iPazzPort KP-810-19R/19VR User manual

User Manual
Rev. 1.0
Model:KP-810-19R/19VR
R
www.i P a z z P o r t . c o m
iPazzPort Universal Remote

Introduction
Contents
.......................................................... 1
Package ................................................................. 2
Feature ................................................................. 2
Specifications ........................................................... 2
System Requirement ................................................ 2
Recharge your keyboard ....................................... 3
Change operation directions ................................... 3
Button Functions
..................................................... 6
DVD Functions
6
Function description of keyboard
.......................................... 8
Setup .....................................................................
9
Code Saver 9
Power-on Default .............................................. 9
Code Setup ..................................................... 9
Code Entry ......................................................... 9
Direct Code Entry ........................................... 9
Code Search ................................................... 10
Code Search by Brand .................................... 10
Code Identification Feature ................................... 11
Programming Combo Device Codes ....................... 11
Controlling Combo Device .................................... 12
Controlling Device Requiring Separate
Power On And Off Buttons .................................. 12
VCR/DVD/DVR Punch-Through Feature ................. 13
Power Switch .......................................................... 3
Volume/Mute Control and Punch-Through Feature 13
.....
Setting All Volume/Mute Control to any one Mode 14
.......
Setting any Mode to use its own Volume/Mute Control 14
..
Troubleshooting 15
.....................................................
.....................................................
SAT Functions
.....................................................
TV/VCR/INPUT
.....................................................
6
.............................. 7
Binds keys description
Battery Saver ....................................................
....................................................
Limited Lifetime Warranty 15
......................................
9
4
Activate audio 15
.....................................................

Introduction
Congratulations on your purchase of iPazzPort Universal wireless
Remote Control.iPazzPort Universal wireless Remote consists of keyboard,
mouse touchpad, and Universal IR remote which is designed small
and portable size.It provides people a unique & capable tool to operate
their personal computer wirelessly. it is widely used for:
The people who need to be apart from their devices yet must control it
for their presentation, teaching and lecturing with large screen or
projector, up to 33 feet wireless operation distance provides you big
free space to communicate with your audience.
The people who want to sit at their easy and comfortable chair to view
the internet content, network television, such as IPTV, Google/
Android/Smart TV, box or internet movies instead of physically change
its channel, it is a really computer remote controller, of course not a TV
remote controller.
iPazzPort Universal wireless Remote let you replace a broken or lost
remote or combine more than one remote into one. In addition, this
remote is equipped with a command learning feature which lets the
remote learn commands from your original equipment remote control!
This remote control operates the common features of most but not all
models and brands of IR Infrared Controlled Video Equipment. This
remote may provide functions that are not available on your equipment.
Some functions of your particular equipment (e.g. menu functions)
may not be controlled by this remote. In such cases, use the original
remote control for your equipment. Please use this manual to become
familiar with your Unisengroup Remote. After you are familiar with
your remote the first thing you need to do is to install batteries and
setup your remote for your particular product and brand.
Thank you for buying a iPazzPort Universal wireless Remote and we
hope it will give you many years of service.

Specifications
Battery capacity: 400mA
Charge voltage: DC 5V/300mA
Standby time: 400 hours
Size: 158mm*60mm*15.4mm
Weight: 100g
System Requirement
Windows
Mac OS
Linux
Google/Andiord/Smart OS
Wireless Keyboard with Universal IR remote
USB Receiver
USB cable for recharding the unit
User Manual
Package
R.F 2.4G connection
Rechargeable lithium-ion battery
USB receiver, Plug and play
Ultra sensitive mouse touchpad
QWERTY keyboard
Universal IR remote control
Integrated wireless microphone and speaker (optional for 19VR)
Feature

Change operation directions
As we know, some times, we want to operate the wireless keyboard
vertically, and some times horizontally, when operation direction is
changed from vertically to horizontal, but touchpad will not, for example,
supposed you operate unit vertically, and you slide your finger on the
touchpad vertically, the mouse cursor on the screen of computor will
move vertically but when operation direction is changed from vertical
to horizontal, when you slide your finger vertically and mouse cursor
will move horizontally, now please press key Fn together with key Esc
to change its operation direction, and mouse cursor will move with your
finger direction.
Insert USB receiver into USB prot in the computer,system will find new
hardware “ Wireless Audio HID Device” and will install driver
automatically, Turn unit on after driver installation successfully by
switching power button to on, LED will flash one time then go
out. That means your keyboard and computer have built connention
and they are paired.
Recharge your keyboard
When your keyboard backlit flash without any operation that means
your keyboard is in low charge, and needs to recharge, Connect your
keyboard to your computer with mini end of USB cable to your
keyboard and another end to computer, then led will light up with
steady on, and go out when it is fully recharged, and LED will go out.
Power Switch

Button Functions
SETUP
GUIDE
MENU
INFO
QUIT
REPEAT
PIP
TOGGLE
MUTE
CC
-
-
Page Up
Page Down
++
SLEEP
VOL CH
TV
VCR
DVD
SAT
OK
1
4
7
ENTER
2
5
8
0
3
6
9
TV/VCR
2
1
3
24
23
45678910 12
11
13
14
15
16
17
18
19
20
21
22
Note: The REC button must be pressed twice to record from your VCR.
For some brands of VCRs, you might need to press the REC button once,
then press it again for three seconds.
Some buttons on the remote might have functions that are referred to
by different names on the device you are controlling. E.G. PREV.CHAN
may be called RECALL, or ENTER may be called DISPLAY. These
differences depend on the brand and model of your product. Also,this
remote can only operate features that exist on your product. E.G.,
your product must have PREV.CHAN ability for the PREV.CHAN button
to operate this feature.
25

