ISA 3DSHOW 120 User manual

1
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
3DSHOW
ISA
Bastia Umbra - Perugia
Italy
Tel. [phone]
Fax [phone]
www.isaitaly.com
120 155 170 190 220
VG
VG
VG
VG
VG
VP VP VP

2
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
1. NOTES / WARNINGS 4
2. MANUFACTURER 10
3. WARRANTY TERMS AND CONDITIONS 10
4. EQUIPMENT IDENTIFICATION 10
5. USE 11
5.1 COMPOSITION 11
6. SAFETY 13
6.1 SAFETY DEVICES PRESENT 13
6.2 FIXED PROTECTIONS 13
6.3 ISOLATING THE ELECTRIC POWER SUPPLY 13
6.4 RESIDUAL RISKS 13
6.5 RISK OF CONTACT WITH LIVE PARTS 13
6.6 FIRE 13
6.7 EXPLOSIVE ATMOSPHERE 14
6.8 SLIPPING 14
6.9 TRIPPING 14
6.10 CIRCUIT FAULTS 14
6.11 WARNING SIGNS (IF ANY) 14
6.12 FALLING OBJECTS 14
6.13 COOLING 14
6.14 FOODSTUFFS SAFETY (PACKAGED PRODUCTS) 14
7. DISPOSAL OF WASTE MATERIAL 15
8. INSTALLATION 16
8.1 STORAGE AND UNPACKING 16
8.2 ENVIRONMENTAL CONDITIONS 17
8.3 INSTALLATION 17
8.4 ELECTRICAL CONNECTION 17
8.5 POSITIONING / LEVELLING 18
9. MAINTENANCE 19
10. FAULTS - TECHNICAL AFTER-SALES ASSISTANCE 20
10.1 ALARMS LIST (WHERE PRESENT) 21
11. TECHNICAL SPECIFICATIONS 22
11.1 CONTAINERS ARRANGEMENT GELATO (OPTIONAL) 23
11.2 TECHNICAL PLANT 28
11.3 OPEN/ CLOSE FRONT GLASS 29
11.4 LIGHTING 30
11.5 GLASS 30
11.6 MAX LOAD ON SHELVES “VP” 31
11.7 OPENING / CLOSING SLIDING 31
12. CONTROL PANEL 32
12.1 USER INTERFACE 34
13. CLEANING 40
13.1 INTERNAL 40
13.2 CONDENSING UNIT 41
13.3 DEFROST WATER COLLECTION TRAY (IF PRESENT) 41
13.4 SLIDING CLOSURE 41
14. PROLONGED APPLIANCE SWITCH-OFF 42

3
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
ATTACHMENTS
1 WIRING DIAGRAM - 412100802000 43
2 WIRING DIAGRAM - 412100812000 46
3 BASE ASSEMBLY 49
4 DUCTING 50
5ACCESSIBILTY COMPONENTS
(CONTROL PANEL) 51
6ACCESSIBILTY COMPONENTS
(POWER PANEL - POWER SWITCH - THERMAL PROTECTOR - TRANSFORMERS) 52
7ACCESSIBILTY COMPONENTS
(THERMOSTATIC VALVE) 53
8 ASSEMBLY INSTRUCTIONS SCOOP WASHER 54
The manual contains symbols to attract the reader’s attention and highlight particularly
important aspects. The table below illustrates the meaning of the various symbols used.
READ THE MANUAL USE OF PROTECTIVE CLOTHING
DANGER
LIVE ELECTRICAL PARTS
REQUESTS FOR MAINTENANCE OR OPERATIONS
MUST BE CARRIED OUT BY QUALIFIED STAFF
OR TECHNICAL AFTER-SALES CENTRES
ATTENTION / DANGER IMPORTANT INFORMATION
INFORMATION OPERATIONS THAT MUST BE PERFORMED BY
TWO PERSONS
VISUAL CHECK NOTES / WARNINGS
ON-BOARD CONDENSING UNIT REMOTE CONDENSING UNIT
DANGER
SLIPPING WASTE DISPOSAL
DANGER
TRIPPING RECYCLABLE MATERIALS
EARTHING

