IOGear MiniView GCS712U User manual

Installation Manual (GCS712U)
®
MiniView™ Micro USB Audio
2 Port USB KVM Switch with Built-in KVM Cables

©2004 IOGEAR®. All Rights Reserved. PKG-M0124
IOGEAR®,the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR®,
Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered
trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered
trademarks of Apple Computer, Inc. IOGEAR®makes no warranty of any kind with regards to the
information presented in this document. All information furnished here is for informational purposes
only and is subject to change without notice. IOGEAR®, Inc. assumes no responsibility for any
inaccuracies or errors that may appear in this document.

Thank you for purchasing one of the most feature-rich keyboard, video, and mouse switches
on the market. IOGEAR®’s MiniView™ Micro USB Audio switches are first-rate connectivity
accessories designed to help reduce the frustration of managing multiple computer systems.
With the MiniView™ Micro USB Audio by IOGEAR®, you can access two computers from a
single console (keyboard, mouse and monitor), and allow them share multimedia speakers.
MiniView™ Micro USB Audio allows you to change ports easily by entering Hot Key
combinations from the keyboard. Setup is fast and easy; plugging cables into their
appropriate ports is all that is entailed.
We hope you enjoy using your MiniView™ Micro USB Audio, yet another first-rate
connectivity solution from IOGEAR®.

PackageContents
Overview
Features
Requirements
Pictorial Introduction
Installation
Operation
Specification
Troubleshooting
Troubleshooting Con’d
Tech Support
Radio & TV Interference Statement
Limited Warranty
02
03
04
05
07
08
11
15
16
17
18
19
20
Table of Contents
1

This package contains:
1 MiniViewTM Micro Micro USB Audio 2 Port KVM Switch
1 User Manual
1 Quick Start Guide
1 Warranty Registration Card
If any items are damaged or missing, please contact your dealer.
Package Contents
2

The GCS712U MiniView Micro USB Audio KVM switch is a control unit that allows access to two
computer systems from a single console (keyboard, monitor, and mouse).
The GCS712U improve on previous models with a 50% smaller desktop footprint plus built-in custom
KVM cables for trouble-free installation and a neat and tidy workspace. For increased efficiency and
cable compactness, each of the GCS712U’s cables use a USB connector (rather than two PS/2
connectors) to transfer keyboard and mouse input to the computer.
Recognizing the increased importance of sound, the GCS712U is speaker enabled. You can listen to the
audio output of both computers (one at a time) on a single set of speakers attached to the Switch.
Setup is fast and easy; plugging cables into their appropriate ports is all that is entailed. There is no
software to configure, no installation routines, and no incompatibility problems. Since the GCS712U
intercepts keyboard input directly, it works on any hardware platform and with all operating systems. It’s
compatible with Windows and Mac computers as well as Sun Solaris workstations.
There is no better way to save time and money than with a GCS712U installation. By allowing a single
console to manage both computers, the GCS712U eliminates the expense of purchasing a separate
keyboard, monitor, and mouse for each computer. Additionally, it saves the extra space they would take
up, and eliminates the inconvenience and wasted effort involved in constantly having to move from one
computer to the other.
Overview
3

• The smallest 2 port KVM switch with audio support available
• Use one keyboard, monitor and mouse to control 2 computers
• Share multimedia speakers among two computers
• 6' long molded-in cables to simplify setup
• Microsoft Intellimouse, Logitech FirstMouse+, and the scrolling wheel on most mice
• Port selection through convenient Hot Keys
• Keyboard and mouse emulation for error-free boot-up
• Save space and reduce desktop clutter
• Plug-n-Play monitor support
• Support video resolutions up to 2048 x 1536; DDC2B
• Easy to install - no software required - connecting cables is all it takes
• Built in AutoScan mode to monitor computer operation
• LEDs allow for easy status monitoring
 Caps Lock, Num Lock, and Scroll Lock states are saved and restored when switchin
 Compatible with Windows 98 or later, Mac OS 8.6 or later, SUN Solaris workstation
Unix, Linux, and other USB-enabled systems*
• 3 Year Limited Warranty
* Additional drivers and support may be needed
Features
4

Requirements
5
Console
• A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be
using on any computer in the installation.
• A PS/2 Style Mouse.
• A PS/2 Keyboard.
Computers
The following equipment must be installed on each computer that is to be connected to the
system:
• A VGA, SVGA or Multisync video card.
• Available USB port

6
Cables
For optimum signal integrity and to simplify the layout, high-quality 3-in-1 Custom KVM
cables have been designed into the GCS712U. There is no need for a separate cable
purchase.
Note:
The KVM cables have PS/2 style keyboard and mouse connectors. The GCS712U does
not support AT keyboards or serial mice.
Requirements

1. KVM Cables
These 3-in-1 cables connect to the USB, video, and
audio ports on the computers you are installing.
2. Port LEDs
A LED lights to indicate its corresponding port is the one
that has the KVM focus. Depending on the port’s status,
the LED may flash according to a specific pattern.
3. Speaker Jack
The cable from your speakers (optional) plugs in here.
4. Console Ports
Your keyboard, monitor, and mouse, plug in here. Each
port is marked with an appropriate icon to indicate itself.
1
2
34
Pictorial Introduction
7

3 4
8
Installation
Step 1.
Before you begin, please turn off the computers you are going to connect to the MiniView™
Micro USB Audio Switch.
NOTE:
To prevent damage to your equipment due to static electric discharge, please make sure that all devices
on the installation are properly grounded.
Connect your monitor to the female VGA port on your
MiniView™ Micro USB Audio.
Connect your PS/2 keyboard into the PS/2 keyboard
port on your MiniView™ Micro USB Audio.
Connect your PS/2 mouse into the PS/2 keyboard port
on your MiniView™ Micro USB Audio.
Connect your speakers directly into the audio port on
your MiniView™ Micro USB Audio.
1.
2.
3.
4.

