OWNERS MANUAL
R- -
-410A Ductless Split System
Floor Console and Heat Pump
MODELS: DLFBF- Indoor
SIZES: 09K, 12K, 18K
NOTE: Read the entire instruction manual before starting the installation.
TABLE OF CONTENTS
PAGE
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
MODEL NUMBER
REFERENCE . . . . . . . . . . . . ............. . . .. 3
PART NAMES AND THEIR FUNCTIONS . . . . . . . . . . . . . . . ..
4
HOW TO USE THE REMOTE
................ ....
5
MAINTENANCE ...................................
10
OPERATING GUIDE . . . . . . . . . . . . . . . . . . . . . ...........
13
PRECAUTIONS . .............................................
15
CHECKING BEFORE CONTACT
. . . . . . . . . . . . . . ....................... . . . . . . .
16
INSTALLATIONOF INDOORUNIT . . . . . . . . . . . . . . . . .....
17
ROUTINE CHECK AFTER INSTALLATION . . . . . . . . . . . . ..
25
CONFIGURATION OF CONNECTION PIPE AND ADDITIONAL
VOLUME OF REFRIGERANT . . . . . . . . . . . . . .............
26
NOTE TO EQUIPMENT OWNER:
Please read this Owner’s Information Manual carefully before installing and using this appliance
and keep this manual for future reference.
For your convenience, please record the model and serial numbers of your new equipment in the
spaces provided. This information, along with the installation data and dealer contact information
will be helpful should your system require maintenance or service.
UNIT INFORMATION
Model #
Serial #
DEALERSHIP CONTACT INFORMATION
Company Name:
Address:
INSTALLATION INFORMATION
Date Installed
Phone Number:
Technician Name:
Specifications are subject to change without notice. 421 02 9260 00
CONTROL TO OPERATE THE UNIT
THE SERVICEMAN

3
SAFETY CONSIDERATIONS
Installing, starting up, and servicing air--conditioning equipment
can be hazardous due to system pressures, electrical components,
and equipment location (roofs, elevated structures, etc.).
Only trained, qualified installers and service mechanics should
install, start--up, and service this equipment.
Untrained personnel can perform basic maintenance functions such
as cleaning coils. All other operations should be performed by
trained service personnel.
When working on the equipment, observe precautions in the
literature and on tags, stickers, and labels attached to the
equipment.
Follow all safety codes. Wear safety glasses and work gloves. Keep
quenching cloth and fire extinguisher nearby when brazing. Use
care in handling, rigging, and setting bulky equipment.
Read these instructions thoroughly and follow all warnings or
cautions included in literature and attached to the unit. Consult
local building codes and National Electrical Code (NEC) for
special requirements. Recognize safety information. This is the
safety--alert symbol !!. When you see this symbol on the unit and
in instructions or manuals, be alert to the potential for personal
injury.Understand these signal words: DANGER, WARNING, and
CAUTION. These words are used with the safety--alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
!WARNING
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal
injury or death.
Before installing, modifying, or servicing system, main
electrical disconnect switch must be in the OFF
position. There may be more than 1 disconnect switch.
Lock out and tag switch with a suitable warning label.
EXPLOSION HAZARD
Failure to follow this warning could
result in death, serious personal injury,
and/or property damage.
Never use air or gases containing
oxygen for leak testing or operating
refrigerant compressors. Pressurized
mixtures of air or gases containing
oxygen can lead to an explosion.
!WARNING
CAUTION
!
EQUIPMENT DAMAGE HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Do not bury more than 36 in. (914 mm) of refrigerant pipe
in the ground. If any section of pipe is buried, there must be
a 6 in. (152 mm) vertical rise to the valve connections on
the outdoor units. If more than the recommended length is
buried, refrigerant may migrate to the cooler buried section
during extended periods of system shutdown. This causes
refrigerant slugging and could possibly damage the
compressor at start--up.
SYSTEM REQUIREMENTS
Allow sufficient space for airflow and servicing unit.
Recommended Connection Method for Power and Communi-
cation Wiring (To minimize communication wiring interfer-
ence)
Power Wiring:
The main power is supplied to the outdoor unit. The field supplied
connecting cable from the outdoor unit to indoor unit consists of
three (3) wires and provides the power for the indoor unit. Two
wires are high voltage AC power and one is a ground wire.
Consult your local building codes and the NEC (National
Electrical Code) or CEC (Canadian Electrical Code) for special
requirements.
All wires must be sized per NEC or CEC and local codes. Use
Electrical Data table MCA (minimum circuit amps) and MOCP
(maximum over current protection) to correctly size the wires and
the disconnect fuse or breakers respectively.
Per caution note, only copper conductors with a minimum 300 volt
rating and 2/64--inch thick insulation must be used.
Communication Wiring:
A separate shielded copper conductor only, with a minimum 300
volt rating and 2/64--inch thick insulation, must be used as the
communication wire from the outdoor unit to the indoor unit.
CAUTION
!
EQUIPMENT DAMAGE HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
SWires should be sized based on NEC and local codes.
SUse copper conductors only with a minimum 300 volt
rating and 2/64 inch thick insulation.
When installing in an application where there is high electrical
frequency all wires should be shielded.
page 2Specifications are subject to change without notice. 421 02 9260 00
To minimize voltage drop, the factory recommended wire
size is 14/3 stranded with a ground. In special cases where
there is high electrical interference, please use a separate
shielded 16GA stranded control wire.

