InterVision hdr412-pro User manual

- 1
-
HD-SDI Hybrid DVRs
User’s Manual
Model: 2+14-CH
4+8-CH
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
HD-Hybrid-DVR-2+14/4+8-CH-M78095E

- 2
-
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
PLEASE REFER SERVICING TO QUALIFIED SERVI
CE PERSONNEL.
NOTE: This equipment has been tested and found to comply with the
limits for a Class “A” digital device, pursuant to P
art 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the users will be
required to correct the interference at their own expense.
FCC Caution: To assure continued compliance, use only shielded
interface cables when connecting to computer or peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.
This Class A digital apparatus meets all the requirements of the Canadian
Interference Causing Equipment Regulations.
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.

- 3
-
LIMITATION OF LIABILITY
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTIBILITY, FITNESS FOR ANY
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF THE THIRD
PARTY’S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCUACIES OR
TYPOGRAPHICAL ERRORS. CHANGES ARE ADDED TO THE
INFORMATION HEREIN, AT ANY TIME, FOR THE IMPROVEMENTS OF
THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT(S).
DISCLAIMER OF WARRANTY
IN NO EVENT SHALL THE SUPPLIER BE LIABLBE TO ANY PARTY OR ANY
PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE
OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO
THE FOLLOWINGS:
ANY DAMAGE OR LOSS, INCLUDING BUT WITHOUT LIMITATION,
DIRECT OR INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY,
ARISING OUT OF OR RELATING TO THE PRODUCT;
PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE
USE OR NEGLIGENT OPERATION OF THE USER;
UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE
PRODUCT BY THE USER;
ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR
DAMAGE, ARISING OUT OF THE SYSTEM COMBINED WITH THE
DEVICES OF THE THIRD PARTY;
ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT BY ANY PERSON OR
ORGANIZATION BEING A PHOTOGENIC SUBJECT, DUE TO VIOLATION
OF PRIVACY WITH THE RESULT OF THAT SURVEILLANCE-CAMERA’S
PICTURE, INCLUDING SAVED DATA, FOR SOME REASON, BECOMES
PUBLIC OR IS USED FOR THE PURPOSE OTHER THAN SURVEILLANCE.

- 4
-
PRECAUTIONS
Please refer all work related to the installation of this product to
qualified service personnel or system installers.
Do not operate the appliance beyond its specified temperature, humidity
or power source ratings.
Use the appliance at temperature within 0
o
C ~ +40
o
C(32
o
F ~ 104
o
F) and
humidity below 85%.
The input power source for this appliance is +12 VDC.
Performance and lifetime of hard disk drives are easily affected by heat (used
at high temperature). It is recommended to use this appliance at
temperature within +20
o
C ~ +30
o
C(68
o
F ~ 86
o
F)
Handle the hard disk drives with care.
It is possible to damage them if they are moved while their motors are still
running. Do not move them just after turning the power on or off (for around
30 seconds).
Protect the hard disk drives from static electricity.
Do not stack them or keep them upright.
Do not use an electric screwdriver to fix them.
Clean only with dry cloth.
Do not block any ventilation openings.
Do not use the appliance near any heat sources such as radiators, heat
registers, stoves or other apparatus that produce heat.
Protect the power cord from being stepped on or pinched particularly at plugs,
convenient receptacles and the points where they exit from the apparatus.
Do not drop metallic parts through slots. This could permanently damage the
appliance. Turn the power off immediately and contact qualified service
personnel for service.
Handle the appliance with care. Do not strike or shake, as this may damage
the appliance.
Do not expose the appliance to water or moisture, nor try to operate it in wet
areas. Do take immediate action if the appliance becomes wet. Turn the
power off and refer servicing to qualified service personnel. Moisture may
damage the appliance and also cause electric shock.
Do not use strong or abrasive detergents when cleaning the appliance body.
When the dirt is hard to remove, use a mild detergent and wipe gently.
Do not overload outlets and extension cords as this may result in a risk of fire
or electric shock.
Please make a note of your settings and save them. This will help when you
are required to change the system configuration, or when unexpected failure
or trouble occurs.
Distributing, copying, disassembling, reverse compiling, reverse engineering,
and also exporting in violation of export laws of the software provided with this
product, is expressly prohibited.

