Intermec PEN*KEY 6400 Operation instructions

EZBuilder
™
P/N 066449-003
Tutorial

Intermec Technologies Corporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. technical and service support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian technical and service support: 1-800-687-7043
Canadian media supplies ordering information: 1-800-267-6936
Outside U.S. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for the purpose of allowing customers
to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for
any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change without notice.
2000 by Intermec Technologies Corporation
All Rights Reserved
The word Intermec, the Intermec logo, EZBuilder, JANUS, IRL, Trakker Antares, Adara, Duratherm,
Precision Print, PrintSet, Virtual Wedge, and CrossBar are trademarks of Intermec Corporation. Microsoft,
Active X, Visual C++, Windows, Win32s, the Windows logo, and Windows NT are either registered
trademarks or trademarks of Microsoft Corporation.
Throughout this manual, trademarked names may be used. Rather than put a trademark (™or ®) symbol in
every occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and
to the benefit of the trademark owner, with no intention of infringement.

Manual Change Record
This page records the changes to this manual, which was originally released as version 001.
Version Date Description of Change
002 07/98 The manual was updated and reformatted. Sample applications were added
as an appendix.
003 08/00 The manual was updated to support EZBuilder v 2.3, which adds support
for 6400 hand-held devices.

Contents
v
Contents
Introduction
Introducing the EZBuilder Code Generator 1-3
Overview of How EZBuilder Works 1-3
Overview of EZBuilder Windows 1-3
Menus and Toolbar Window 1-4
Object Manager 1-5
Viewport 1-5
Overview of EZBuilder Components 1-6
Applications 1-6
Menus 1-6
Moving Between Fields 1-6
Screens 1-6
Selecting an Item 1-7
Transactions 1-7
View Resource Dialog Box 1-7
Overview of the EZBuilder Simulator 1-8
Introducing the Tutorial 1-8
Tutorial Organization 1-9
Tutorial Time 1-10
Chapter Summary 1-10
What's Next 1-10
Creating Menus
Getting Started 2-3
Exercise 1: Creating the Main Menu 2-3
Exercise 2: Creating Menu Items for User Options 2-8
Creating a Menu Item 2-8
Creating a Second Menu Item 2-10
Creating a Third Menu Item 2-11
Exercise 3: Creating a Hidden Menu Item 2-11
Chapter Summary 2-12
1
2

EZBuilder Tutorial
vi
Creating Screens
Overview 3-3
Exercise 4: Designing the MM_Help Screen 3-3
Labeling the MM_Help Screen 3-3
Creating a Multi-Line Object to Contain Help Data 3-4
Exercise 5: Designing the JobOn Screen 3-7
Labeling the JobOn Screen 3-7
Exercise 6: Defining and Labeling Data Fields 3-8
Defining the Badge Identification Number Field 3-8
Labeling the Badge Identification Number Field 3-9
Defining the Part Number Field 3-9
Labeling the Part Number Data field 3-9
Creating the Order Number Field 3-10
Wrapping Data 3-10
Exercise 7: Programming the Function Keys 3-11
Exercise 8: Programming the Beep Sound 3-14
Exercise 9: Creating the JobOff Screen 3-15
Copying the JobOn Screen 3-15
Changing the Duplicate Screen 3-16
Exercise 10: Completing the Data_Help Screen 3-18
Chapter Summary 3-20
Creating Transactions
Overview 4-3
Exercise 11: Creating a Transaction 4-3
Exercise 12: Creating the JOF_Tran (Job Off) Transaction 4-8
Exercise 13: Finishing the Transactions 4-10
Exercise 14: Creating the CopyBadge Transaction 4-12
Exercise 15: Creating Toggle Capability 4-15
Chapter Summary 4-16
3
4

Contents
vii
Testing Your Program on the Simulator
Overview 5-3
Exercise 16: Building the Program 5-3
Exercise 17: Testing the Program 5-6
Suggested Tests 5-6
Example Data 5-8
Record Identification Codes 5-8
Record Data Order 5-8
Automatic Data Entered into the Record 5-8
Example Output Listing 5-9
Exercise 18: Downloading Your Program 5-9
Chapter Summary 5-12
Where Do You Go From Here? 5-13
Using the Simulator Editor 5-13
Using the Example Applications 5-13
Using the Online Help 5-13
Using EZBuilder Features
Using the Example EZBuilder Applications A-3
Working With User Functions and Libraries A-5
Reviewing the Example Application A-6
Building a Static Library From the Function A-7
Placing Function Calls in the EZBuilder Application A-8
Configuring EZBuilder to Link With Your Library A-8
Parsing a Single Scanned Label Into Multiple Fields A-9
Scrolling Through a File and Selecting a Record A-11
Clearing All Fields on a Screen at One Time A-13
Transferring Data Between a TCP/IP Server and a Trakker Antares TCP/IP Terminal A-15
Transmitting a File from a Trakker Antares TCP/IP Terminal to a TFTP Server Using
Static Filenames A-17
5
A

