involight SBL1008 User manual

DMX LED 8PAR 192 System manual
Our DMX LED 8PAR system offers many possibilities to achieve the effects which you want. It is pack-and-go for
DJs, bands, nightclubs and other performers who want a complete LED wash light system. This system includes
PAR-BAR, a four-pedal foot switch, adjustable tripod, packing bag and transport case. Please read the manual
before operation.
A. SPECIFICATION:
1. Weight: 13kgs
2. Size: 1200*2400mm
3. Power input: AC100-240V/50-60HZ
4. Wattage: 160W
5. LEDS: 1536 (512 red, 512 green, 512 blue) 10mm LEDs (192 per light)
6. Beam angle: 30 degree
7. 3 pin female XLR socket and 3 pin male XLR socket
8. Each light height adjustable.
9. RGB control of 8 separate lights
10. Independent positioning of each light
11. four-pedal foot switch: auto run, sound active, freeze, blackout
12. Working place: indoor, temperature: -20 °C~+ 45° C, humidity: 0%-90%.
13．LED display for easier operation.
14. Selectable built-in programs, Auto running, DMX mode, M/S, sound-active mode.
15. 6selectable DMX modes: 2，3, 4, 7, 14, 26 DMX channels mode.
B.OPERATION:

After power on, Press “MODE”button to activate the main menu: Built-in programs mode, Auto running
mode, DMX mode, Slave mode, sound-activited mode.
“SETUP”is to set the relative specification for current mode.
“UP”is to add the value of current specification.
“DOWN”is to decrease the value of current specification.
Built-in programs-- running one of 17 built-in programs
Auto run—running built-in programs one after another in continuous loop.
DMX mode--controlled by DMX controller
Slave mode—the projectors in this mode will be synchronously run with the projectors in master mode
Sound active mode-- running by sound - activated
four-pedal foot switch: auto run, sound active, freeze, blackout
1. built-in programs mode
Press mode until it shows Prxx, you can select 17 different built-in Programs. press“SETUP”and “UP”
“DOWN”buttons to select the programs (from Pr01 to Pr17) and select the desired program values. When it
shows Pr01, press “SETUP”to choose the seven static color.
When it is Pr02 to Pr17, press “SETUP” and “UP” “DOWN”buttons, you can set the values for
flash(FS00-FS99), fading time(Fd00-Fd99), running speed(SP00-SP99).
When it is Pr16 and Pr17, you can set the background color and running color for this effect, switch it from 1-
-r (background color)to 2- -r(running color) by “SETUP”, adjust different colors by “UP” “DOWN”.
2. Auto run mode
You can press “MODE”button to select auto run mode, it shows , then it will run the built-in
programs automatically.
Press “SETUP”, it shows n. 001, then you can adjust the running loops number by “UP” “DOWN”
3. DMX mode
You can control the devices individually via your DMX-controller. Press “MODE”button until it shows
, this means DMX address is 001, you can set the DMX address by “UP”and“DOWN”buttons.
If press “SETUP”button, it will show d-p1 , it means the device is in which DMX mode 1. You can switch
these DMX modes by “UP”and“DOWN”buttons. There are 6 DMX modes.
DMX value as follows:
DMX mode1：d-P1
CH1 CH2 CH3
R G B
0—255 Light
(0 = OFF)
0—255 Light
(0 = OFF)
0—255 Light
(0 = OFF)
DMX mode2：d-P2

CH1 CH2 CH3 CH4
R G B
Master
dimmer
0—255 Light
(0 = OFF)
0—255 Light
(0 = OFF)
0—255 Light
(0 = OFF)
0—255 Light
(0 = OFF)
DMX mode3：d-P3
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12 CH13 CH14
R1+
R2
G1+
G2
B1+
B2
R3+
R4
G3+
G4
B3+
B4
R5+
R6
G5+
G6
B5+
B6
R7+R
8
G7+G
8
B7+B
8flash Master dimmer
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
0—255
Flash
0 = OFF
0-255
Light
0=OFF
DMX mode 4: d-P4
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12 CH13
R G B R G B R G B R G B R
0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255
CH14 CH15 CH16 CH17 CH18 CH19 CH20 CH21 CH22 CH23 CH24 CH25 CH26
G B R G B R G B R G B flash dimming
0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255 0-255
DMX mode5：d-P5
CH1 CH2
NO. DMX
value FUNCTION SPEED
10--9 OFF Value=0 OFF
210--19 red
SPEED
0—255
3 20--29 yellow
4 30--39 green
5 40--49 cyan
6 50--59 blue
7 60--69 purple
8 70--79 white
9 80--89 PROGRAM02

10 90--99 PROGRAM03
11 100--109 PROGRAM04
12 110--119 PROGRAM05
13 120--129 PROGRAM06
14 130--139 PROGRAM07
15 140—149 PROGRAM08
16 150--159 PROGRAM09
17 160--169 PROGRAM10
18 170--179 PROGRAM11
19 180--189 PROGRAM12
20 190--199 PROGRAM13
21 200--209 PROGRAM14
22 210--219 PROGRAM15
23 220--229 PROGRAM16
24 230--239 PROGRAM17
25 240--255 Sound Mode Sensitivity
0--255
DMX mode 6：d-P6
CH1 CH2 CH3 CH4 CH5 CH6 CH7
R G B NO. DMX value FUNCTION SPEED FLASH Master
dimmer
0-255
Light
0=OFF
0-255
Light
0=OFF
0-255
Light
0=OFF
1 0--9 OFF NO USE NO USE
0—255
Light
(0 = OFF)
2 10--19 red
SPEED
0—255
FLASH
0—255
3 20--29 yellow
4 30--39 green
5 40--49 cyan
6 50--59 blue
7 60--69 purple
8 70--79 white
9 80--89 PROGRAM02
10 90--99 PROGRAM03
11 100--109 PROGRAM04
12 110--119 PROGRAM05
13 120--129 PROGRAM06
14 130--139 PROGRAM07
15 140—149 PROGRAM08
16 150--159 PROGRAM09
17 160--169 PROGRAM10
18 170--179 PROGRAM11

19 180--189 PROGRAM12
20 190--199 PROGRAM13
21 200--209 PROGRAM14
22 210--219 PROGRAM15
23 220--229 PROGRAM16
24 230--239 PROGRAM17
25 240--255 SOUND
ACTIVE
Sensitivity
0--255
4. Slave mode
Press “MODE” button to select SlAv to run the slave mode.
5. Sound active mode
Press “MODE” button to select SU31 to be run, now if activated one time, it will run one step, adjust the
sensitivity by “UP” and “DOWN” buttons.
Sensitivity: SU01-SU31
6. Static color mode
Press “MODE” button to select Colr to be run, press “SETUP”, it will show r255, then you can adjust the
colors by “UP”and“DOWN”buttons.
7. 4-Pedal foot switch
Connect the foot switch to the BAR, then you can control the effect easily by your foot.
Auto run—running the effects automatically.
Sound active—running the effects by sound activated.
Freeze—freeze the effect which you are running( if you want to run the unit again, please press auto run or
sound active to activate it).
Blackout—the unit will be off.