4
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
NOTE
The content of this manual is of technical nature and is owned by ISA.
It is forbidden to reproduce, circulate or modify all or part of its content
without written consent. Any infringement will be legally pursued.
The manual and the conformity certificate are an integral part of the equipment
and should always accompany the product in the event of a transfer to a new
location or to a new owner. The user is responsible for the integrity of these
documents, for their consultation and during the whole life cycle of the equipment
itself. Keep this manual in a safe place.It should be available for consultation
near the equipment at all times. If lost or destroyed, you can request a copy of
the manual from ISA by specifying the exact model, serial number and year of
manufacture. The manual reflects the manufacturing technology at the time of
supply.The manufacturer reserves the right to modify its products in any way it
deems necessary, with no obligation to update manuals and machines relating to
previous manufacturing batches.
The equipment can be used by children no younger than 8 and by persons
with reduced physical, sensorial or mental capabilities, or lacking experience or
necessary knowledge, as long as supervised or after having received training
regarding safe use of the equipment and have an understanding of the inherent
risks involved. Do not allow children to play with the device. The cleaning and
maintenance that the user will carry out must not be undertaken by children
without supervision.
Always refer to this manual before going ahead with any operation. Before doing
any type of work, disconnect the equipment from the power supply. Any work on
electric and electronic parts or cooling system components should only be carried
out by trained personnel in compliance with current laws.
The Manufacturer cannot be held liable for any damage to persons, animals or to
the product in the cases below:
• Improper use of the equipment or use of the appliance by unqualified or
unauthorised personnel.
• Failure to comply with current legislation.
• Incorrect installation and/or power supply faults.
• Failure to observe the instructions contained in this manual.
• Failure to follow the maintenance programme.
• Unauthorised modifications.
• Installation of non-original spare parts in the equipment.
• Installation and use of the equipment for purposes other than those for which
the appliance was designed and sold;
• Tampering with or damage to the power supply cable.
1. NOTES / WARNINGS

5
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
Liability for applying the safety instructions contained in this manual is held by
the technical personnel responsible for the intended use of the equipment, who
should ensure that authorised personnel:
• Are qualified to carry out the requested activity;
• Is aware of and carefully complies with the instructions contained in this
document
• Are aware of, and apply, the general safety standards applicable to the
equipment.
The buyer is responsible for training personnel using the appliance on the risks,
safety devices and general health and safety rules required by the laws of the
country where the appliance is installed.Users/operators should be aware of the
position of all the controls and how they work, as well as of the features of the
appliance.
They should also read this manual in its entirely. Maintenance work should
be conducted by qualified personnel after the appliance has been prepared
adequately..
DANGER
Unauthorised tampering or replacement of one or more parts of the
appliance, use of accessories that modify the use of the same and use
of spare parts different to those recommended, can become the cause
of injury.
DANGER
Any work conducted on the on the appliance must involve
disconnection from the power socket and in any case, none of the
protective elements (grid, casing) should be removed by non-qualified
staff.The appliance should not be operated when these protective
elements have been removed.
NOTE
In order not to compromise functionality and safety of the appliance,
the particularly complex installation and maintenance activities are
not documented in this manual and are performed by specialised ISA
technicians.
Never use electric devices inside this appliance. Do not use mechanical or
other means to accelerate the defrosting process, other than recommended by
the manufacturer. Keep the air vents in the casing of the appliance or in the
structure built into the wall free of obstructions. Do not damage the refrigerant
circuit.
RISK OF EXPLOSION
Do not store in the equipment products which contain flammable propellants
and explosives.
1. NOTES / WARNINGS

