IonWays RO System Supplement

Thank you for choosing the
IonWays Reverse Osmosis
Drinking Water System
Includes Remineralization
System tested and certified by WQA against NSF/NSI Standard 58 for the reduction of Arsenic, Barium, Copper,
Cyst, Fluoride, Hexavalent Chromium, Lead, Radium 226/228, Selenium, TDS, and Trivalent Chromium.

©Copyright 2009 IonWays, LLC VS.1 Page 2
Installation & Service Manual
Thank you for choosing the IonWays Reverse Osmosis Drinking Water System. With proper care your water
filtration system will produce high quality drinking water for many years.
Read carefully and follow the instructions in this manual before proceeding with the actual installation. Pay
particular attention to all warnings, cautions and notes. Failure to do so could result in personal injury or damage
to the equipment or other property. System and installation need to comply with state and local laws and
regulations. If you have any questions, please contact us at 775-324-2400 option 2.
CHECK LIST:
1.) Reverse Osmosis Unit.
2.) Water storage tank, 6 gallon capacity.
3.) Four colored tubings (black, red, yellow, blue ¼”) 4 feet each color.
4.) Installation kit: tank ball valve, drain saddle valve, feed water valve, faucet assembly.
5.) Manual and warranties.
6.) Optional: Undersink Kit (Sold Separately)
Optional Under Sink Kit
Sold Separately
RECOMMENDED TOOLS LIST:
•Variable speed drill
•1/8” and 1/4 “ drill bit ½” and 9/16 open-end wrenches (or adjustable)
•7/16” drill bit and 9/16 open-end wrench (or adjustable)
•Phillips screwdriver
•Utility knife
•Teflon tape
This reverse osmosis system contains a replaceable treatment component critical for effective reduction of total
dissolved solids. The product water shall be tested periodically to verify the system is performing satisfactorily.
System Tested and Certified by the Water Quality Association against NSF/ASNI Standard 58 for the reduction of
Arsenic, Barium, Cadmium, Copper, Cyst, Hexavalent Chromium, Lead, Radium 226/228, Selenium, TDS,
Trivalent Chromium. Do not use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected water that
may contain filterable cysts.

©Copyright 2009 IonWays, LLC VS.1 Page 3
IonWays R/O Filtration Diagram
SPECIFICATIONS:
1st Stage: Sediment Filter, 5 micron, 10” – 6-12 months
2nd Stage: Carbon Filter, 5 micron, 10” – 6-12 months
3rd. Stage: DOW-TFC membrane, 100 GPD@ 60 PSI – 18-24 months
4th Stage: IonWays Remineralizer w/Carbon - 6-12 months
Auto shut off valve
Operating Pressure: 50-90 PSI
Operating Temperature:40-100 F
The following table is to be used if you intend to connect the Reverse Osmosis system to your ionizer installed on
top of the counter. IonWays also offers an optional double spouted faucet that is fed from the ionizer installed
under the sink. If you are using the double spouted faucet, do not use the blue hose and connect either of the
black tubes on the faucet to the R/O system where the blue hose is located.
4 Connections Item No.
Color of
Tubing
Description
A To Ionizer FU-EDF-103-3NSF Blue
R/O Water to the Ionizer through
Countertop
B Feed Water Valve W-WWC-1, W-WNV-4 Red Feed Water to RO System
C Tank Ball Valve VV-BLP014WJG Yellow RO Water to Storage Tank
D Drain Connector VV-DSP014/3 Black Discharge Water to Drain
Please follow all plumbing codes in your area.
Remineralizer

©Copyright 2009 IonWays, LLC VS.1 Page 4
REMINERALIZER CARTRIDGE
The water experts at IonWays have created systems and products to take advantage of the best of R/O –
contaminant free water – by installing our remineralizer as a pre-filter before the ionizer. To make it possible to
ionize “pure” water (natural or man-made), IonWays has perfected the Remineralization Technology to add a
healthy blend of bicarbonates and organic forms of calcium, magnesium and other trace elements to the water
before ionization. Our unique remineralizer is a proprietary blend of organic and inorganic minerals that also
provides over 70 trace elements. A partial list of minerals/trace elements in the organic mineral source are:
Beryllium
Calcium
Carbon
Cerium
Cesium
Germanium
Holmium
Magnesium
Molybdenum
Neodymium
Niobium
Osmium
Palladium
Potassium
Praseodymium
Rhenium
Rhodium
Rubidium
Ruthenium
Samarium
Scandium
Sodium
Strontium
Tantalum
Tellurium
Terbium
Thallium
Vanadium
Yttrium
Zirconium
Fitting Installation Instructions
Many of the connections needed on your IonWays R/O system are quick connect. Inserting and removing the
tubing is simple to do if the following instructions are followed:
MAKE A CLEAN TUBE CUT
Cut the tube squarely and if using plastic tubing, ensure that making the cut has not flattened the tube. It needs to
be round and cut squarely. Also ensure that the tube has a smooth outside diameter without any burrs or score
marks prior to inserting it into the fitting.
INSERT TUBE INTO FITTING
Push the tubing through the collar and dual o-rings until it bottoms out against the tube stop.
TEST AND INSPECT
Push and pull the tubing toward and away from the fitting to ensure that it has been installed properly (tug it to test
the connection). Test and inspect the installation for any leaks.

©Copyright 2009 IonWays, LLC VS.1 Page 5
TUBE REMOVAL
Relieve pressure from the tubing and fitting by shutting off the water supply. Push uniformly around the collar
flange against the fitting body while pulling the tubing away from the fitting to release it.
RECOMMENDED MAINTENANCE
It is recommended that installations are inspected at least annually and parts replaced as needed.
Tapping Into Cold Water Line
Caution: The water supply to your unit MUST be from the COLD WATER LINE. Hot water will severely
damage your R.O. System.
1.) Locate the cold water angle shut off valve underneath the sink and turn it off. Open cold water faucet to
release the pressure. On single handed faucets, the hot water may have to be turned off to prevent any
hot water cross over. If water continues to come out of faucet with angle valve turned off, the house main
will have to be turned off. Care must be taken for appliances that may be damaged by an interrupted
water supply.
2.) Easy Connector (Cold Water Supply Connector )
Your R/O system and the optional Undersink Faucet both come with a cold water connector. The style
that comes with the optional faucet is the most convenient to use. The Cold Water Supply Connector is
1/2" male x 1/2" female NPT, which is the size of most cold water lines under the sink. Under most sinks
is a flexible braided stainless steel line attached to the hard copper tubing that is part of your faucet.
Simply disconnect water lines where the braided hose connects to the hard copper and install the cold
water connector shown below. Make sure to reinstall any gaskets on both sides of the Cold Water
Connector. Insert the Red Tube from the R/O system into the ¼” quick connect on this cold water supply
connector.
.
Standard Connector w/R/O Optional Connector w/Faucet Kit
