Intex Marketing Krystal Clean Poolwater 6110 User manual

KRYSTAL CLEAN POOLWATER™ LOW-SALT AUTOMATIC
SALTWATER SYSTEM MODEL 6110
CONTROLS BACTERIA AND ALGAE in Storable Swimming pool Waters. DOMESTIC. A
Maximum of 55,000 L (14,530 gal) of water can be treated with one Krystal Clean Poolwater™
Low-Salt Automatic Saltwater System Model 6110 unit. Maximum output of hypochlorous acid
equivalent to 0.16kg (0.35 lb) of free available chlorine per day. For swimming pools, 1.0-3.0 ppm
of free available chlorine must be maintained.
READ THE LABEL AND OWNER’S MANUAL BEFORE USING. KEEP OUT OF REACH OF
CHILDREN. REGISTRATION NO.28720 PEST CONTROL PRODUCTS ACT.
Intex Trading Ltd., 9th floor Dah Sing Financial Center, 108 Gloucester
Road, Wanchai, Hong Kong
The Canadian Group, 430 Signet Drive Suite A, Toronto, Ontario M9L2T6, Canada Tel: [phone]
WARNING: Operating Krystal Clean Poolwater™ Low-Salt Automatic Saltwater
System Model 6110 without water flow through the cell can cause a build up of flammable gases
which can result in FIRE OR EXPLOSION.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
CONTROL UNIT WARNING LABEL (CANADA)
2015-6332
2016-02-09

Children can fall into bucket
and drown. Keep children
away from bucket with even
a small amount of liquid.
WARNING
BUCKET LABEL (CANADA)
SIZE: 180mm x 70mm
DATE: 07/11/2007

WARNING:
RISK OF ELECTRIC SHOCK.
CONNECT ONLY TO GROUNDING
TYPE RECEPTACLE PROTECTED
BY A CLASS A GROUND FAULT
CIRCUIT INTERRUPTER (GFCI).
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
PLUG WARNING LABEL (CANADA)

KRYSTAL CLEAN POOLWATER™
LOW-SALT AUTOMATIC SALTWATER
SYSTEM MODEL 6110
110 – 120 V~, 60 Hz, 1.6 A THERMALLY
PROTECTED WEATHERPROOF
ENCLOSURE CSA ENCLOSURE 3
DOUBLE INSULATED AND
GROUNDED FOR USE WITH
STORABLE SWIMMING POOLS ONLY.
CAUTION
FOR CONTINUED PROTECTION
AGAINST POSSIBLE ELECTRIC SHOCK,
USE ONLY IDENTICAL REPLACEMENT
PARTS WHEN SERVICING.
IMPORTANT
READ THE LABEL AND OWNER’S
MANUAL BEFORE USING.
6110 POOLWATER SYSTEM (CANADA)
SIZE: 150mm x 100mm
07/11/2007
©2007 Intex Marketing Ltd. - Intex Trading Ltd. - Intex Recreation Corp. All rights reserved.
®™ Trademarks used in some countries of the world under license from Intex Marketing Ltd. to Intex
Trading Ltd. and Intex Recreation Corp., P.O. Box 1440, Long Beach CA 90801.
Made in China
CONFORMS TO
UL STD. 1081
CERTIFIED TO
CSA STD. C22.2
No. 108-01
3077995
US C
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
SAFETY WARNING LABEL (CANADA)

111
IMPORTANT
SAFETY RULES
Read, Understand, and Follow all Instructions Carefully before Installing and using
this Product.
CD
OWNER’S MANUAL
Krystal Clean Poolwater™
Low-Salt Automatic Saltwater System
Model 6110
To find out more about additional Intex products, please visit our website.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time
111CD-R0-0807
Page 1/ 29

