10-85
SEL (Select) 10-86
SOM (Start of Message) 10-87
Stop Bits 10-88
Timeout Delay 10-89
Transmit Abort Timeout 10-91
Turnaround Delay 10-93
UPC/EAN 10-94
Advanced Operations
Making More RAM Available on the JANUS 2050 11-3
Not Installing the PC Card Drivers 11-3
Unloading the Reader Wedge TSR 11-3
Accessing the Boot Loader Menu 11-4
Changing the Password 11-6
Putting the JANUS 2050 in Storage Mode 11-6
Exiting Storage Mode 11-7
Configuration and Full ASCII Charts
Entering ASCII Control Characters A-3
Entering Escape Sequences A-4
User-Defined Protocol Character Combinations A-5
Multi-Drop POL and SEL Combinations A-6
Key Codes A-7
Keypad Charts A-13
11
A

code 39
nuggetnugget A
Contents
xiii
Full ASCII Table A-16
Full ASCII Bar Code Chart A-19
Bar Code Chart for Moving Around in Menus A-22
Default Configuration A-23
Configuration Command by Syntax A-27
Specifications
Physical and Environmental Specifications B-3
Connecting Devices to the JANUS 2050 B-4
COM Port Connector B-4
Input Device Connector B-6
Types of Memory Used in the JANUS 2050 B-8
Conventional Memory (0 Through 640K) B-9
Upper Memory Area B-9
RAM Drive B-10
Extended Memory B-10
Expanded Memory B-10
High Memory Area (HMA) B-11
User Flash Memory B-11
Application Flash Memory B-11
Software Utility Reference
Interlnk C-3
INTERLNK.EXE C-4
Intersvr C-7
POWER.EXE C-9
Auto-Loader Batch Files C-10
Learning How to Use Auto-Loader C-10
Using LOAD_USA C-11
USING LOADLANG C-11
Using LOADADD C-11
Using LOADIMG C-13
Using LOADNEW C-13
B
C

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB)
xiv
Using LOADXIMG C-14
Using MAKE_USA C-14
Using MAKELANG C-14
Using MAKENEW C-15
Glossary
Index
G
I

code 39
nuggetnugget A
Before You Begin
xv
Before You Begin
This section introduces you to standard warranty provisions, safety
precautions, warnings and cautions, document formatting conventions, and
sources of additional product information.
Warranty Information
To receive a copy of the standard warranty provision for this product, contact
your local Intermec support services organization. In the U.S. call
1-800-755-5505, and in Canada call 1-800-688-7043. Otherwise, refer to the
Worldwide Sales & Service list that ships with this manual for the address and
telephone number of your Intermec sales organization.
Safety Summary
Your safety is extremely important. Read and follow all warnings and cautions
in this book before handling and operating Intermec equipment. You can be
seriously injured, and equipment and data can be damaged if you do not
follow the safety warnings and cautions.
Do not repair or adjust alone Do not repair or adjust energized equipment alone
under any circumstances. Someone capable of providing first aid must always
be present for your safety.
First aid Always obtain first aid or medical attention immediately after an
injury. Never neglect an injury, no matter how slight it seems.
Resuscitation Begin resuscitation immediately if someone is injured and stops
breathing. Any delay could result in death. To work on or near high voltage,
you should be familiar with approved industrial first aid methods.
Energized equipment Never work on energized equipment unless authorized
by a responsible authority. Energized electrical equipment is dangerous.
Electrical shock from energized equipment can cause death. If you must
perform authorized emergency work on energized equipment, be sure that you
comply strictly with approved safety regulations.

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB) CD39CD39nugnugjv mujv mu
xvi
Warnings and Cautions
The warnings and cautions in this manual use this format.
WARNING
Warning
A warnin
g
warns
y
ou o
f
an o
p
eratin
g
p
rocedure,
p
ractice, condition, or
statement that must be strictl
y
observed to avoid death or serious in
j
ur
y
to
the
p
ersons workin
g
on the e
q
ui
p
ment.
Avertissement
Un avertissement vous alerte d’une
p
rocédure de
f
onctionnement, d’une
méthode, d’un état ou d’un ra
pp
ort
q
ui doit être strictement res
p
ecté
p
our
éviter l’occurrence de mort ou de blessures
g
raves aux
p
ersonnes manu
p
ulant
l’équipement.
Caution
A caution alerts
y
ou to an o
p
eratin
g
p
rocedure,
p
ractice, condition, or
statement that must be strictl
y
observed to
p
revent e
q
ui
p
ment dama
g
e or
destruction, or corru
p
tion or loss o
f
data.
Conseil
Une
p
récaution vous alerte d’une
p
rocédure de
f
onctionnement, d’une
méthode, d’un état ou d’un ra
pp
ort
q
ui doit être strictement res
p
ecté
p
our
em
p
êcher l’endomma
g
ement ou la destruction de l’é
q
ui
p
ement, ou
l’altération ou la perte de données.

