involight LEDMH100 User manual

LEDMH100 MOVING HEAD
1
LEDMH100
USER MANUAL

LEDMH100 MOVING HEAD
2
TABLE OF CONTENTS
INTRODUCTION .................................................................................................................3
MAIN FEATURES.........................................................................................................3
UNPACKING.................................................................................................................3
SAFETY WARNING.............................................................................................................3
PANEL REVIEW ..................................................................................................................4
INSTALLATION AND SETTING...........................................................................................4
1. MULTI-FIXTURES CONNECTION ..........................................................................4
2. LAMP BODY INSTALLATION ..................................................................................5
OPERATION ........................................................................................................................5
1.SET DIPSWITCHES..................................................................................................5
2. DMX CHANNEL SUMMARY....................................................................................6
3. CHANNEL FUNTIONS .............................................................................................6
4. ABOUT EACH CHANNEL ........................................................................................7
MAINTENANCE................................................................................................................. 11
1.TROUBLESHOOTING ............................................................................................ 11
2. CLEANING ............................................................................................................. 11
TECHNICAL SPECIFICATION ..........................................................................................12
APPENDIX.........................................................................................................................12

LEDMH100 MOVING HEAD
3
INTRODUCTION
Thanks for your purchase of our product, mini led moving-head fixture. It can works
under auto mode and sound -active mode with 16 built-in programs. The product has a
long lifespan and low power consumption. It is exquisite and applicable for all kinds of
entertaining occasions. Before you begin, please read instructions carefully. If you meet
with any problem, please contact with your distributor nearby.
MAIN FEATURES
■DMX-512 control, 11 channels
■DMX, AUTO, SOUND-ACTIVE mode
■RGB control with 255 grades
■RGB total dimmer is 0~100%
■Shutter speed is 10flashes/sec ~10secs / flash
■36X1W LED
■PAN scan angle 0~5400
■TILT scan angle 0~2300
UNPACKING
★LEDMH100 MINI LED FIXTURE
★USER MANUAL
SAFETY WARNING
For your convenient and accurate operation, please read following information
carefully.
◆Suitable for indoor use only.
◆Put it in a dry, well -ventilated place in case of short cut caused by erosion of moisture
and rain.
◆Do not install it nearby hot sources in case that rising temperature of lamp damages

LEDMH100 MOVING HEAD
4
itself.
◆Do not barrier vent in order to ventilate well and dissipate in time.
◆Connect the fixture with power source, which has a ground line, and voltage of power
source should accord with rating voltage.
◆If fuse was damaged, change the same type.
◆You can only choose accessories the manufacturer provides when need repairing.
◆Ambient temperature of the lamp should not exceed 40℃
◆If any problem, contact with professional technicians working in our after-sales service
department.
PANEL REVIEW
Press FUN button: Switch to function menu or return to previous menu
Press UP/DOWN: Adjust current activated field. If the four point twinkle, indicating value
has been changed.
Press ENTER: Enter into sub-menu or confirm the current value.
INSTALLATION AND SETTING
1. MULTI-FIXTURES CONNECTION
DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain
connection is where the DATA OUT of one fixture connects to the DATA IN of the next
fixture. The order in which the fixtures are connected is not important and has no effect on
how a controller communicates to each fixture. Use an order that provides for the easiest
and most direct cabling. Connect fixtures using shielded two conductor twisted pair cable
with three pin XLR male to female connectors.

LEDMH100 MOVING HEAD
5
The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive
(S+).
2. LAMP BODY INSTALLATION
Notes: do not install it nearby the curtain or flammable materials.
Only for indoor use.
OPERATION
1.SET DIPSWITCHES
■Each fixture occupies 11 DMX channels.
■DMX 512 signal can control multi-fixtures together, however you must set DMX address of
each lamp first. Different DMX address will lead to different movements.
■You can set DMX address from 1~501 on the multi-function display panel.
■Switch on power supply and after finishing resetting, the panel will show 001,that is to say
DMX address is 1 and the first lamp has been controlled by 1~11channels.In turn the
second fixture has been controlled by 12~22 channels. (When panel shows 001,press
UP button until it shows 012.Then just press ENTER button). In the same way, the third
fixture has been controlled by 23~33 channels and the panel shows023.
■Through this method, you can control multi-fixtures to perform different movements.

LEDMH100 MOVING HEAD
6
2. DMX CHANNEL SUMMARY
3. CHANNEL FUNTIONS
DISPLAY FUNCTION
VALUE 001-501 DMX address (16BT is on, the max value is 501.)
MODE M-DM DMX mode
M-AU AUTO mode
Notes: Only one lamp can be set as Master and the left are
Slaves (Slaves set to DMX mode with DMX address “001”). Do
not connect the Slaves lamp with controller.
M-SO SOUND mode
Notes: Only one lamp can be set as Master and the left are
Slaves (Slaves set to DMX mode with DMX address “001”). Do
not connect the Slaves lamp with controller.
PRCO PR1~8 8 built-in programs
LEDMH1

