IQ HAMS-01 User manual

To use the product safely and correctly, please read this manual carefully before installation.
This product is suitable for 65-100 inch interactive display.
The maximum capacity of this cart is 100 KG
HAMS-01
Model: HAMS-01

Main Parts:
D-wall plate 1pc
E-bracket 2pcs
B-right column 1pc
A-left column 1pc
C-tray 1pc F-4 inch wheels 4pcs
Screw kits:
a-M8*20 Screw
12pcs
d-Ø16*Ø8.5*1.0
Washer
4pcs
c-M8*25 Screw
4pcs
b-M6*16 Screw
4pcs
Spanner
(Self provided)
e-Ø24*Ø12.5*1.5
Washer
4pcs
Cross screwdriver
(Self provided)
f-Ø20*Ø12.5*3.5
Spring washer
4pcs
Page 2 of 5
HAMS-01

f
e
Figure 1
Reserve 8mm
a
a
1
2
3
Page 3 of 5 Figure 2
Step 1:
Adjust the wheels to the braking state, and then screw the four wheels onto the left and right columns.
(Figure 1)
Before installing the wheel,
adjust it to the brake state.
Step2:
There are 3 combinations of installation holes in the wall plate. Choose the combination you need.
Turn a screw (a) into the lower hole of the combination in advance. Do not lock it and reserve
adistance of 8mm. Then hang up the wall plate and lock all six screws (a).(Figure 2)
3 combinations
of holes
HAMS-01

b/c
Reserve 8mm
a
a
d
Page 4 of 5
Step 3:
Turn a screw (a) into the hole as shown in Figure 3 in advance, do not lock and reserve adistance of
8mm. Then hang up the tray and lock all six screws (a).(Figure 3)
Figure 3
Figure 4
Step 4:
As shown in Figure 4, lay the conference screen flat, and select the appropriate screw to connect the
bracket with the screen.(Figure 4)
HAMS-01

Page 5 of 5
Step 5:
Install the interactive display with the bracket on the wall plate, ensure that the hook is hung on the
border of the wall plate,and then lock the safety screw on the bracket.(Figure 5)
Step 6:
The effect after installation is as follows.
Figure 5
Figure6
