UT120020
PRODUCT: ultrasonic diffuse reflection sensor, analog
DESIGN: M12x1, with beam columnator
very small sonic cone angle
filling level monitoring in small containers from
approx. Ø10mm possible
integrated amplifier
adjustment of the switch-point via teach-in
teach-in via white wire (PIN 2)
one yellow and one red LED for receiving display and teach-in
housing made of nickel-plated brass
connection with M12-connector
delivery in storage box
technical data electrical connection
operating voltage 15 ... 30V DC
current consumption (w/o load) < 35mA
max. current load 20mA
analog output 0 … 10V
measuring range (teachable) 20 ... 200mm
dead zone 20mm
repeatability 0.5mm
ultrasonic frequency 380kHz
sonic cone angle 6°
ambient temperature -10 ... +60°C
system of protection (EN 60529) IP67
housing material brass,nickel-plated
electrical connection M12-connector, 4pin
fitting cable socket e.g. VK200321
measuring range adjustment (teach-in)
1. Connect voltage supply and analog output, the teach-in process must take place within 5 minutes time.
2. Connect the teach-contact (white wire / PIN 2) with +UBfor until the yellow and the red LED are flashing alter-
nating. After this open the connection.
3. The LED flashes red. Bring the object to be detected into the position where the analog output should output
0V. Afterwards connect the teach-contact shortly (< 1sec) with +UB.
4. The LED flashes yellow. Bring the object to be detected into the position where the analog output should out-
put 10V. Afterwards connect the teach-contact shortly (< 1sec) with +UB.
5. The sensor confirms the successful teach-process by flashing of both LEDs for 2sec.
bn= brown, wh = white, bk = black, bl = blue
terminal markings of the cable socket in brackets