- 5
-
Table of Contents
1. Product Overview………………….……………………….……...
1.1 Features…………………..…….…………..…………………...
2. Panels And Remote Controller…………...………………….…….
2.1 Front Panel………….……….…………………………….…….
2.2 Back Panel………………….…………………………….……..
2.3 Remote Controller…………..…….……………………….……
3. Installations…….…….……………………………………….……
3.1 Basic Connections…………….………………………….……..
3.2 Optional Connections…………..………………………….……
4. Main ScreenAnd Basic Operations………….……..……….…...
4.1 Text Input……………………………………….………………
4.2 Login And Logout………………………………………………
4.3 Basic Operations…………………………….…………………
4.4 Digital Zoom…….………………………….………….………
5. Menu Display………..……..………………………………….…...
5.1 Status Display….……………………………….………………
5.2 Volume Control…………..……………..……………..………
5.3 Video Adjustment (Analog Cameras Only)…………..…………
5.4 Display……………..…………………..………………………
5.5 Backup Device……………..……………..……………………
5.6 Software Upgrade (Administrator) ……………………………
5.7 System Shutdown (Administrator)……………….……………
6. Setup (Administrator)………………..….………………………...
6.1 Pre-Camera Setup…………………..….………………………...
6.2 Camera Setup……………………………………………………
6.2.1 Video Loss Setup…………………..………………………
6.2.2 Motion Setup……………………….………………………
6.3 Alarm Setup………………….…..…………………….……….
6.4 SEQ Display Setup………………………………………………
6.5 Scheduled Record Setup……………..…….………….…………
6.6 HDD Setup………………………………………………………
6.6.1 HDD Format/Clear………………..……………………….
6.6.2 Advanced HDD Setup……………..……………………….
6.7 Password Setup……………………………..…………………..
6.8 System Setup…………...………………………………………
6.9 RS-232/422/485 Setup…………..…………………….………..
6.10 Network Setup……………..…………………………………..
7
7
9
9
12
14
15
15
17
21
22
23
23
25
27
28
29
29
31
32
35
36
37
38
40
42
44
47
50
52
55
57
60
62
66
67
70

- 6 -
6
.
10.1
E
-
mail
Setup
……………..………………………………..
6.10.2 FTP Setup……………..…………………………………..
6.10.3 3G Modem Setup(Not Supported Yet) ..…………………
6.10.4 Advanced Network Setup……………..…………………
7. PTZ Control……………………….………………………………
8. Search/Playback/Archive (Administrator/Supervisor) ………....
8.1 Search By Time……………………………………….…………
8.2 Search By Event / Log Display………………………….………
8.3 Smart Search………………………..………….……….………
8.4 Search Archived Files………………………….……….………
8.5 POS Search…………………………………….……….………
8.6 Playback/Archive For Search By Time………….….….………
8.7 Playback/Archive For Search By Event…………………………
8.8 Playback/Archive For Smart Search……………………………
8.9 Playback For Archived Files……………………………………
8.10 Playback/Archive For POS Search……………………………
9. Remote Access …………………………………………………..…
9.1 PC Remote Access…………………………………….…………
9.2 PDA/Mobile Phone Remote Access…………………….………
Appendix A – Specifications
Appendix B – Time Zone Table
Appendix C – Keyboard Control Protocol
Appendix D – MS-Windows Utilities
Appendix E – GPS Function in Remote Software with Google Earth
Appendix F – Protocol Converter for Multiple POS
7
3
74
75
76
79
81
82
83
85
88
89
91
95
95
96
96
97
97
107
109
111
113
115
119
123

