Intermec Janus 2010 User manual

JANUS®
PSK for Ada
P/N 062038-002
Reference Manual

IntermecCorporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. technical and service support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian technical and service support: 1-800-688-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for the purpose of
allowing customers to operate and/or service Intermec manufactured equipment and is not to
be released, reproduced, or used for any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change without notice.
1995 by Intermec Corporation
All Rights Reserved
The word Intermec, the Intermec logo, JANUS, IRL, Duratherm, Virtual Wedge, and CrossBar
are trademarks of Intermec Corporation.
Throughout this manual, trademarked names may be used. Rather than put a trademark ()
symbol in every occurrence of a trademarked name, we state that we are using the names only
in an editorial fashion, and to the benefit of the trademark owner, with no intention of
infringement.

Contributors
Authors Beryl Doane
Maureen Norling
Editor Craig Thompson
Technical Illustrators John Bickley
George Wilson
Technical Reviewers Roy Law
Yong-Qin Lu

Manual Change Record
This page records the changes to this manual.
Version Date Description of Change
001 9/94 This manual was first released as version -001.
002 7/95 Renumbered chapters and made other changes according to
current Technical Publications document standards.
Updated manual to support the Programmer’s Software Kit
version 2.1. The new information includes:
Functions to support JANUS J2050 VMU.
Preamble and postamble functions.
Other new topics include:
Using the status code macros.
Using JANUS Application Simulator.
Deleted the following five functions from the manual. They are
still available in the PSK library, but Intermec does not
recommend using them:
im_flush_expanded_keyboard
im_get_expanded_keyboard
im_set_expanded_keyboard
im_kb_insert_keycodes
im_kb_insert_string

Contents
v
Contents
Before You Begin xi
Warranty Information xi
Cautions xi
About This Manual xii
Other Intermec Manuals xv
Getting Started
What Your JANUS Reader Can Do 1-3
Virtual Wedge 1-4
Reader Services 1-5
Function Libraries 1-6
Software Interrupts 1-6
Installing the JANUS PSK Ada Library 2-3
Working With Ada
Programming With Ada 2-4
Building an Executable File 2-5
Build Requirements 2-6
Compiling 2-7
Binding 2-8
Linking 2-9
Debugging With JANUS Application Simulator 2-10
Building a Sample Program Using a Batch Program 2-10
Running Your Program on the Reader 2-11
1
2

Contents
vi
Runtime Requirements 2-12
Protocol Handlers 2-12
Reader Wedge 2-13
Specific Functions With Runtime Requirements 2-14
Status Code Macros 2-16
Ada Library
Using the Ada Library Functions 3-3
Ada Library Functions Listed by Category 3-4
im_appl_break_status 3-6
im_backlight_off 3-8
im_backlight_on 3-9
im_backlight_toggle 3-10
im_cancel_rx_buffer 3-11
im_cancel_tx_buffer 3-12
im_command 3-13
im_cursor_to_viewport 3-15
im_decrease_contrast 3-16
im_get_config_info 3-18
im_get_contrast 3-20
im_get_control_key 3-22
im_get_display_mode 3-24
im_get_display_type 3-27
im_get_follow_cursor 3-29
im_get_input_mode 3-30
im_get_keyclick 3-32
im_get_label_symbology 3-33
im_get_length 3-35
im_get_postamble 3-36
im_get_preamble 3-38
im_get_viewport_lock 3-40
im_get_warm_boot 3-42
im_increase_contrast 3-43
3

Contents
vii
im_input_status 3-45
im_irl_a 3-47
im_irl_k 3-51
im_irl_n 3-55
im_irl_v 3-59
im_irl_y 3-64
im_iserror 3-69
im_isgood 3-70
im_issuccess 3-71
im_iswarn 3-72
im_link_comm 3-73
im_message 3-75
im_number_pad_off 3-76
im_number_pad_on 3-78
im_power_status 3-80
im_protocol_extended_status 3-83
im_receive_buffer 3-85
im_receive_buffer_no_wait 3-89
im_receive_buffer_noprot 3-93
im_receive_byte 3-97
im_receive_input 3-100
im_rs_installed 3-103
im_rx_check_status 3-104
im_serial_protocol_control 3-105
im_set_contrast 3-108
im_set_control_key 3-110
im_set_display_mode 3-112
im_set_follow_cursor 3-115
im_set_input_mode 3-117
im_set_keyclick 3-119
im_set_viewport_lock 3-121
im_set_warm_boot 3-123
im_sound 3-125
im_standby_wait 3-127
im_transmit_buffer 3-129
im_transmit_buffer_no_wait 3-131