TABLE OF CONTENTS
Warnings............................................................................... 3-4
Parts List & Reference......................................................... 5-7
Product Information & Specifications................................ 8
Set Up Instructions.............................................................. 9-11
Salt and Pool Water Volumes.............................................. 12-13
Operating Instructions......................................................... 14-18
Intex Pools Operating Time Table....................................... 15-16
Non-Intex Pools Operating Time Table............................... 16
Alarms................................................................................... 19-21
Maintenance........................................................................ 22-24
Long Term Storage............................................................... 23
INTEX 3-Way Test Strips...................................................... 23
Pool Maintenance and Chemical Definitions..................... 24
Troubleshooting Guide........................................................ 25
General Aquatic Safety........................................................ 26
Limited Warranty.................................................................. 27
Pool Safety Sign................................................................... 28
Intex Service Center Locations........................................... 29
111
CD
SAVE THESE INSTRUCTIONS
Page 2/ 29

SAFETY RULES
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
CAUTION
This product is for use with storable pools only. Do not use with permanently-installed
pools. A storable pool is constructed so that it is capable of being readily disassembled
for storage and reassembled to its original integrity. A permanently-installed pool is
constructed in or on the ground or in a building such that it cannot be readily
disassembled for storage.
These product warnings, instructions and safety rules provided with the product represent
some common risks of water recreation devices and do not cover all instances of risk and
danger. Please use common sense and good judgement when enjoying any water activity.
WARNINGCAUTION
•To reduce the risk of injury, do not permit children to use this product. Always
supervise children and those with disabilities.
•Risk of electric shock. Connect this product only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI). Contact a qualified electrician
if you cannot verify that the receptacle is protected by a GFCI.
•Do not bury electrical cord. Locate cord where it will not be damaged by lawn
mowers, hedge trimmers, and other equipment.
•To reduce the risk of electric shock, replace damaged cord immediately. Use a
qualified electrician to replace the cord.
•To reduce the risk of electric shock, do not use extension cords, timers, plug
adaptors or converter plugs to connect unit to electric supply; provide a properly
located outlet.
•Assembly and disassembly by adults only.
•Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI
since the ALCI will not protect people.
• Position this product away from pool to prevent a child from climbing on pump to
access the pool.
•Children must stay away from this product and electrical cord(s).
•Do not operate this product when pool is occupied.
•Never use the pool if indicated chlorine level is more than 3 ppm.
•Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
•Operating this product without water flowing through the system can cause a build
up of flammable gases which can result in FIRE OR EXPLOSION.
•This product is intended to be used only for the purposes described in the manual!
•Follow all aspects of the local and National Electrical Code(s) when installing the
Krystal Clean Poolwater-Low-Salt Automatic Saltwater System Model 6110.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN
PROPERTY DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR
OTHER SERIOUS INJURY OR DEATH.
SAVE THESE INSTRUCTIONS
Page 3/ 29

