IS5 COMMUNICATIONS iSG18GFP User manual

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
This controlled document is the property of iS5 Communications Inc. This
document contains proprietary information. Any duplication, reproduction or
transmission to unauthorized parties without prior permission of iS5
Communications Inc is strictly prohibited. All rights will be protected by iS5
iS5 Communications iSG18GFP
Installation Guide

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 2 of 33
Communications Inc.
Copyright Notice
Copyright © 2013 iS5 Communications Inc.
All rights reserved.
No part of this publication may be reproduced in any form without the prior
written consent of iS5 Communications Inc. (iS5).
Statement of Conditions
The information contained in this document is subject to change without
notice. iS5 Communications Inc. shall not be liable for errors contained
herein or for incidental or consequential damage in connection with the
furnishing, performance, or use of this document or equipment supplied with
it.
Revision History
This installation guide includes the relevant information for initial
installation of the iS5 Communications iSG18GFP switches.
The information in this document is subject to change without notice and
describes only the product defined in the introduction of this document.
This document is intended for the use of customers of iS5 Communications
only for the purposes of the agreement under which the document is
submitted, and no part of it may be reproduced or transmitted in any form
or means without the prior written permission of iS5 Communications .
The document is intended for use by professional and properly trained
personnel, and the customer assumes full responsibility when using it.
If the Release Notes that are shipped with the device contain information
that conflicts with the information in this document or supplements it, the
Date
Rev
Description
Prepared by
Approved by
18/7/2014 1.0 Initial release. Boris Tseitin Boris Tseitin
14/3/2016 1.1 Installation updates Kevin Ouellette Kevin Ouellette
22/3/2016 1.2 Updates Kevin Ouellette Kevin Ouellette

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 3 of 33
customer should follow the Release Notes.
The information or statements given in this document concerning the
suitability, capacity, or performance of the relevant hardware or software
products are for general informational purposes only and are not considered
binding. Only those statements and/or representations defined in the
agreement executed between iS5 Communications and the customer shall bind
and obligate iS5 Communications .
iS5 Communications however has made all reasonable efforts to ensure that
the instructions contained in this document are adequate and free of
material errors and omissions. iS5 Communications will, if necessary,
explain issues which may not be covered by the document.
iS5 Communications sole and exclusive liability for any errors in the
document is limited to the documentary correction of errors. iS5
COMMUNICATIONS IS NOT AND SHALL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS
IN THIS DOCUMENT OR FOR ANY DAMAGES OR LOSS OF WHATSOEVER KIND, WHETHER
DIRECT, INCIDENTAL, OR CONSEQUENTIAL (INCLUDING MONETARY LOSSES), that
might arise from the use of this document or the information in it.
This document and the product it describes are the property of iS5
Communications , which is the owner of all intellectual property rights
therein, and are protected by copyright according to the applicable laws.
Other product and company names mentioned in this document reserve their
copyrights, trademarks, and registrations; they are mentioned for
identification purposes only
Copyright © 2013 iS5 Communications Inc. All rights reserved.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 4 of 33
Table of contents
Table of contents ····························································································· 4
Introduction······································································································· 6
Key Features ·································································································· 6
Using This Document ······················································································· 7
Documentation Purpose ··············································································· 7
Intended Audience······················································································ 7
Documentation Suite ··················································································· 7
Conventions Used ······················································································ 8
Safety Information ··························································································· 9
System Description··························································································13
Power Supply Module ·················································································13
Input circuit protection················································································14
Main Unit ·······························································································14
I/O interface ···························································································14
Installing the iSG18GFP ··············································································15
Package Contents ······················································································15
Unpacking·······························································································15
Mounting iS5 Communications iSG18GFP – Non Explosive Enviroment ····················15
Mounting of iS5 Communications iSG18GFP in explosive atmospheres within TYPE ‘n’, ‘d’,
‘p’, ‘tD’ and ‘pD’ enclosures ··········································································16
Cable Glands for Mounting iS5 Communications iSG18GFP within TYPE ‘n’, ‘d’, ‘p’, ‘tD’
and ‘pD’ enclosures ····················································································17
Mounting for DIN Rail ·····················································································18