1. Red Indicator Lights when any R button is pressed
2. SETUP Used for setup.
3. TV, VCR, DVD, etc. Selects product to be operated.
4.
5.
6. REPEAT Replays the last 8 seconds of a program.
7. PIP.
8.
9. Page Up/Down.
10.
11. NUMBERS Enter numbers for direct channel selection. Some
products require Enter to be pressed after channel selection..
12. CC Used for digital channels, e.g. 2-3
13.
14. TV/VCR.
15. SLEEP
16.
17.
18.
19. TOGGLE .
20. MUTE Turns off the TV sound while the picture remains.
21. INFO Displays/selects on-screen channel information.
22. QUIT Use to exit menu functions.
23. POWER Turns product On or Off.
I
GUIDE brings up the DVD Title Menu screen.Displays on-screen
program guide.
MENU brings up the DVD disc Menu screen - use with the UP, DOWN,
LEFT & RIGHT navigation buttons.T-CENTRAL The TiVo key for
TiVo Central.
VOLUME UP/DOWN Changes the volume level of the product,
normally the TV.
RECORD, PLAY, STOP, REW, FF, PAUSE,VCR control buttons
operate your VCR even when the remote is set to operate the TV.
ENTER Used after direct channel number entry to immediately
change to the selected channel.
SELECT Selects menu items for the device you are controlling.
UP, DOWN, LEFT & RIGHT navigation buttons.
CHANNEL UP/DOWN Changes the channels. CHAPTER +/-
controls DVD/CD track selection i.e.DVD/CD Track Skip Up/Down
(in DVD and SATmodes). Note the VCR buttons also control DVD
when in DVD Mode.
or Blue indicator
Lights when the audio feature is activated(optional for KP-810-19VR)
24. On as charging and off as full charging
25. Microphone (optional for KP-810-19VR)

SAT Functions
GUIDE button displays on-screen Satellite Channel Guide.
CHANNEL + and CHANNEL -buttons perform the “Page +” and “Page -”
function for on-screen Guide Menus used by some Satellite systems.
INFO button brings up Satellite Display screen for current Channel and
system information.
MENU brings up the Satellite Menu screen-use with the
UP,DOWN,LEFT & RIGHT navigation buttons.
OK button is used for on-screen Menu selection.
QUIT button is used to Exit or Clear on-screen Menu displays.
DVD Functions (labeled in blue)
CHANNEL + and CHANNEL - button respectively locate the succeeding
or preceding Chapters or Tracks on a disc.
LAST button performs DVD players “A-B Repeat ” (or RPTA.B) function
for repeat play of current Chapter or Track.
INFO button brings up DVD Display or Control Menu for Chapter/Track/
Title number, Time remaining/elapsed indication, system information,
etc.
MENU brings up the DVD disc Menu screen - use with the UP, DOWN,
LEFT & RIGHT navigation buttons.
OK button is used for on-screen Menu selection. Note some DVD
players require the Play button to be used.
SUBTITLE ON-OFF (CC) Turns the subtitles on or off.
QUIT Exit On-Screen Menus and/or Return to previous On-Screen
selection.
Note, not all DVD Players support all the functions described above.
TV/VCR/INPUT
When in TV mode the TV/VCR/INPUT button performs the INPUT
source switch function.
When in a mode that has been programmed for VCR the TV/VCR/INPUT
button performs the TV/VCR antenna switch function.
When in a mode that has been programmed for Cable theTV/VCR/INPUT
button performs the A.B switch function.
When in a mode that has been programmed for SAT the TV/VCR/INPUT
button performs the TV/SAT switch function.
When in a mode that has been programmed for DVD the TV/VCR/INPUT
button performs the DVD Setup function.

Function description of keyboard
8. Front view
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
F11 F12
KEY R.F Back Space Touch PAD
Indicator
Mouse left Navigator Mouse right
Page up/down
Item Function Operation
Mouse left Mouse left Press to operate like left mouse key
Mouse right Mouse right Press to operate like right mouse key
Key R.F Key R.F Press to pair keyboard and USB receiver
Navigate key Cursor up,down
left, right
Press the four keys to move cursor up,
down, left,and right
Page up Page up Press to scroll page up
Page down Page down Press to scroll page down
Touch PAD Mouse touch pad Slide your finger on touch pad to move
mouse cursor
Indicator Flash when signal transited
Light up when switch to Caps lock input

Binds keys description
all binds key must work with Fn, for example: if you want to operate
key “Home”, you have to press key “Fn” and key “9” together
8. Front view
F1 F2 F 3 F4 F 5 F6 F 7 F8 F 9 F10
F11 F12
Work with other binds keys Press this key and other
binds key together
Change operation directions Press “Esc” and “Fn” together
Press “F1” and “Fn” together
Press “F2” and “Fn” together
Press “F3” and “Fn” together
Press “F4” and “Fn” together
Press “F5” and “Fn” together
Press “F6” and “Fn” together
Press “F7” and “Fn” together
Press “F8” and “Fn” together
Press “F9” and “Fn” together
Volume down
Volume up
Mute
Previous
Stop
Next
Return to main page
Back to previous page
Fn
PrtSc
Press “F10” and “Fn” together
Press “ ” and “Fn” together
Press “9” and “Fn” together
Press “=” and “Fn” together
Press “-” and “Fn” together
Press “0” and “Fn” together
Press “8” and “Fn” together
Print screen
Delete
Home
Home
F11 F11
End End
Ins
Del
Insert
F12 F12
Ctrl+Alt+Del Ctrl+Alt+Del Press Fn+Enter together
Key R.F
