International Ozone Titan 2000 User manual

Titan
2000 & 4000
OPERATIONS
MANUAL
International Ozone Technologies Group, Inc.
Delray Beach, Florida USA
2015
“Manufactures Of Environmental Products That Solve Problems”

Copyright
Copyright 2015 International Ozone Technologies Group, Inc. All Rights
Reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language
or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual, or otherwise, without
the prior written permission of International Ozone Technologies Group,
Inc.
Disclaimer: International Ozone Technologies Group, Inc. Shall not be
liable for technical or editorial errors or omissions contained herein; nor
for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.
In the interest of continuing product improvement, International Ozone
Technologies Group, Inc. reserves the right to change product
specifications without notice. Information in this document may change
without notice.
For Your Records
The serial number for this product Is located on the back right bottom of the case.
Write the model number, serial number and the original date of purchase in the spaces
below for future reference for warranty or insurance purposes.
Product Name: Titan Hydroxyl Generator
Model Number: _________________________
Serial Number: _________________________
Purchase Date: _________________________
Glossary
Bacteria Disease causing microscopic organism.
BOD Biological Oxygen Demand
CFM Cubic Feet Per Minute
COD Chemical Oxygen Demand
Corona Arcing halo around an electrical discharge.
EPA Environmental Protection Agency
Fungus A plant without leaves, flowers or roots.
Example = mushroom.
Germ Disease causing microbe.
Half-life The time it takes for half the atoms in a
substance to decay.
Mildew A type of destructive fungus that grows in moist
environments.
Milligrams Per Hour Amount of ozone produced, and measured by
weight, by a given ozone generator under
certain conditions.
Mold A fungoid growth caused by dampness.
OSHA Occupational Safety & Health Administration.
Oxidize To transform a substance by changing its
chemical structure. Fire and rust are forms of
oxidation.
Ozone A triatomic form of oxygen with a pungent odor.
PPM Parts per million. One shot glass in a ten
thousand gallon tanker truck is an example of
one part per million.
RMA Number Returned Merchandise Authorization Number
Virus Disease causing sub-microscopic organisms.
VOC Volatile organic compound.
17

OPERATIONS MANUAL
Model 2000 & 4000
International Ozone Technologies Group, Inc.
WITH BUSINESS RELATIONSHIPS OR OTHER COMMERCIAL LOSS EVEN IF ADVISED OF,,
THE POSSIBILITY OF SUCH DAMAGES.
2. , , .ANY OTHER DAMAGES WHETHER INCIDENTAL CONSEQUENTIAL OR OTHERWISE
3. .ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY
Effect of state law:
This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state. Some states do not allow limitations on implied warranties and/or do not allow the exclusion of
incidental or consequential damages, so the above limitations and exclusions may not apply to you.
Sales outside the U.S.A.:
For products sold outside of the U.S.A., contact your dealer for warranty information andTitan Titan
service.
16 1
S
p
a
c
e
A
g
e
T
e
c
h
n
o
l
o
g
y
S
p
a
c
e
A
g
e
T
e
c
h
n
o
l
o
g
y
TiO Photo Catalytic Oxidizer
2
Safe / Chemical Free
Air Purification
&
Deodorization
TiO Photo Catalytic Oxidizer
2
Safe / Chemical Free
Air Purification
&
Deodorization
Titan
Hydroxyl Generator

Contents
Important Safeguards 3
Warnings and Precautions 4
Theory of Operation 5
General Use Guidelines 6
Trouble Shooting 8
Applications 7
Maintenance 9
Specifications 10
Dimensions 11
Front & Back Views Of Your Titan 12
Purifier or Scrubber??? 13
Titan Testing 14
Warranty 15
Glossary 17
LIMITED WARRANTY
Titan Hydroxyl Generators
What the warranty covers:
International Ozone Technologies Group, Inc. warrants its products to be free from defects in material
and workmanship during the warranty period. If a product proves to be defective in material or
workmanship during the warranty period, will, at itsInternational Ozone Technologies Group, Inc.
sole option, repair or replace the product with a like product. Replacement product or parts may include
remanufactured or refurbished parts or components.
How long the warranty is effective:
The is warranted for one (1) years for all parts and one (1) year for all
Titan Hydroxyl Generator
labor from the date of the first consumer purchase.
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follow instructions supplied with the product.
b. Repair or attempted repair by anyone not authorized by International Ozone Technologies
Group, Inc.
c. Any damage of the product due to shipment.
d. Removal or installation of the product.
e. Causes external to the product, such as electric power fluctuations or failure.
f. Use of supplies or parts not meeting International Ozone Technologies Group, Inc.
specifications.
g. Normal wear and tear.
h. Any other cause which does not relate to a product defect.
I. Shipping & Handling to or from International Ozone Technologies Group, Inc.
3. Removal, installation, and set-up service charges.
How to get service:
1. For information on obtaining warranty service, call International Ozone Technologies Group,
Inc. The customer support telephone numbers are: U.S. and Canada 1-877-406-9663. Internet
address http://www.internationalozone.com
2. To obtain warranty service, you will be required to provide (a) the original dated sales slip, (b)
your name, (c) your address, (d) a description of the problem, and (a) the serial number of the
product. Obtain a # (Returned Merchandise Authorization) fromRMA International Ozone
Technologies Group, Inc.
3. Take or ship the product prepaid in the original container to International Ozone Technologies
Group, Inc. 1100 10th. Street, Ste J, Delray Beach, Florida 33444.at SW
Limitation of implied warranties:
THERE ARE NO WARRANTIES EXPRESS OR IMPLIED WHICH EXTEND BEYOND THE,,
DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSEA.
Exclusion of damages:
International Ozone Technologies Group, Inc.'s LIABILITY IS LIMITED TO THE COST OF
REPAIR OR REPLACEMENT OF THE PRODUCT. International Ozone Technologies Group, Inc.
SHALL NOT BE LIABLE FOR:
1. ,DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT
DAMAGES BASED UPON INCONVENIENCE LOSS OF USE OF THE PRODUCT LOSS,,
OF TIME LOSS OF PROFITS LOSS OF BUSINESS OPPORTUNITY LOSS OF,, ,
GOODWILL INTERFERENCE,
15
2