EZBuilder Tutorial
viii
Transferring Files Between a Trakker Antares TCP/IP Terminal and a TFTP Server A-19
Transferring Files Between a TCP Server and a Trakker Antares TCP/IP Terminal Using
Dynamic Filenames A-22
Troubleshooting
Troubleshooting Error Messages B-3
B

Introduction
1

dsf

asdIntroduction
1-3
1
Menus and
Toolbar Window
This chapter introduces the EZBuilder code, defines some basic EZBuilder terms, and
introduces the EZBuilder tutorial exercise.
Introducing the EZBuilder Code Generator
EZBuilderis a software code generator product that provides a quick and easy way to
create application programs for the Trakker Antares terminals, the T2090, and the 6400.
Overview of How EZBuilder Works
After telling EZBuilder you want to create a new application (or enhance an existing
one), you give simple commands to create menus, screens, and transactions and to
define menu items, labels, and data fields. You can set appropriate attributes and other
parameters as properties for these objects; define function keys to cause specific actions
to occur when keys are pressed; and specify other processes, such as calculations, as
needed for your application.
When you have completed your application and give the Build command, EZBuilder
generates the application code for you. Using the Simulator tool, you can then test the
program on your computer. When your application is ready to use, download your
generated application program to your terminal.
Overview of EZBuilder Windows
This section illustrates and describes the Menus and Toolbar window, the Object
Manager, and the Viewport. Other windows and dialog boxes are illustrated later in this
document, as needed.
Object Manager Viewport

EZBuilder Tutorialasd
1-4
Menus and Toolbar Window
EZBuilder commands are available by selecting from drop-down menus or by clicking
toolbar buttons.
Menus
The EZBuilder commands are grouped under menu headings File, Edit, View, Default,
Options, Build, Tools, and Help. Before beginning the tutorial, you should take a
moment to open each menu and read which commands are available on each. Most of
the commands listed on these menus are included in the tutorial.
Applications recently opened in EZBuilder are shown at the bottom of the File menu.
This list helps you quickly locate and open EZBuilder applications you have recently
developed or edited.
Toolbar
EZBuilder toolbar buttons are located beneath the menu headings. Toolbar buttons
provide quick access to many EZBuilder commands. Some toolbar buttons are available
only as needed for the creation of certain objects.
You can often access menu commands using a toolbar button. To learn the function of
any toolbar button while using EZBuilder, move the mouse pointer over the button and
read the description that appears.
The toolbar buttons are identified below:
New Application
Open Application
Save Application
Build
Simulate Trakker and Run
Application
Download
New Math Process
New Screen
New Menu
New Transaction
Add Label to
Screen/Menu
Add Field to Screen
Add Menu Item to Menu
Add Scrolling Section to
Screen
Add Horizontal Line to
Screen/Menu
Add Vertical Line to
Screen/Menu
Add Box to Screen/Menu

