iQTS244-CE 254mm Tile Saw
Operator’s Manual
Use QR Code to download the iQTS244
Operator’s Manual in your language.
Please read the operator’s manual
carefully and make sure you understand
the instructions before using the machine.
Utilisez le code QR pour télécharger le manuel
d’utilisation de l’iQTS244 dans votre langue.
Utilizzare il codice QR per scaricare il manuale
dell’operatore iQTS244 nella propria lingua
Gebruik de QR-code om de iQTS244
bedieningshandleiding in uw taal te downloaden
Brug QR-kode til at downloade
brugervejledningen til iQTS244 på dit sprog
Verwenden Sie den QR-Code, um das iQTS244-
Benutzerhandbuch in Ihrer Sprache herunterzuladen

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
M-iQTS244CE-001-0M012018
We declare in sole responsibility that the equipment ,Tile Saw (iQ TS244-CE)
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
EMC Directive: 2014/30/EU
Year of axing CE marking: 2018
Signature:
Name, Surname: Paul Guth
Position/ Title: VP Product Development
Date :10/01/2018
DECLARATION

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
TABLE OF CONTENTS
Key Symbols & Safety Rules
Explanation Of Warning Levels
Safety Rules
Introduction
Design And Features
iQTS244
What Is What?
Machine’s Safety Equipment
Blades
Blades For Dierent Materials
Assembling
Power Cable Selection And Assembly
Mounting The Support Arm
Connecting The Vacuum Motor Power
Assembling The Table Extension
Installing The Rolling Table
Blade Installation
Dust Guard Installation
Safety
Personal Protective Equipment
General Safety Precautions
Electrical Safety
Work Area Safety
Machine Use And Care
Starting And Stopping
Starting The Machine
Stopping The Machine
Laser Switch
Transport And Storage
Operating
Basic Working Techniques
General Maintenance
Daily Maintenance
Vacuum And Filter Maintence
Cleaning The Filter
Changing The Filter
Replacing The Carbon Brushes
Changing The Louvers
Adjustments
Adjusting The Top Slot
Adjusting And Squaring The Rolling Table
Adjusting The Rolling Table Upper Roller
X-Stand
Troubleshooting
Technical Data
Wiring Diagram
Warranty Policy
1
1.1
1.3
2
2.1
2.1
3
4
5
5.1
6
6.1
6.2
6.3
6.3
6.4
6.5
6.6
7
7.1
7.1
7.2
7.3
7.3
8
8.1
8.1
8.1
8.1
9
9.1
9.2
9.2
10
10.1
10.2
10.3
10.4
11
11.1
11.1
11.2
12
13
14
15
16
Topic Section

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
KEY SYMBOLS & SAFETY RULES
Symbols on the machine
WARNING! The machine can be a
dangerous tool if used incorrectly or
carelessly, which can cause serious or
fatal injury to the operator or others.
Please read the operator’s
manual carefully and make sure
you understand the instructions
before using the machine or
performing any maintenance.
Explanation of Warning Levels
The warnings are graded in three levels.
Used if there is a risk of serious injury or death for
the operator or damage to the surroundings if the
instructions in the manual are not followed.
Used if there is a risk of injury to the operator or
damage to the surroundings if the instructions in
the manual are not followed.
Used if there is a risk of damage to materials or the
machine if the instructions in the manual are not followed.
NOTICE
1.1
Always wear hearing protection
Always wear protective goggles
or a visor
Do not view directly with optical
instruments. Do not expose users of
binoculars or telescopes.
Class 1M Laser Product.
High voltage. Risk of an electric shock.
Turn o machine and unplug before
transportation, maintaining, adjusting,
and/or changing the blade.
Should not be disposed of with general
household waste, but collected
separately for reuse or recycling.
Keep your hands and feet away from the
blade.
CE approved.

