IRUS Kabine Z111 User manual
System
®
exhibition
Assembly instructions
for the Kabine Z111
constisting of:
- 2x Aluminium proles à 1250 mm incl. 8 bores
- 2x Aluminium proles à 1250 mm incl. 8 bores and adjustable feet
- 5x Aluminium cross proles with pointed screws for the lower and upper mounting
- 2x Aluminium cross proles for the middle mounting
- 8x H-proles à 1200mm to stabilize the panels.
- 2x Extension bolts for aluminium prole
- 4x PVC rigid foam panels à 952 x 1212 mm
2x
5x
2x 2x
2x
8x 4x
System
®
exhibition
Important
Pointed screws must be used for all proles with screw holes.
1. Mount the bottom cross proles
including the pointed screws.
2. Insert the lower panels with the
H-proles.
3. Mount the cross proles and insert
the bolts in the prole.
4. Push the top proles onto the bolts.
Ensure that the holes face upward.
System
®
exhibition
5. Insert the upper panels with the
H-proles one after the other.
6. Mount the cross proles
including the pointed screws.