- 7 -
1. Pro uct Overview
The HD-SDI hybrid digital video/audio recorders are designed for use within a
surveillance system and are a combination of a hard disk recorder, a video multiplexer,
and a web server. To achieve the highest inter-connectivity and inter-operability,
this series of digital video/audio recorders are all based on industry-leading front-end
to back-end surveillance infrastructure. With state-of-the-art system architecture,
powerful hardware compression/decompression engine, and intelligent recording
algorithms, sixfold operation can be easily achieved without sacrificing the increasing
demands of functionality, performance, reliability, and availability in the surveillance
industry.
1.1 Features
2 HD-SDI and 14 analog, or 4 HD-SDI and 8 analog cameras can be connected
H.264 High Profile video compression/decompression with configurable quality
Hardware ADPCM audio compression/decompression
Real sixfold operation - simultaneous record, live, playback, backup, control, &
remote access
Record capabilities –
HD-SDI: 2+14 model: up to 1080p 25 or 720p 60/50,
4+8 model: up to 1080p 40 or 720p 90.
Full-D1: 2+14 model: up to 210 (NTSC) / 175 (PAL) IPS,
4+8 model: up to 120 (NTSC) / 100 (PAL) IPS.
Half-D1: 2+14 model: up to 420 (NTSC) / 350 (PAL) IPS,
4+8 model: up to 240 (NTSC) / 200 (PAL) IPS.
CIF: 2+14 model: up to 420 (NTSC) / 350 (PAL) IPS,
4+8 model: up to 240 (NTSC) / 200 (PAL) IPS.
Playback capabilities –
HD-SDI: 2+14 model: up to 1080p 25 or 720p 60/50,
4+8 model: up to 1080p 40 or 720p 90.
Full-D1: 2+14 model: up to 210 (NTSC) / 175 (PAL) IPS,
4+8 model: up to 120 (NTSC) / 100 (PAL) IPS.
Half-D1: 2+14 model: up to 420 (NTSC) / 350 (PAL) IPS,
4+8 model: up to 240 (NTSC) / 200 (PAL) IPS.
CIF: 2+14 model: up to 420 (NTSC) / 350 (PAL) IPS,
4+8 model: up to 240 (NTSC) / 200 (PAL) IPS.
Realtime live display, 30 (NTSC) / 25 (PAL) IPS, for each channel
Support HDMI output, VGA output, and TV output
Event recording, time-lapse recording or both
Playback search by time or event (alarm, motion, & video loss)
Smart search & playback
Versatile display formats
Digital zoom, X2 & X4
Intelligent motion detection with programmable area and sensitivity
Support privacy mask
Powerful alarm processor with configurable triggering conditions and reactions
Up to five hard disk drives with storage > 2TB/HDD

- 8 -
eSATA extension for external hard disk drives
SupportAdvanced format HDD developed by Western Digital
Video/audio backup to USB2.0 storage devices, including pen drive, DVD+RW,
DVD+R, and DVD-R
Internal DVD Models: Video/audio backup to internal DVD, including
DVD+RW, DVD+R, and DVD-R
Ethernet interface for remote access through web browser or proprietary remote
software, remote alarm notification, FTP video/audio storage, remote setup, and
remote software upgrade
Free DDNS server
1 I.E./Firefox software for multiple DVRs
PTZ control capabilities & RS-422/RS-485 keyboard control capabilities
Multi-lingual support
Multi-level password and authentication key protection to ensure high degree of
security
Streaming video for mobile phone or PDA, no Apps required
N-Streaming internet/intranet remote access
Free iPhone/iPad/Android software app.
GPS support
POS support
Support mouse operation

- 9 -
2. Panels an Remote Controller
2.1 Front Panel
1. DVD Writer (optional)
Used for backup purpose if installed. If DVD is installed, it must be
connected to SATA#6 connector.
2. USB Mouse Connector
Connect to USB 2.0 compatible mouse. Please note that mouse button
clicks may be lost sometimes due to the limitation of the main chip used.
3. USB connector
Connect to USB 2.0 compatible device, such as USB 2.0 disk drive,
DVD+RW, USB 3G dongle, etc.
4. LEDs
Indicators for POWER, HDD, and Net.
5. MODE Button
In some dialogs, this button is used as a miscellaneous function key. At
playing, this button is used as “slow backward”.
6. SEQ Button
Press this button to switch to or return from SEQ display mode in main
screen display. In some dialogs, this button is used as a miscellaneous
function key. At playing, this button is used as “slow forward”.
7. CALL Button

- 10 -
Press this button to switch to or return from full screen display of the focus
camera in main screen display. In some dialogs, this button is used as a
miscellaneous function key.
8. SEARCH Button
Press this button to display the search menu in main screen display. In
some dialogs, this button is used as a miscellaneous function key.
9. Remote I/R Sensor
Used to receive signal from I/R remote controller.
10.REC Button
Press this button to force manual recording. To stop manual recording,
press it again.
11.Play/Pause Button ( )
Press this button to play the recorded images, or pause the playback.
12.Stop Button ( )
Press this button to stop the playback.
13.Copy Button ( )
Press this button to copy the playback images to the internal DVD writer or
the storage device connected to the USB port. Press this button again to
stop copying.
14.MENU / ESC Button
Press this button to display the main menu or escape to the upper level
display.
15.PAGE Button
Press this button for page down in multi-split-window displays.
16.Left/Right Buttons (◄,►)
In PTZ control, press these buttons to pan the camera. In the other
screens, press this button to move the cursor or focus window.
17.Up/BS Button (▲/BS)
Press this button to move the cursor or focus window in most
circumstances. In PTZ control, press this button to tilt up the camera. In
text editing mode, this button is used as “backspace” key.
18.Down/DEL Button (▼/DEL)
Press this button to move the cursor or focus window in most
circumstances. In PTZ control, press this button to tilt down the camera.
In text editing mode, this button is used as “del” key.

