Iron Cross Automotive 51-700 Assembly instructions

TUBE STEP
INSTALLATION
SHEET
Only use mild soap for regular cleaning. For
heavy build up, a solution of ammonia and water
can be used. Never use and abrasive material,
i.e. steel wool, for cleaning purposes. Use terry
cloth towels wiping in the direction of the tube at
all times.
MAINTENANCE AND CARE
REMOVE ALL CONTENTS FROM THE BRACKET BOX AND CHECK FOR CORRECT QUANTITY AND ANY DAMAGED PARTS
INSTALL FRAME LOCKING BOLTS INTO THE SQUARE HOLES IN THE FRAME, AS SHOWN IN FIG. 1 & 2.
TACOMA TRUCKS USE THE LOWER MOUNTING HOLES IN THE BRACKET
TUNDRA TRUCKS USE THE UPPER MOUNTING HOLES IN THE BRACKET
INSTALL FRONT AND REAR BRACKETS USING HARDWARE DESCRIBED. HAND TIGHTEN ALLOWING FOR FINAL ADJUSTMENTS. THE FRONT
MOUNTING BRACKET SHOULD SIT FLUSH WITH THE BODY SUPPORT MOUNT.
THE TUBES ARE UNIVERSAL FROM SIDE TO SIDE. BOLT THE TUBE TO THE BRACKETS USING HARDWARE DESCRIBED. HAND TIGHTEN THE
BOLTS. ALIGN THE TUBE WITH THE TRUCK AND TIGHTEN THE TUBE STEP BOLTS FIRST TO 65 FT./LBS. THEN TIGHTEN THE BRACKET BOLTS
TO 35 FT./LBS.
REPEAT STEPS 2 THROUGH 6 FOR INSTALLATION OF PASSENGER.
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
99-03 Toyota Tundra Access Cab
01-04 Toyota Tacoma Access Cab
04-06 Toyota Tundra Double Cab
01-04 Toyota Tacoma Double Cab
QTY. PARTS LIST QTY. PARTS LIST
2 1700 FRONT BRACKETS 8 ½” FLAT WASHERS
2 1700 REAR BRACKETS 8 ½” LOCK WASHERS
8 ½” X 1 -3/4” HEX BOLTS 2 TUBE STEPS
4 FRAME LOCKING BOLTS
RV5.30.07
51-700/702,704,710