6
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
STAFF TRAINING
The buyer is responsible for ensuring personnel who will use the appliance
and maintenance technical staff are instructed and trained adequately. The
manufacturer is available for advice, clarifications, etc. so that the operator and
technical staff can use the appliance correctly.
To ensure the operator’s safety, appliance devices should be kept in constant
working order. This manual is intended to illustrate the use and maintenance of
the appliance. The operator has a responsibility and duty to carefully observe the
instructions contained within it.
Failure to comply with safety standards may result in injury to personnel and
damage to the equipment components and control unit. The user can contact
the dealer to request additional information not contained in this document, or
suggest improvements, at any time.
Before the product is delivered to the customer, it is essential that
a trained technical member of staff checks that the appliance is
operating correctly in order to achieve maximum performance.
INTRODUCTION
ISA employs materials of the best quality and as they enter the company,
we constantly monitor their storage and the use as part of the manufacturing
process to prevent damage, deterioration and failure. All manufacturing elements
are designed and manufactured in order to guarantee reliability and high safety
standards.Allappliancesaresubjectedto a strict testing procedure beforedelivery.
However, please bear in mind that product performance over time depends on
correct use and adequate maintenance. This manual contains the necessary
instructions to maintain the appliance’s initial appearance and functions over
time.
The Use and Maintenance manual contains the necessary information for
understanding how the appliance works and how to use it properly, namely:
the technical description of the various operational units, equipment and safety
systems, operations, how to use the instruments and the interpretation of
any diagnostics reports, main procedures and information relating to routine
maintenance. For correct use of the appliance, the working environment should
comply with current health and safety standards.
The safety requirements, indications, standards and notes illustrated in the
various chapters of the manual are aimed at establishing a code of conduct and
a series of obligations to be observed when performing the various activities, in
order to create safe conditions for personnel, the equipment and the surrounding
environment.
1. NOTES / WARNINGS

7
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
Thesafetystandardsreportedinthisdocumentareintendedfortrained,authorised
personnel responsible for:
• Transport
• Installation
• Operation
• Management
• Maintenance
• Cleaning
• Putting out of order
• Disposal
ATTENTION
Reading this manual, albeit in full, is no substitute for adequate user
experience. therefore it should only be considered a useful reminder
of the technical features and the main operations to perform.
NOTE
The installers and users must read and understand
the instructions contained herein before any
operation on the appliance.
1. NOTES / WARNINGS

8
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
1. NOTES / WARNINGS
R744 - REFRIGERANT (WHERE APPLICABLE)
R744 The refrigerant R744 is a gas that is compatible with the environment.
Pay close attention during transport, installation and that the
destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep away from the flame or ignition sources. Properly ventilate the premises
for a few minutes. Turn the unit off, pull the plug. Inform customer support
service.
WARNING
The refrigerant system is High Pressure.
Do not tamper with the system, but call a specialised and qualified technician
before disassembly.
ATTENTION
Maintenance must be performed exclusively by qualified staff.
R290 - REFRIGERANT (WHERE APPLICABLE)
The refrigerant R290 is a gas that is compatible with the environment,
but highly flammable.
Pay close attention during transport, installation and that the
destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep flames or sources of ignition away from the appliance. Properly ventilate
the premises for a few minutes. Turn the unit off, pull the plug. Inform customer
support service. The more refrigerant containing an appliance, the greater must
be the environment in which there is the unit. In areas too small, in the event of
leakage can form a flammable mixture of air and gas. The volume of the room
where the appliance is installed must be at least 19 m³ for each cooling
system present in the room.
ATTENTION
Maintenance must be performed by qualified personnel that has been
to work with flammable refrigerants.

9
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
1. NOTES / WARNINGS
R600a - REFRIGERANT (WHERE APPLICABLE)
The refrigerant R600a is a gas that is compatible with the
environment, but highly flammable.
Pay close attention during transport, installation and that the
destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep flames or sources of ignition away from the appliance. Properly ventilate
the premises for a few minutes. Turn the unit off, pull the plug. Inform customer
support service. The more refrigerant containing an appliance, the greater must
be the environment in which there is the unit. In areas too small, in the event of
leakage can form a flammable mixture of air and gas. The volume of the room
where the appliance is installed must be at least 17 m³ for each cooling
system present in the room.
ATTENTION
Maintenance must be performed by qualified personnel that has been
to work with flammable refrigerants.