0RGHO 1XPEHU 5HIHUHQFH
DLF A H H 09 K 1 A
Position 11 - Not Defined
Position 10 – Not Defined
Position 9 - Electrical characteristics
J = 115/l/60
K = 208-230/l/60
H = 208-230/3/60
L = 460/3/60
Position 7, 8 - System capacity in 1000 BTU/Hr
Example: 09 = 9000 BTU/Hr
Position 6 - Indoor Fan Coil Unit Type
B = High-Wall
C = Cassette
D=Ducted
F = Console
G = Underceiling
H = High Wall Color Variation
R=Outdoor
Position 5 – Unit Type
A = Cooling Only
H = Heat Pump
Position 4 - Model letter
Positions 1 to 3 - Equipment type
DLF = Indoor unit;
DLC = Outdoor unit
3 Specifications are subject to change without notice. 421 02 9260 00
Model Numbers
System Tons Unit Btuh Volt-Ph@60Hz Indoor Model Number
0.75 9000 208/230-1 DLFBHF09K1A
1.00 12000 208/230-1 DLFBHF12K1A
1.50 18000 208/230-1 DLFBHF18K1A

Part names and their functions
INDOOR UNIT
CAUTION
OPERATION INSTRUCTIONS
77℉(25℃)
77℉(25℃)
1. Titanium Apatite Photocatalytic
Air-Purifying Filter:
12. Run lamp
13. LED display
16.Air outlet selection switch
17.Room temperature sensor:
It senses the air temperature around the unit.
15.Signal receiver:
It receives signals from the remote controller.
When the unit receives a signal, you will hear
a short beep.
Settings changed.....beep
14. Indoor Unit ON/OFF switch:
Push this switch once to start operation.
Push once again to stop it.
2. Air outlet
3. Display
4. Front panel
5. Louvers (vertical blades)
The louvers are inside of the air outlet.
6. Air inlet
7. Air filter
8. Flap (horizontal blade)
9. Cool mode lamp
10. Heat mode lamp
11. Dry mode lamp
These filters are attached to the inside
of the air filters.
The operation mode refers to the following table.
This switch is useful when the remote controller
is missing.
Model Mode
Temperature
setting
Air flow rate
AUTO
AUTO
COOL
AUTO
COOLING
ONLY
HEAT
PUMP
ķIf the power wire is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
ĹAn all-pole disconnection switch having a contact separation of at least LQPP in all poles should be connected in fixed wiring.
ĸThe appliance shall be installed in accordance with national wiring regulations.
NOTE:
16
Air outlet selection switch
This setting blows air from
upper outlet only.
噝
This setting automatically
decides a blow pattern
depending on mode and
conditions.
噝
The unit is shipped from the
factory with this setting.
This setting is recommended.
Opening the Front Panel
Indoor unit
wiring terminal
N(1) 2 3
BU BK BN YELLOW/
GREEN
3
9
12
10
14 15
13
11
12
5
6
2
4
7
8
Before opening the front panel, be sure to
stop the operation and turn the breaker OFF.
Do not touch the metal parts on the inside
of the indoor unit, as it may result in injury.
17
噝
噝
4Specifications are subject to change without notice.
421 02 9260 00

