Intermec ScanImage 1470 User manual

S C A N I M A G E
User's Manual
Edition 3
from United Barcode Industries
Februry 1994

This page intentionally left blank

©1994 UBI Scanimage User's Manual Page i
Notice
Patent Information
Scanners discussed in this manual are covered by patents
issued or pending in the U.S. and other countries.
Copyright Information
The information contained in this manual are for information
purposes only and are subjected to change without notice. The
content of this manual are copyrighted. In addition, all software
code in the ScanImage itself is copyrighted. No part of either
this manual, or the ScanImage's software, may be copied or
reproduced in any manner, or disseminated to any unauthorized
person, without the prior written permission of United Barcode
Industries.
ScanImage is a trademark of
United Barcode Industries

Page ii User's Manual ©1994 UBI Scanimage
Notice
The ScanImage is certified to be a CDRH Class II laser (class 3A
for 97x and 99x models) product with the United States
Department of Health and Human Services Center for Devices
and Radiological Health, and IEC Class II.
FCC Compliance Information
Warning: This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance
with the instruction manual, it may cause interference to radio
communications. It has been tested and found to comply with
the limits for a Class A computing device pursuant to Subpart J
of Part 15 of FCC Rules, which are designed to provide
reasonable protection against such interferences when operated
in a commercial environment. Operation of the equipment in a
residential area is likely to cause interferences in which case the
user at his own expense will be required to take whatever
measure may be required to correct the interference.

©1994 UBI Scanimage User's Manual Page iii
Using this manual
This User's Manual explains in detail how to set up and operate
the ScanImage. Section 1 provides an overview of the
ScanImage versions available. Section 2, 3 and 4 cover,
respectively, programming for the following versions.
9X1 - Wand emulation
9X2 - RS-232 interface
9X7 - Wedge connection
This User's Manual will help you:
Install the ScanImage on your terminal.
Configure the ScanImage to your system and data
communications requirements via bar code menus.
Select the bar code formats to be activated.
Configure the ScanImage to incorporate preambles and/or
postambles.
Make use of ScanImage's advanced features such as, laser
management, character masking, bar code verification, and bar
code identifiers.

Page iv User's Manual ©1994 UBI Scanimage
Table of contents
Notice .........................................................................................i
Using this manual..................................................................iii
Table of contents....................................................................iv
PART I - INSTALLATION
Section 1 - Description of the ScanImage and Special
Features
ScanImage Versions.................................................................1-1
Preparing the ScanImage for configuration............................1-2
Special Features.......................................................................1-3
Section 2 - Installing the ScanImage as a Wand
emulation
Wand emulation.......................................................................2-1
-Wand emulation Enable..................................................2-1
-Transmission...................................................................2-2
-Signal State .....................................................................2-2
-Speed ...............................................................................2-2
-Delay................................................................................2-3

©1994 UBI Scanimage User's Manual Page v
Table of contents
Section 3 - Installing the ScanImage as an RS-232 output
device
Single RS-232 mode.................................................................3-1
-Single RS-232 Mode (P/N 9X2)........................................3-1
-ScanImage 9X2 With Single RS-232 Output ..................3-2
-Pin Assignments for Single Output
Cable Management Module.............................................3-4
Dual RS-232 mode ...................................................................3-5
-Dual RS-232 Mode...........................................................3-5
-ScanImage 9X2 With DUAL RS-232 Ouput Option .......3-6
-Standard Dual RS-232 Option
(P/N 901196 or 700352) ...................................................3-8
RS-232 interface parameters...................................................3-9
-RS-232 Enable.................................................................3-9
-Baud Rate......................................................................3-10
-Data/Stop/Parity............................................................3-11
-End of message Control Codes......................................3-12
-Protocols for Contolling Data Transmission .................3-13
Section 4 - Installing the ScanImage as a Keyboard
Wedge
Keyboard Wedge mode.............................................................4-1
-Keyboard Wedge Mode (P/N 9X7)...................................4-1
-ScanImage 9X7 Wedge Connection with
Cable Management Module.............................................4-2
-Compose Terminal Type..................................................4-4
-End of message Control Codes........................................4-5
-Upper Lower Case Options .............................................4-6
-Alt Mode ..........................................................................4-6

Page vi User's Manual ©1994 UBI Scanimage
Table of contents
PART II - READING PARAMETERS
Family A - Audio and data management
Audio Managment ..................................................................A-1
-Speeker Volume..............................................................A-1
-Speeker Tones ................................................................A-2
Data Management ..................................................................A-3
-Preambles and Postambles.............................................A-3
-Intercharacter Delay......................................................A-4
-Rolling Buffer.................................................................A-5
-Intermessage Delay........................................................A-6
Family B - Activation/Deactivation of Bar Code
Formats
Bar Code Formats...................................................................B-1
Family C - Code 39 Parameters
Code 39 Parameters................................................................C-1
Family D - Interleaved 2 of 5 Parameters
Interleaved 2 of 5 Parameters................................................D-1
Family E - 2 of 5 Standard Parameters
2 of 5 Standard Parameters....................................................E-1
Family F - Codabar Parameters
Codabar Parameters............................................................... F-1