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
Other symbols/decals on the
machine refer to special certification
requirements for certain markets.
before
Do not expose to rain.
Never cut without using the
blade guard.
Risk of injury due to accidental
starting. Do not use in an area
where children may be present.
Unused tile saw may cause
personal injury - Remove this
tile saw blade when using other
accessories.
Always use manufacturer’s
approved cutting wheels.
Replace damaged cutting
wheel before operating.
Use tool only with smooth
edge cutting wheels free of
openings and grooves.
KEY SYMBOLS & SAFETY RULES
1.2
Additional Safety Warnings
LASER RADIATION DO
NOT STARE INTO BEAM,
CLASS 1M PRODUCT

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
SAFETY RULES
1.3
Safety Rules
Warning: Read all safety warnings, instructions,
illustrations and specification provided with this
power tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
1. WORK AREA SAFETY
A) Keep work are clean and well lit. Cluttered or
dark areas invite accidents.
B) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
C) Keep children and bystanders away while
operating a power tool.Distractions can cause you
to lose control.
2. ELECTRICAL SAFETY
A) Power tool plugs must match outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce the risk of electric shock.
B) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
C) Do not expose power tool to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
D) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damages or entangled cords
increase the risk of electric shock.
E) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
F) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3. PERSONAL SAFETY
A) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
B) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
C) Prevent unintentional starting. Ensure the
switch is in the o-position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energizing power tools that
have the switch on invites accidents.

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
D) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
E) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
F) Dress properly. Do not wear loose clothing or
jewellery. Keep hair and clothing away from moving
parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
G) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust
collection can reduce dust-related hazards.
H) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4. POWER TOOL USE AND CARE
A) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do a better job and safer at the rate for which
it was designed.
B) Do not use the power tool if the switch does
not turn it on and o. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
C) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventative safety measure reduces the risk
of starting the power accidentally.
D) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
E) Maintain power tools accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may aect the
power tool’s operation. If damaged, have power tool
repaired before use. Many accidents are cause by
poorly maintained power tools.
F) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and easier to clean.
G) Use power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
dierent from those intended could result in a
hazardous situation.
H) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5. SERVICE
A) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure the safety of the power tool is
maintained.
B) Replacement of the plug or the supply cord shall
always be carried out by the manufacturer of the
tool or his service organization.
C) Keep liquid clear of the parts of the tool and away
from persons in the working area.
SAFETY RULES
1.4

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
Dear Customer
We at IQ Power Tools™ want to congratulate you on
selecting the iQTS244™ Dust Control Tile Saw. We
are certain that you will be pleased with your purchase.
iQ Power Tools takes pride in manufacturing the most
innovative tools and equipment in the industry.
If operated correctly, your iQTS244™ should provide
you with years of quality service. This operator’s
manual contains information you need to operate and
maintain your iQTS244™ safely and correctly. Please
take a few minutes to familiarize yourself with your
new iQTS244™ by reading and reviewing this manual.
If you should have any questions concerning your
iQTS244™ please feel free to contact us at
Phone: [phone]
Email: [e-mail]
It is our wish that you will be satisfied with your product
and that it will prove to be a valued tool for a long time.
A purchase of one of our products gives you access
to professional help with repairs and services. If
the retailer who sells your machine is not one of our
authorised dealers, ask him for the address of your
nearest service workshop.
This operator’s manual is a valuable document. Make
sure it is always at hand at the work place. By following
its content (using, service, maintenance etc.) the life
span and the second-hand value of the machine can
be extended. If you ever lend or sell this machine, make
sure that the borrower or buyer gets the operator’s
manual, so they will also know how to properly maintain
and use it.
Owner Responsibility
It is the owner’s/employer’s responsibility that the
operator has sucient knowledge about how to use
the machine safely. Supervisors and operators must
have read and understood the Operator’s Manual.
They must be aware of:
• The machine’s safety instructions.
• The machine’s range of applications and limitations.
• How the machine is to be used and maintained.
Local regulations could restrict the use of this machine.
Find out what regulations are applicable where you
work before you start using the machine.
INTRODUCTION
The Manufacturer’s Reservation
Subsequent to publishing this manual IQ Power Tools
may issue additional information for safe operation of
this product. It is the owner’s obligation to keep up with
the safest methods of operation.
iQ Power Tools has a policy of continuous product
development and therefore reserves the right to
modify the design and appearance of products
without prior notice.
For customer information and assistance,
contact us at our website: www.iQPowerTools.com
Design & Features
Values such as high performance, reliability, innovative
technology, and environmental considerations
distinguish iQ Power Tools’ products. Safe operation of
this product requires the operator to read this manual
carefully. Ask your dealer or iQ Power Tools should you
need more information.
iQTS244
DESIGNED WITH AN INTEGRATED VACUUM SYSTEM,
FILTER SYSTEM AND DUST CONTAINMENT
This innovative patent pending design combines
the features of a professional tile saw with a
powerful cyclonic vacuum system that cuts
cleanly and eciently with no water and no dust.
COMPACT AND MOBILE DESIGN
With compact size and built-in wheels the
integrated pull-out handle makes for easy transport.
LARGE CUT CAPACITY
Enables cutting of 24”x24” (600mmx600mm)
and 18” tile on diagonal.
FUNCTIONAL ROLLING TABLE WITH EXPANDABLE
TABLE EXTENSION
The rolling table is extra long for better support when
cutting. The table extension can be extended for larger
tiles then collapsed in for easy transport.
2.1