10
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
2. MANUFACTURER
ISA Bastia Umbra - Perugia - Italy
Tel. [phone]
Fax [phone]
www.isaitaly.com
3. WARRANTY TERMS AND CONDITIONS
The seller’s warranty on the equipment is valid for 12 (TWELVE) months from the date of delivery.
The warranty includes repairs or replacements of any faulty parts due to manufacturing processes or installation after
written communication has been received, stating the appliance serial number and date of installation.
Not included in the warranty:
• All defects caused by incorrect use of the appliance.
• All defects caused by incorrect electrical connection.
• All defects caused by normal wear (for instance compressor failure and fluorescent lamp malfunctioning that is not
due to manufacturing defects).
• Calls for installation, technical instructions, adjustments and cleaning the condenser.
If the seller’s technical staff detect any tampering, unauthorised repairs or inappropriate use of appliance the warranty
will be invalidated.
Shipment of components covered by the warranty is freight collect only.
Any damage to the appliance detected at the time of delivery due to transport must be reported on the same shipping
note to claim compensation from the carrier.
The seller cannot be held liable in the event of damage to the preserved product due to appliance failure.
4. EQUIPMENT IDENTIFICATION
• Find the label affixed on the machine to read the technical data.
• Check the machine model and the power supply voltage before you perform any operation.
• If you uncover mismatches, contact the manufacturer or the company that supplied the machine immediately.
1 IDENTIFICATION OF THE COMPANY PRODUCT MANAGER
2 SYMBOLS OF COMPLIANCE
3 TYPE
4 MODEL NAME
5 ARTICLE
6 PRODUCTION DATE
7 PRODUCTION ORDER
8 CUSTOMER ORDER
9 PRODUCT CLASS
10 SERIAL NUMBER
11 OWNER REGISTRATION NUMBER
12 VOLTAGE
13 SUPPLY VOLTAGE
14 FUSE VALUE
15 LAMP POWER
16 ELECTRICAL RESISTANCE ABSORPTION
17 NOMINAL POWER (NORMAL OPERATION)
18 POWER (DEFROSTING)
19 MINIMUM PRESSURE
20 MAXIMUM PRESSURE
21 SAFETY CLASS
22 NOMINAL CURRENT
23 CURRENT DURING DEFROSTING
24 LEVEL LOAD
25 TANK LOAD
26 TYPE OF COOLANT
27 WEIGHT OF COOLANT
28 GROSS VOLUME
29 EXPANDING ISOLATION AGENT
30 WEEE MARK

11
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
5. USE
This appliance is exclusively intended to:
VG DISPLAY AND SELL SPREADABLE GELATO
VP DISPLAY AND SELL OF FRESH PASTRY
The manufacturer is not liable for injury to persons or damage to property or the appliance itself caused by the
displaying of products other than those described above.
THE APPLIANCE IS INTENDED FOR PROFESSIONAL USE
Uses not allowed
• Food preservation.
• Displaying and/or preserving non-food products (chemicals, pharmaceuticals, etc...).
ATTENTION
LOAD LIMITS
It is fundamental not to exceed the load limits indicated in order to avoid altering the correct circulation
of air and to avoid the temperature of the product being too high.
The limits indicated refer to a static and evenly distributed load. Therefore dynamic overloads due to
violent loading operations are excluded, which must be prevented foe safety reasons.
5.1 COMPOSITION
The appliance is made up from a unique cabinet, onto which all devices necessary to make it a professional and efficient
product for its declared use, are installed.
The appliance is made up from:
Cooling system at Ventilated Refrigeration (RV)
Condensing unit on board (UCA) or remote (UCR)
Electrical system
Electronic controller
Insulated monolithic structure in ecological polyurethane
Operator side closure with sliding
Height adjustable feet
Front glass tilted manually
LED lighting
Pivoting movement wheels with brake

12
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
5.1 COMPOSITION
01 01
02
03
04
0506
07
08
CONE HOLDER OPTIONAL
SCOOP WASHER OPTIONAL
ACCESS TO VALVE THERMOSTATIC
CONDENSER INTERNAL CONDENSING UNIT
PASSAGE PIPES IN PLATFORM
OUTPUT POWER SUPPLY CABLE
ACCESS TO POWER PANEL, POWER SWITCH, THERMAL PROTECTOR AND TRANSFORMERS
DISPLAY + KEYBOARD
01
02
03
04
05
06
08
07