- 11 -
19.ENTER Button
This button is used as “enter” key in most circumstances. In PTZ control,
this button is used to start/stop the selected PTZ control mode.
20.(Split Windows) +/- Buttons ( )
In split-window display, press these buttons for next/previous split-window
display. In the others, press these buttons to change the contents.

- 12 -
2.2 Back Panel
1. HD-SDI Input Connectors (1-2/4)
Connect HD-SDI cameras to these BNC connectors via RG-6U cables.
The internal 75Ωtermination is always ON.
2. Analog Video Input Connectors (3-16/5-12)
Connect analog cameras to these BNC connectors. The internal 75Ω
termination is always ON.
3. Video Out (CALL, MAIN)
Connect TV monitor to the upper BNC connector for call monitor display
for analog cameras, and connect TV monitor to the lower BNC connector
for main monitor display.
4. Audio In/Out Connector (AUDIO IN 1-8, OUT 1-2)
Connect to Audio In 1-8/Out 1-2 Cable. The cable is as shown below.

- 13 -
5. Audio In Connector (AUDIO IN 9-16)
Connect to Audio In 9-16 Cable.
6. VGA Connector
Connect VGA monitor to the VGA connector for main monitor display.
7. Remote Sensor Connector (optional)
Beside the remote controller sensor on the front panel, the user may
connect an extended remote controller sensor to this connector. Once
this connector is used, the built-in remote controller sensor on the front
panel will have no effect anymore to avoid signal interference.
8. HDMI Connector
Connect HDMI monitor to the HDMI connector for main monitor display.
Please note that audio can also be output from this connector.
9. Ethernet Connector (lower one)
Connect this unit to a 10/100Base-T Ethernet network through this port.
10.eSATA Connector
Connect this port to external SATA storage device for HDD extension.
11.RS-232 Connector
Connect this connector to PTZ camera(s), GPS modem, or POS system.
12.Alarm Input Connectors (ALARM IN 1-16)
Connect these connectors to external devices such as sensors or door
switches.
13.Alarm Output Connectors (ALARM OUT 1-4)
Connect these connectors to 2 Normally Closed (NC) alarm outputs (1-2)
and 2 Normally Open (NO) alarm outputs (3-4).
14.RS-485 Connector
Connect this connector to RS-485 compatible PTZ camera(s) or keyboard.
Please refer to the manuals come with the RS-485 compatible devices for
the correct settings. Please refer to Appendix C for the Keyboard Control
Protocol for the digital video recorder.
15.Power Input (DC 12V IN)
Connect to DC 12V power source.
16.Power Switch (POWER)
Turn the power of this unit on/off.

- 14 -
17.USB Mouse Connector (Reserved)
Connect to USB 2.0 compatible mouse.
2.3 Remote Controller
The remote controller is an optional accessory to ease the user’s operations. You can
do all the operations by the remote controller instead of the buttons on the front panel.
The effective distance is about 10 meters without any obstacle.
Most of the buttons corresponds to one of those buttons on the front panel. Please
refer to the descriptions in Section 2.1. For the other buttons, the descriptions are as
below:
1. Alpha-numeric Buttons (1-9, 0, *, #)
Press these buttons for camera selection in most of the circumstances.
These buttons can also be used to enter text and number in the way
similar to most of the mobile phones.
2. Alarm Reset Button
Press this button to cancel alarm activation, and return the system to the
condition before the alarm was activated.
3. MUTE/NEXT Button
In PTZ control, press this button for the next miscellaneous control. In
the other screens, press this button to mute the audio.
4. X2/GOTO Button
In PTZ control, press this button to move the camera to the preset position.
In full screen display, press this button for Digital Zoom (X2/X4).
5. (Vol/Zoom) +/- Buttons ( / / )
In PTZ control, press these buttons to zoom in/out the camera.