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
WHAT IS WHAT?
1 - Dust Tray Lift Lever
2 - Transport Handle Lock
3 - Transport Handle
4 - Table Remove Lever
5 - Extension Table Lock Knob
6 - Rolling Table Lock Knob
7 - Cutting Guide
8 - Rolling Table
9 - Blade
10 - Blade Guard Bolt
11 - Handle
12 - Power Switch
13 - Laser Switch
14 - Blade Guard
15 - Dust Guard Retainer Knob
16 - Dust Guard
17 - Extension Table
18 - Cyclones
19 - Filter Spin Knob
20 - Filter Cover
21 - Wheels
22 - Dust Tray
Front
3.1
1
2
3
4
5
6
789
13
12
10
11 15
16
17
14
21
20
19
18
22

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
WHAT IS WHAT?
23 - Vacuum Motor
24 - Vacuum Motor Power Supply
25 - Vacuum Motor Power Cord
26 - Support Arm
27 - Lock Down Knob
28 - Depth Adjustment Knob
29 - Blade Shaft Lock Button
30 - Saw Motor
Side
31 - Power Cord
32 - Power Cord Storage
33 - 8mm Allen Wrench
34 - Blade Wrench
Back and Side
35 - Top Slot
Back
3.2
26
25
24
29
2827
30
23
33
34
32
31
35

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
Back and Side
Back
General
This section describes the machine’s safety equipment,
its purpose, and how checks and maintenance should be
carried out to ensure that it operates correctly.
WARNING! NEVER USE A MACHINE THAT HAS
FAULTY SAFETY EQUIPMENT
BLADE GUARD
The blade guard is designed to prevent parts of
the blade or cutting fragments from being thrown
towards the user.
CHECKING THE BLADE GUARD
Check that the guard over the blade is not cracked or
damaged in any other way. Replace when damaged.
NEVER USE THE MACHINE
WITHOUT A GUARD NOR WITH A
DEFECTIVE GUARD. ALWAYS CHECK THAT THE GUARD IS
CORRECTLY FITTED BEFORE STARTING THE MACHINE.
IT IS NOT PERMITTED TO EXPOSE THE BLADE MORE THAN
180 DEGREES WITHOUT PROTECTION.
WARNING!
WARNING!
SHUT DOWN THE MACHINE AND
DISCONNECT THE POWER PLUG
BEFORE TRANSPORTING, MAINTAINING, AND CHANGING
THE BLADE.
DUST GUARD
The dust guard is designed to prevent dust being pulled
up from the backside of the blade. The dust guard should
be inspected periodically for damage. The dust guard
should move freely sliding up and over cutting material.
MACHINE’S SAFETY EQUIPMENT
SAW POWER SWITCH
The power switch - / O should be used to start and stop
the machine.
CHECKING THE SAW POWER SWITCH
The saw power switch starts the saw motor and
vacuum motor simultaneously.
To start the saw motor press the POWER switch - or
on symbol. To stop the saw motor press the POWER
switch Oor o symbol.
Defective switches should be replaced by an authorized
service workshop.
LASER SWITCH
This tile saw is equipped with a laser light guide for
lining up cuts.
To turn on the laser light guide press the LASER switch
-or on symbol. To turn o the laser light guide press the
LASER switch Oor o symbol.
LOCKING KNOB, ROLLING TABLE
The locking knob is used to lock the rolling table in place
when in transit. Be sure to lock rolling table before
transit to avoid injury.
4.1

