Iqua miniUFO PHF-301 User manual

Iqua miniUFO
Bluetooth®Handsfree PHF -301
User Guide

1
EN
Contents
About Bluetooth® Technology ............................................................................2
General Information ............................................................................................3
Getting Started ....................................................................................................6
Call functions ....................................................................................................10
Advanced Call Functions ..................................................................................12
Product Specifications .......................................................................................14
Battery Information ............................................................................................15
Care and Maintenance ......................................................................................16
Correct disposal of this product .........................................................................17
12 MONTH LIMITED WARRANTY ....................................................................18
PHF-301_miniUFO_UG_en.fm Page 1 Wednesday, April 12, 2006 11:49 AM

2
About Bluetooth®Technology
Bluetooth is technology used for wireless communication between devices.
Bluetooth technology is based on a radio receiver and transmitter built into a tiny microchip,
one of which is incorporated into this product and the other in a compatible mobile phone.
Bluetooth enables wireless connections between a device and a mobile phone within a radius
of 10 meters of each other, without a physical cable or a line-of-sight connection.
Iqua miniUFO Bluetooth® Portable Handsfree can be used with any brand of Bluetooth mobile
phones that supports Headset or Handsfree profiles. For the latest compatibility information,
please visit www.iqua.com.
The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by IQUA is
licensed. Other trademarks and trade names belong to their respective owners.
PHF-301_miniUFO_UG_en.fm Page 2 Wednesday, April 12, 2006 11:49 AM

3
EN
General Information
Thank you for purchasing Iqua miniUFO Bluetooth®Portable Handsfree. Your new device is
a stylish product that enables you to communicate comfortably with compatible mobile phones
that support Bluetooth wireless technology. In addition to being light and pocket-sized, it has
been designed for use in the car, at the office, or at home. You can charge the device in your
car with the car charger, which has a removable USB charging cable and is included in the
sales package.
Overview of the product
1.
3.
4.
5.
2.
7.
6.
8.
PHF-301_miniUFO_UG_en.fm Page 3 Wednesday, April 12, 2006 11:49 AM

4
1. Loudspeaker
2. Indicator Light
Indicates status with blue and red lights
3. Volume Down button
Decreases the volume
4. Volume Up button
Increases the volume
5. Call button
Answer a call, end a call, reconnect to phone, or switch between handsfree and phone
mode
6. Power button
Switch the device on/off
7. Microphone
8. Charger connector
PHF-301_miniUFO_UG_en.fm Page 4 Wednesday, April 12, 2006 11:49 AM

5
EN
Sales package content
1. miniUFO
2. Sunvisor clip
3. Mounting plate with
double-sided sticker
4. Car charger with
removable USB
charging cable
5. User Guide 3.
5.
1.
4.
2.
PHF-301_miniUFO_UG_en.fm Page 5 Wednesday, April 12, 2006 11:49 AM

6
Getting Started
Safety
•Always concentrate on traffic safety while driving and obey the law.
•The miniUFO is not a toy. Keep it away from small children since it contains small
parts that may pose a choking hazard.
Car Installation
You can attach your miniUFO to the sunvisor of your car with the sunvisor clip as shown in
Fig. 1 and 2. Alternatively, you can use the mounting plate that has a double-sided sticker to
attach it to the dashboard as shown in Fig. 3. Make sure that the product is not in the
operating area of any side impact airbags or any of the other safety or operating
equipment in your car. In addition, check that the product is securely fastened and does
not interfere with you being able to operate the vehicle.
Fig. 1. Fig. 2. Fig. 3.
PHF-301_miniUFO_UG_en.fm Page 6 Wednesday, April 12, 2006 11:49 AM

7
EN
Charging the battery
Before using the miniUFO, you must charge it for approximately 4 hours. Once the battery is
fully charged, it will provide up to 10 hours of talk time and up to 450 hours of standby time.
Always use the charger that comes in the sales package.
1. Connect the charger cable to the miniUFO.
2. Plug the car charger into the cigarette lighter in your car. The red and blue lights will turn
on.
3. The red light will turn off once the battery is fully charged.
You can also use the removable USB charging cable for charging the miniUFO from your PC,
which will take longer to charge as the power output of the USB port is lower than it is with the
car charger. The miniUFO indicates that its battery is low with a warning sound and a flashing
red light.
Once the charger is connected, the miniUFO turns itself off. Press the button to turn the
miniUFO back on.
PHF-301_miniUFO_UG_en.fm Page 7 Wednesday, April 12, 2006 11:49 AM