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 5 of 33
Distance kept for natural air flow ····································································19
Grounding ······························································································20
Connecting to a Power Source·············································································21
POE Ports····································································································25
The Switch Led indicators ····················································································27
Switch Configuration························································································28
Connecting to the Console Port······································································28
Using the Command Line Interface (CLI)································································29
Accessing the CLI······················································································29
The CLI Modes ························································································29
Committing Configuration Commands······························································30
Using the CLI ··························································································31
Default IP address·····················································································32
Changing the vlan 1 IP address·······································································32
Setting static route as default gateway································································33
Activating telnet ························································································33
Activating the Web Interface ·········································································33

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 6 of 33
Introduction
The iS5 Communications Service-aware Industrial Ethernet switch combines a
ruggedized Ethernet platform with a unique application-aware processing
engine.
As an Industrial Ethernet switch the iS5 Communications switch provides a
strong Ethernet and IP feature-set with a special emphasis on the fit to
the mission-critical industrial environment such as harsh environment, high
reliability and network resiliency.
In addition iS5 Communications switches have unique service-aware
capabilities that enable an integrated handling of application-level
requirements such as implementation of security measures.
Such an integrated solution results in simple network architecture with an
optimized fit to the application requirements.
Key Features
The iSG18GFP device offers the following features:
•Wire speed, non-blocking Layer 2 switching
•High-density modular system
•Advanced Ethernet and IP feature-set
•Application-aware firewall per port
•Integrated VPN agent
•Fit to harsh industrial environment
•Supported by a dedicated industrial service management tool
(iSIM)
•Multiple interfaces types

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 7 of 33
Using This Document
Documentation Purpose
This user guide includes the relevant installation and basic management
information for the iS5 Communications iSG18GFP.
Intended Audience
This user guide is intended for network administrators responsible for
installing and configuring network equipment.
Users must be familiar with the concepts and terminology of Ethernet and
local area networking (LAN) to use this User Guide.
Explosive Gas Atmospheres related Audience
By using an enclosure of adequate robustness and Ingress Protection Level
of IP54 or IP65 it is possible to comply with ATEX Group II Category 3G or
3D suitable for Zone 2 or 22.
Users must be familiar with the concepts, terminology and methods of
installing apparatus within type ‘n’,‘d’ or ‘p’ ‘tD, ‘pD’ enclosures as
appropriate including cable gland requirements.
Documentation Suite
This document is just one part of the full documentation suite provided
with this product.
Document Function
Initial Setup Guide Provided with the device in the box. Immediate information
required for power up and management availability.
Installation Guide Contains information about installing
the hardware and
software; including site preparation, testing, and safety
information.
User Guide Contains information on configuring and using the system.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 8 of 33
Conventions Used
The conventions below are used to inform important information:
NOTE
Indicating special information to which the user needs to pay special attention.
CAUTION
Indicating special instructions to avoid possible damage to the product.
DANGER
Indicating special instructions to avoid possible injury or death.
The table below explains the conventions used within the document text:
Conventions Description
commands
CLI and SNMP commands
command example CLI and SNMP examples
<Variable> user-defined variables
[Optional Command Parameters] CLI syntax and coded examples

