MicroLink ADSL Modem Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c h e n 

G e r m a n y
E - m a il : v e r t r i eb s in f o @ de v o l o .d e I n t e rn e t : w w w. d e v ol o . de
Stand: 10.12.2002
devolo ADSL modem, LAN router and switch in one device
Technical specifications
LAN standards Ethernet specification IEEE 802.3
Fast-Ethernet specification IEE 802.3u
Full-duplex specification IEEE 802.3x
ADSL standards ADSL over ISDN (Annex B [Germany])
ITU G.992.1 (G.dmt)
Telekom specification (U-R2)
or: ADSL over POTS (Annex A)
ANSI T1.413 Issue 2
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
Transmission rates Download: up to 8 Mbps, upload: up to 1 Mbps (e.g. T-DSL, T-DSL 1500)
Firewall as protection
against
IP Spoofing
Ping of Death
Land Attack
Reassembly Attack
SYN Flooding
ICMP Redirection
Source Routing
Winnuke Attack
Diagnostics support ADSL status table
Downstream/upstream table
LAN status table
WAN status table
ATM status table
PPP status table
TCP status table
System log table
Routing table
Ports 4 LAN with auto MDI-X (LAN ports also applicable as uplink port),
1 WAN
WAN connection Connector Typ: RJ11
LEDs LEDs:
Power
4x3 status LEDs for Ethernet connection and uplink port
3 for WAN status
Computer interface RJ45
Routing Class C, 254 User
Power supply Power adapter 9 V AC / 800 mA
Environment 0–40°C (= 32–104°F), 10–90% humidity (non-condensing)
Protocols
PPP over Ethernet (RFC 2516) (disabling)
PPP over ATM (RFC 2364)
IP over ATM: Bridged Ethernet/Routed IP (RFC 2225/2684)
Classical IP over ATM (RFC 1577)
ATM AAL 5
vpn pass through (PPTP) aided

MicroLink ADSL Modem Router
d e v o l o A G 

S o n n e n w e g 1 1 

5 2 0 7 0 A a c h e n 

G e r m a n y
E - m a il : v e r t r i eb s in f o @ de v o l o .d e I n t e rn e t : w w w. d e v ol o . de
Stand: 10.12.2002
System requirements •CD-ROM drive
•For Internet access: ADSL connection by Deutsche Telekom or another
provider
Operating systems Windows®98, Windows®Me, Windows®2000, Windows®XP, Linux®, MacTM OS X
Miscellaneous Firmware updates from file
On/off switch
Factory default—reset button
Alarm protocols
DNS configuration
FTP server
TFTP server
DMZ
IGMP proxy
PPP half bridge
Service filter
Virtual server
RIP configuration
Time zone choosing
ADSL configuration
Approvals CE compliant in accordance with all technical requirements for all EU countries
and Switzerland:
EN60950: 1992+A1 : 1993+A2 : 1993+A3 : 1995+A5 : 1997+A11 : 1997
EN55022: 1998
EN55024: 1998
Sales information
Article numbers 01874 (DE, Annex B)
01890 (AT, Annex A)
01879 (AT, Annex B)
01891 (CH, Annex A)
01880 (CH, Annex B)
EAN code 4250059618749 (DE, Annex B)
4250059618909 (AT, Annex A)
4250059618794 (AT, Annex B)
4250059618916 (CH, Annex A)
4250059618800 (CH, Annex B)
Warranty 3 years
Service and Support line Phone: [phone] (within Germany)
E-mail: [email protected]
On-Site Help Phone: [phone] (within Germany)
Sales Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Design Plastic housing
Dimensions 169 x 134 x 40 mm (height x width x depth)
Weight 325 g
Packaging size 188 x 302 x 115 mm (height x width x depth)
Accessories
Modem—splitter—connection: telephone cable (RJ11 – RJ45) 5 m
Power adapter: 9V / 800 mA
Documentation: installation guide (in print)
CD-ROM: Windows®drivers (98, Me, 2000, XP), PDF manual