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
BLADES
General
The iQTS244 dry cutting tile saw utilizes a specially
designed diamond blade with a Q-Drive Arbor hole.
The 10” Q-Drive dry cutting blade uses a proprietary
composition of diamond concentration, metal type,
and flange thickness to make a blade that cuts
cool while reducing vibration and movement. The
specially designed blade works in conjunction with
the vacuum flow to keep the blade and the material
cool while cutting.
The iQTS244 10” Dry Cutting blades with Q-Drive
Arbor hole can be purchased from your local
iQ Power Tools dealer or directly from iQ Power
Tools by calling 888-274-7744 or through our
website at www.iQpowertools.com
The Q-Drive Arbor hole with the included bushing
also fits a standard 5/8 round blade shaft for
versatility.
The Q-Drive Arbor hole shape without bushing also
fits a standard 1” round blade shaft for versatility.
BLADES CAN BREAK AND
CAUSE SERIOUS INJURIES
TO THE USER. DIAMOND BLADES CAN BECOME VERY
HOT WHEN NOT USED PROPERLY. AN OVERHEATED BLADE
MAY CAUSE DEFORMATION OF THE BLADE, RESULTING IN
DAMAGE AND INJURIES.
WARNING!
WITH BUSHING WITHOUT BUSHING
Blades for Dierent Materials
The iQTS244 dry cutting tile saw is supplied with
specially designed 10” Dry Cutting Combination Blade
with Q-Drive Arbor hole that is engineered to cut a
variety of material such as: porcelain, marble, granite,
ceramic, and stone.
A 10” Dry Cutting Hard Material Blade is also available
for the iQTS244 with Q-Drive Arbor hole.
Blade selection should be made according to the
material being cut ask your local dealer for help in
choosing the right product.
BLADE VIBRATIONS
• The blade can become out of round and
vibrate if a too high feed pressure is used.
• A lower feed pressure can stop the vibration.
Otherwise replace the blade.
SHARPENING DIAMOND BLADES
• Always use a sharp diamond blade.
• Diamond blades can become dull when
the wrong feeding pressure is used or
when cutting certain materials such as
very hard material. Working with a dull
diamond blade causes overheating, which
can result in the diamond segments
coming loose.
• Sharpen the blade by using a dressing
stone or by cutting in a soft material such
as sandstone or soft brick.
TRANSPORT AND STORAGE
• Remove the blade before transportation or
storage of the machine.
• Store the blade in a dry place.
• Inspect new blades for transport or
storage damage.
NEVER USE A BLADE FOR ANY
OTHER MATERIALS THAN THAT IT
WAS INTENDED FOR. CUTTING PLASTICS WITH A DIAMOND
BLADE CAN CAUSE KICKBACK WHEN THE MATERIAL
MELTS DUE TO THE HEAT PRODUCED WHEN CUTTING AND
STICKING TO THE BLADE. NEVER CUT PLASTIC MATERIALS
WITH A DIAMOND BLADE!
WARNING!
5.1

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
6.1
ASSEMBLING
UN-BOXING AND ASSEMBLING
Open the top of the box. Remove top layer of foam with
parts and set aside. Remove main frame assembly and
place on a flat horizontal and stable surface (preferably
a workbench) to prevent the equipment from tipping or
sliding during assembly.
POWER CABLE SELECTION AND ASSEMBLY
This power tool is supplied with 3 dierent power
cables to select from. Choose the power cable that
meet your requirement.
Install power cable into support arm.
Connect power cable in support arm.
Insert cable relief into slot.
TYPE F
TYPE G
TYPE I

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
ASSEMBLING
MOUNTING THE SUPPORT ARM
Remove the support arm/saw motor head from box
and packaging. Install the support arm onto the left rear
support arm mounting surface by lining up the pins.
Install the (4) Allen screws. Tighten all 4 screws finger tight.
Securely tighten the (4) Allen screws with supplied
Allen wrench.
Install cable grip.
Install back cover plate.
6.2

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
CONNECTING THE VACUUM MOTOR POWER
The vacuum power supply cable from the support
arm needs to be routed through the cable retainer.
Snap the cable retainer closed securing the cable.
Plug the vacuum power cable into the vacuum power
supply receptacle.
ASSEMBLING THE TABLE EXTENSION
Remove the table extension from packaging. Insert the
extension shafts into the right side of rolling table.
With a Phillips screwdriver, install screws in each end of
extension shaft to secure
INSTALLING THE ROLLING TABLE
Put the remove table lock lever in the down position.
This allows the rolling table to be installed or removed.
ASSEMBLING
6.3

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
Put the remove table lock lever in the up position.
The remove table lock lever should remain in the up
position for normal operation. The remove table lock
lever should only be put in the down position for table
removal and maintenance
IF THE REMOVE TABLE LOCK
LEVER IS LEFT IN THE DOWN
POSITION INADVERTENTLY THIS COULD CAUSE DAMAGE
AND/OR INJURY
WARNING!
6.4
INSTALLING THE ROLLING TABLE
Put the remove table lock lever in the down position.
This allows the rolling table to be installed or removed.
Holding the table in front of you, on the left side of the
table line the 1st notch wheel roller with the guide rail.
Push the table along the guide rail until their 2nd and
3rd notch wheel rollers are on the guide rail.
ASSEMBLING