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 9 of 33
Safety Information
Shock Hazard
To avoid shock, do not perform any servicing other than those contained in the unpacking
instructions.
Shock Hazard
HIGH VOLTAGE
Disconnect the product from the power line before removing the cover. Any adjustment
and maintenance of the opened device should be done only while the device is
disconnected from its source of power and should only be performed by qualified
personnel.
Explosive Gas Atmosphere
The product must be installed by a competent installer within a type ‘n’, ‘d’, ‘p’, ‘tD, or ‘pD’
enclosure.
Shock Hazard
HIGH VOLTAGE - EXPLOSIVE GAS ATMOSPHERE
1. Disconnect the product from the power line before removing the enclosure cover.
Disconnecting the unit from its power source should performed only by qualified
personnel.
Shock Hazard
GROUNDING - EXPLOSIVE GAS ATMOSPHERE
Verify protective ground connected from the ground terminal of the device to the inner
safety ground conductor of the enclosure. Verify that the outer safety ground conductor of
the enclosure is connected to the ground conductor of the mains power cord.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 10 of 33
Shock Hazard
GROUNDING
Before connecting the product to the power line, make sure that the protective ground
terminal of the
device is connected to the safety ground conductor of the mains power
cord.
The main power supply plug should only be inserted in a socket outlet provided with a
connected safety ground. The protective action must not be negated by use of an extension
cord
(power cable) without a protective conductor (grounding). Any interruption of the
protective (grounding) conductor or disconnection of the protective ground terminal can
make the device unsafe to use. Intentional interruption is prohibited.
This equipment has a connection between the earthed conductor of the DC supply circuit
and the grounding conductor.
Shock Hazard
LINE VOLTAGE
Before connecting the product to the power line, make sure the voltage of the power source
matches the requirements of the product, as marked on the label located near the power
connectors.
Shock Hazard
POWER SOURCE
The power source should be protected with a branch circuit over-current protection
Danger
Install this equipment only in a Restricted Access Location per UL 60950-1 clause 1.2.7.3.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 11 of 33
Laser Warning
The equipment is designed to be used with Class 1 Laser fiber optic transmitters which
may endanger your eyes.
Do not look directly into the fiber optic cables or transmitter.
Laser Warning
The device is provided with SFP sockets in which fiber optic transceivers may be installed.
In order to meet the safety requirement of Class 1 fiber optic laser emission, use only fiber
optic transceivers which comply with IEC 60825-1 or IEC 60825-2 and FDA 21 CFR 1040.10
and CFR 1040.1.
Caution
This equipment contains Electrostatic Discharge (ESD) sensitive components. Use ESD
protection before servicing or installing components of this system.
Caution
Changes or modifications made to this device that are not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Caution
Remove the power cord from a power-supply unit before installing it or remove it from the
device. Otherwise, as a result, the power supply or the device could be damaged. (The
device can be running while a power supply is being installed or removed, but the power
supply itself should not be connected to a power source.)

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 12 of 33
Caution
The unit is designated to operate in environments of up to 70 degrees ambient
temperature.
For AC units, under some conditions the housing of the unit might get hot and direct
touch should be avoided.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 13 of 33
System Description
The iS5 Communications iSG18GFP is a compact switch product family with
high L2/L3 switching capability and secure servicing of industrial
protocols.
Power Supply Module
Available power input versions and their respective current consumption:
Input Voltage Max current [A]
Version without POE ports
Max current [A]
Version with POE ports
24vDC
1.3
4
48vDC
0.7
2
110vAC
0.4
1.2
220vAC
0.2
0.6
For the DC versions two inputs for external sources are available, allowing
power redundancy to the unit.
CAUTION
AC Power variants holds double pole/neutral fusing