T-ON T-OFF
1
7
Press it to set HEALTH or AIR function.
8
I FEEL
/(This function is only applicable for some models.)
4
3
2
5
6
11
13
12
16
10
14
9
15
Press it to start or stop operation.
ON/OFF
MODE
+
-
Press it to select operation mode
(AUTO/COOL/DRY/FAN/HEAT).
: Press it to increase temperature
setting.
: Press it to decrease temperature
setting.
FAN
Press it set swing angle.
QUIET
SWING
CLOCK
X-FAN
TEMP
TURBO
SLEEP
LIGHT
Press it to set fan speed.
Press it to set
Press it to set auto-off /auto-on timer.
Press it set clock.
3
15
5
4
14
7
16
13
12
9
8
11
10
2
1
6
Press it to turn on/off the light.
QUIET function.
OPERATION INSTRUCTIONS
How to use the remote control to operate the unit
Remote Controller Description
5 Specifications are subject to change without notice. 421 02 9260 00

6
Press this button to set up &down swing angle, which circularly changes as below:
OFF
This remote controller is universal . If any command , or is sent out,
the unit will carry out the command as
indicates the guide louver swings as:
Press this button to turn on I FEEL function. The unit automatically adjust temperature
according to the sensed temperature. Press this button again to cancel I FEEL function.
I FEEL:
SWING:
7
Remote Controller Description
ON/OFF :
MODE :
+:
AUTO COOL DRY FAN HEAT *
*Note:Only for models with heating function.
After energization, AUTO mode is defaulted. In AUTO mode, the set temperature will not
be displayed on the LED of the indoor, and the unit will automatically select the suitable operation
mode in accordance with the room temperature to make indoor room comfortable.
This button is used for setting Fan Speed in the sequence that goes from AUTO,
to then back to Auto.
,
,, ,
FAN :
1
4
3
2
5
Press this button to turn on the unit .Press this button again to turn off the unit.
Press this button to decrease set temperature. Holding it down above 2 seconds rapidly
decreases set temperature. In AUTO mode, set temperature is not adjustable.
Press this button to increase set temperature.Holding it down above 2 seconds rapidly
increases set temperature. In AUTO mode, set temperature is not adjustable.
Aut o
Medium speedLow-Medium speedLow speed
High speedMedium-High speed
Each time you press this button,a mode is selected in a sequence that goes from AUTO,
COOL,DRY, FAN,and HEAT *, as the following:
How to use the remote control to operate the unit
OPERATION INSTRUCTIONS
6Specifications are subject to change without notice.
421 02 9260 00

