IntesisBox Modbus Server-FC330A User manual

IntesisBox
®
Modbus Server – FC330A
Doc. Rev.
2
Installation Manual
URL
email
tel
http:/
/www.intesis.com
[email protected]
[phone]
1 / 5
This information is subject to change without notice.
•
IntesisBox must be installed by accredited electrician or similar technical personnel, following all the safety instructions
given here, and in accordance always with the country legislation for installation of electric equipment.
•IntesisBox can not be installed outdoors or exposed to direct solar radiation, water, high relative humidity or dust.
•IntesisBox must only be installed in a restricted access location
•In case of wall mount, fix firmly IntesisBox on a not vibrating surface following the instructions below.
•In case of DIN rail mount fix IntesisBox properly to the DIN rail following the instructions below.
•Mounting on DIN rail inside a metallic cabinet properly connected to earth is recommended.
•Disconnect always power of any wires before manipulating and connecting them to IntesisBox.
•A power supply with an NEC Class 2 or Limited Power Source (LPS) and SELV rated is to be used.
•Respect always the expected polarity of power and communication cables when connecting them to IntesisBox.
•Supply always a correct voltage to power IntesisBox, see details of voltage range admitted by the device in the technical
characteristics below.
•This device was designed for installation in an enclosure. To avoid electrostatic discharge to the unit in environments with
static levels above 4 kV precautions should be taken when the device is mounted outside an enclosure. When working in
an enclosure (ex. making adjustments, setting switches etc.) typical anti-static precautions should be observed before
touching the unit
Safety Instructions
WARNIN
Follow carefully this safety and installation instructions. Improper work may lead to serious harmful for your
health and also may damage seriously the IntesisBox and/or any other equipment connected to it.
Use the software LinkBoxMB to configure IntesisBox, follow the instructions of the user's manual for more
details.
See instructions to download and install the latest version of LinkBoxMB and
the user's manual at
http://www.intesis.com/down/mb/linkboxmb.html
Configuration and setup
•Disconnect from mains the power supply before connecting it to IntesisBox.
•Disconnect power of any bus or communication cable before connecting it to IntesisBox.
•Mount IntesisBox on the wall or DIN rail following the instruction given below, respecting the safety
instructions given above.
•Connect a NEC Class 2 or Limited Power Source (LPS) and SELV rated power supply to IntesisBox,
respect the polarity if DC power or Line and Neutral if AC power. Apply always a voltage within the range
admitted by IntesisBox and of enough power (see technical characteristics).
•Circuit-breaker must be used before the power supply. Rating 250V-6A
•Connect the communication cables to IntesisBox, see details on the user's manual.
•Power IntesisBox and the rest of devices connected to it.
Installation instructions

IntesisBox
®
Modbus Server – FC330A
Doc. Rev.
2
Installation Manual
URL
email
tel
http:/
/www.intesis.com
[email protected]
[phone]
2 / 5
This information is subject to change without notice.
IntesisBox
®
www.intesis.com
61 mm
100 mm
Ø 3 mm
1. Separate the fixing clips in the bottom of the box, pushing them to the outside until hear the "click" which
indicates that now the clips are in position for wall mount, see in the figure below.
2. Use the holes of the clips to fix the box in the wall with screws. Use the template below for the wall holes.
With the clips of the box in their original position, insert first the box in the upper edge of the DIN rail and later insert
the box in the down part of the rail using a small screwdriver and following the steps in the figure below.
Clips in their original position, for DIN rail
mount Clips in position for wall mount
DIN
Rail
1
2
3
Top view of the box
DIN rail mount
Side view of the box
Botton view of the box
Wall mount