3
14
Titan Testing
This testing was done on a model that is
equal to the Titan #1000
International Ozone Technologies Group, Inc
along with many of its dealers have tested
on many odors such as cigarette smoke,Titan
dead body odor, urine odor, garbage odor, and
airborne s, just to name a few, and haveVOC
come out “Smelling Like A Rose” every time.
Important Safeguards
>Do not operate equipment before reading and familiarizing
yourself with all instructions, procedures, cautions and
warnings contained in this manual.
>Save these instructions for later reference
>Follow all warnings and cautions marked on the product
and contained herein.
>Do not use this product near water or in a moist
environment.
>Operate equipment only with the correct electrical power
specified on the backside of the case.
>Do not attempt to service this product yourself as opening
or removing the enclosure may expose you to dangerous
voltage or other hazards.
>Do not put foreign objects inside the equipment.
>Do not operate equipment with a damaged cord or plug, if
fans fail to rotate, after the equipment malfunctions or if it
has been dropped or damaged in any manner. Return
equipment to manufacturer for examination, electrical or
mechanical adjustment or repair. (See warranty for
information.)
>Do not block air flow through equipment. Set equipment
at least 6 inches from walls or any structure that could
block the air intake.
>Do not use equipment in a flammable or explosive
atmosphere.
>
>Do not run cord under carpeting. Do not cover cord with
throw rug, runner, or similar coverings. Do not route cord
under furniture or appliances. Arrange cord away from
traffic area and where it will not be tripped over.
>

Titan Warnings And Precautions
Caution:
As with all electrical devices this equipment should not be operated in a
wet or damp environment.
This equipment should only be operated using a properly grounded
electrical outlet.
International Ozone Technologies Group, Inc. assumes no liability for
damages or injuries incurred by misuse of this equipment.
413
Titan #4000
Is it an Air Purifier
That Scrubs The
Air
Or
An Air Scrubber
That Purifies The
Air?

Theory of Operation
UV Rays in the 365 to 385 nanometer wavelength, which are safe to
look at and let shine on your skin, are emitted from Titan's TiO2
Photocatalytic Lamp and shine on the 23” Nano TiO Coated Super
2
Reactor Screen. As a result, electron hole pairs are formed that react
with H 0 and O in the air and produce free electrons and hydroxyl
22
radicals that when dispersed by the fan will decompose organic and
inorganic gases and air pollutants into carbon dioxide and water.
Titan will produce larger amounts of purifying agents when used in
high humidity situations.
Titan is safe to use at any time with or without people or animals in the
treatment area.
NOTE: 60%+ humidity is required for
optimum performance.
NOTE: 60%+ humidity is required for
optimum performance.
5
Model #2000
Model #4000
12
Views
5,000 CFM
Ball Bearing Fan
&
4 - 8” Diameter
High Output
TiO / Photocatalytic
2UVA
Lamps
20” x 20” x 1/2”
Permanent
Washable
Electrostatic Filter
82% Efficient
Rear Mounted
On/Off Switch
900 CFM
Ball Bearing Fan
&
2 - 8” Diameter
High Output
TiO / Photocatalytic
2UVA
Lamps and 2 TiO Coated
2
Super Reactor Screens
Washable
82% Efficient
Electrostatic Filter
Resettable
Circuit Breaker
Operational Tip:
Set a 5 gallon bucket of water 2 feet behind the Titan and
it will work much better.
You don’t have to raise the humidity in the entire
building, just in the air going through the machine.
Or better yet - Purchase a Hydroxyl Maximizer Ultrasonic
Cold Vapor Injector.

