Ψυγείο Μίνι Μπαρ
Mini Bar Refrigerator
Owner’s Manual
English/Ελληνικά/ Româna
INV-06FSDMB4
MINI BAR 42 L
Models/Μοντέλα:

1
Dear customer,
Before placing your new refrigerator/freezer into operation please read these operating
instructions carefully. They contain important information for safe use, for installation and for
care of the appliance.
Please keep these operating instructions for future reference. Pass them on to possible new
owners of the appliance.
Notes which are important for your safety or for the proper functioning of the appliance are
stressed with a warning triangle and/or with signal words (Warning!, Caution!, Important! ).
Please observe the following carefully.
Supplementary information regarding operation and practical applications of the appliance
appear after this symbol.
Tips and notes concerning economical and environmentally sound use of the appliance are
marked with the cloverleaf.
The operating instructions contain instructions for the correction of possible malfunctions by
the user in the section “Trouble shooting” . If these instructions should not be sufficient,
contact your local Service Force Center.
Printed on paper manufactured with environmentally sound processes he who thinks
ecologically acts accordingly...

2
Contents
Important Safety Instruction ------------------------------------------------------------page 3
Remove transport packaging-----------------------------------------------------------page 4
Installation ----------------------------------------------------------------------------------page 4
Positioning ----------------------------------------------------------------------------------page 5
Description of the appliance --------------------------------------------------------- page 5
Reversing the door------------------------------------------------------------------------ page 6
Starting up and temperature regulation---------------------------------------------- page 7
Interior Accessories----------------------------------------------------------------------- page 7
Defrosting------------------------------------------------------------------------------------page 8
Cleaning and Care ------------------------------------------------------------------------page 8
Energy Saving Tips------------------------------------------------------------------------page 9
Trouble shooting----------------------------------------------------------------------------page 9
Noises during Operation -----------------------------------------------------------------page 10
Regulations, Standards, Guidelines ---------------------------------------------------page 10
Disposal of the appliance-----------------------------------------------------------------page 10

3
Important safety instructions
These warnings are provided in the interests of your safety. Ensure you fully
understand them before installing or using the appliance.
Your safety is paramount importance. If you are unsure about the meaning of these
warnings contact the Customer Care Department for assistance.
Intended use
The refrigerator is intended for use in the home. It is suitable for the storage of food at low temperature.
If the appliance is used for purposes other than those intended or used incorrectly, no liability can be
accepted by the manufacturer for any damage that may be caused.
Alterations or changes to the refrigerator are not permitted for reasons of safety.
If you use the refrigerator in a commercial application or for purposes other than the cooling of foods,
the manufacturer accepts no liability for any damages that may occur.
Prior to initial start-up
Check the appliance for transport damage. Under no circumstances should a damaged appliance be
plugged in. In the event of damage, please contact your supplier.
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance, a
natural gas with a high level of environmental compatibility, which is nevertheless flammable.
During transportation and installation of the appliance, ensure that none of the components of
the refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
Caution: risk of fire
If the refrigerant circuit should become damaged:
zAvoid open flames and sources of ignition.
zThoroughly ventilate the room in which the appliance is situated.
The instructions shall include the warnings:
WARNING!—Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING!—Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING!—Do not damage the refrigerant circuit.
WARNING!—Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
WARNING!—This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for
their safety
WARNING!—Young children should be supervised to ensure that they do not play with the
appliance
WARNING!—The cord should be neither lengthened nor folded into coil during operation.
Moreover, it is forbidden that cord is kept close onto the compressor at the back of the
refrigerator, the surface temperature of which is quite high when operating. Touching with it
would deactivate the insulation or cause leakage for electricity. Extension cord is not
recommended to use. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING!—When disposing of the appliance, do so only at an authorized waste disposal centre.

