iRobot Braava jet User manual

Owner’s Guide

Braava jet™ Owner’s Guide 1
EN
Table of Contents
What’s In the Box
Robot Anatomy
Setup Guide
Choosing the Right Braava jet™Pad
How iRobot Braava jet Cleans
Tips for Best Performance
Troubleshooting
Regular Robot Care
Safety and Compliance Information
2
4
8
18
20
28
30
32
38

Braava jet™ Owner’s Guide 3
EN
2 For Customer Care go to www.irobot.com/support
EN
What’s In the Box
Pad and battery quantities may vary by model
• iRobot Braava jet™ Robot
• Lithium Ion Battery
• Battery Charger
• iRobot Braava jet Cleaning Pads (type and
quantity of cleaning pads may vary by model)
• (2) Wet Mopping Pads (Blue)
• (2) Damp Sweeping Pads (Orange)
• (2) Dry Sweeping Pads (White)

Braava jet™ Owner’s Guide 5
EN
4 For Customer Care go to www.irobot.com/support
EN
Robot Anatomy
Top View - BackTop View - Front
Handle
CLEAN
Button
Precision
Jet Spray
Nozzle
Braava jet
Cleaning
Pad
Pad Eject
Button
Tank Cap
Battery

Braava jet™ Owner’s Guide 7
EN
6 For Customer Care go to www.irobot.com/support
EN
Robot Anatomy
iRobot Braava jet Cleaning PadsBottom View
Wet Mopping
(Blue)
Damp Sweeping
(Orange)
Dry Sweeping
(White)
Washable Wet
Mopping (Blue)
Front Cli Sensors
Pad Reader
Pad Tracks
Wheels
Rear Cli Sensors
(Included with select
models. Also available for
purchase as an accessory.)

Braava jet™ Owner’s Guide 9
EN
8 For Customer Care go to www.irobot.com/support
EN
Setup Guide
Follow these simple steps to get started with your
Braava jet™ Mopping Robot.
Charge & Insert the Battery
• Remove the battery and put it in the battery charger.
• The indicator light will blink amber while the battery is charging. The light will
switch to solid green when the battery is fully charged.
• The wall charger automatically goes into low-power mode when the battery is
fully charged to maintain the life of the battery and limit power usage.
• The battery will fully charge within 2 hours.
• Insert the fully charged battery into the robot.
1
Battery Tip #1: For best results in
rooms with a lot of furniture fully
charge the battery for 2 hours
before using the robot.
Battery Tip #2: iRobot also oers
additional batteries and chargers
as accessories for purchase, so
you can always have a charged
battery ready to go.
Charge Insert

Braava jet™ Owner’s Guide 11
EN
10 For Customer Care go to www.irobot.com/support
EN
Cleaning Agent
Cleaning Agent
Wet
Mopping
(Blue)
Damp
Sweeping
(Orange)
Dry
Sweeping
(White)
Select a Braava jet Cleaning Pad
• Choose a cleaning pad that matches how you want to clean your floor.
• Your robot comes with a sample pack of Wet Mopping, Damp Sweeping,
and Dry Sweeping Braava jet cleaning pads.
• Braava jet will automatically recognize the pad and adjust its
cleaning behavior based on the pad you choose.
2
Setup Guide
Cleaning Motion and Wetness Level
Washable
Wet Mopping
(Blue)
Pad Type
Cleaning Tip: Before using a Wet
Mopping or Damp Sweeping
pad, use a Dry Sweeping pad or
vacuum to clean loose debris.
(Included with select models.
Also available for purchase
as an accessory.)

Braava jet™ Owner’s Guide 13
EN
12 For Customer Care go to www.irobot.com/support
EN
3Slide in a Cleaning Pad
• Slide a Braava jet pad into the track on the bottom of the robot until
it clicks into place.
• You can attach a Braava jet pad from either side of the robot.
Fill the Robot with Water
• Fill the robot if you choose Wet Mop or Damp Sweep.
• Lift the robot handle to find the tank cap and lift and swivel it open.
• Slowly fill the tank to the top with warm water.
• Turn the cap back and close. Lower the robot handle before
starting the robot.
• Do not use any other cleaning solution with your robot other than water.
4
Setup Guide
Cleaning Tip: For
easier filling, tilt the
robot downward and
fill slowly with water.
Note: If you are using
a Dry Sweeping Pad,
skip to Step 5.