KRYSTAL CLEAN POOLWATER™ LOW-SALT AUTOMATIC
SALTWATER SYSTEM MODEL 6110
110 – 120 V~, 60 Hz, 1.6 A
THERMALLY PROTECTED
WEATHERPROOF ENCLOSURE
CSA ENCLOSURE 3
DOUBLE INSULATED AND GROUNDED
FOR USE WITH STORABLE SWIMMING POOLS ONLY.
CAUTION
FOR CONTINUED PROTECTION AGAINST POSSIBLE ELECTRIC SHOCK,
USE ONLY IDENTICAL REPLACEMENT PARTS WHEN SERVICING.
IMPORTANT
READ THE LABEL AND OWNER’S MANUAL BEFORE USING.
KRYSTAL CLEAN POOLWATER™ LOW-SALT AUTOMATIC
SALTWATER SYSTEM MODEL 6110
CONTROLS BACTERIA AND ALGAE in Storable Swimming pool Waters.
DOMESTIC.
A Maximum of 55,000 L (14,530 gal) of water can be treated with one Krystal Clean
Poolwater™ Low-Salt Automatic Saltwater System Model 6110 unit.
Maximum output of hypochlorous acid equivalent to 0.16 kg (0.35 lb) of free available
chlorine per day.
For swimming pools, 1.0-3.0 ppm of free available chlorine must be maintained.
READ THE LABEL AND OWNER’S MANUAL BEFORE USING.
KEEP OUT OF REACH OF CHILDREN.
REGISTRATION NO. 28720 PEST CONTROL PRODUCTS ACT.
Intex Trading Ltd., 9th floor Dah Sing Financial Center, 108 Gloucester Road, Wanchai,
Hong Kong
The Canadian Group, 430 Signet Drive Suite A, Toronto, Ontario M9L2T6, Canada
Tel: [phone]
WARNING
Operating Krystal Clean Poolwater™ Low-Salt Automatic Saltwater System Model 6110
without water flow through the cell can cause a build up of flammable gases which can
result in FIRE OR EXPLOSION.
WARNING
RISK OF ELECTRIC SHOCK.
CONNECT ONLY TO GROUNDING TYPE RECEPTACLE PROTECTED BY A CLASS
A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
111
CD
SAVE THESE INSTRUCTIONS SAVE THESE
Page 4/ 29

PARTS LIST
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
SAVE THESE INSTRUCTIONS
Page 5/ 29

PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.A
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
SAVE THESE INSTRUCTIONS
Page 6/ 29

PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
C
OMMON
FOR
CONNECTI
ON TO
ABOVE
GROUND
POOLS
EQUAL OR
HIGHER
THAN
107CM
(42") IN
HEIGHT
FOR
CONNECTI
ON TO
FILTER
PUMPS
WITH
32MM (1-
1/4")
HOSE SIZE
FOR
CONNECTI
ON TO
FILTER
PUMPS
WITH
38MM (1-
1/2")
HOSE SIZE
1 SALT MEASURING SCOOP 1 10999
2 WATER LEVEL INDICATOR 1 11045
3 TANK COVER (COVER CLIPS & SCREWS INCLUDED) 1 11000
4 COVER CLIP 2 11046
5 SCREW 4 11047
6 SALT CONTAINER NET 1 11048
7 SALT CONTAINER 1 11001
8 SALTWATER TANK FILTER 1 11049
9 SALTWATER TANK 1 11002
10 DRAIN VALVE PLUG 1 10044
11 DRAIN VALVE CAP 1 10649
12 WATER FILTER 1 11003
13 O-RING 211050
14 WATER BAFFLE ADAPTOR A (OPTIONAL) 1 11051
15 ADAPTOR A WITH THREADED COLLAR (OPTIONAL) 2 10849
16 HOSE CLAMP (OPTIONAL) 2 10122
17 HOSE (OPTIONAL) 1 10116
18 CONNECTOR HOSE WITH THREADED FITTINGS (OPTION
A
1 10720
19 DRAIN CONNECTOR 1 10184
PART
NO.
REF. NO.
DESCRIPTION QTY.
SAVE THESE INSTRUCTIONS Page 8
SAVE THESE INSTRUCTIONS
Page 7/ 29

