IPGARD STC-100 User manual
Secure Touch Screen KVM
Controller
SETTINGS CONFIGURATION
Accessing admin settings from an external
computer
• In order to access administrator settings,
establish an RS-232 serial connection via
the STC-100 RJ11 port using Terminal,
Putty, or a similar terminal program.
• Enter “//cnfg” in the terminal to access
the administrator settings.
• Enter the administrator password in order
to access settings options. The default
password is “12345”.
Administrator Tool Functions
• Update/View Computer Names After
accessing the Administrator tool, use the
specied options to view and update the
computer names seen on the
STC-100 Screen. The names will update
immediately.
TECHNICAL SPECIFICATIONS
STC-100
CONTROL A SECURE KVM SWITCH
FROM ASINGLE USB CABLE
WITH OPTIONAL EXTENSION
Quick Start Guide
USB
Signal Type USB 1.1 and 1.0 Keyboard/
Mouse only
USB Type B Inputs Keyboard-Mouse
User Console Output
Interface
(2) USB Type-A for keyboard and
mouse connection only
CONTROL
RS-232 Baud rate: 115200; data bit: 8;
stop bit: 1; no parity
OTHER
Power 5V DC, 2A power supply through
Mini USB
Dimensions 5.25” L x 2.75” W x 2.50” H
Weight 0.4 lbs
Operating Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (no condensation)
WHAT’S IN THE BOX
PART NO. QTY DESCRIPTION
STC-100 1Secure Touch Screen KVM
Controller
MINIUSB5V2A 1 5V DC, 2A power Mini USB cable
1Quick Start Guide
A full manual can be downloaded from
www.ipgard.com/documentation/
DESIGNED
AND MADE
IN THE USA
NOTICE
The information contained in this document
is subject to change without notice. iPGARD
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
tness for a particular purpose. iPGARD
will not be liable for errors contained
herein, or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material. No
part of this document may be photocopied,
reproduced, or translated into another
language without the prior written consent
from iPGARD, Inc.
20170518
Toll Free: (888)-994-7427
Phone: (702) 800-0005
Fax: (702)-441-5590
WWW.iPGARD.COM
SETTINGS CONFIGURATION HARDWARE INSTALLATION
1. Ensure that power is turned off or disconnected from the unit and the computers
2. Use a USB cable (Type-A to Type-B) to connect the USB Type-B port on the Touchscreen
Controller to the Type-A USB port labeled “KM” on the KVM.
3. Insert keyboard and mouse into the USB Type-A port on the Touchscreen Controller
4. To establish a connection with an external computer, use an RJ11 to RS-232 serial cable to
connect to the RJ11 port on the Touchscreen Controller and the serial port on the external
computer.
5. Power on the Touchscreen Controller by connecting a Mini USB cable to a power source, and
then turn on all the computers.
DESIGNED
AND MADE
IN THE USA
Operations
• Switching Channels
• Switch channels by pressing the name
of the computer on the touch screen.
A green light on the Touchscreen
Keyboard will indicate which computer
is selected.
Changing computer colors
• Select the computer’s name on the
Touchscreen Keyboard
• Click the settings icon [settings icon
picture]
• Select the color you wish to use
• Click “OK”
Virtual COM Option
For setup purposed, there is a virtual
COM option available to access the serial
administrator tool via a USB connection
to any PC. The following steps are used to
enable the V-COM option:
1. Open Device Manager on the desired PC
in order to determine the Port # of the
device.
2. Connect the STC-100 USB-B connection
to any USB port on your PC and power on
the STC-100. The device manager should
update and display the COM port for the
STC-100. This option is only temporary so
note the specic COM port for future use.
3. Use any serial application such as putty
and set up the terminal with the above
noted COM port and the serial settings
in the specication section.The STC-
100 needs to be rebooted and from
the connection to power there is a 7
second window to send the following
serial command: $#36. If the resoponse
is “unknown command” VCOM was
accessed properly.
The Administrator tool can now be accessed
through the USB Serial connection to update
Computer names and set the CAC mode.
A full Manual can be downloaded from
www.ipgard.com/documentation/