General Use Guidelines
Determine the source of the odor and remove any odor causing
substance that can be found.
Determine the size of the area that will be purified or deodorized. Multiply
the width by the length by the height to determine the total cubic feet of
the area.
The following suggestions are general. The actual time it will take to
remove an odor or to purify an area depends on many variables such as
pollutant load, temperature, humidity, etc.
Examples for 1000 cubic feet (100 Square feet with 10 foot
ceilings) with lite to moderate odor:
Titan 2000 = 2 Hours
Titan #4000 = 1 Hour
As stated above, these are just general guidelines. In some cases you
will have to go longer and in other cases you will go shorter. Once you
have become experienced with using your Titan for odor removal you will
be able to determine the treatment times from your past experiences.
Set your Titan anywhere in the area to be treated and turn it on.
.
6
Dimensions
#4000
#2000
11
26”
26”
12”
12”
12”
16”

Specifications
10 7
Applications for Titan’s Use
Adult Day Care Centers & Nursing Homes
Air Conditioning Contractors
Apartment Complexes
Auto Dealerships
Auto Detailers
Automobile Rentals
Beauty Parlors & Nail Salons
Bowling Alleys
Bus Lines
Business Opportunity
Businesses
Carpet Cleaners & Installers
Chemical Supply
Child Care Centers
Cocktail Lounges & Bars
Condominium Associations
Country / Golf Clubs
Cruise Ships
Doctors, Dentist & Chiropractors and Medical Clinics
Dry Cleaners
Duct Cleaning Companies
Equipment Rental Companies
Fire & Water Damage Restoration
Florists
Funeral Homes
Garbage/Dumpsters Rooms
Grocery Stores, Meat Markets and Fish & Seafood Markets
Health Clubs & Gyms
Home Owners
Hotels
Insurance Companies
Janitorial Companies
Janitorial Supply
Karate Studios
Limousine Services
Marinas / Boats
Motorhome / Recreational Vehicle Rentals
Movie Theaters
Painting Contractors
Pest Control Companies
Police Departments
Pool Supply Companies
Print Shops
Public Rest Rooms
Realtors
Restaurants
Schools
Sick Building Syndrome
Trucking Companies
Vegetable & Fruit Preservation
Warehouse / Storage Facilities
Model #2000 #4000
Size 12" x 12" x 16" 26" x 26" x 12"
Weight 20 lbs. 38.5 lbs.
Process
UVA/Titanium Dioxide
Based Photo Catalytic
Oxidation
UVA/Titanium Dioxide
Based Photo Catalytic
Oxidation
Filtration
10" x 10" x 1/2"
Permanent Washable
Electrostatic Filter
20" x 20" x 1/2"
Permanent Washable
Electrostatic Filter
Air Movement 900 CFM Max. 5000 CFM Max.
Max. Treatment
Area 20,000 Cu. Ft. 40,000 Cu. Ft.
Volts / Amps 110 / 2 110 / 4
Hertz 50 / 60 50 / 60
Case Material Anodized Aluminum
.060 / 14 Gauge
Anodized Aluminum
.060 / 14 Gauge
Finish Industrial Powder Coat Industrial Powder Coat
Warranty One Year Parts & Labor One Year Parts & Labor

8
Trouble Shooting
Problem Possible Cause Remedy
Unit does not turn on Power Cord Not Plugged
In
Plug Power Cord Into
Suitable Outlet With
Correct Voltage
Circuit Breaker In
Building Tripped
Reset Circuit Breaker At
Panel Box
Faulty Power Outlet Try Another Outlet
Fuse or Circuit Breaker
is Blown On back Of Unit
Replace Fuse Or Reset
Circuit Breaker
Unit Keeps Tripping
Circuit Breaker Electrical Short Circuit Return Unit To Manufacturer For repair
9
Maintenance
Your was engineered, designed and built to require very littleTitan Hydroxyl Generator
maintenance. The only maintenance necessary to keep your running at peakTitan
performance is to wash the electrostatic filter located on the back of the unit with soap and
water, air dry, then re-install. If you ever feel that your is not working as well as it did whenTitan
it was new, call the factory for an number and ship the unit back. We will inspect andRMA
diagnose the problem. If the equipment only needs adjustments or cleaning to bring it back into
specifications we will gladly service and re-certify your equipment , you only payfree of charge
shipping and handling. are self-cleaning and will perform atTitan’s Photo Catalytic Lamps
their optimum for a period of 8000 hours (24 Hours Per Day - 7 Days A Week - For 1 Year) at
which time they may need to be replaced.
Removing & Re-Installing Filter
12
34
5
(#1) Slide fingers under frame of the filter.(#2) Using your thumb to push against the case,
pull the corner of the filter free and remove from case.
(#3) Place the bottom of the filter into the bottom and completely to the back of the opening.
(#4) Using the palms of your hands push down on the filter as you push it into the opening.
(#5) Grab the outside of the case with your fingers and use your thumbs to push the
corners of the filter to seat the filter completely into the opening. Repeat #5 on the bottom
corners of filter.