PRODUCT INFORMATION/SPECS
HOW SANITIZER IS GENERATED
Common salt (sodium chloride) is made up of two elements, sodium
and chlorine. During the installation of your Saltwater System, a
measured quantity of salt is dissolved in the saltwater tank with pool
water to make it slightly salty. This salty water is passed through the
saltwater system’s electrolytic cell to produce HOCL which dissolves
instantly in the water. The HOCL destroys bacteria, algae and oxidizes
other organic materials.
Key Saltwater System Parts:
• Power Supply
The power supply converts AC electrical current to a low voltage DC
current. This is required by the electrolytic cell to perform the electrolysis
that creates chlorine.
• Electrolytic Cell (with Titanium Plates)
The electrolytic cell contains bipolar titanium electrodes which perform the
electrolysis and produce liquid sanitizer (HOCL) when energized with DC
electricity. Sanitizer is generated when pool water containing salt passes
through the cell. The sanitizer production can be varied by changing the
number of hours the saltwater system is operating each day. The
saltwater system has a built-in self cleaning cycle that operates every
ten hours without interrupting sanitizer production. The expected life
expectancy of the electrolyte cell is 2,880 hours under normal use
conditions.
• Flow Sensor
The flow sensor protects the electrolytic cell and ensures there is
adequate water flowing through the cell. When the water flow drops below
a minimum flow rate, the electrolytic cell will automatically shut down to
protect the titanium plates. A safety buzzer will sound and the red LED on
the right will light up indicating the problem.
• Electronic Control Station
The electronic control station contains two LED lights and a time control
dial to program the saltwater system operating hours. It also monitors
the different parameters such as salt concentration, water flow and the
electrolytic cell activity. If any deviation from the norm occurs then a
buzzer will sound and the red LED on the right will light up indicating the
problem.
PRODUCT SPECIFICATIONS
Power: 110 - 120 Volt
Amperage: 1.6 A
Wattage: 160 W
Maximum Sanitizer Output/hour: 18 grams/hour
Minimum Flow Rate: 1893 litres/hour (500 gallons/hour)
Limited Warranty: 1 Year (see “Limited Warranty”)
SAVE THESE INSTRUCTIONS
Page 8/ 29

SET-UP INSTRUCTIONS
IMPORTANTIMPORTANT
• The saltwater system must be installed as the last piece of pool
equipment in the water return line to the pool as displayed in Fig. 6.
This location extends the life of the titanium plates.
• Disassemble the heater and accessories within the circulation line
before use.
1. Assemble the above-ground-pool (AGP) and its filter pump per
installation instructions.
2. Remove the saltwater system and it’s
accessories from the packaging.
3. Lift up the saltwater tank from the
position it was stored in. See Fig. 1.
4. Flip the saltwater tank over. Press it
downward onto the base as shown.
Make sure the tank is securely
connected to the base. See Fig. 2.
5. In a clockwise motion screw the salt
container (7) to the underneath of
tank cover (3). See Fig. 3.
6. Attach the cover to the saltwater tank.
Lock the cover clips (4) on the handle
of the tank. See Fig. 4.
7. Connect the hose to the saltwater
pool system inlet. For installation: see
page 9 for 32mm (1-1/4") hose and page 10
for 38mm (1-1/2") hose connections.
SAVE THESE INSTRUCTIONS
Page 9/ 29

AVE THESE INSTRUCTIONS Page 10
For connection to filter pumps with 32mm (1-1/4”) hose size:
1. If your above-ground-pool is filled up with water, unscrew the strainer
grids from the strainer connectors and insert the black hat-like plugs
into the strainer connectors to prevent water from flowing out of pool.
Go to step 2 directly if your pool is empty.
2. If your above ground pool is equal
or higher than 107cm (42") in height,
insert the water baffle adaptor A (14)
into the saltwater system outlet as
shown in Fig. 5. Go to step 3 directly
if your pool is lower than 107cm (42")
in height.
3. Connect the adaptors A (15) to the
saltwater system as shown in Fig. 6.
Tighten securely.
NOTE: Make sure the LED lights on the saltwater system are facing out
from the pool during the installation as shown in Fig. 6.
4. Disconnect the water return (to the pool) hose from the filter pump
connection, and connect it to the adaptor A (15) on the saltwater
system outlet with a hose clamp. See Fig. 6.
5. Connect connector hose (17) to the filter pump outlet (lower connection)
and saltwater system inlet with hose clamps. Tighten securely.
6. Return strainer grids to strainer connectors inside pool after removing
black hat-like plugs that prevented water from flowing out of the pool.
Fig (6)
Fig (5)
SET-UP INSTRUCTION (continued)
SWIMMING POOL
FILTER PUMP
NOTE: Remove the strainer at the pool inlet to allow the maximum flow rate of the
water to the pool.
111
SAVE THESE INSTRUCTIONS
Page 10/ 29