13
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
6. SAFETY
The appliance is equipped with safety devices. The buyer is responsible for training personnel using the appliance on
the risks, safety devices and general health and safety rules required by the laws of the country where the appliance
is installed. Users/operators should be aware of the position of all the controls and how they work, as well as of the
features of the appliance. They must also have read this manual in its entirety.
6.1 SAFETY DEVICES PRESENT
Devices whose operation prevents the occurrence of risk situations in operating conditions (e.g. fuses, pressure
switches, protections, magnet circuit breakers, etc.).
6.2 FIXED PROTECTIONS
Fixed protective devices consist of fixed perimeter shields, which are used to prevent external parts from entering the
equipment.
DANGER
It is prohibited to re-start the appliance following maintenance without having correctly restores the
panels.
VISUAL CHECK
You should check the integrity of fixed panels and corresponding fixings to the frame, focussing in
particular on the protective panels.
6.3 ISOLATING THE ELECTRIC POWER SUPPLY
Before conducting any maintenance work on the equipment or part of it, it is necessary to section the power supply that
powers it.
DANGER
In the event of maintenance operations in which the operator cannot prevent accidental closure of the
circuit by others, to totally disconnect the appliance from the mains electricity.
6.4 RESIDUAL RISKS
During design the manufacturer examined all the areas or parts at risk.Therefore, all necessary precautions have been
taken to prevent risks to persons and damage to the appliance.
ATTENTION
• Periodically check that all safety devices are operating correctly.
• Do not remove the fixed guards.
• Do not introduce objects or tools into the work area.
Although the appliance is fitted with the safety devices prepared, there are still some risks that cannot be eliminated,
but reduced via corrective actions by the final integrator and correct operational procedures.
Below is a summary of the remaining risks associated with the appliance during:
• Normal operation.
• Adjustement and tweaking.
• Maintenance.
• Cleaning.
6.5 RISKS OF CONTACT WITH LIVE PARTS
Risk of breaking or damaging the electrical components of the appliance, with a possible reduction in safety levels,
following a short circuit.
Before connecting the electricity supply, make sure there is no ongoing maintenance work.
ATTENTION
Before making the connection, check that the d.c. current in the installation point does not exceed that
indicated on the protections switches present in the electric control board.If this is not the case, the user
must envision the relevant limiting devices. It is strictly forbidden to conduct any electrical modification, in
order to prevent additional unforeseen hazards and risks.
6.6 FIRE
DANGER
In the event of a fire, immediately disconnect the master switch from the main power supply line.

14
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
6.7 EXPLOSIVE ATMOSPHERE
The equipment must not be located in an area classified as an explosion risk according to 1999/92/EC such as:
Zone 0
An area in which there is a permanent, long-lasting or frequently explosive atmosphere made up of a mixture of air and
flammable substances in the form of gases, fumes or steam.
Zone 1
An area in which the formation of an explosive atmosphere, made up of a mixture of air and flammable substances in
the form of gases, fumes or steam is occasionally probable during normal activities.
Zone 20
An area in which there is a permanent, long-lasting or frequently explosive atmosphere in the form of clouds of
combustible dust in the air.
Zone 21
An area in which the formation of an explosive atmosphere in the form of clouds of combustible dust is occasionally
probable during normal activities.
6.8 SLIPPING
DANGER
Any leaks in the areas surrounding the appliance may cause personnel to slip. Check that there are
no leaks and keep these areas clean at all times.
6.9 TRIPPING
DANGER
Generally untidy deposits of material may constitute a tripping hazard and a total or partial
obstruction of emergency exit routes. You should ensure that operating and transit areas and escape
routes are free from obstacles in compliance with current law.
6.10 CIRCUIT FAULTS
Owing to potential faults, safety circuits may become less effective, which results in lower safety levels. You should
check the operational condition of the appliance devices regularly.
6.11 WARNING SIGNS (IF ANY)
The appliance is fitted with warning danger, warning and obligation signs defined in agreement with the Standard relative to
the graphical signs to be used on plants. The signs are located in clearly visible positions.
ATTENTION
The warning plates present on the appliance must not be removed.
The user is responsible for replacing warning signs that, owing to wear, become unreadable.
6.12 FALLING OBJECTS
Positioning of the cabinet display parts (i.e. counters, rods and hooks), as also product arrangement inside the cabinet
can be the source of potential hazards if not properly performed. Follow the positioning instructions described in this
Manual before you place products inside the cabinet, check that the counters are properly fastened, as also the hooks,
etc. Do not exceed the maximum load limit. Do not exceed the maximum load limit. Do not position tilted product on
the counters if they are not held in place by their stoppers.
6.13 COOLING
During different operations to perform on the counter, such as cleaning or loading goods, it is necessary to handle
products and/or counter parts at a low temperature with the risk of “cold injury” for the operators and/or accidental
slipping hazard. Follow the safety regulations in the place where the cabinet is installed; more specifically, be sure to
always use the right PPE (especially gloves).
6.14 FOODSTUFFS SAFETY (PACKAGED PRODUCTS)
The refrigerator cabinet described herein is meant to be used to display packaged products. As such, it is not designed
for direct contact between the foodstuffs and display surfaces. If the foodstuffs do accidentally make contact with
the surfaces and for a rather long time, the product may be contaminated. Follow the guidelines on how to use the
cabinet. If a product package breaks, remove it from the cabinet and clean, if necessary.