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
INSTALLING THE BLADE
While pushing down on the cutting head handle
loosen the depth adjustment knob and pull out on the
lock down knob. Allow the cutting head to move to the
full up position
Loosen the blade guard bolt.
Open outside blade guard by tilting back exposing blade
shaft nut and flange washer
Remove the blade shaft nut and outside flange washer.
Note the Q-Drive shaped blade shaft. The IQTS244
must be used with the specially designed
10” dry cutting blade with Q-Drive Arbor hole.
(Note: Q-Drive Arbor hole with the included bushing also
fits a standard 5 /
8round blade shaft for versatility. Also,
the Q-Drive Arbor hole shape without bushing also fits a
standard 1 inch round blade shaft for versatility.)
BLADE INSTALLATION
WITH
BUSHING
WITHOUT
BUSHING
6.5

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
Remove blade from packaging, remove bushing if
installed into Q-Drive Arbor hole. Install the blade lining
up the Q-Drive Arbor hole with the Q-Drive blade shaft.
Install the outside blade flange washer and nut. With
supplied blade wrench tighten blade nut turning right or
clockwise while depressing the blade shaft lock button.
Tighten till secure.
Close outside blade guard and secure by tightening
guard bolt.
INSTALLING THE DUST GUARD
Note: Blade should be installed before installing
dust guard.
While pushing down on the cutting head handle
loosen the depth adjustment knob and pull out on the
lock down knob. Allow the cutting head to move to the
full up position. With the dust guard retainer clip fully
extended line up dust guard track to shoulder screws
and push-up.(Note: blade also needs to line up with a
slot in dust guard)
While holding the dust guard in the up position release
clip and lower dust guard.
DUST GUARD INSTALLATION
6.6

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
SAFETY
WARNING!
POWER TOOLS AND CUTTING
MACHINES HAVE THE
POTENTIAL TO CREATE SPARKS. ALWAYS KEEP FIRE
EXTINGUISHERS HANDY.
WARNING!
SAWING, DRILLING AND
GRINDING GENERATES
DUST THAT COMES FROM THE MATERIAL
BEING CUT, WHICH FREQUENTLY CONTAIN
SILICA. SILICA IS A BASIC COMPONENT OF
SAND, QUARTZ, BRICK CLAY, GRANITE AND
NUMEROUS OTHER MINERALS AND ROCKS.
ALWAYS EMPLOY ENGINEERED DUST
CONTROLS AND PERSONAL PROTECTION
EQUIPMENT SUITABLE TO THE MATERIAL
BEING SAWED, DRILLED OR GROUND; SEE
OSHA (29 CFR PART 1910.1200).
NEVER EXPOSE YOURSELF OR BY STANDARDS
TO HAZARDOUS DUST THAT EXCEEDS THE
PERMISSIBLE EXPOSURE LIMIT (PEL) AS
SET BY YOUR LOCAL JURISDICTION OR
GOVERNING AGENCY. I.G. OSHA, CSST.
7.1
WARNING!
THE USE OF PRODUCTS SUCH
AS CUTTERS, GRINDERS,
DRILLS, THAT SAND OR FORM MATERIAL CAN GENERATE
DUST AND VAPORS WHICH MAY CONTAIN HAZARDOUS
CHEMICALS. CHECK THE NATURE OF THE MATERIAL
YOU INTEND TO PROCESS AND USE AN APPROPRIATE
BREATHING MASK.
General
Do not use the machine unless you are able to call
for help in the event of an accident. Always have a
first aid kit nearby.
CAUTION!
LONG TERM EXPOSURE
TO NOISE CAN RESULT IN
PERMANENT HEARING IMPAIRMENT. SO ALWAYS USE
APPROVED HEARING PROTECTION.
WARNING!
THERE IS ALWAYS A RISK
OF CRUSH INJURIES WHEN
WORKING WITH PRODUCTS CONTAINING MOVING PARTS.
WEAR PROTECTIVE GLOVES TO AVOID BODY INJURIES.
PERSONAL PROTECTIVE EQUIPMENT
You must use approved personal protective equipment
whenever you use the machine. Personal protective
equipment cannot eliminate the risk of injury but it will
reduce the degree of injury if an accident does happen.
Listen out for warning signals or shouts when you are
wearing hearing protection. Always remove your hearing
protection as soon as the motor stops.
Always use approved eye protection
• If you use a face shield then you must also
wear approved protective goggles. Approved
protective goggles must comply with standard
ANSI Z87.1 in the USA or EN 166 in EU countries.
Visors must comply with standard EN 1731.
Recommended Personal Protective Equipment:
• Hearing protection
• Breathing mask
• Protective gloves.
• Hair covering or devices to contain long hair,
i.e.: Hair Ties For Guys
Generally clothes should be close-fitting without
restricting your freedom of movement. Be careful
as clothing, long hair, and jewellery can get caught
in moving parts.
WARNING!
USE OF THIS PRODUCT CAN
CAUSE EXPOSURE TO
MATERIALS KNOW TO THE STATE OF CALIFORNIA TO
CASUE CANCER AND/OR BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM.
WARNING!
PROTECT YOURSELF AND
OTHERS FROM OVER EXPOSURE.
REFER TO YOUR LOCAL JURISDICTION OR GOVERNING
AGENCY. I.G. OSHA, CSST.