Braava jet™ Owner’s Guide 15
EN
14 For Customer Care go to www.irobot.com/support
EN
5Just Press CLEAN
• Place your robot in the lower left corner of the area you want to clean,
about a foot away from any walls.
• Press CLEAN once to wake up the robot. Press CLEAN again to start the
cleaning cycle.
• The robot will clean up to 150 ft2while mopping, and up to 200 ft2while
damp or dry sweeping.*
• Braava jet will finish by cleaning the edges and perimeters of your
room, furniture and toilets.
Setup Guide
Cleaning Tip: When it has
finished cleaning, Braava jet
returns to where it started
and powers o.
See How iRobot Braava jet Cleans section for more details on placement
and cleaning pattern behavior.
*Tested in iRobot’s Home Test
Lab on hard floors.

Braava jet™ Owner’s Guide 17
EN
16 For Customer Care go to www.irobot.com/support
EN
Setup Guide
Eject the Cleaning Pad and Prepare iRobot Braava jet
for Next Use
• To eject the cleaning pad without touching the dirt, lift the handle and
pull back on the Pad Eject Button. Disposable cleaning pads can be dropped
directly into the trash and Washable Cleaning Pads (sold separately) can be
dropped into the laundry bin.
• Remove the battery and put it in the wall charger so it
can charge for the next cleaning.
• Empty the water tank before storing the robot.
• Braava jet can be stored wheels-down or on its side with the battery
side down.
6

Braava jet™ Owner’s Guide 19
EN
18 For Customer Care go to www.irobot.com/support
EN
Choosing the Right Braava jet™ Pad
Choose the right cleaning pad
for your cleaning needs.
Wet
Mopping
Damp
Sweeping
Dry
Sweeping
OVERVIEW
Washable
Wet Mopping
RECOMMENDED FOR
(Included with select models. Also
available for purchase as an accessory.)
*Tested on dried coee and soda.
Cleaning Agent
Cleaning Agent
(Blue)
(Orange)
(White)
(Blue)
DustFresh
Scent
Hair Stains*
Dirt
Pad Type Cleaning Motion and Wetness Level

Braava jet™ Owner’s Guide 21
EN
20 For Customer Care go to www.irobot.com/support
EN
Where to Place the Robot in a Room
Place the robot in the lower left of the area you want it to clean.
The robot will systematically clean the area to the right and in front of where
it started.
• The robot will start by cleaning to the right until it encounters a wall
or other barrier.
• When the robot has cleaned as far as it can to the right, the robot will
continue to the area in front and to the right of where it started.
• The robot will stop cleaning and will return to where it started once it has cleaned
an entire enclosed space or has cleaned up to 150 ft2while wet mopping or up to
200 ft2while damp and dry sweeping.
Braava jet is designed to intelligently navigate and clean
typical kitchens and bathrooms each time it runs, up to
150 ft2while wet mopping and up to 200 ft2while damp
and dry sweeping.*
How iRobot Braava jet™ Cleans
*Tested in iRobot’s Home Test Lab
on hard floors in damp/dry mode.

Braava jet™ Owner’s Guide 23
EN
22 For Customer Care go to www.irobot.com/support
EN
How iRobot Braava jet™Cleans

Braava jet™ Owner’s Guide 25
EN
24 For Customer Care go to www.irobot.com/support
EN
iRobot Braava jet adjusts its cleaning pattern based on the
cleaning pad you choose.
• When you attach a Braava jet Wet Mopping Pad or Washable Wet Mopping Pad
(blue), Braava jet mops your floors with triple-pass coverage, moving similarly
to how you would mop yourself. The robot drives forward a short distance to one
side, backs up slightly, then moves forward to the other side. It alternates to the
left and right as it progresses through the room, providing triple-pass coverage
of each section of your floor.
• With a Braava jet Damp Sweeping Pad (orange), Braava jet cleans your floors
with gentle yet thorough double-pass cleaning. It first drives forward a short dis-
tance and then backs up in a straight line, continuing this back and forth pattern
as it cleans the area.
• When you attach a Braava jet Dry Sweeping Pad (white), Braava jet swiftly
moves forward in a straight line for single-pass coverage of the area.
• Braava jet does not spray furniture or walls. Before the robot sprays, it will back up to
ensure it’s only spraying a portion of the floor it knows is clear.
• As Braava jet finds edges, chair legs, and other obstacles, it will clean around them
and then return to its original path and resume cleaning.
• After Braava jet has cleaned the entire space, it finishes the job by cleaning along
edges, walls, furniture, and other obstacles a second time.
• Once Braava jet finishes its cleaning job, it returns to where it started, plays
a tone so you know it’s done, and powers o.
• Braava jet creates a new map every time it cleans.
How iRobot Braava jet™Cleans