Press this button, could select displaying the indoor setting temperature or indoor ambient
temperature.When the indoor unit firstly power on it will display the setting temperature,
if the temperature's displaying status is changed from other status to" ",displays the
ambient temperature, 5s later or within 5s, it receives other remote control signal that will
return to display the setting temperature. if the users haven't set up the temperature
displaying status,that will display the setting temperature.
SLEEP:
9
Press this button, can select Sleep 1 ( ), Sleep 2 ( ),Sleep 3 ( ) and cancel the Sleep,
circulate between these, after electrified, Sleep Cancel is defaulted.
Sleep 1 is Sleep mode 1, in Cool, Dehumidify modes: sleep status after run for one hour, the main
unit setting temperature will increase 1.8 ℉(1 ℃)
10 TEMP:
How to use the remote control to operate the unit
OPERATION INSTRUCTIONS
Sleep 3- the sleep curve setting under Sleep mode by DIY:
(1) Under Sleep 3 mode, press "Turbo" button for a long time, remote control enters into user individuation sleep
setting status, at this time, the time of remote control will display "1 hour ", the setting temperature "88" will
(2) Adjust "+" and "-" button, could change the corresponding setting temperature, after adjusted, press
"Trubo "button for confirmation;
(3) At this time, 1 hour will be automatically increased at the timer postion on the remote control, (that are
(4) Repeat the above step (2) (3) operation, until 8 hours temperature setting finished, sleep
curve setting finished, at this time, the remote control will resume the original timer display;
display the corresponding temperature of last setting sleep curve and blink (The first entering will display
according to the initial curve setting value of original factory);
"2 hours " or "3 hours " or "8 hours "), the place of setting temperature "88" will display the
corresponding temperature of last setting sleep curve and blink;
temperature display will resume to original setting temperature.
Sleep3- the sleep curve setting under SLEEP mode by DIY could be inquired:
The user could accord to sleep curve setting method to inquire the presetting sleep curve, enter into user
individuation sleep setting status, but do not change the temperature, press "Turbo" button directly for confirmation.
Note: In the above presetting or enquiry procedure, if continuously within10s, there is no button pressed, the
sleep curve setting within10s, there is no button pressed, the sleep curve setting status will be automatically
quit and resume to display the original displaying. In the presetting or enquiry procedure, press "ON/OFF"
button, "Mode" button, "Timer"button or "Sleep" button, the sleep curve setting or enquiry status will quit similarly.
,setting temperature increased 3.6 ℉(2℃) , the unit will run
at this setting temperature; In Heat mode: sleep status after run for one hour, the setting temperature will
decrease 1.8 ℉(1 ℃), 2 hours, setting temperature will decrease 3.6 ℉(2℃), then the unit will run at this
setting temperature.
Sleep 2 is sleep mode 2, that is air conditioner will run according to the presetting a group of sleep temperature curve.
P ress this button to achieve the on and off of healthy and scavenging functions in operation status.
Press this button for the first time to start scavenging function;
LCD displays“ ”. Press the button for the
second time to start healthy and scavenging functions
simultaneously; LCD displays“ ” and “ ” . Press this button for the third time to quit healthy
and scavenging functions simultaneously. Press the button for the fourth time to start healthy
function; LCD display “ ” . Press this button again to repeat the operation above.
/
8
7 Specifications are subject to change without notice. 421 02 9260 00

T-ON T-OFF:
present time.Holding down either button above 2 seconds increases or decreases the
CLOCK :
time by 1 minute every 0.5 second and then by 10 minutes every 0.5 second. During
blinking after setting, press CLOCK button again to confirm the setting,and then
Press T-ON button to initiate the auto-ON timer. To cancel the auto-timer program, simply
press this button again.
After press of this button, disappears and "ON "blinks .00:00 is displayed for ON time
setting. Within 5 seconds, press + or - button to adjust the time value. Every press of either
button changes the time setting by 1 minute. Holding down either button rapidly changes the
time setting by 1 minute and then 10 minutes. Within 5 Seconds after setting, press TIMER
ON button to confirm.
12
will be constantly displayed.
13
Press T-OFF button to initiate the auto-off timer. To cancel the auto-timer program, simply
press the button again.TIMER OFF setting is the same as TIMER ON.
How to use the remote control to operate the unit
OPERATION INSTRUCTIONS
Press CLOCK button, blinking . Within 5 seconds,pressing +or - button adjusts the
LIGHT:
15
Press LIGHT button to turn on the display's light and press this button again to turn off
the display 's light. If the light is turned on , is displayed. If the light is turned off,
disappears.
TURBO:
14
X-FAN:
16
Pressing X-FAN button in COOL or DRY mode,the icon is displayed and the indoor
fan will continue operation for 10 minutes in order to dry the indoor unit even though you
have turned off the unit.
After energization, X-FAN OFF is defaulted. X-FAN is not available in AUTO,FAN or
HEAT mode.
Press this button to activate / deactivate the Turbo function which enables the unit to
reach the preset temperature in the shortest time. In COOL mode, the unit will blow strong
cooling air at super high fan speed. In HEAT mode, the unit will blow strong heating air
at super high fan speed.
Press "+ " and "-" buttons simultaneously to lock or unlock the keypad. If the remote
controller is locked, is displayed. In this case, pressing any button, blinks
three times.
Combination of "+" and "-" buttons: About lock
17
QUIET:
11
Press this button, the Quiet status is under the Auto Quiet mode (display and "Auto"" " signal)
and Quiet mode (display " " singal) and Quiet OFF (there is no signal of " " displayed),
after powered on, the Quiet OFF is defaulted. Note: the Quiet function cannot be set up in Fan
and Dry mode;Under the Quiet mode (Display " " signal), the fan speed is not available.
8Specifications are subject to change without notice.421 02 9260 00