SAVE THESE INSTRUCTIONS Page 11
For connection to filter pumps with 38mm (1-1/2”) hose size:
Do not use adapter A (15)
1. If your above-ground-pool is filled with water, close the plunger valves
before saltwater system installation. Go to step 2 directly if your pool is
empty.
2. If your above ground pool is equal or
higher than 107cm (42") in height,
insert the water baffle adaptor A (14)
into the saltwater system outlet as
shown in Fig. 5. Go to step 3 directly
if your pool is lower than 107cm (42") in height.
3. Disconnect the water return (to the
pool) hose from the filter pump
connection, and connect it to the
saltwater system outlet. See Fig. 7.
NOTE: Make sure the LED lights on the saltwater system are facing out
from the pool during the installation as shown in Fig. 7.
4. Connect connector hose (18) to the filter pump outlet (lower connection)
and saltwater system inlet. Tighten securely. See Fig. 7.
5. Open plunger valves to allow water to flow.
Fig (7)
SWIMMING POOL
FILTER
PUMP
Fig (5)
NOTE: Remove the strainer at the pool inlet to allow the maximum flow rate of the
water to the pool.
SAVE THESE INSTRUCTIONS
Page 11/ 29

ADDING SALT
SALT & POOL WATER VOLUMESSALT & POOL WATER VOLUMES
Use only Fine Sodium Chloride Salts (table salt type)
Use only fine sodium chloride (NaCl) salt that is at least 99.8% pure. Do not use salt
pellets or crystals. Do not use iodized or yellow (yellow prussiate of soda) colored
salt. The electrolytic cell uses this salt to create the sanitizer. The purer the salt the better
the performance of the electrolytic cell.
Optimum Salt Concentrations
The ideal salt concentration in the saltwater tank is between 30,000-35,000 ppm (parts
per million). A low salt concentration will reduce the efficiency of the saltwater system and
result in low sanitizer production. High salt concentration may damage the power supply
and cause corrosion to pool metal fixtures and accessories. The best way to ensure the
proper salt concentration is to carefully follow these instructions.
How to Add Salt
NOTE: Only add salt for initial use and each time saltwater tank water is replenished.
1. Depress the ON button on the filter pump switch to circulate pool water.
2. Keep the saltwater system “OFF”.
3. In counter-clockwise motion unscrew and lift up the salt measuring scoop (1).
4. Using the salt measuring scoop, measure out four full scoops of salt (total 1kg or 2.2lbs)
into the salt container (7). See Fig. 8.
5. Attach the salt measuring scoop to the cover, turn clockwise and secure in place.
6. Turn the water filling valve counterclockwise to open the valve. Pool water will flow into
the tank.
See Fig. 9.
IMPORTANT
DO NOT add pool chemicals directly to the saltwater tank. This may damage the
cell.
Fig (8)
IMPORTANT
DO NOT try to move the unit by holding the handles on the tank when it is filled with water.
This will cause the salt water to flow out of the tank.
If you have unintentionally moved the unit in this way, please immediately secure the tank
to its right position.
Follow the manual’s instructions to add salt and water as needed.
7. When you see the red indicator on the cover pop up, immediately turn the water filling
valve clockwise to close the valve. The tank should fill in 3-4 minutes. See Fig. 10.
Fig (9)
Fig (10)
SAVE THESE INSTRUCTIONS
Page 12/ 29