- 15 -
3. Installations
The installations described below should be made by qualified service personnel or
system installers.
3.1 Basic Connections
Please refer to the following diagram for the connections.
Please make sure to set the NTSC/PAL Selector Switch on the main board
according to the local TV system for the digital video/audio recorder to work
correctly.
Cameras
Connect the camera video input connectors to the video outputs from system
cameras or other video sources via coaxial cables. Please make sure to use
RG-6U or better cable to connect to HD-SDI cameras.
Main monitor
Connect the main monitor output connector (BNC/VGA/HDMI) to a surveillance
TV/VGA monitor. The TV/VGA monitor displays selected live or recorded
cameras in any available split window format.
Hard disk drive(s) / DVD Writer
Make sure to install at least one SATA hard disk drive (Max. storage size >
2TB/HDD) inside the DVR. The steps are as below:
1. Power off the machine, and then use a screwdriver to uncover it.
2. Use a screwdriver to fix the SATA HDDs (and internal DVD writer), and

- 16 -
connect the cables as shown.
3. Cover the machine.
Note: Each of the HDDs must be formatted before it can be used to record
video/audio. Please refer to Section 6.6.1 HDD Format/Clear to
format the HDDs.
Note: If DVD is installed, it must be connected to SATA#6 connector.
Power
Connect DC 12V power source to DC 12V Input.

- 17 -
3.2 Optional Connections
Audio inputs
Connect the Audio In/Out Connector to a Audio In/Out Cable, and then
connect the audio input connectors of the cable to the audio line-outs from system
cameras or other audio sources. Please make sure to associate the audio inputs
with the cameras in Camera Setup as described in Section 6.2 accordingly.
Audio output
Connect the Audio In/Out Connector to a Audio In/Out Cable, and then
connect the audio output connectors of the cable to the audio line-ins from
speakers. The user may also use HDMI monitor to output audio.
Alarm inputs
Connect the alarm inputs to NC and/or NO type of alarm signals. Please make
sure to setup the alarm configurations in Alarm Setup as described in Section 6.3
accordingly.
Alarm outputs
Connect the alarm outputs 1-2 to NC type of alarm signals, alarm outputs 3-4 to
NO type of alarm signals.
Ethernet
Connect the Ethernet connector to a standard twisted-pair Ethernet cable for
remote access via LAN or internet. Please make sure to setup the related
configurations as described in Section 6.10 Network Setup.
USB 2.0 disk drives, DVD+RW, card reader, etc.
If the user wants to use USB2.0 peripheral device to retrieve important recorded
images and/or audio, please connect it to the USB port connectors.

- 18 -
Call monitor
Connect the call monitor output connector to a surveillance TV monitor. This
monitor displays the full screen images of the analog cameras associated with the
events (alarm or motion) or the images from the installed analog cameras
sequentially according to the SEQ Display Setup (Section 6.4) for call monitor.
PTZ Cameras
Connect the RS-232 connector or the RS-485 connector to PTZ camera(s) via the
appropriate cable. The system supports a variety of different PTZ cameras,
including Pelco D protocol Dome, SamSung SCC-641P, Kalatel Cyber Dome,
Bosch AutoDome, etc. But different PTZ cameras can coexist in a system only
if they support the same protocol. Please make sure to set the PTZ ID of the
camera(s), and setup the camera (Section 6.1), and RS-232 or RS-422/485
(Section 6.9) accordingly.

- 19 -
RS-485 keyboard or Terminal
Connect the RS-485 connector to a RS-485 keyboard controller or VT-100
terminal via the appropriate cables. Please make sure to setup the RS-422/485
configurations as described in Section 6.9 accordingly. Please refer to
Appendix C for the Keyboard Control Protocol for the digital video recorder.
eSATA Hard Disk
Connect the eSATA connector to an eSATA hard disk for HDD extension.
GPS modem
Connect the RS-232 connector to GPS modem via the appropriate cable. The
system supports the GPS modems with NMEA0183 protocol. Please make sure
to setup the RS-232 port (Section 6.9) accordingly.

- 20 -
POS system
Connect the RS-232 connector to POS system via the appropriate cable. The
system supports the POS systems which can be connected to the following
printers – Epson-TM200, Epson-TMU295, Epson-TMU300, Epson-TMU675,
Epson-TMT882, Epson-RPU420, and Epson-MD332S. Please make sure to
setup the RS-232 port (Section 6.9) accordingly.
Top figure: 1-to-1; bottom figure: RS-232/Multiple, 1-to-many