code 39
nuggetnugget A
Before You Begin
xvii
Terms and Conventions
This manual refers to the JANUS 2050 RF Vehicle-Mount Data Collection
Computer as “the JANUS 2050,” “the computer,” or “the device.” The
following conventions are used to emphasize keypad and bar code input,
screen messages, command syntax, and warnings and cautions.
JANUS 2050 Keypad Input
Key icons represent keystrokes you enter on the JANUS 2050. For example, “press e
“ directs you to press the key labeled “e” on the JANUS 2050 keypad.
When you must press a series of keys in order, the keys are shown in order without
connectors. For example, “press caf.to boot the JANUS 2050” directs you to
press and release each key in the order shown.
When you must press more than one key simultaneously, the keys are shown
separated by a dash. For example, “press f- dto enter control mode.” When
keys are separated by a dash, you must press and hold them in the order
shown.
Bar Code Input
You can scan the bar codes listed in this manual to enter data or perform a
command. Each bar code includes the name and human-readable
interpretation. For example:
*$+*
Change Configuration
*$+*
Name
Bar code (Code 39)
Human-readable
interpretation
2050U.033
Screen Messages
When discussing messages displayed on the JANUS 2050 screen, the messages
are shown as in this example.
Error, too many
files exist in
directory
2050U.086

JANUS 2050 Vehicle-Mount Computer User’s Manual (4MB) CD39CD39nugnugjv mujv mu
xviii
Commands
• Command syntax is shown in the text as it should be entered into the
JANUS 2050. For example, to see a listing of directories on the JANUS 2050,
type the following command and press e.
dir
• Commands may be shown with special characters that are not part of the
command. Do not include the special characters when you type or scan the
command. These characters indicate information about each part of the
command.
Braces { } enclose a parameter that is required. For example, you format an
SRAM card with this command:
format {
drive:
}
where you replace {drive:}with the letter designation of the drive where
the SRAM card is located.
• Configuration commands use the convention data to indicate variable data.
For example, the configuration command for beep volume is:
BVdata
where data can be a number from 0 through 4. Replace the term data with
one of the options listed with the command syntax. For example, the
configuration command to turn the beep volume off is BV0.
• Bold type is used when keystrokes that you enter are included within
textual information. For example, “To load the protocol handler for COM1,
you would use 1” indicates you would press 1 on your keypad.

code 39
nuggetnugget A
Before You Begin
xix
Suggested Reading
You may need to refer to the manuals listed below. To order additional
manuals, contact your local Intermec representative or distributor.
Manual Intermec Part No.
0100 Access Point User’s Manual 062367
0110 Access Point User’s Manual 065053
The Bar Code Book 051241
Data Communications Reference Manual 044737
DOS user’s manual 064673
IRL Programming Reference Manual 048609
JANUS 2.4 GHz Installation Utility (4MB) User’s Manual 064673
JANUS 2.4 GHz Terminal Emulation Quick Reference Guide 063682
JANUS 2.4 GHz Radio Frequency Quick Reference Guide 064819
JANUS 900 MHz Radio Frequency Quick Reference Guide 060207
JANUS Application Simulator User’s Manual 062778
JANUS PSK for Ada Reference Manual 062038
JANUS PSK for Basic Reference Manual 063191
JANUS PSK for C++ Reference Manual 062133
PC-IRL Reference Manual 049212
RF System/9180 User’s Manual 054292
If you are using the JANUS PSK, you may have one or more of the JANUS PSK
manuals listed above, depending on the programming language you use. Refer
to your PSK manual when you see these instructions:
“For help, see your JANUS PSK reference manual.”