4
Do not expose to flame.
WARNING!—Please keep the appliance away from substance, which can cause ignition.
WARNING!--- Before obtaining access to terminals, all supply circuits must be disconnected.
WARNING!--- Please remove the door before you dispose your refrigerator.
WARNING!--- The fridge is only applied with power supply of single phase alternating current of
220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds
the above scope, for safety sake, be sure to apply A.C. Automatic voltage regulator to the fridge.
The fridge must employ a special power socket instead of common one with other electric
appliances. Its plug must match the socket with ground wire.
WARNING!—This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
–catering and similar non-retail applications.DŽ
WARNING!—Do not store explosive substances such as aerosol cans with a flammable propellant
in this appliance..
WARNING! — Keep burning candles,lamps and other item swith naked flames away from the
ppliance so that do not set the appliance on fire.
Safety of children
Packaging (e.g. wraps, polystyrene) can be dangerous for children.
There is a risk of suffocation! Keep packaging material away from children!
Make old appliances unusable prior to disposal. Pull out the mains plug, cut off the mains cable, break
or remove spring or bolt catches, if fitted. By doing this you ensure that children cannot lock themselves
in the appliance when playing (there is risk of suffocation!) or get themselves into other dangerous
situations.
Often children cannot recognize the hazards present in household appliances. It is therefore important
that you ensure adequate supervision and never let children play with the appliance!
Daily Operation
Containers with flammable gases or liquids can leak at low temperatures. There is a risk of an
explosion! Do not store any containers with flammable materials such as spray cans, fire extinguisher
refill cartridges etc in the refrigerator and/or freezer.
Do not operate any electrical appliances in the refrigerator and/or freezer (e.g. electric ice cream
makers, mixers etc.).
Before cleaning the appliance, always switch off the appliance and unplug it, or pull the house fuse or
switch off the circuit breaker.
When unplugging always pull the plug from the mains socket, do not pull on the cable.
In case of malfunction
If a malfunction occurs on the appliance, please look first in the ĀTrouble shootingāsection of these
instructions. If the information given there does not help, please do not perform any further repairs
yourself.
Under no circumstance should you attempt to repair the appliance yourself. Repairs carried out by
inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force
Center.
Remove transport packaging
The appliance and the interior fittings are protected for transportation. Pull off the adhesive tape on the
left and right side of the door. You can remove any remnants of adhesive using white spirit. Remove all
adhesive tape and packing pieces from the interior of the appliance.
Installation
Installation Location

5
Before installing, carefully read the instruction in order to avoid a certain number of problems.
Positioning
Position the appliance away from sources of heat such as stoves, radiators, direct sunlight etc.
Maximum performance and safety are guaranteed by maintaining the correct indoor
temperature for the class of unit concerned, as specified on the rating plate. This application
perform well from N to ST. The Appliance may not work properly if it is left for a longer period at
a temperature above or below the indicated range.
IMPORTANT! -There is a need of good ventilation around the fridge for easy dissipation of heat,
high efficiency of refrigeration and low power consumption. For this purpose, sufficient clear
space should be available around the fridge. It is advisable for there to be 75mm separating the
back of the fridge to the wall, at least 100mm of space at its two sides, height of over 100mm
from its top and a clear space upfront to allow the doors to open 160
e
.
Climate classification Ambient temperature
SN 10~32°C
N 16~32°C
ST 16~38°C
T 16~43°C
Appliances must not be exposed to rain. Sufficient air must be allowed to circulate in the lower
rear section of appliances, as poor air circulation can affect performance. Built-in appliances
should be positioned away from heat sources such as heaters and direct sunlight.
Description of the appliance
1ǃIce Cube Tray
2
ǃ
Temperature Control Knob
3
ǃ
Drip Tray
4
ǃ
Removable Shelf
5
ǃ
Freezer Compartment
6
ǃ
Dairy Rack
7
ǃ
Bottle Rack
8
ǃ
Adjustable Leg