OPERATION INSTRUCTIONS
WARNINGARNING
•Risk of electric shock. Connect this product only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI). Contact a qualified electrician
if you cannot verify that the receptacle is protected by a GFCI.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors
or converter plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
•Position this product away from pool to prevent a child from climbing on pump to
access the pool.
•Do not operate this product when pool is occupied.
•Operating this product without water flowing through the system can cause a build
up of flammable gases which can result in FIRE OR EXPLOSION.
Before starting the saltwater system be sure that:
•The entire filtering and saltwater system is connected to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI).
•The filter pump operates several minutes before starting the saltwater system (This
removes air pockets and debris in the water hoses).
•No air is trapped in any of the hoses (Follow the Filter Pump Owner’s manual to
release any trapped air).
1. Adjust the time control dial which is located at the back of the electronic control station
to the suitable level for your pool size. See operation time table. See Fig. 11.
NOTE: The operating time level is already set in the factory if you are purchasing a pool
set.
2. Switch on the unit. The left side green LED on the control panel will light up.
3. The right side green LED light on the control panel will light up about ten minutes after
the salt is thoroughly dissolved and mixed with water, which indicates the saltwater
system has started chlorine production. The built-in timer will now operate for the number
of hours selected at the same time each day.
NOTE: The saltwater system will not operate if the filter pump is not operating.
4. The number of operating hours can be re-adjusted as necessary. Switch off the unit and
adjust the time control dial.
5. The right side green LED light on the control panel will turn off when the cycle has
ended. The system automatically goes into a “Power Saving Mode” and will automatically
turn itself back on in 24 hours to continue its daily chlorine production.
Fig (11)
Level and Operation Time
Level 1 2 3 4 5
Operation Time (Hours) 1 2 4 6 12
SAVE THESE INSTRUCTIONS
Page 13/ 29

INTEX POOLS OPERATING TIME TABLE
This table shows the operating time required for normal use of the Saltwater System with above
ground pools.
Number of
days before
salt and water
Level
replenishment
(Liters) (Gals) (Days)
(Approximate)
INTEX ABOVE GROUND POOLS (AGP)
244cm x 76cm (8' x 30) " 2419 639 1 4
305cm x 76cm (10' x 30) " 3853 1018 1 4
366cm x 76cm (12' x 30) " 5621 1485 1 4
366cm x 91cm (12' x 36) " 6734 1779 2 3
457cm x 84cm (15' x 33) " 9792 2587 2 3
457cm x 91cm (15' x 36) " 10681 2822 2 3
457cm x 107cm (15' x 42) " 12430 3284 2 3
457cm x 122cm (15' x 48) " 14141 3736 3 1
488cm x 107cm (16' x 42) " 14209 3754 3 1
488cm x 122cm (16' x 48) " 16173 4273 3 1
488cm x 132cm (16' x 52) " 17464 4614 3 1
549cm x 107cm (18' x 42) " 18115 4786 3 1
549cm x 122cm (18' x 48) " 20647 5455 3 1
549cm x 132cm (18' x 52) " 22309 5894 3 1
305cm x 76cm (10' x 30) " 4485 1185 1 4
366cm x 76cm (12' x 30) " 6503 1718 1 4
366cm x 91cm (12' x 36) " 7896 2086 2 3
366cm x 107cm (12' x 42) " 9288 2454 2 3
457cm x 91cm (15' x 36) " 12422 3282 2 3
457cm x 107cm (15' x 42) " 14614 3861 3 1
457cm x 122cm (15' x 48) " 16805 4440 3 1
488cm x 122cm (16' x 48) " 19156 5061 3 1
549cm x 122cm (18' x 48) " 24311 6423 4 1
549cm x 132cm (18' x 52) " 26423 6981 4 1
732cm x 132cm (24' x 52) " 47241 12481 5 1
488cm x 122cm (16' x 48) " 19156 5061 3 1
549cm x 132cm (18' x 52) " 26423 6981 4 1
ROUND
METAL
FRAME POOL
ULTRA FRAME™
POOL
Level
Water Capacity
(Calculated at 90%for
Frame Pool
and 80%for Easy Set
& Oval Pool)
Pool Size
EASY SET®
POOL
SAVE THESE INSTRUCTIONS
Page 14/ 29