©1994 UBI Scanimage User's Manual Page vii
Table of contents
Family G - UPC/EAN Parameters
UPC/EAN Parameters............................................................G-1
Family H - Code 128, PLESSEY, MSI, Code 93, Code 11,
TELEPEN, MATRIX 2/5, EAN 128 Parameters
Code 128, PLESSEY ...............................................................H-1
MSI, Code 93...........................................................................H-2
Code 11, TELEPEN, MATRIX 2/5..........................................H-3
EAN 128..................................................................................H-4
Family I - Advanced features
Laser management .................................................................. I-1
Laser Time-out Variable.......................................................... I-2
Consecutive same read code validation................................... I-3
No read message...................................................................... I-4
Character masking and reordering......................................... I-5
Single code type identifier ....................................................... I-9
Identification AIM ................................................................. I-11
Delay character...................................................................... I-12
Character substitution/deletion............................................. I-13
Configuration password......................................................... I-13

Page viii User's Manual ©1994 UBI Scanimage
Table of contents
Appendix - Full ASCII Bar Code Chart and Command
Menu
Full ASCII Bar Code Chart ....................................................X-1
Command Menu......................................................................X-9

PART I
INSTALLATION

This page intentionally left blank

S e c t i o n 1
Description of the ScanImage
and Special Features

This page intentionally left blank

SECTION 1
1994 UBI ScanImage User's Manual Page 1-1
ScanImage Versions
The ScanImage is available with six different optical
configurations for the HP (High Performance), IP (Industrial
Performance), and seven different interfaces. Each optical
configuration is available with each interface. All part numbers
start with the digit 9. The second digit indicates the optics; the
third digit the interface. Listed below are the available Optics
and Interfaces.
Optics Available
STD Standard (91X)
VIN Wind-shield (92X)
LR Long Range (95X)
UHD Ultra High Density (96X)
XLR Extra Long Range (97X)
ULR Ultra Long Range (99X)
Interfaces Available
(9X0) - Undecoded for connection to UBI's MaxiBar
(9X1) - Wand Emulation for connection to on-line Readers
(9X2) - RS-232 for connection to a serial port, or as a dual port
device for connection on the serial communications line between
a terminal and host.
(9X3) - IBM 4683 for connection to IBM 4683 and 4684 P.O.S.
registers.
(9X5) - OCIA for connection to NCR, TEC and other P.O.S.
registers.
(9X6) - Fujitsu for connection to Fujitsu and other registers
with parallel interfaces.
(9X7) - Wedge for connection to terminals and PC's in keyboard
emulation mode.

SECTION 1
Page 1-2 User's Manual 1994 UBI ScanImage
Preparing the ScanImage for configuration
To prepare the ScanImage for configuration follow these steps:
1. Verify that the correct ScanImage cables and accessories, if
any were ordered, have been received.
2. Turn off power to the terminal to which the ScanImage will
be connected.
3. Install the ScanImage according to the instructions in the
following sections. Chapter two describes installation of
wand emulation mode, chapter three RS-232, and chapter
four wedge installation.
4. Connect the power supply, if necessary. Power up the
host according to the interface (except 9x1), the ScanImage
will beep five or six times indicating that hookup has been
completed.
5. Type on the keyboard to verify that the terminal is
transparent to the system.
6. Test the ScanImage by scanning your bar code label(s). If
further changes are required go to the appropriate family
in Part II and make the additional changes.

SECTION 1
1994 UBI ScanImage User's Manual Page 1-3
Special Features
Resetting the scanner to factory defaults
Return to Factory Defaults
Printed Label
Normal*
Normal or Inverted
Autostand Mode
Autostand Enabled
Autostand Disabled*
Marker Beam
Marker Beam Enabled
Marker Beam Disabled*
Master
Slave
Software Version

SECTION 1
Page 1-4 User's Manual 1994 UBI ScanImage
Special Features
Return to Factory Defaults
At any time, the ScanImage can have its settings reset to
factory defaults which are indicated by (*) asterisk throughout
the manual. By scanning the Return to Default Parameters
bar code label, the ScanImage will return back to the
indicated default settings.
Autostand
The ScanImage may be configured for use with UBI's
Autostand, which allows the scanner to work in a hands-free
mode. The ScanImage will revert to its normal method of trigger
activation when temporarily removed from the stand to read
large or bulky items.
The autostand mode is a factory installed feature that is added
to 91X UBI laser scanners. The user has the capability to enable
the autostand mode by scanning the Autostand Enable bar
code. The scanner will respond by emitting a continuous, low
level, red beam of light. The autostand mode is deactivated by
scanning Autostand Disable bar code.
Marker Beam
The Marker Beam is available on all scanimage and
automatically selected in the long range 95X, Etra Long Range
97X and Ultra Long Range 99X ScanImage. The marker beam is
a stationary spot that appears momentarily before the
ScanImage begins scanning. It shows the operator exactly
where the scanner is aimed for error-free scanning of hard-to-
target symbols. The marker beam can be disabled or enabled at
any time.

SECTION 1
1994 UBI ScanImage User's Manual Page 1-5
Special Features
Software version
By scanning this label, the Scanimage will emit a sequence of
beeps to let you hear the Prom version, and then will display
this version and the date of the prom.
Example: sequence of beeps: 2.03
3 beeps, 1 silence, 1 beep, 1 silence, 4 beeps.
The digits are incremented by one due to the zero
digit.
Master
This command designates the ScanImage as the master
enabling it to "clone" its configuration to additional ScanImage.
Slave
This command designates an unconfigured ScanImage or an
improperly configured ScanImage as a slave, and instructs it to
"clone" to its own memory the configuration in the ScanImage
master to which it is connected.
For further information on these two functions, contact UBI's
technical service.

SECTION 1
Page 1-6 User's Manual 1994 UBI ScanImage
This page intentionally left blank