asdIntroduction
1-5
1
Object Manager
The Object Manager has three separate parts: the Object List field, the Properties and
Actions area, and three tabs labeled Properties, On Entry, and On Exit. These main
parts are briefly described below. When you make changes to the value of a field in the
Object Manager, you must move to another field to cause those changes to take effect.
Object List
Applications, screens, menus, and transactions that are created as you work in
EZBuilder are called objects, as are menu commands, data fields, and their respective
labels. The Object List, located near the top of the Object Manager, lists these objects
when you click the Object List down arrow. Altogether, objects are generally called
resources.
Objects are also listed in the View Resource dialog box, which is described and
illustrated later in this tutorial.
Properties and Actions Area
The Properties and Actions Area shows the default of each object selected in the
Viewport. In this tutorial, the Properties and Actions Area is referred to as the Object
Manager.
Properties, On Entry, On Exit Tabs
At the bottom of the Object Manager are three tabs labeled Properties, On Entry, and
On Exit. Click any of these tabs to view its respective screen.
The Properties screen shows the values, or properties, of items—menus, menu items
(commands and labels), screens, data items (data fields and their labels), and
transactions—that you create. Use the Properties screen to enter the values for the
object being defined and the actions, if any, caused by specific objects being selected,
entered, exited, or executed by the application user.
The On Entry screen shows parameters used when entering an application or data field.
The On Exit screen shows parameters used when exiting an application or data field.
Details and illustrations of each of these screens are provided throughout the tutorial.
Viewport
The Viewport shows your application as it will appear to your users. When you begin
an application in EZBuilder, the Viewport is blank; when you open an existing
application, the Viewport shows that application. How your application looks in the
Viewport depends upon your device type and terminal characteristics.
The Viewport has row and column coordinates that you use to specify the location of
items. The upper left corner is Row 0 and Column 0. This tutorial demonstrates how to
move items in the Viewport (and, subsequently, in your final application) by changing
Row and Column values.

EZBuilder Tutorialasd
1-6
Overview of EZBuilder Components
In addition to understanding the EZBuilder windows, you need to know a few basic
EZBuilder terms and characteristics before you start the tutorial exercise.
Applications
From the information you provide, EZBuilder generates an application program with
built-in verification functions. For example, you could build applications for
•factory automation systems.
•inventory control.
•labor time records.
High-level component resources of an application include menus, screens, and
transactions. Each of these components (objects) can include other objects, such as
menu commands, data fields, and their labels.
Menus
A menu usually contains an identification label and a list of user options. These options
are called menu items in EZBuilder, but they are called menu commands by your users.
You can create your menus so the user can choose to execute a menu command in a
variety of different ways. For example, the user can
•press a function key (such as F1, F2, F3, and so on).
•use the up and down arrow keys, and then press Enter.
•enter text or numbers using the keyboard (such as “EXIT”).
•scan text characters (such as “SFCLBR”) using the terminal’s wand or some other
scanning device.
Moving Between Fields
In the Object Manager, use the Tab key to move the cursor to the next field, and the
Back Tab function (Shift+Tab) to move the cursor to the previous field.
Screens
An EZBuilder screen is the software display of information shown in the Viewport. An
identification label is usually included at the top of a screen.
In this tutorial, there are two main types of screens: data entry screens and help screens.
You can also create a screen to show results of calculated data or other processing.

asdIntroduction
1-7
1
Selecting an Item
To edit an item, you must first select it. You can select an item in one of two ways:
•Double-click the item in the Viewport.
•Open the View Resource dialog box, click the object once, and then click Edit to
return to the Viewport. For more information about the View Resource dialog box,
see “View Resource Dialog Box”below.
Selected objects appear in the Viewport with small boxes, or “handles, ”around them.
Transactions
An identification label is usually included at the top of a transaction screen.
The variable data that is scanned or keyed in by the user is accepted in the data fields
(shown on data entry screens), and then packaged as transactions. The packaging
process can append data from the system, including the current date and time or
calculated data.
Transactions can be handled in different ways. They can be
•sent to or received from the RF network.
•sent to or received from a COM (communications) port.
•saved to or read from a record in a file.
•sent to another field or fields.
In this tutorial, each transaction is saved as a record and sent to a file that later can be
printed for review and analysis.
View Resource Dialog Box
The View Resource dialog box graphically shows the interaction of current components
of your application. To open the View Resource dialog box, click Resource from the
View menu.

EZBuilder Tutorialasd
1-8
View Resource Dialog Box
Overview of the EZBuilder Simulator
A simulator allows one device (such as your computer) to act like or emulate another
device (such as your terminal).
EZBuilder comes complete with a Simulator tool so you can run the application that
you create with EZBuilder on your computer for program testing and debugging as well
as for training and demonstration purposes.
The simulator lets you check out all the menus, screens, transactions, and other
processing that you defined in EZBuilder before you download your generated
application program to the terminal.
Introducing the Tutorial
In this tutorial, you will develop a simple application to collect the start and end times
of factory workers as they perform various activities or projects (called “jobs”in this
document). Factory workers keep track of the time they spend on each job by scanning
the SFCLBR (Start Factory Labor) bar code printed on work orders when they begin
the job (producing the Job On transaction). They scan the EFCLBR (End Factory
Labor) bar code when they end the job (producing the Job Off transaction). As
alternates to scanning, the SFCLBR and EFCLBR codes can be entered as text on the
keyboard, or they can be selected from the menu using the up and down arrow keys and
the Enter key.
Each transaction is packaged as one data output record and sent to a file. The data
record will show the worker’s Badge ID Number, the Part Number, and the Order
Number. In addition, it will show the automatic date and time stamps and the Job On or
Job Off transaction identification code (JOTRAN or JOFTRAN).