8
Switching on and off
To switch on the miniUFO:
•Press and hold the button until the blue light starts blinking (1 blink every 3
seconds).
•To switch off the miniUFO, press and hold the button until the lights stop blinking.
Pairing the miniUFO and a mobile phone
Pairing is the process of linking your miniUFO to a Bluetooth-enabled mobile phone. Once this
process is over, you will be able to use the miniUFO with the mobile phone you have paired it
to. If you want to use the miniUFO with another mobile phone, you must repeat the pairing
process again. Even though the miniUFO can be paired with up to 8 compatible phones, it can
only be connected to one phone at a time.
1. Press and hold down the button until you hear a sound and the blue and red lights
start flashing in turns.
2. Release the button. The miniUFO is now in pairing mode and is waiting for your mobile
phone to contact it.
3. Complete the pairing with your mobile phone. Please refer to your mobile phone's
manual for details on how to search and pair. Once the mobile phone has found the
handsfree device, the phone will show Iqua miniUFO on its display. In order to pair with
the phone, enter the PIN code of the miniUFO, which is 0000.
4. After it has paired, the miniUFO will automatically connect to your mobile phone. Once
they have been successfully paired and connected, you will hear a sound and the blue
light will start flashing (3 flashes every 2 seconds).
PHF-301_miniUFO_UG_en.fm Page 8 Wednesday, April 12, 2006 11:49 AM

9
EN
Disconnecting the miniUFO from a phone
To disconnect the miniUFO from the phone it is connected to, do one of the following:
1. Switch off the miniUFO.
2. Disconnect the miniUFO from the phone it is connected to in the phone's menu.
3. Move the phone more than 10 meters away from the miniUFO.
Reconnecting the paired miniUFO to a phone
To reconnect the miniUFO to the last phone used, simply switch on the miniUFO and it will
automatically connect to the phone. If the miniUFO is already on, you can reconnect to the last
phone used by pressing the button of the miniUFO. Otherwise, make the connection in
the phone menu as instructed in your phone's user guide.
PHF-301_miniUFO_UG_en.fm Page 9 Wednesday, April 12, 2006 11:49 AM

10
Call Functions
Answer a call
When there is an incoming call, you will hear the mobile phone's ringing tone through the
miniUFO speakers. To answer a call, just press the button.
End a call
To end an active call, press the button briefly.
Reject a call
When you receive an incoming call that you do not want to answer, simply press the
button for 3 seconds.
Redialing the last number dialed
To place a call to the last number dialed, press the button for 3 seconds.
Adjusting volume
Adjust the volume by pressing the and buttons respectively.
PHF-301_miniUFO_UG_en.fm Page 10 Wednesday, April 12, 2006 11:49 AM

11
EN
Voice dialing (when supported by the phone)
To activate the voice dialing feature of your phone, press the button for 3 seconds. Please
refer to your phone's user guide for additional details, especially as some phone models do
not support voice dialing. For optimal performance, connect your phone to the miniUFO before
recording voice tags.
Muting an active call
You can mute or unmute the miniUFO during an ongoing call by pressing the and
buttons at the same time.
Switching the call between phone and handsfree mode
To transfer an active call from the miniUFO to your mobile phone, press and hold down the
button until the call is transferred to your phone. To transfer an active call from your
mobile phone to the miniUFO, press the button or use the functions of your phone as
instructed in its user guide.
PHF-301_miniUFO_UG_en.fm Page 11 Wednesday, April 12, 2006 11:49 AM

12
Advanced Call Functions
If your mobile phone has call waiting or conference functions, you can do the following with
the miniUFO:
1. A new call comes in during another call:
1. Press the button for 3 seconds to put the current call on hold and accept the
incoming call.
2. Press the button to end the current call and answer the new call.
2. Two calls, one active and the other on hold:
1. Press the button for 3 seconds to toggle between the call on hold and the active
call.
2. Press the button to end the active call and accept the call on hold.
3. Press the button for 3 seconds to merge the calls into a conference call.
PHF-301_miniUFO_UG_en.fm Page 12 Wednesday, April 12, 2006 11:49 AM

13
EN
Light indication summary
The miniUFO's LED lights can be either blue or red and are usually accompanied by a sound
signal.
The different signals indicate:
•Blue light flashing once every 3 seconds – power is on, no Bluetooth-connection.
•Blue light flashing three times every 2 seconds – power is on, Bluetooth-connection is
open.
•Blue and red light flashing in turns – in pairing mode, waiting for user to complete pairing
with mobile phone.
•Red light flashing every 3 seconds – low battery.
•Red and blue light stay on – the battery is charging.
•Blue light on continuously – charger connected, battery fully charged.
PHF-301_miniUFO_UG_en.fm Page 13 Wednesday, April 12, 2006 11:49 AM

14
Product Specifications
Model: PHF-301
Size: 98.6mm (L) x 98mm (W) x 27.5mm (H)
Weight: 81 g
Talk Time: Up to 10 hours
Standby Time: Up to 450 hours
Charging Time: Approx. 3 hours
Supports: Bluetooth
Profiles: Handsfree 1.0 and Headset 1.1
Bluetooth Compliance: Bluetooth 1.2 specification
Connection: Point-to-point
Paired Devices: Up to 8 paired, one connected at a time
Battery: Lithium Polymer (LiPo) rechargeable battery 900 mAh
Speaker: Max 1,5W
Operating Temperature: -30ºC to +55ºC (-22ºF to +131ºF)
Operating Range: Up to 10 meters
Sales Package Contents: miniUFO, LiPo battery (inserted), sunvisor clip,
mounting plate with double-sided sticker, car charger
(with removable USB charging cable), user guide
PHF-301_miniUFO_UG_en.fm Page 14 Wednesday, April 12, 2006 11:49 AM