IntesisBox
®
Modbus Server – FC330A
Doc. Rev.
2
Installation Manual
URL
email
tel
http:/
/www.intesis.com
[email protected]
[phone]
3 / 5
This information is subject to change without notice.
Connections
________________________________________________________________________________________
Notes:
1. Must use NEC Class 2 or Limited Power Source (LPS) and SELV rated power supply.
If using DC power supply:
•Respect polarity applied of terminals (+) and (-). Be sure the voltage applied is within the range admitted (9 to 30 Vdc).
The power supply can be connected to earth but only through the negative terminal, never through the positive terminal.
If using AC power supply:
•Make sure the voltage applied is of the value admitted (24 Vac). Do not connect any of the terminals of the AC power
supply to earth, and make sure the same power supply is not supplying any other device.
2. Modbus connection. Only one type of modbus connection can be used simultaneously, Modbus TCP, Modbus RTU EIA485, or
Modbus RTU EIA232, the type of Modbus connection to use must be selected within the configuration software LinkBoxMB.
Modbus TCP connection: This connection with the Modbus TCP master device can be done directly using a ethernet
CAT5 crossover cable, or through the LAN of the building, in this case use a ethernet CAT5 straigh cable to connect to a
switch or hub of the LAN, check with the network administrator that the TCP traffic and the port used (502 by default) are
allowed through all the LAN path used.
Modbus RTU EIA485 connection: Connect the EIA485 bus to the connector Modbus RTU EIA485 of IntesisBox. Respect
the polarity. Remember the characteristics of the standard EIA485 bus: maximum distance of 1200 meters, maximum 32
devices connected to the bus, and in each end of the bus it must be a termination resistor of 120 ohms. IntesisBox has an
internal bus biasing circuit that incorporates the termination resistor, if you install IntesisBox in one of the ends of the bus
then do not install an additional termination resistor in that end.
Modbus RTU EIA232 connection: Connect the serial cable EIA232 coming from the Modbus RTU master to the connector
Modbus RTU EIA232 of IntesisBox, this is a DB9 male (DTE) connector in which only the lines TX, RX and GND are
used, see details of the pinout in the user's manual. Respect the maximum distance of 15 meters in this serial line
EIA232.
3. Connection with the FC330A panel: Connect the serial cable EIA232 coming from the panel to the connector FC330A EIA232 of
IntesisBox, this is a DB9 male (DTE) connector in which only the lines TX, RX and GND are used. See details of this connection in
the user's manual. Respect the maximum distance of 15 meters in this serial line EIA232.
4. Use the software LinkBoxMB to configure IntesisBox. See the user's manual for details.
Console cable 1.8 m.
DB9 Female - DB9 Male
standard. Supplied.
Modbus RTU
master EIA232
See Note 2
LinkBoxMB
Only for
configuration
See Note 4
Power
See Note 1
PC Console
- +
IntesisBox
®
www.intesis.com
EIA232
EIA485
- +
Modbus RTU
FC330A
Modbus RTU
master EIA485
See Note 2
EIA232
Modbus TCP
master
See Note 2
Ethernet
RJ45
Ethernet
RJ45
FC330A
Panel
See Note 3
CMN 24Vac
9 - 30Vdc
Max. 25 mA
24Vac
Max. 27mA
50-60Hz

IntesisBox
®
Modbus Server – FC330A
Doc. Rev.
2
Installation Manual
URL
email
tel
http:/
/www.intesis.com
[email protected]
[phone]
4 / 5
This information is subject to change without notice.
Enclosure Plastic, type PC (UL 94 V-0).
Dimensions: 07mm x 05mm x 58mm.
Colour Light Grey. RAL 7035.
Power
9 to 30Vdc +/- 0%, Max.: 25mA.
24Vac +/- 0% 50-60Hz, Max.: 27mA
Must use a NEC Class 2 or Limited Power Source (LPS) and SELV
rated power supply.
Plug-in terminal block for power connection (2 poles).
Terminal wiring
(for power supply
and low-voltage
signals)
Per terminal: solid wires or stranded wires (twisted or with ferrule)
core: 0.5mm
2
… 2.5mm
2
2 cores: 0.5mm
2
… .5mm
2
3 cores: not permitted
Mounting Wall.
DIN rail EN607 5 TH35.
Modbus TCP port x Ethernet 0Base-T RJ45.
Modbus RTU ports x EIA232. DB9 male connector (DTE). SELV
x EIA485. Plug-in terminal bloc (2 poles). SELV
FC330A port x EIA232. DB9 male connector (DTE). SELV
LED indicators
x Power.
2 x FC330A port activity (Tx, Rx).
2 x Modbus RTU port activity (Tx, Rx).
2 x Ethernet port link and activity (LNK, ACT).
Console port EIA232. DB9 female connector (DCE). SELV
Configuration Via console port.
Firmware Allows upgrades via console port.
Operational
temperature 0°C to +70°C
Operational
humidity 5% to 95%, non condensing
Protection IP20 (IEC60529).
RoHS compliance Compliant with RoHS directive (2002/95/CE).
Norms and
standards
CE conformity to EMC directive (2004/ 08/EC) and Low-voltage
directive (2006/95/EC)
EN 6 000-6-2
EN 6 000-6-3
EN 60950-
EN 5049 -3
1
Standard cable DB9male-DB9female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device. The configuration software, compatible with Windows
®
operating systems, is also
supplied.
Technical characteristics

IntesisBox
®
Modbus Server – FC330A
Doc. Rev.
2
Installation Manual
URL
email
tel
http:/
/www.intesis.com
[email protected]
[phone]
5 / 5
This information is subject to change without notice.
Dimensions
External dimensions.
Free space recommended to install the device, with spacing enough for external connections.
5 mm
30 mm
00 mm
Power
+
Ethernet port
07 mm
05 mm
58 mm
Console
port
Modbus RTU
ports
FC330A
port