asdIntroduction
1-9
1
An overview of the process for a Job On transaction (currently being scanned by a
worker with Badge ID Number B714) is illustrated next.
Job On Transaction Process
Transaction packaged in a record with data fields delimited
by commas; TRAN code, date, time automatically added
Data scanned or
entered into terminal
Transaction record
sent to a disk file
Transaction data file listed for
management upon request
JOTRAN,B714,WIDGET1234,22,04-23-1997 02:04:30
JOTRAN,B714,WIDGET1008,21,04-23-1997 01:00:30
JOFTRAN,B714,WIDGET1008,21,04-23-1997 02:00:25
JOTRAN,B714,WIDGET1234,22,04-23-1997 02:04:30
Job On
Badge B714
Part WIDGET1
234
Order 22
2
1
3
4
Transaction
code
Date Time
EZB.001
Tutorial Organization
This tutorial includes several exercises. EZBuilder offers different ways to accomplish
some tasks; however, new users should follow the exercises described in this tutorial in
the order presented, entering the data and building the application step-by-step as
directed.
The exercises for this tutorial are presented over four chapters.
•In Chapter 2, you create a main menu and its menu items to provide navigation
options to users. This chapter includes an exercise to create hidden menu items that
can be useful during program development.
•In Chapter 3, you create screens and their data fields. This chapter includes creation
of scrolling sections for help text as well as data entry fields where your user will
enter Badge ID, Part Number, and Order Code for the tutorial’s example
application. This chapter includes an exercise to program function key actions.

EZBuilder Tutorialasd
1-10
•In Chapter 4, you create transactions that process the scanned or keyed data for
both Job On and Job Off records. Records of these transactions are saved in a file
that can be listed for management who might want to analyze the time spent for
each job and factory worker.
•In Chapter 5, you build and test your application. You will instruct EZBuilder to
build the application’s program code, and then you will use the EZBuilder
Simulator to test your application. This chapter includes information about
downloading your generated application program files to your terminal.
Tutorial Time
Depending upon how thoroughly you study the material and check each screen result in
this tutorial, you can complete the basic tutorial exercises and build and test your
program in less than two hours. Allow more time if you want to explore EZBuilder to
expand on information in the tutorial as you go along.
Note: We recommend that you complete the entire tutorial once before experimenting
with your own enhancements.
Chapter Summary
This chapter introduced you to EZBuilder: its purpose, window descriptions, and
definitions of major terms related to creating and using EZBuilder applications. This
chapter also introduced you to the tutorial and its organization.
What's Next
The remainder of this document provides simple tutorial exercises designed to quickly
teach you the basic features of EZBuilder.
An overview of the EZBuilder components included in the tutorial is illustrated next.
This illustration is repeated at the end of each chapter, with the components that you
have created up to that point shaded. Use the illustration at the end of each chapter to
see completed and upcoming exercises.

asdIntroduction
1-11
1
Tutorial Exercise Summary
Application: EZBTUTRL
Menu Screens Transactions
(Chapter 2) (Chapter 3) (Chapter 4)
Tasks 1, 2 and 3
MainMenu
Task 4
MM_Help
Task 5
JobOn
Task 6
JobOff
Task 7
Data_Help
Task 8 and 10
JON_Tran
Task 9 and 10
JOF_Tran
Task 11
CopyBadge
EZB.002
Upon completion of this tutorial, you will know and understand the basic functions of
EZBuilder. Building upon this foundation, you can easily learn additional features
during experimentation and study of example applications included with EZBuilder
(see the EZBuilder Getting Started Guide).
Before you begin the tutorial, ensure that
•EZBuilder has been properly installed on your computer (see the EZBuilder Getting
Started Guide for more information).
•a RAM drive (E drive) has been created on your terminal. This is the disk drive to
which you may want to send your output file when your application program is
executed (see the EZBuilder Getting Started Guide for details).
You are now ready to start the tutorial! Go to Chapter 2 to learn how to create a menu.
