IOGear GUC3100 User manual

1
Quick Start Guide
USB 3.0 GigaLinq
USB 3.0 to Gigabit Ethernet Adapter
GUC3100
PART NO. Q1282
www.iogear.com
Guía rápida de inicio
Guide de démarrage rapide
USB 3.0 GigaLinq
Adaptador de USB 3.0 a Gigabit Ethernet
USB 3.0 GigaLinq
Adaptateur USB 3.0 à Gigabit Ethernet

© 2014 IOGEAR®Part No. Q1282
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and Windows are registered
trademarks of Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of their
respective holders. IOGEAR makes no warranty of any kind with regards to the information presented in this document. All
information furnished here is for informational purposes only and is subject to change without notice. IOGEAR assumes no
responsibility for any inaccuracies or errors that may appear in this document.

Package Contents 4
System Requirements 4
Overview 4
Software Installation 5
Hardware Installation 12
FCC Statement 13
CE Statement 13
Limited Warranty 14
Contenu de l’emballage 15
Exigences système 15
Vue d’ensemble 15
Installation du logiciel 16
Installation du matériel 23
Déclaration de la FCC 24
Conformité CE 24
Garantie limitée 25
Contenido del paquete 26
Requisitos del sistema 26
Generalidades 26
Instalación del software 27
Instalación del hardware 34
Declaración de la FCC 35
Cumplimiento con la CE 35
Garantía limitada 36
Contact / Contacto / Coordonnées 37
Table of Content

2
3
1
4
1 x GUC3100 USB 3.0 GigaLinq
1 x Installation CD
1 x Quick Start Guide
1 x Warranty
Package Contents
PC
• Windows Vista®, Windows®7, Windows®8, Windows®8.1
• USB 3.0 port
Mac
• Mac OS®X V10.6 +
• USB 3.0 port
System Requirements
1. USB 3.0 Connector
2. Link LED (green)
3. Activity LED (yellow)
Overview

5
Software Installation
Note: DO NOT connect IOGEAR GUC3100 USB 3.0 GigaLinq to your
computer before completing the driver installation.
*The descriptions of driver installation shown here is an example.
*The actual strings may vary slightly on each operating system.
*The driver version is subject to change without prior notice.
Windows®7 / Windows®8 / Windows®8.1
1. Insert the installation CD into your disc drive.
2. Open Windows folder.
3. Double click the Setup.exe le in the Driver folder to launch the
setup program.

6
4. Wait for the program to install the driver.
5. Click Finish to complete the installation.

7
Mac OS X V10.6 +
1. Insert the installation CD into your disc drive.
2. Open Mac folder.
3. Open the appropriate version.

8
4. Double-click GUC3100.dmg le in the Driver folder on Mac.
5. Double-click AX88179.
6. Double-click AX88179_178A_v1.7.0.pkg

9
7. Click Continue.
8. Click Install and it will restart your computer automatically.

10
9. Click Continue Installation.

11
10. Once installation is completed, you may need to Restart your
computer.
11. You can click System Preferences on the desktop to check if the
installation is complete.

or
1
2
12
Hardware Installation
Note: DO NOT connect IOGEAR GUC3100 USB 3.0 GigaLinq to your
computer before completing the driver installation.
1. Connect IOGEAR GUC3100 to a free USB port on your laptop.
2. Now you can connect your network device, e.g. switch router, DSL/
Cable modem, to the adapter’s LAN port via an Ethernet cable.

13
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential setting. This product generates,
uses, and can radiate radio frequency energy and, if not installed and
used as directed, it may cause harmful interference to radio commu-
nications. Although this product complies with the limits for a Class B
digital device, there is no guarantee that interference will not occur in a
particular installation.
CE Statement
This device has been tested and found to comply with the following
European Union directives: Electromagnetic Capability (2004/108/EC),
Low Voltage (2006/95/EC) and R&TTED (1999/5/EC).

14
Limited Warranty
WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Visit www.iogear.com for more product information
2. Visit www.iogear.com/support for live help and product support
Warranty Information
This product carries a 3 Year Limited Warranty. For the terms and condi-
tions of this warranty, please go to
http://www.iogear.com/support/warranty
Register online at https://www.iogear.com/registration
Important Product Information
Product Model
Serial Number

2
3
1
15
1 x GigaLinq USB 3.0 GUC3100
1 x CD d’installation
1 x Guide de démarrage rapide
1 x Carte de garantie
Contenu de l’emballage
Exigences système
PC
• Windows Vista®, Windows®7, Windows®8, Windows®8.1
• USB 3.0 port
Mac
• Mac OS®X V10.6 +
• USB 3.0 port
Vue d’ensemble
1. Connecteur USB 3.0
2. Voyant DEL de liaison (vert)
3. Voyant DEL d’activité (jaune)

16
Installation du logiciel
Remarque: NE PAS brancher le GigaLinq USB 3.0 GUC3100
IOGEAR à votre ordinateur avant d’installer le pilote.
*Les descriptions de l’installation du pilote montrées servent
d’exemples.
*La séquence réelle peut varier légèrement d’un système
d’exploitation à l’autre.
*La version du pilote est sujette à des changements sans préavis.
Windows®7 / Windows®8 / Windows®8.1
1. Insérez le CD d’installation dans le lecteur CD.
2. Ouvrez un dossier Windows.
3. Cliquez deux fois sur le chier Setup.exe dans le dossier Driver an
de lancer le programme d’installation.

17
4. Attendez que le programme installe le pilote.
5. Cliquez sur Finish (Terminé) pour terminer l’installation.

18
Mac OS X V10.6 +
1. Insérez le CD d’installation dans le lecteur CD.
2. Ouvrez un dossier Mac.
3. Ouvrez la version appropriée.

19
4. Cliquez deux fois sur le chier GUC3100.dmg dans le dossier Driver
sur le Mac.
5. Cliquez deux fois sur AX88179.
6. Cliquez deux fois sur AX88179_178A_v1.7.0.pkg.

20
7. Cliquez sur Continue.
8. Cliquez sur Install (Installer) et l’ordinateur redémarrera
automatiquement.