IIIINTEX POOLS OPERATING TIME TABLE (continued)
This table shows the operating time required for normal use of the Saltwater System with above ground pools.
Number of
days before
salt and water
Level
replenishment
(Liters) (Gals) (Days)
(Approximate)
INTEX ABOVE GROUND POOLS (AGP)
549cm x 274cm x132cm (18' x 9' x 52") 17203 4545 3 1
975cm x 488cm x132cm (32' x 16' x 52") 54368 14364 5 1
549cm x 274cm x132cm (18' x 9' x 52") 17203 4545 3 1
732cm x 366cm x132cm (24' x 12' x 52") 31805 8403 4 1
975cm x 488cm x132cm (32' x 16' x 52") 54368 14364 5 1
488cm x 244cm x107cm (16' x 8' x 42") 7691 2032 2 3
549cm x 305cm x107cm (18' x 10' x 42") 10920 2885 2 3
610cm x 366cm x122cm (20' x 12' x 48") 16628 4393 3 1
732cm x 366cm x122cm (24' x 12' x 48") 20465 5407 3 1
853cm x 366cm x122cm (28' x 12' x 48") 24300 6420 4 1
853cm x 366cm x132cm (28' x 12' x 52") 26211 6925 4 1
220cm x 150cm x 60cm (86-5/8" x 59" x 23-5/8") 1662 439 1 4
260cm x 160cm x 65cm (102-1/2" x 63" x 25-5/8") 2282 603 1 4
300cm x 200cm x 75cm (118" x 78-3/4" x 29-1/2") 3834 1013 1 4
380cm x 220cm x 80cm (149-5/8" x 78-3/4" x 31-1/2") 5197 1373 1 4
450cm x 220cm x 85cm (177-1/4" x 86-5/8" x 33-1/2") 7218 1907 2 3
RECTANGULAR
ULTRA FRAME™
POOL
OVAL FRAME
POOL
SMALL
RECTANGULAR
METAL FRAME
POOL
Level
Water Capacity
(Calculated at 90%for
Frame Pool
and 80%for Easy Set
& Oval Pool)
Pool Size
RECTANGULAR
METAL FRAME POOL
NOTE: The tank may be drained in less than the number of days shown depending on the actual flow rate of
water through the system. The flow rate is dependent on filter-pump size, pool size, filter cartridge condition
(a dirty filter reduces the flow rate considerably) and pool water level. Accordingly, check the volume of
water in the tank on a regular basis. For example, if you are operating the system on level 1 (1 hour of daily
operation), you should check the tank level 4 days after filling and daily after that until empty. If the tank is
draining very slowly (6 days or longer) or too fast (2 days or faster), please see the trouble shooting guide.
NON-INTEX POOLS
Non-Intex Pools Operating Time Table
Number of days
before salt and water
Level replenishment
(Days)
(
A
pp
roximate
)
1500 to 6500 396 to 1717 1 4
6501 to 12500 1717 to 3302 2 3
12501 to 22500 3302 to 5944 3 1
22501 to 32000 5944 to 8454 4 1
32001 to 55000 8454 to 14529 5 1
Level
Pool Capacity
(Liters) (Gals)
SAVE THESE INSTRUCTIONS
Page 15/ 29

OPERATION INSTRUCTIONS (continued)
Minimum Water Level
The water level in the tank may drop to or below the “MIN” line
marked on the inner wall depending on the actual flow rate of water
through the system. The flow rate is dependent on filter-pump size,
pool size, filter cartridge condition (a dirty filter reduces the flow rate
considerably) and pool water level. When the tank cannot be drained
anymore and the water level stopped at or below the “MIN” line,
replenish salt and water by following the manual’s instruction.
PERATION INSTRUCTIONS (continued)
Minimum
Water Level
SAVE THESE INSTRUCTIONS
Page 16/ 29
