Ironwood GLACIER LWSC User manual

09/06
LWSC
SQUARE
CONNECTOR
IMPORTANT!
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX [phone].
BY

PARTS & HARDWARE
A
Square
Connector 000000 1 ea.
H1 Angle Bracket 1401170 9 ea.
#1
Lab Workstations may be joined using the Square Connector in the configurations shown below.
Arrange the units in the chosen configuration and indicate the panels that will be drilled for the
mounting brackets by marking them with your chosen method.
NOTE: Drill only the appropriate panels!
NOTE: The Square Connector is pre-drilled on all sides allowing attachment of Lab Workstations in
any direction as shown. If you choose configuration “A” there will be no access to the angle
brackets of the fourth workstation. For this reason, we supply only enough brackets for three
connections. Simply set the fourth unit in place.
CONFIGURATION “A”
CONFIGURATION “B”
CONFIGURATION “C”
CONFIGURATION “D” CONFIGURATION “E”
H2 Panhead Screw 901220 12 ea.

#4
#5
#6
Attach three Angle Brackets (H1) to each
attaching Side Panel using the Panhead
Screws (H2) into the pilot holes.
NOTE: Do not tighten these screws yet.
Position the Lab Workstations
together in the chosen configuration
and place of use. Align the Side
Panels and adjust the levelers to
equalize the height if necessary.
See steps #2 and #3 printed on the template to mark and drill pilot holes.
NOTE: Only drill the appropriate panels!
#2 #3
Place the Square Connector
(A) onto the Angle Brackets
(H1) as shown. Secure in
place using the Panhead
Screws (H2) through the
Angle Brackets (H1) into the
pre-drilled holes in the
underside of the Square
Connector (A).
NOTE: Tighten all the
Panhead Screws at this time.
H1
H2
H1
H2