How to use the remote control to operate the unit
OPERATION INSTRUCTIONS
ƾ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
1.Remove the battery cover plate from the rear of the remote controller.
(As shown in the figure)
2.Take out the old batteries.
3.Insert two new AAA1.5V dry batteries, and pay attention to the polarity.
4. Reinstall the battery cover plate.
When replacing the batteries, do not use old or different types of batteries,
If the remote controller will not be used for a long time, please
otherwise, it may cause malfunction.
remove batteries to prevent batteries from leaking.
The operation should be performed in its receiving range.
It should be kept 1m away from the TV set or stereo sound sets.
If the remote controller does not operate normally, please take the
batteries out and reinsert them after 30 seconds.If it still can't operate properly,
Notes:
replace the batteries.
Sketch map for
replacing batteries
Replacement of Batteries
At unit OFF, press "MODE"and"- " buttons simultaneously to switch between and .
ć
About Back-lighting Function
21
Combination of "MODE " and "-" buttons :
18 About switch between Fahrenheit and centigrade
Press “TEMP” and “CLOCK” simultaneously in COOL mode to start energy-saving function.
Nixie tube on the remote controller displays “SE”. Repeat the operation to quit the function.
Combination of " TEMP " and "CLOCK" buttons : About Energy-saving Function
19
Press “TEMP” and “CLOCK” simultaneously in HEAT mode to start
The unit lights for 4s when energizing for the first time, and 3s for later press.
46 ℉(8 ℃)Heating
Function Nixie tube on the remote controller displays “ ” and a selected temperature of
.
“46℉(8℃)”
Combination of " TEMP " and "CLOCK" buttons : About 46℉(8℃)Heating Function
20
Repeat the operation to quit the function.
9 Specifications are subject to change without notice. 421 02 9260 00

Maintenance
Before inspection and maintenance of the unit. PLEASE set power switch to “OFF” to cut off the
power supply.
3.1 Units
3.2 Filters
CAUTION
ŏIndoor unit, Outdoor unit and Remote controller
ŏFront panel
1. Wipe them with dry soft cloth.
1. Open the front panel.
1. Open the front panel.
2. Remove the air filter.
Slide the two stoppers on the left and right sides inward until they click.
2. Remove the front panel.
5HPRYHWKHVWULQJ
Allowing the front panel to fall forward will enable you to remove it.
3. Clean the front panel.
:LSHLWZLWKDVRIWFORWKVRDNHGLQZDWHr.
2QO\QHXWUDOGHWHUJHQWPD\EHXVHG
,QFDVHRIZDVKLQJWKHIURQWSDQHOZLWKZDWHr,dry it with cloth, dry
it up in the shade after washing.
4. Attach the front panel.
,QVHUWWKHIURQWSDQHOLQWRWKHJURRYHVRIWKHXQLWSODFHV
3UHVVWKHFODZVRQWKHULJKWDQGOHIWRIWKHDLUILOWHUGRZQVOLJKWO\, then
pull upward.
3. Take off the Titanium Apatite Photocatalytic Air-Purifying
Filter.
+ROGWKHWDEVRIWKHIUDPHDQGUHPRYHWKHFODZVLQSODFHV
'RQ¶WWRXFKWKHPHWDOSDUWVRIWKHLQGRRUXQLW,I\RXWRXFKWKRVHSDUWVWKLVPD\FDXVHDQLQMXU\
:KHQUHPRYLQJRUDWWDFKLQJWKHIURQWSDQHOXVHDUREXVWDQGVWDEOHVWRRODQGZDWFK\RXUVWHSVFDUHIXOO\
:KHQUHPRYLQJRUDWWDFKLQJWKHIURQWSDQHOVXSSRUWWKHSDQHOVHFXUHO\ZLWKKDQGWRSUHYHQWLWIURPIDOOLQJ
104℉(40℃)
VFUXEELQJEUXVKHVQRURWKHUKDQGVWXII
$IWHUFOHDQLQJPDNHVXUHWKDWWKHIURQWSDQHOLVVHFXUHO\IL[HG