Contents
viii
im_transmit_buffer_noprot 3-132
im_transmit_byte 3-134
im_unlink_comm 3-137
im_viewport_end 3-138
im_viewport_getxy 3-139
im_viewport_home 3-141
im_viewport_move 3-142
im_viewport_page_down 3-145
im_viewport_page_up 3-146
im_viewport_setxy 3-147
im_viewport_to_cursor 3-148
Status Codes
Status Code Bit Values A-3
Status Codes Listed Numerically A-4
Status Codes Listed by Subsystem A-22
Subsystem 0100 RS (Reader Services) A-23
Subsystem 0200 CM (Configuration Management) A-24
Subsystem 0300 SC (Scanner) A-27
Subsystem 0400 DC (Decodes) A-28
Subsystem 0500 RW (Reader Wedge) A-30
Subsystem 0600 CU (Communications) A-32
Subsystem 0800 PM (Power Management) A-34
Subsystem 0A00 TM (Timer) A-35
Subsystem 0B00 BP (Beep) A-36
Subsystem 0E00 IM (Intermec Library) A-37
Subsystem 0F00 LG (Event Logger) A-38
Subsystem 1000 KB (Keyboard Buffer) A-39
Subsystem 1100 SS (System Configuration) A-40
Subsystem 1200 KP (Keypad Services) A-41
Subsystem 1300 DP (Display) A-42
A

Contents
ix
Sample Programs
DISPMODE.ADA B-3
KEYCLICK.ADA B-5
PWR_STAT.ADA B-7
XCOMM.ADA B-9
Index I-3
B

Before You Begin
xi
Before You Begin
This section introduces you to standard warranty provisions, safety
precautions, warnings and cautions, document formatting conventions, and
sources of additional product information.
Warranty Information
To receive a copy of the standard warranty provision for this product,
contact your local Intermec sales organization. In the U.S. call (800) 755-
5505, and in Canada call [phone]. Otherwise, refer to the Worldwide
Sales & Service list shipped with this manual for the address and telephone
number of your Intermec sales organization.
Cautions
The cautions in this manual use the following format.
CAUTION
Caution
A caution alerts
y
ou to an o
p
eratin
g
p
rocedure,
p
ractice, condition, or
statement that must be strictl
y
observed to
p
revent e
q
ui
p
ment dama
g
e or
destruction, or corru
p
tion or loss o
f
data.
Conseil
Une
p
récaution vous alerte d’une
p
rocédure de
f
onctionnement, d’une
méthode, d’un état ou d’un ra
pp
ort
q
ui doit être strictement res
p
ecté
p
our
em
p
êcher l’endomma
g
ement ou la destruction de l’é
q
ui
p
ement, ou l’altération
ou la perte de données.

JANUS PSK for Ada Reference Manual
xii
About This Manual
This manual is part of the JANUS Programmer's Software Kit manual set. It
describes the special features and methods needed for programming the
JANUS family of PC-compatible readers. If you plan to write programs in
Ada, the information in this manual is very valuable. You may also refer to
one of the other books listed under “Other Intermec Manuals” later in this
section.
Organization
The JANUS Programmer’s Software Kit for Ada Reference Manual is divided
into three chapters and one appendix as described below:
Chapter What You Will Find
1 Gettin
g
Started
This chapter describes the capabilities and programming
methods applicable to the Intermec family of PC-compatible
readers. It also explains how to install the Programmer’s
Software Kit Language Libraries disk that is provided with
this manual.
2 Workin
g
With Ada
This chapter describes how to write applications in Ada
using the library functions.
3 Ada Librar
y
This chapter explains the purpose and syntax for each Ada
function and provides samples.
Appendix A Status Codes
This appendix lists status codes that are returned by the
PSK functions.
Appendix B Sam
p
le Pro
g
rams
This appendix lists sample applications written in the Ada
language.

Before You Begin
xiii
Terms and Conventions
•A reader is the JANUS 2010, 2020, or 2050 PC-compatible bar code reader.
•An operator is anyone who runs applications on the reader.
•A programmer is anyone who writes applications for the reader.
•A normal PC is assumed to be a DOS-based PC/AT-compatible 386, with
a hard disk, 14-inch monitor, full-size keyboard, floppy disk drives, and
at least two communication ports.
•Reader services are the functional abilities that distinguish the Intermec
family of PC-compatible readers from a normal PC. For example, the
reader’s ability to decode bar code data as if it came from a PC keyboard
is a typical reader service.
•Software interrupts are the synchronous triggering of interrupts used for
application program interfaces.
•Library functions are the specialized Ada functions provided in the
language libraries that you use to invoke various reader services.
•PSK means the Programmer’s Software Kit and refers to both the
language libraries and this manual.
•The Programmer’s Software Kit Language Libraries is the disk shipped with
this manual. It contains sample programs and library functions for
interfacing with the reader.
• The keypad is the custom JANUS keyboard. Throughout this manual,
specific references to the JANUS keyboard use the term keypad.
• The keyboard buffer is the machine-level buffer that stores key presses
and scanned labels. Throughout this manual, specific references to this
buffer and its status flags use the term keyboard.