Braava jet™ Owner’s Guide 27
EN
26 For Customer Care go to www.irobot.com/support
EN
Creating an Invisible Barrier
You can create an invisible barrier with the Virtual Wall®Mode so that the robot
will avoid cleaning part of a room or a dierent floor type.
• Begin with the robot powered o. When placing the robot, note that the invisible line
will be created in line with the back of the robot.
• To activate Virtual Wall Mode, start with a powered-o robot and press and hold the
CLEAN button until two blue lines appear on the top of the robot. The blue lines will
indicate that the Virtual Wall Mode has been activated.
• Once in Virtual Wall Mode, the robot will mark an invisible boundary in its internal
map, extending out to each side (see illustration). As the robot cleans your floor, it
will not go beyond the invisible line.
• Once the robot is in place, just press CLEAN to start the job.
• Virtual Wall Mode will turn o automatically when the robot completes its job. To
manually clear a Virtual Wall Mode cleaning cycle and turn o the robot, press
and hold the CLEAN button until all indicators turn o.
Cleaning Tip: You can also use
Virtual Wall Mode to divide a
larger room into smaller areas
to help Braava jet clean more
eciently.
How iRobot Braava jet™Cleans

Braava jet™ Owner’s Guide 29
EN
28 For Customer Care go to www.irobot.com/support
EN
Tips for Best Performance
General Cleaning Tips
• For best results, use a Dry Sweeping Pad or vacuum to pick up dirt and dust
before running your robot with a Wet Mopping or Damp Sweeping Pad.
• To pause your robot during a cleaning cycle, press the CLEAN button.
To resume the cleaning cycle, press the CLEAN button again.
• Do not pick up and move your robot while it is cleaning – the robot will
end its cleaning run if you do.
• Always fill Braava jet to the top with water and check for any air
bubbles before closing the tank cap.
• Only use water inside your robot. Cleaning solutions, even natural ones, can
clog the spray nozzle and break down the materials inside the robot.
• Your robot will only run with Braava jet Pads, which are specifically made
for the robot.
• Braava jet cleans best on smooth hard surfaces and may not perform as well on
uneven tiles, heavily waxed floors or rough surfaces like slate or brick which may
snag the cleaning pads.

Braava jet™ Owner’s Guide 31
EN
30 For Customer Care go to www.irobot.com/support
EN
Troubleshooting
Repeating Error Messages
If your robot remains on after an error occurs, press the bumper toward the body
of the robot once to repeat the message. If your robot has turned o after an
error occurs, press CLEAN to turn it on. If the error is ongoing, the robot will repeat
the message. Visit www.irobot.com/support to view a complete error table.
Rebooting Instructions
For some errors, rebooting Braava jet may resolve the problem. To reboot Braava jet,
press and hold CLEAN for 10 seconds until you hear an audible tone. Take out the
battery and insert it again. Press CLEAN again to turn the robot back on.
Braava jet will tell you something is wrong by alerting you
with sounds and lights. If the problem is not resolved,
learn more online at www.irobot.com/support or contact
Customer Service at [phone].
Precision Jet Spray Troubleshooting
If the robot is not spraying or is spraying unevenly and you have checked that the
tank has enough water and can hear the pump running, contact Customer Service
at [phone].
Water Level Troubleshooting
If you encounter problems with the amount of water Braava jet uses on your
floors in wet mopping or damp sweeping modes, contact Customer Service at
[phone].

Braava jet™ Owner’s Guide 33
EN
32 For Customer Care go to www.irobot.com/support
EN
Regular Robot Care
Cleaning the Cli Sensors and Pad Reader
Clean the sensors on the bottom of your robot with a damp cloth.
Follow these tips to keep your iRobot Braava jet
running at peak performance.
Cleaning the Wheels
Pull o any visible debris or hair that gathers around the wheels.
Front Cli Sensors
Pad Reader
Rear Cli Sensors
Wheels

Braava jet™ Owner’s Guide 35
EN
34 For Customer Care go to www.irobot.com/support
EN
Regular Robot Care
Cleaning the Body of the Robot
Use a damp cloth to lightly wipe o any dirt on its body or bumper.
Cleaning the Precision Jet Spray Nozzle
Wipe clean with a damp cloth.
Precision Jet
Spray Nozzle

Braava jet™ Owner’s Guide 37
EN
36 For Customer Care go to www.irobot.com/support
EN
Regular Robot Care
Caring for Washable Cleaning Pads (sold separately)
After using washable cleaning pads to clean, hand washing and air drying is
recommended for regular maintenance. The cleaning pad can be washed up to
50 times* before replacing. If using a washing machine, wash on warm cycle and air
dry. Do not wash with delicates.
*Tested in washing machine. Do not wash with delicates.
Cleaning the Tank
If you notice an odor in the tank, fill the tank with hot tap water.
Do not use boiling water. Close the cap and lightly shake the robot. Rinse the
tank and repeat. Allow the tank to dry with the cap open before using your robot.