6
Reversing the door
The side at which the door opens can be changed from the right side (as supplied) to the left side, if the
installation site requires.
Tools you will need
1ǃ8mmsocketdriver 2ǃcross-shaped screwdriver
3ǃPutty knife or thin-blade screwdriver
Ř
Š
ş
Ş
ŝ
Ŝ
ś
Ś
ř
1. Remove the upper hinge cap (1).
2. Using a sharp object, pry out the plug buttons(5).
3. Remove the two Phillips screws(2) that connect the upper hinge(3) on the right side of the cabinet
top.
4. Carefully lift the door and place it on a padded surface to prevent it from scratching.
5. Remove the plug(9) and transfer it to the uncovered hole at the right side. Be sure to press the
button firmly into the hole.Remove the two bolts(7) that hold the lower hinge(4) on the right side.
6. Remove the screw-type leveling front leg(8) and transfer it to the right side as shown in the figure
below.
7. Set the door into it's new place making sure the pin enters the bushing at the lower frame
section(hole).
8. Secure the upper hinge(3) previously removed in step 3 on the left side. Make sure the pin enters
the bushing at the upper frame section(hole).
9. Loosely secure the lower left hinge(4) and do not tighten the bolts until the door is in the closed
position and leveled.
10. Insert the plug buttons(5) on the uncovered holes(right side).
11. Replace the upper hinge cap(1).

7
Warning!
When changing the side at which the door opens, the appliance must not be connected to the mains.
Remove plug from the mains beforehand.
Starting up and temperature regulation
Insert the plug of the connection lead into the plug socket with protective earth contact.
The temperature selector knob is located on the side of the freezer compartment.
Setting 0 means:
Turning the temperature control to "0" position stops the cooling cycle, but does not shut off the power
to the refrigerator.
Turning clockwise in direction Refrigerating unit on, the latter then operating automatically. If the unit is
unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting the unit. If you
attempt to restart before this time delay, the refrigerator will not start.
Setting 1 means:
Highest temperature, warmest setting.
Setting 7 (end-stop) means:
Lowest temperature, coldest setting.
Important!
Normally we advise you select setting of 3 or 4, if you want the temperature warmer or colder
please turn the knob to lower or higher setting accordingly.
When you turn the knob to lower which can lead to the more energy efficiency. Otherwise, it
would result the energy-consuming.
Important!
High ambient temperatures (e.g. on hot summer days) and a cold setting on the temperature regulator
(position 6 to 7) can cause the compressor to run continuously or even non-stop!
Reason: when the ambient temperature is high, the compressor must run continuously to maintain the
low temperature in the appliance.
Interior accessories
IMPORTANT!- In order to take full advantage of the storage volume ,the user can store
waterproof foodstuffs on the Drip Tray, such as packed food with heat sealing, etc. But during
the process of manual defrosting, the user had better take the foodstuffs away from the drip
tray.
Tips:
Food in the refrigerator can be covered or packaged, to prevent drying and tainting of other food.
The following are suited for packaging:
Polyethylene airtight bags and wraps,
Plastic containers with lids;
Special plastic covers with elastic,