JANUS PSK for Ada Reference Manual
xiv
Keypad Input
• Keys that you press on the keypad are emphasized in bold. For example,
“press Enter” means you press the key labeled “Enter” on the reader
keypad.
•All key names use first-letter capitalization. For example:
Ctrl = Control key
Enter = Enter key
F3 = F3 key
• When you are required to press and release a series of keys in order, the
keys are listed in order with no connectors. For example, to enter the
uppercase character A, press Shift A. To enter this character, you press
and release the Shift key, and then press the key marked A.
• When you are required to press more than one key at the same time, the
keys are connected by a dash in the text. For example, press Ctrl-Alt-Del
to perform a warm boot on a standard PC. When the keys are connected
by a dash, it is important that you press and hold the keys in the order
they are listed in the text.
Commands
•DOS commands are printed in Courier, exactly as you must type them.
For example:
COPY INTERMEC.* E:\
•Code examples are printed in 8-point Courier. For example:
if(step != 0) level = step; // use step value if provided
if(level >= 31) level = 0; // keep level within bounds
Other Conventions
•Italic type identifies a syntax parameter where it is defined in text. Italic
type is also used to indicate references to other manuals and to indicate
important terminology.
•Hexadecimal numbers in text are followed by an uppercase H. For
example, 03 hex is shown as 03H.
•Hexadecimal numbers in C language code segments begin with 0x. For
example, AX_REG = 0x5300.

Before You Begin
xv
Other Intermec Manuals
You may need additional information for working with the PSK in a data
collection system. To order additional manuals, contact your local Intermec
representative or distributor.
The following publications contain useful information for programming the
Intermec family of PC-compatible readers:
Manual Intermec Part No.
JANUS Programmer’s Software Kit for C/C++ Reference Manual
JANUS Programmer’s Software Kit for Basic Reference Manual
JANUS 2010 Hand-Held Computer User’s Manual
JANUS 2020 Hand-Held Computer User’s Manual
JANUS 2050 Vehicle Mount Unit User's Guide
JANUS Application Simulator User's Manual
IRL Programming Reference Manual
Data Communications Reference Manual
The Bar Code Book
062133
063191
058426
059951
062874
062778
048609
044737
051241
For additional programming information, see the software development kit
manuals provided with your language.
Note: The Programmer’s Software Kit Language Libraries disk accompanying this
manual includes a file called README.TXT. This file contains updates to this
document and errata of specific importance to programmers.

nugget code39 helconital
Getting Started
1

nugget code39 helconital

Getting Started
1-3
1
This chapter briefly describes the programming methods and capabilities that
apply to the JANUS family of readers and explains how to install the PSK.
What Your JANUS Reader Can Do
JPSK.001
I/O
Conn Data
Ctrl Alt
Shift Caps
F6
F1
F2
F3
F4
F5
F7
F8
F9
F10
f
ABCDEF
GH I J K L
MNO PQR
STUVWX
YZ
Ctrl Alt
f
~_+{}:
`
-=[];
"<>?
'\,./
Caps
789
456
123
space
0.
home
&* (
$%^
!@#
)>
+pg up
-*/
end enter pg dn
Esc
num lock
enter
ins del
TM
J2050
JR2020 JR201
0
Your JANUS reader is a portable, programmable bar
code reader and a 386-based computer in one. Each
reader has the Intermec controlled BIOS and Microsoft
ROM DOS 5.0. The reader behaves and functions like
a normal PC with 640K of memory, with these
exceptions:
• The JANUS 2010 and 2020 are hand-held, with a
small LCD dis
p
la
y
, custom ke
y
board, and either a
p
ort for a bar code in
p
ut device or a built-in
scanner.
• The JANUS 2050 is mounted to a vehicle, such as a
forklift, and has a monochrome CGA display,
custom keyboard, built-in RF, and a port for a bar
code input device.
• The o
p
eratin
g
s
y
stem and
p
rotocol su
pp
ort
p
ro
g
rams reduce the memor
y
available for
y
our
application to about 450K.
You can run batch programs and copy, name, or move files in the same
manner as you would with any normal PC. The only difference is that the
JANUS reader has ROM and RAM drives and a PC card drive.
You can also run DOS-based programs on the reader the same as you can
on a PC. When you do, the reader behaves like a PC, but has the advantage
of accepting bar code input as if it came from the keypad. If you are an
experienced PC programmer, you have already written programs that will
run on the reader.

JANUS PSK for Ada Reference Manual
1-4
Virtual Wedge
The Virtual Wedge feature of the reader allows application programs to
receive decoded bar codes from the keyboard buffer. The Virtual Wedge
makes the reader functionally equivalent to a reader wedge connected to a
PC. Bar code input is inserted into the PC keyboard buffer as if entered from
the keypad. The Virtual Wedge also allows rapid porting of PC applications
to the reader.
Note: If your PC application follows DOS programming conventions, it should
run correctly on the JANUS reader. Not all programming languages, especially
database languages, follow these conventions. If your PC application does not
follow DOS programming conventions, your scanned input will be incorrect.
Valid configuration commands and reader commands are not put into the
keyboard buffer. Bar code configuration commands beginning with $+ are
tagged as configuration commands by the Virtual Wedge and sent to the
configuration manager to reconfigure the reader. The command parser in
the Virtual Wedge software recognizes and processes reader commands.
You can run applications that use the Virtual Wedge (instead of Intermec
interrupt extensions or function libraries) on either the reader or on your
PC.