Attach the string to the right, inner-side of the front grille.
&ORVHWKHSDQHOVORZOy.
String
Place front
panel in
grooves.
OPERATION INSTRUCTIONS
String
10Specifications are subject to change without notice.421 02 9260 00

4. Clean or replace each filter.
6. Wash the air filters with water or clean them with vacuum
cleaner.
1. Vacuum dusts, and soak in warm water or water for about 10 to 15 minutes if dirt is heavy.
Remove the tabs on the filter frame and replace with a new filter.
2. Do not remove filter from frame when washing with water.
3. After washing, shake off remaining water and dry in the shade.
4. Since the material is made out of paper, do not wring out the filter when removing water from it.
See figure.
5. Set the air filter and Titanium Apatite Photocatalytic
Air-Purifying Filter as they were and close the front
panel.
2SHUDWLRQZLWKRXWDLUILOWHUVPD\UHVXOWLQWURXEOHVDVGXVWZLOODFFXPXODWH
inside the indoor unit.
,IWKHGXVWGRHVQRWFRPHRff easily, wash them with neutral detergent
thinned with lukewarm water, then dry them up in the shade.
'LVSRVHRIWKHROGILOWHUDVIODPPDEOHZDVWH
'LVSRVHRIWKHROGILOWHUDVIODPPDEOHZDVWH
,WLVUHFRPPHQGHGWRFOHDQWKHDLUILOWHUVHYHU\ZHHN
Air filter
Titanium Apatite
Photocatalytic
Air-Purifying
Filter
The Titanium Apatite Photocatalytic Air-Purifying Filter can be renewed by washing it with water
once every 6 months. We recommend replacing it once every 3 years.
3.3 Titanium Apatite Photocatalytic
Air-Purifying Filter
NOTE
ŏMaintenance
ŏReplacement
2peration with dirty filters:
(1) cannot deodorize the air. (2) cannot clean the air.
(3) results in poor heating or cooling. (4) may cause odour.
2PERAT,2N,NSTRUCT,2NS
Maintenance
11 Specifications are subject to change without notice. 421 02 9260 00

1. Operate the “FAN only” for several hours on a fine day to dry out the inside.
2. After operation stops, turn off the breaker for the room air conditioner.
3. Clean the air filters and set them again.
:KHQDPXOWLRXWGRRUXQLWLVFRQQHFWHGPDNHVXUHWKHKHDWLQJRSHUDWLRQLVQRWXVHGDWWKHRWKHUURRPEHIXUH\RXXVHWKHIDQ
operation.
4. Take out batteries from the remote controller.
3UHVV³02'(´EXWWRQDQGVHOHFW³)$1´RSHUDWLRQ
3UHVV³212))´EXWWRQDQGVWDUWRSHUDWLRQ
3.4 Before a long idle period
Check
NOTE
Check that the base, stand and other fittings of the outdoor unit are not decayed or corroded.
Check that nothing blocks the air inlets and the outlets of the indoor unit and the outdoor unit.
&KHFNWKDWWKHGUDLQFRPHVVPRRWKO\RXWRIWKHGUDLQKRVHGXULQJ&22/RU'5<RSHUDWLRQ
If no drain water is seen, water may be leaking from the indoor unit. Stop operation and consult
the service shop if this is the case.
OPERATION INSTRUCTIONS
Maintenance
12Specifications are subject to change without notice.
421 02 9260 00