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 14 of 33
Input circuit protection
Following are maximum values of upstream fuse / circuit breaker
protection
Input Voltage Max current [A]
24vDC
10
48vDC
5
110vAC
6
220vAC
6
Main Unit
The Main Switch module is responsible for:
•Switch management.
•L2 switching.
•L3 routing.
•Application aware firewall and special services.
•Interfaces on this module are :
oEthernet Copper RJ45 ports
oSFP FO ports.
oSerial console RJ45 port.
oUSB management port.
I/O interface
The I/O card is holding the following user and network interfaces:
•Serial Asynchrony RS232 ports.
•Discrete IO inputs / outputs.
•Cellular GPRS/UMTS modem.
•Power connectors for DC versions.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 15 of 33
Installing the iSG18GFP
This section includes the relevant information for installing the iSG18GFP
device.
Package Contents
The iS5 Communications iSG18GFP package includes the following items:
•Basic system including
iS5 Communications iSG18GFP module
1x RS-232 console cable (white cable, CBL-TJ45-DB9/S-RPT)
USB memory stick
Unpacking
The package contents are factory tested and inspected prior to shipment,
however keep the shipping package until the device is installed and
verified as operational. In case of damage to the device during shipment,
contact iS5 Communications support.
Mounting iS5 Communications iSG18GFP – Non
Explosive Enviroment
The iS5 Communications iSG18GFP is designed as a fixed unit that is
connected in its rear side to an industry standard DIN rail and is setup
with the DIN-rail mount as the default setup.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 16 of 33
Mounting of iS5 Communications iSG18GFP in
explosive atmospheres within TYPE ‘n’, ‘d’, ‘p’, ‘tD’ and
‘pD’ enclosures
• The iS5 Communications iSG18GFP conforms to the standard IEC 60079-15
for type ‘n’ protection. When installed in a suitable ‘restricted
breathing’ enclosure meeting the requirements of the protection type ‘nR’
of the standard, it is suitable for use in a Zone 2 explosive atmosphere.
It is also suitable for mounting in enclosures protected according to types
of protection ‘d’, ‘p’, ‘tD and ‘pD’ when installed and verified in
accordance with the hazardous areas electrical installation standard IEC
60079-14.
• The iS5 Communications iSG18GFP is not suitable for installation in
explosive atmospheres without an explosion-protected enclosure
Mounting of iS5 Communications iSG18GFP within enclosures should consider
following mandatory requirements:
• The iS5 Communications iSG18GFP is designed as a fixed unit that is
connected in its rear side to an industry standard DIN rail and is setup
with the DIN-rail mount as the default setup within the enclosure.
• Follow below instructions - Mounting for DIN Rail
• Follow below instructions - Distance kept for natural air flow,

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 17 of 33
Cable Glands for Mounting iS5 Communications
iSG18GFP within TYPE ‘n’, ‘d’, ‘p’, ‘tD’ and ‘pD’
enclosures
The iS5 Communications iSG18GFP, when installed within explosion-
protected enclosures, its interface cables must be sealed with cable
glands suitable for the relevant type of protection installed
according to IEC 60079-14.
NOTE
It is the installer responsibility to use proper
Cable Glands suitable for the relevant type of
protection.

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 18 of 33
Mounting for DIN Rail
These mounting instructions assume that a standard DIN rail has been
previously installed. If one has not then use the installation instructions
that come with the DIN rail to mount the DIN rail on the wall.
Locate on the back of the device the DIN mounting brackets.
Assembly:
Position the module with the DIN rail guide on the upper edge of the DIN
rail, and snap it in with a downward motion.
Removing:
Pull the snap lever open with the aid of a screwdriver and slide the module
out at the lower edge of the DIN rail.
CAUTION
Please observe product installation must be vertical so that bottom side of the device
must face downwards towards the floor to enable proper natural air flow

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 19 of 33
Distance kept for natural air flow
Proper installation requires keeping 10cm distance from top and bottom
between the iS5 Communications switch to any other neighbor device for
proper cooling using natural air flow.
10 cm above and below
kept clear
10 cm above and below kept
clear

Installation Guide iSG18GFP R3.5
Ver: 1.2
Date: 22.03.2016
iS5 Communications Inc. Page: 20 of 33
Grounding
The iSG18GFP chassis ground connection uses a #6-32 Screw. We recommend
terminating the ground connection using a #6 ring lug, and a torque setting
of 15 in.lbs (1.7Nm). The red outline indicates the location of the
chassis ground.
CAUTION
Do not remove the earth connection unless all power
supply connections are
disconnected.
DANGER
Before connecting power to the platform, make sure that the grounding posts are
firmly connected to a reliable ground, as described above.