8
Aluminium foil.
Defrosting
Why defrosting
Water contained in food or getting into air inside the fridge be opening doors may form a layer pf frost
inside. It will weaken the refrigeration when the frost is thick. While it is more than 10mm thick, you
should defrost.
Defrosting in feezer compartment
Defrosting in freezer chamber is operated manually. Before defrosting, take the food out; take the ice
tray out or put it into the fresh food compartment temporarily, then set the knob of the temperature
regulator to position “0”(where the compressor will stop working) and leave the door of the refrigerator
open until ice and frost dissolve thoroughly and accumulation at the drip tray. Wipe off the water with
soft cloth. In the case of speeding up the process of defrosting, you may put a bowl of warm water
(about 50ć) into the freezer chamber, and scrape away the ice and frost with a defrosting spatula. After
doing so, be sure to set the knob of the temperature regulator to the original position.
It is not advisable to heat the freezer chamber directly with hot water or hair dryer while defrosting to
avoid deformation of the inner case.
It is also not advisable to scrape off ice and frost or separate food from the containers which have been
congealed together with the food with sharp tools or wooden bars, so as not to damage the inner
casing.
Warning!
Switching off the appliance.
To switch off the appliance, turn the temperature regulator to position ”0”.
Important!
The fridge should be defrosted at least every one month. During the using process, if the door was
opened frequently or using the appliance in the extreme humidity, we advise the user to defrost every
two weeks. .
If the appliance is not going to be used for an extended period:
Remove all refrigerated packages.
Switch off the appliance by turning the temperature regulator to position Ā0ā.
Remove the mains plug or switch off or disconnect the electricity supply.
Clean thoroughly (see section: Cleaning and Care)
Leave the door open to avoid the build up of odors.
Cleaning and Care
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
The fridge should be cleaned and maintained at least every two months.
Warning!
The appliance may not be connected to the mains during cleaning. Danger of electrical shock! Before
cleaning switch the appliance off and remove the plug from the mains, or switch off or turn out the
circuit breaker or fuse.
Never clean the appliance with a steam cleaner. Moisture could accumulate in electrical components,
danger of electrical shock! Hot vapors can lead to the damage of plastic parts.
The appliance must be dry before it is placed back into service.
Important!
Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice from orange
peel, butyric acid, cleanser that contain acetic acid.
Do not allow such substances to come into contact with appliance parts.
Do not use any abrasive cleansers.
Remove the food from the refrigerator. Store it in a cool place, well covered.
Switch the appliance off and remove the plug from the mains, or switch off or turn out the circuit breaker
or fuse.

9
Clean the appliance and the interior accessories with a cloth and lukewarm water. Commercially
available dish washing detergents may also be used.
After cleaning wipe with fresh water and rub dry.
Accumulation of dust at the condenser increases energy consumption.
For this reason carefully clean the condenser at the back of the appliance once a year with a soft brush
or a vacuum cleaner.
Check the water drain hole on the rear wall of the refrigerator compartment.
Clear a blocked drain hole with the aid of something like soft green peg, be careful not to make any
damage to the cabinet by sharp things.
After everything is dry place appliance back into service.
Energy Saving tips
1. Do not place warm foods into the appliance. Allow warm foods to cool first. Do not install the
appliance near cookers, radiators or other sources of warmth. High ambient temperatures cause
longer, more frequent operation of the compressor
2. In order to make the cooling system work efficiently, please make sure the side plates and back
plate of the product are with some distance from the wall. It is strongly recommended that its
back is 75mm away from the wall, its sides at least have a space of
100mm separately and the height from over its top is not less than 100mm.
3. When the product works, please do not open the door too often or leave the door open any
longer than necessary.
4. Do not set temperature any colder than necessary.
5. The direct cooling refrigerator (with a freezer) needs to be defrosted when necessary. This will
improve the cold transfer and reduce energy consumption.
6. The sketch map shows the right combination of the shelves which can lead to the more energy
efficiency. If users adjust the combination, it would result in the energy-consuming.
7. Store food logically. Do not exceed the storage period specified.
Trouble shooting
Correcting Malfunctions
A malfunction may be caused by only a minor fault that you can rectify yourself using the following
instructions. Do not perform any other work on the appliance if the following information does not
provide assistance in your specific case.
Important!
Repairs to refrigerators/freezers may only be performed by competent service engineers. Improper
repairs can give rise to significant hazards for the user. If your appliance needs repairing, please
contact your specialist dealer or your local Service Force Center.
Symptom Possible Cause Remedy
Appliance is not switched on. Switch on the appliance.
Mains plug is not plugged in or is
loose. Insert mains plug.
Fuse has blown or is defective. Check fuse, replace if necessary.
Appliance does not work.
Socket is defective. Mains malfunctions are to be
corrected by an electrician.
Appliance cools too much. Temperature is set too cold. Turn the temperature regulator
to a warmer setting temporarily.
Temperature is not properly adjusted. Please look in the “initial Start
Up” section.
Door was open for an extended
period. Open the door only as long as necessary.
The food is too warm.
A large quantity of warm food was
placed in the appliance within the last
24 hours.
Turn the temperature regulation
to a colder setting temporarily.