Operating guide
OPERATION INSTRUCTIONS
Working principle and special functions for cooling
Working principle and special functions for heating
Defrosting:
*
When outdoor temperature is low but high humidity, after a long while running, frost will
form on outdoor unit, that will effect the heating effect, at this time, the auto defrosting
function will act, the heat running will stop for 8-10mins.
*
During the auto defrosting, the fan motors of indoor unit and outdoor unit will stop.
*
During the defrosting, the indoor indicator flashes(or display “H1”), the outdoor unit may
emit vapor, This is due to the defrosting, it isn't malfunction.
*
After defrosting finished,the heating will recover automatically.
The climate type of this unit is according to the nameplate.
Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that
indoor ambient temperature decreased, its cooling capacity will increase or decrease by
outdoor ambient temperature.
If the unit is running in COOL mode and in low temperature, there will be frost formed on
the heat exchanger, when indoor heat exchanger temperature decreased below 32℉(0℃),
the indoor unit microcomputer will stop compressor running and protect the unit.
Principle:
*
Air conditioner absorbs heat from outdoor and transmits to indoor, in this way to increase
room temperature. This is the heat pump heating principle, its heating capacity will be
reduced due to outdoor temperature decrease.
*
If outdoor temperature becomes very low, please operate with other heating equipments.
Anti-cool wind function:
In Heat mode, the following three kinds of status, if indoor heat exchanger hasn't achieve
certain temperature that indoor fan motor will not start, in this way to prevent blowing cool
wind (within 3mins):
1. Heat operation just startedup. 2. After Auto defrosting operation is finished.
3. Heating under low temperature.
Principle:
Anti-freezing function:
13 Specifications are subject to change without notice. 421 02 9260 00

Operating guide OPERATION INSTRUCTIONS
14Specifications are subject to change without notice.421 02 9260 00

OPERATION INSTRUCTIONS
Precautions
15 Specifications are subject to change without notice. 421 02 9260 00

OPERATION INSTRUCTIONS
CAUSESPROBLEM
Checking before contact the service man
$
16Specifications are subject to change without notice.421 02 9260 00

INSTALLATION INSTRUCTIONS
The appliance shall not be installed in the laundry.
Installation of indoor unit
Such a place where cool air can be distributed
Such a place where condensation water is easily
Such a place that can handle the weight of indoor unit.
Such a place which has easy access for maintenance.
drained out.
throughout the room.
SELECTION OF INSTALLATION LOCATION.
Each type is similar to the other as follows;
THERE ARE 2 STYLES OF INSTALLATION.
CEILING TYPE
FLOOR TYPE
Schematic drawing of hooks:
Where there is too much of oil area.
Where it is acid base area.
Where there is irregular electrical supply.
TOOCCUR.
AIR CONDITIONER TROUBLEIS LIABLE
CAUTIONS FOR INSTALLATION WHERE
7 7/8 in (200 mm)
Indoor unit
The indoor unit should be sited in a place where:
1) the restrictions on installation specified in the indoor
unit installation drawings are met.
2) both air intake and exhaust have clear paths met.
3) the unit is not in the path of direct sunlight.
4) the unit is away from the source of heat or steam.
5) there is no source of machine oil vapour (this may shorten indoor unit life).
6) cool(warm) air is circulated throughout the room.
7) the unit is away from electronic ignition type fluorwscent lamps
(inverter or rapid stert type) as they may shorten the remote
controller range.
8) the unit is at least 3.28 ft (1 m) away from any television or radio
set(unit may cause interference with the picture or sound).
Indoor Unit Installation Drawings
The indoor unit may be mounted in any of the three styles shown here.
Exposed
Floor lnstallation Wall Installation
Molding
Mounting plate
Half conceated Concealed
Grid(field supply)
Location for securing the installation panel.
27 5/9 in (700 mm)
25 1/3 in (644 mm)
4 5/7 in (120 mm)
8 2/3 in (220 mm)
1 1/6 in (30 mm)
6 2/7 in (160 mm)
1 1/6 in (30 mm)
6 2/3 in (170 mm)
8 2/3 in (220 mm)
4 5/7 in (120 mm)
22 4/9 in (570 mm)
23 5/8 in (600 mm)
7 7/8 in (200 mm)
or more
from the floor
or more
59 in(150cm）
59 in(150cm）
59 in(150cm）
59 in(150cm）
or more
or more
INSTALLATION
PAPER PLANK
6 in(15cm)or below
17 Specifications are subject to change without notice. 421 02 9260 00

