iQ Power Tools
Repair Manual
iQTS244
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
1
Table of Contents
IQTS244 DISASSEMBLY 3
Blade Removal 3
Blade Guard Removal and Disassembly 7
Blade Guard Dust Seal Removal 9
Laser Assembly Removal 11
Blade Shaft Assembly Removal 13
Control Module Removal and Disassembly (Early Version) 15
Control Module Removal and Disassembly (Newer Version) 19
Saw Motor Removal and Disassembly 23
Saw Motor Stator Disassembly 25
Gear Housing Removal and Disassembly 27
Support Arm Removal and Disassembly 31
Vacuum Inlet Removal 35
Vacuum Motor Removal 37
Vacuum Brushes Removal (Early Version) 39
Vacuum Brushes Removal (New Version) 41
Filter Removal 43
IQTS244 ASSEMBLY 45
Vacuum Filter Installation 45
Vacuum Suction Installation 47
Vacuum Motor Brushes Installation (Early Version) 49
Vacuum Brushes Installation (New Version) 51
Vacuum Motor Installation 53
Support Arm Assembly and Installation 55
Pivot Shaft Mount and Gear Housing Assembly 59
Saw Motor Armature Installation 63
Saw Motor Stator Installation 65
Control Module Installation (Early Version) 69
Control Module Installation (Newer Version) 73
Blade Shaft (Arbor) Assembly Installation 75
Blade Guard Assembly and Installation 77
Blade Guard Dust Seal Installation 79
Blade Guard Installation 81
Blade Installation 83
IQTS244 ADJUSTMENTS 85
Sliding Table Lower and Upper Rollers Adjustments 85
Sliding Table Travel Check and Adjustment 93
Pivot Arm Squareness Check 99
Table Louver and Vacuum Suction Clearance Check and Adjustment 103
Laser Check and Adjustments 105

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
3
IQTS244 DISASSEMBLY
Blade Removal
1. Loosen the locking Knob
2. Pull the Lock Pin Knob
3. Raise the Gear Housing

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
4
4. Lift the Dust Guard
5. Lift the Dust Guard Quick Set so the Dust
Guard may be removed
6. With the Dust Guard Quick Set in the UP
position, lower the Dust Guard and
Remove

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
5
7. Loosen the Outer Blade Guard locking
knob
8. Lift the Outer Guard up to expose the tile
blade
9. Depress the Spindle Lock Button and
engage the Spindle Lock

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
6
10. loosen hex nut using the wrench
provided.
11. Remove the blade hex nut and outer blade
flange and the blade.

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
7
Blade Guard Removal and Disassembly
1. Loosen and remove the Outer Blade
Guard retaining screw
2. Remove the outer blade guard cover
3. Remove the Control Module Cover
retaining screws

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
8
4. Lift the Control Module Cover to expose
the Printed Circuit Board
5. Disconnect the Laser connection
6. Remove the Inner Dust Guard retaining
screws and remove the Inner Dust Guard

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
9
Blade Guard Dust Seal Removal
NOTE: Removing the Blade Guard Dust Seal
is the same for the Inner and the Outer
Blade Guards
NOTE: The Dust Seal Plates are specific to
the Inner and Outer Blade Guards and are
NOT interchangeable
1. Remove the Dust Seal Plate retaining
screws
2. Lift and remove the Dust Seal Plate
3. Lift and remove the Dust Seal

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
10

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
11
Laser Assembly Removal
1. Remove the Laser Assembly retaining
screw
2. The Laser Assembly can be pulled out of
the wire channel

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
12

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
13
Blade Shaft Assembly Removal
1. Remove the Spindle Lock, button and
compression spring
2. Remove the blade shaft assembly
retaining screws
3. Using a flat screwdriver of a small pry bar,
carefully separate the Blade Shaft Assembly
from the Gear Housing Assembly

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
14
4. Remove the Blade Shaft Assembly
5. Check the needle bearing for completeness
If required, remove the needle bearing using inner
bearing puller and slide hammer tool

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
15
Control Module Removal and Disassembly (Early Version)
1. Move the Control Module Cover to
one side to gain access to the
Printed Circuit Board
2. Disconnect all the electrical wire
connection from the Printed Circuit
Board and remove the Printed
Circuit Board hold down screw and
remove the Printed Circuit Board
from the Control Module
3. Remove the Vacuum Power Cord
Clamp

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
16
4. Remove the Main Handle top
retaining screws
5. Remove the Main Handle Bottom
retaining screws
6. Lift the Main Handle Top up and
away from the Main Handle
Bottom.

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
17
7. Disconnect all the electrical
connection from the switches
8. Route the wire through the Main
Handle channel
9. Continue routing the electrical
wires through the Control Module
channel and remove

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
18
10. Remove the Control Module Base
retaining screws
11. Route the saw motor, main power
and vacuum power cords through the
opening at the base of the Control
Module and remove the Control
Module base

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
19
Control Module Removal and Disassembly (Newer Version)
1. Move the Control Module Cover to
one side to gain access to the
Printed Circuit Board
2. Disconnect all the electrical wire
connection from the On/Off Switch
and to access the Printed Circuit
Board (PCB)
3. Disconnect the wires from the
Printed Circuit Board

888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
20
4. Remove the Printed Circuit Board
retaining screw
5. Remove the Printed Circuit Board
6. Remove the Control Module Base
retaining Screw