LEDMH100 MOVING HEAD
7
Pr1-4 means skip
Pr5-8 means fade
SPCO SP01~15 Auto speed SP01: 0.1sec/step, SP15: 10secs/step
r PAN STND Run clockwise as DMX value increases
REV Run anticlockwise as DMX value decreases
R TILT STND Run clockwise as DMX data increase
REV Run anticlockwise as DMX data decreases
r-PT STND CH7: PAN, CH8: TILT, CH10: PAN FINE, CH11: TILT FINE.
REV CH7: PAN, CH8: TILT, CH10: PAN FINE, CH11: TILT FINE.
TEST ALL Check all channels with motors
PAN Check pan channels
TITL Check tilt channels
RED Check red channels
GREEN Check green channels
BLUE Check blue channels
DISP STND Display bites normally
REV Display bytes upside down
REST REST/ON Reset
(Press ENTER button to enter into REST menu and the screen
reads flashing “REST”. Then press UP/DOWN button and the
screen reads flashing “ON”. If to press ENTER again, the light
engine resets again)
16BT ON PAN, TILT is 16 bit, CH10: PAN FINE, CH11: TILT FINE.
OFF PAN, TILT is 8 bit. CH10, CH11 does not exist.
4. ABOUT EACH CHANNEL
■Channel 1:DMX MODE
Ch DMX Function CH2 CH3 CH4 CH5 CH6
CH1
0~24 RGB
Red
0~255
Green
0~255
Blue
0~255
Strobe
Speed
0~255
Dimme
r
0~255
25~49 Built-in program
1
No
function
No
function
No
function
Auto
speed
No
functio
n
50~74 Built-in program
2
75~99 Built-in program
3

LEDMH100 MOVING HEAD
8
100~124 Built-in program
4
125~149 Built-in program
5
150~174 Built-in program
6
175~199 Built-in program
7
200~224 Built-in program
8
225~255 Sound-active
program
No
function
■Channel 2: RED
When CH1 is 0~24
DMX value red
255 carmine
0 0
■Channel 3：GREEN
When CH1 is 0~24
DMX value green
255 bottle green

LEDMH100 MOVING HEAD
9
0 0
■Channel 4:Blue
When CH1 is 0~24
DMX value blue
255 navy blue
0 0
■Channel 5：Strobe
When CH1 is 0~24
DMX value strobe speed
255 slowest
16 fastest
15 nostrobe
0 nostrobe
Notes: CH2~4 decides brightness. When CH2, CH3, CH4 is 0, there is no
brightness.
When CH1 is 25~224:
DMX value AUTO speed
255 slowest

LEDMH100 MOVING HEAD
10
0 fastest
■Channel 6：RGB Dimming
When CH1is 0~24:
DMX value RGB brightness
255 0
0 brightest
■Channel 7: PAN（540°）
NO. DMX value Effect
1 0 Leftmost
2127 Medium
3 255 Rightmost
■Channel 8: TILT（230°）
NO. DMX value Effect
1 0 Bottommost
2127 Medium
3 255 Topmost
■Channel 9：PAN or TILT SPEED
■Channel 10 : PAN FINE (2.4°)
■Channel 11:TILT FINE (2.4°)
Notes: When 16 BT is on, CH10, CH11 exists; otherwise they do not exist.

LEDMH100 MOVING HEAD
11
MAINTENANCE
1.TROUBLESHOOTING
Problem Probable cause(s) Suggested remedy
Fixtures does not
work
No power source Check if power source is on or cord works
well.
Fuse burnt
Cut off power source and change the
same type fuse. If fuse was burnt on end,
it may be the problem of connection; Find
qualified professors to repair.
Reset normally, but
console abnormally
or no response
False or incomplete data
connection
Check, repair or change the data line.
Ensure connection is well and the first
lamp’s single input is connected with the
controller output.
False address setting Check DMX address.
Problem of signal
connector of some
fixtures
Pull out the signal output and input of one
fixture. Then connect both directly. If it
works well, this fixture is proved to be the
failed one. Handle the rest fixtures alike to
check which fixture has problems. If any
problem, please connect the technician.
Signal output does not
match with the pin (pins2
and pins3 has a wrong
sequence)
Toggle the PHASE button on the
controller to reverse the polarity.
2. CLEANING
Though increasing reliability by designing well and we never stop to improve quality to
lengthen lamp’s lifespan. It is still indispensable to maintain it well by certain time in order
to ensure best performance
First , clean fan and vent.
Favorable heat-dissipation and ventilation is vital to lamp’s normal work. So clean the fan
and vent during a certain time to guarantee smooth of wind path. Otherwise dust will
barrier vent, which will affect the performance because of over heat after working for some
time.
Second, lens cleaning and maintenance

LEDMH100 MOVING HEAD
12
To ensure the best effect of lamp, please clean every lean or reflective setting. Use the
soft cotton with some lotion to clean it, but do not damage lens.
Third, check line during a certain time.
Check connecting line, wiring and ground line to ensure safety of using lamp during a
certain time.
Forth, mechanical transmission part maintenance.
Check mechanical transmission part if it has any loose part during a certain time, such as
a strap. Abrasion of mechanical transmission part will affect stability of lamp work. If strap
is loose, you should change it if needed.
TECHNICAL SPECIFICATION
Type-------------------------------------------------------------LEDMH100 MINI LED MOVING-HEAD
LED Number& Voltage------------------------------------------------------------------------36X1W LED
Power------------------------------------------------------------------------------------------------------160W
Voltage-----------------------------------------------------------------------------------------------------220V
Electrical current------------------------------------------------------------------------------------0.7 2 6 A
Total lumens---------------------------------------------------------------------------------------528.15 1m
Max light intensity-------------------------------------------------------------------------------1089 c d
Lamp efficiency----------------------------------------------------------------------------------3.8 lm/w
Optic angle -----------------------------------------------------------------------------------------------230
Dimension-----------------------------------------------------------------------L250XW220XH376 (MM)
Weight------------------------------------------------------------------------------------------------------ 7KG
APPENDIX
Color Total output (Lumens) Efficiency Color index
Red 465 5 21
Green 528 4 -12
Blue 788 5 -50