iQTS244
Operator’s Manual
888-274-7744
www.iqpowertools.com
English
ALWAYS THINK ABOUT YOUR WORK ENVIRONMENT
AND USE COMMON SENSE.
It is not possible to cover every conceivable situation
you can face. Always exercise care and use your
common sense. If you get into a situation where you
feel unsafe, stop and seek expert advice. Contact your
dealer, service agent or an experienced user. Do not
attempt any task or operation that makes you feel
unsure whether or not it is safe.
ELECTRICAL SAFETY
WARNING! There is always a risk of shocks from
electrically powered machines. Avoid unfavourable
weather conditions and body contact with lightning
conductors and metal objects. Always follow the
instructions in the Operator’s manual to avoid damage.
• Never connect the machine to a outlet if plug
or cord is damaged.
• Check that the mains voltage corresponds
with that stated on the rating plate on
the machine.
• Inspection and/or maintenance should be
carried out with the motor switched o and
the plug disconnected.
• Always shut down the machine before
disconnecting the power plug.
• Never drag the machine by means of the cord
and never pull out the plug by pulling the cord.
Hold the plug to disconnect the power cord.
• Never use the machine if any cable or plug
is damaged, but hand it in to an authorized
service workshop for repair.
• Never use the machine if any cable or plug
is damaged, but hand it in to an authorized
service workshop for repair.
• Prevent unintentional starting of the motor.
Ensure the power switch is in the OFF-
position before connecting the machine to
a power source.
WARNING!
WHEN CLEANING THE MACHINE
MAKE SURE TO AVOID WATER
ENTERING THE ELECTRICAL SYSTEM AND THE MOTOR
UNIT. WATER CAN CAUSE DAMAGE TO THE MACHINE OR
SHORT CIRCUIT.
Do not modify the plug. If it will not fit the outlet have a
proper outlet installed by a qualified electrician. Make
sure local regulations and ordinances are followed.
EXTENSION CORDS AND CABLES
The marking on the extension cable must be the
same or higher than the value stated on the machine’s
rating plate.
• When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the
risk of electric shock.
• Keep the connection to the extension cord dry
and o the ground.
• Keep cable away from heat, oil, sharp edges or
moving parts. Damaged or entangled cable
increase the risk of electric shock.
• Check that the cord and extension cord are
intact and in good condition. Never use the
machine if any cable or plug is damaged. Take it
into an authorized service workshop for repair.
• To avoid overheating do not use the extension
cord while it is rolled up.
• When using an extension cable, use only
certified extension cables with sucient reach.
WARNING!
IMPROPER CONNECTION CAN
RESULT IN THE RISK OF ELECTRIC
SHOCK. CONTACT A QUALIFIED ELECTRICIAN IF IN DOUBT AS
TO WHETHER THE APPLIANCE IS PROPERLY GROUNDED.
NOTICE!
GOOD MOTOR PERFORMANCE
DEPENDS ON PROPER VOLTAGE.
EXTENSION CABLES THAT ARE TOO LONG AND/OR WHICH
HAVE A GAGE THAT IS TOO SMALL, REDUCE POWER TO
THE MOTOR UNDER LOAD, RESULTING IN REDUCED OUTPUT
OR MALFUNCTIONS.
SAFETY
7.2