15
EN
Battery Information
– Do not expose the product to temperatures above 80°C (175°F), direct sunlight, or fire.
– Do not attempt to replace the battery by yourself as it is built-in and cannot be changed.
– Do not dismantle the charger as it may expose you to dangerous voltages or other
hazards.
– Please charge the device only with the chargers provided by the manufacturer.
– Incorrectly reassembling the device can cause electric shock when it is used again.
– Do not use the charger outdoors or in a humid environment.
– Avoid charging the device in extremely high or low temperatures.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter
conditions, will reduce the capacity and lifetime of the battery and its ability to charge. Always
try to keep the battery between 15°C and 25°C (59°F and 77°F). A device with a hot or cold
battery may not work for a while, even when the battery is fully charged. Battery performance
is particularly limited in temperatures well below freezing.
PHF-301_miniUFO_UG_en.fm Page 15 Wednesday, April 12, 2006 11:49 AM

16
Care and Maintenance
– Do not expose the device to liquid, moisture or humidity as it is not waterproof.
– Do not use or store the device in dusty, dirty areas. Its moving parts and electronic
components can be damaged.
– Do not store the device in hot areas. High temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain plastics.
– Do not store the device in cold areas. When the device returns to its normal temperature,
moisture can form inside the device and damage electronic circuit boards.
– Do not drop, knock, or shake the device. Rough handling can break internal circuit boards
and fine mechanics.
– Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
– Use a soft, clean, dry cloth to clean any lenses.
– Do not expose your device to contact with sharp objects as this will cause scratches and
damage.
– Do not stick anything inside the device as this may damage internal components.
– Do not attempt to take apart the device as it does not contain serviceable components.
PHF-301_miniUFO_UG_en.fm Page 16 Wednesday, April 12, 2006 11:49 AM

17
EN
Correct disposal of this product
(Applicable in the European Union and other European countries with separate collection
systems)
This symbol, shown on the product or its literature, indicates that it should not be
disposed of with other household wastes at the end of its working life. To prevent
harming the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources. Household users should
contact either the retailer where they purchased this product or their local
government office for details on where and how they can take this item for
environmentally safe recycling. Business users should contact their supplier and
check the terms and conditions of the purchase contract. This product should not
be mixed with other commercial wastes for disposal.
PHF-301_miniUFO_UG_en.fm Page 17 Wednesday, April 12, 2006 11:49 AM

18
12 MONTH LIMITED WARRANTY
The Iqua standard warranty (IQUA Ltd.) guarantees that this product is free from material and
workmanship defects for a period of twelve (12) months from date of purchase provided the
following terms of this warranty are satisfied. This warranty only applies to the original owner
of this product. The length of warranty may vary from country to country, however, so please
check with your retailer for more details.
1. The purchaser must be able to prove that he or she purchased the product by
presenting the original sales receipt that describes the product in order to establish the
validity of the warranty claim to IQUA Ltd. with the provider of warranty service. IQUA
Ltd. reserves the right to deny warranty without dated proof-of-purchase. Any
evidence of alteration, erasure, or forgery shall result in termination of the right of
warranty.
2. IQUA Ltd. agrees to repair or replace, without charging the owner, any defective
product that is still under warranty. Said warranty does not apply to cases where the
owner has used product accessories, such as chargers, other than those supplied by
Iqua with this product.
3. Replacement or repair does not extend the original warranty period.
4. This warranty is not valid for product owners who attempt to repair defective units
themselves.
5. Certain product liability regulations may apply to you as the owner of the Product;
however, under no circumstances is IQUA Ltd. liable for any indirect or consequential
damages to person or property resulting from the use of any IQUA product.
PHF-301_miniUFO_UG_en.fm Page 18 Wednesday, April 12, 2006 11:49 AM

19
EN
6. The warranty is not valid in case of fire, lighting, earthquake, accident, misuse,
unusual physical or electrical stress or any other cause beyond the normal usage and
care of the product.
7. IQUA Ltd. reserves the right to make changes or improvements in design or
manufacture without having any obligation to install such changes in existing and sold
products.
8. This warranty does not cover normal wear and tear on the product or the operation
time of the battery.
DECLARATION OF CONFORMITY
We, Iqua Ltd., declare under our sole responsibility, that the product, PHF-301, conforms with
the provisions of the following Council Directive: 1999/5/EC.
PHF-301_miniUFO_UG_en.fm Page 19 Wednesday, April 12, 2006 11:49 AM