Refrigerant piping
1)Drill a hole ( 2 1/6 in (55 mm) in diameter ) in the spot indicated by the symbol in the illustration as below .
2)The location of the hole is different depending on which side of the pipe is taken out .
3)For piping ,see Connecting the refrigerant pipe ,under Indoor Unit Installation(1).
4)Allow space around the pipe for a easier indoor unit pipe connection.
Min.allowable length
The suggested shortest pipe length is 8.2 ft (2.5 m),in order to avoid noise from the outdoor unit and vibration.
(Mechanical noise and vibration may occur depending on how the unit is installed and the environment in which it is
used.)
See the installation manual for the outdoor unit for the maximum pipe length.
CAUTION
13 7/9 in (350 mm)
wall
Refrigerant pipe
1 7/9 in (45 mm)
3 in (75 mm)
Floor
1 7/9 in (45 mm)
1 7/9 in (45 mm)
1 7/9 in (45 mm)
1 7/9 in (45 mm)
2 1/3 in (60 mm)
3 in (75 mm)
3 in (75 mm) 3 in (75 mm)
3 in (75 mm)
1 7/9 in (45 mm)
Left back piping
Wall
(Unit : in/mm)
Right back piping
Left bottom piping Right bottom piping
Left/right piping
INSTALLATION INSTRUCTIONS
Installation of indoor unit
18Specifications are subject to change without notice.
421 02 9260 00

Drain piping
1)Use commercial regid polyvinyl chloride pipe general VP 20 pipe, outer diameter 1 in (26 mm), inner diameter
4/5 in (20 mm) for the drain pipe.
2)The drain hose (outer diameter 5/7 in (18 mm) at connecting end, 8 2/3 in (220 mm) long)is supplied with the indoor
unit. Prepare the drain pipe picture below position.
3)The drain pipe should be inclined downward so that water will flow smoothly without any accumulation.(Should not
be trap.)
4)Insert the drain hose to this depth so it won’t be pulled out of the drain pipe.
5)Insulate the indoor drain pipe with 10mm or more of insulation material to prevent condensation.
6)Remove the air filters and pour some water into the drain pan to check the water flows smoothly.
4 in (100 mm)
Drain hose
4 in (100 mm)
6 in (150 mm)
Vinyl chloride
drain pipe
2 in (50 mm)
or more
Reducer
Must be no trap
Do not touch water
INSTALLATION INSTRUCTIONS
Installation of indoor unit
Boring a wall hole and installing wall embedded pipe
For walls containing metal frame or metal board ,be sure to use a wall embedded
pipe and wall cover in the feed-through hole to prevent water leakage.
Be sure to caulk the gaps around the pipes with caulking material to prevent
water leakage.
1)Bore a feed-through hole of 2 1/6 in (55 mm) in the wall so it has a down slope
toward the outside.
2)Insert a wall pipe into the hole.
3)Insert a wall cover into wall pipe .
4)After completing refrigerant piping, wiring, and drain piping, caulk pipe hole gap
with putty.
Inside Outside
Caulking
Wall embedded pipe
(field supply)
Wall hole cover
Wall embedded pipe
(field supply)
2 1/6 in (55 mm)
19 Specifications are subject to change without notice. 421 02 9260 00

Open the front panel, remove the 4 screws and dis-
mount the front grille while pulling it forward.
Follow the procedure below when removing the slit
portions.
Front panel
Open the front panel
Remove
front grille
Casing
Front
grille
Remove 4 screws
3 tabs
For Moldings
Remove the pillars. (Remove the slit portions on the
bottom frame using nippers.)
For Side Piping
Remove the pillars.
1)Remove the 7screws.
2)Remove the upper casing (2 tabs).
3)Remove the left and right casings (2 tabs on each
side ).
4)Remove the slit portions on the bottom frame and
casings using nippers .
5)Return by following the steps in reverse order(3>2>
1).
3)Side
casings
2)Upper casing
3)Side
casings
Remove the pillar
Remove 7 screws
Casing
Remove the pillar
Casing
Remove the pillar
Bottom frame
Secure using 6 screws for floor installations.(Do not forget to secure to the rear wall.)
For wall installations, secure the mounting plate using 5 screws and the indoor unit using 4 screws.
Follow the arrows to disengage the clasps on the
front case to remove it.
Installing indoor unit
1.Preparation
2.Installation
INSTALLATION INSTRUCTIONS
Installation of indoor unit
20Specifications are subject to change without notice.
421 02 9260 00