Step. 2
Installation
9
Connect the VGA cable that is built into
the KVM cable of your MiniView™ Micro
Audio to the VGA port on your computer.
Connect USB cable to an available USB
port on your computer
Connect the speaker cable that is built
into the KVM cable of your MiniView™
Micro USB Audio to the speaker port on
your computer.
1.
2.
3.

Installation
10
Step 3.
Repeat step 2 for the rest of you computers.
Step 4.
Turn on the power to the computers.

Operation
11
Accessing both of your computers from a single console could not be easier. The GCS712U
uses Hotkey combinations to provide KVM focus to the computers. The Hotkey combinations
allow you to:
• Select the Active Port
• Invoke Auto Scan Mode
• Set the Auto Scan Time Interval
Selecting the Active Port
You can toggle the KVM focus between the two computers by pressing and releasing the
Scroll Lock key twice:
[Scroll Lock] [Scroll Lock]

Operation
12
Auto Scan Mode
The GCS712U’s Auto Scan feature automatically switches the KVM focus between the
two computers at regular intervals so that you can monitor their activity without having to
take the trouble of switching yourself. The default time interval is 5 seconds. To invoke
Auto Scan Mode:
Press and release the Left Shift key; then press and release the Right Shift key:
[Left Shift] [Right Shift]
Once scanning begins, it continues until you press the [Spacebar] to exit Auto Scan
Mode. The port that was currently active at the time scanning stopped remains active.
Note: While Auto Scan Mode is in effect, ordinary keyboard and mouse functions are
suspended.You must exit Auto Scan Mode by pressing the [Spacebar] in order to regain
normal control of their use.

Operation
13
Changing the Scan Interval
Before you invoke Auto Scanning you can change the amount of time Auto Scan dwells on
each port. To do so, use the following Hotkey combination.
[Left shift] [Right shift] [S] [n]
Where n represents a number from 1 to 4 that specifies the desired scan interval time, as
shown in the table below: n Scan Interval
[1] 3 secs
[2] 5 secs
[3] 10secs
[4] 20secs
Note:You must press and release the keys one at a time.

ActivityFunction
Off
On(Steady)
Flashing
Portisnotselected
Portisconnected to an active computer
Portisconnected to an active computer,and isbeing accessed
inAutoScanMode
Operation
14
LED Display

Specification
15
Specifications

Symptom Possible Cause Action
Keyboard Not
Responding1Loose cables.
Keyboard needs to
be reset.
Check all keyboard cable
connections to make sure they
are completely seated in their sockets.
Unplug the keyboard from the Console
Keyboard Port, then plug it back in.
Switch needs to be
reset Turn off the computers. Unplug the
KVM cables. Wait five seconds; then
plug the cables back in and turn the
computers on.
Switch is in Auto Scan
Mode. Press the [Spacebar] to exit Auto Scan
Mode.
Pressing Hot
Keys Gets No
Response.2
Selected port
connects to a
powered Off computer.
Resend the Hotkey command
selecting a port that has a powered On
computer attached.
Resend the Hotkey command - press
and release each key in the sequence
individually.
Hotkey sequence
input incorrectly.
Switch is in Auto Scan
Mode. Press the [Spacebar] to exit Auto Scan
Mode.
Mouse Not
Detected, or
Does Not
Respond
Correctly.2
Loose cables.
Use of Mouse Port
Adapters
Mouse needs to be
reset.
Check all mouse cable connections to
make sure they are completely seated
in their sockets.
This unit is designed to only work with
PS/2 mice and computers with PS/2
type mouse ports. Serial mouse ports
with adapters cannot be used.
Unplug the mouse from the Console
Mouse Port, then plug it back in.
TroubleShooting
16
TroubleShooting

Symptom Possible Cause Action
Mouse Not
Detected, or
Does Not
Respond
Correctly.2
Switch needs to be
reset.
Mouse set to Serial
Mode.
Incorrect Mouse
Driver.
Resolution and/or
Bandwidth set too
high
Video
Problems
Turn off the computers and unplug the
KVM cables. Wait five seconds; then
plug the cables back in and turn the
computers on.
Some mice can be set to act as either
a PS/2 or serial mouse. Make sure the
mouse is set to PS/2 mode.
Check your Device Manager to be sure
that the correct driver for your mouse
(obtained from the manufacturer, or
supplied by the operating system), has
been installed.
Select a lower resolution and/or
bandwidth.
TroubleShooting Con’d
17
TroubleShooting Con’d
The unit is designed to work
with PS/2 keyboards only.
XT (84 key) and AT
keyboards will not work.
Some Notebooks, notably
the IBM Thinkpad and
Toshiba Tecra, have trouble
when their mouse and
keyboard ports are used
simultaneously. To avoid
this, only connect the
mouse port, you will need to
use the notebook’s
keyboard when the
notebook becomes the
active computer.