15
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
7. DISPOSAL OF WASTE MATERIAL
During normal operation, the appliance does not generate any environmental contamination. At the end of its life cycle,
or if it is necessary to proceed to permanent decommissioning, we recommend following the procedures below:
DISPOSAL (USER)
The symbol, applied to either the product or its packaging, indicates that the product should not be
considered as normal domestic waste, but should be taken to a waste collection point for the recycling
of electrical and electronic appliances. The correct disposal of this product contributes to preventing
potential negative consequences that might derive from an inadequate disposal of the product. For detailed
information about recycling this product, contact your council, your local waste collection service or the
store where you purchased the product.
PROCEDURE FOR DISPOSAL and RECYCLING AT THE END OF APPLIANCE LIFE SPAN
(AUTHORISED BODIES)
• Switch off the equipment and unplug the power supply cable.
• Remove the lamps (if installed).These should be disposed of separately.
• Remove the power units and the electronic cards.These should be disposed of separately.
• Remove all the independent parts (grids, casings, profiles, etc.) and group them according to shared features in
order to access the heat exchangers, pipes, cables, etc. and be careful not to damage the cooling circuit.
• Remove all mobile parts (doors, sliding doors, glass parts, etc.) and group the various materials according to their
features.
• Check the type of refrigerant on the plate positioned inside the counter; extract the refrigerant and dispose of it
through authorised services.
• Disconnect the evaporator, condenser, compressor, pipes and fans. These are made of copper, aluminium, steel and
plastic and should therefore disposed of separately.
• On removal of all guards and the various components from the frame, separate the different types of material
making up the appliance (plastic, sheet steel, polyurethane, copper, etc) and collect them separately.
All recyclable materials and waste should be processed and recycled by professionals, in compliance
with the laws in the country in question. The company responsible for recycling the materials should be
registered and certified as a waste disposal service in accordance with the country in question.
ATTENTION
Illegal disposal of the product by the owner will result in administrative sanctions as required by current
laws. Disposal of the product should comply with current laws on the disposal of coolant liquids and mineral
oils.
IMPORTANT
If the crossed wheelie bin sign is not present on the appliance, it means that the disposal of the product is
not the manufacturer’s responsibility. In this case, the Regulations regarding the disposal of waste in force
are valid.
ADDITIONAL INFORMATION
Further information on the disposal of liquid coolant, oils and other substances is available on the safety
data sheet corresponding to the substance itself. In order to dispose of foamed assemblies, remember that
the polyurethane foams used are CFC, HFC and HCFC free.

16
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
8. INSTALLATION
This manual supplies the information necessary for correct unpacking, procedures for positioning and connection to
mains electricity.
8.1 STORAGE AND UNPACKING
The appliance, with or without the packaging, should be carefully stored inside warehouses or in areas away from the
elements and direct sunlight, at a temperature between 0and +40 °C.
The movement of the apparatus should only be carried out using a fork lift of a suitable power for
the weight of the same and manoeuvred by qualified personnel: during such operations
the equipment must be positioned on the supplied pallet.
Unplug the appliance from removing the screws that lock the pallet.
All packaging materials are recyclable and should be disposed of in accordance with local regulations.
Please destroy “plastic” bags to prevent them from becoming hazardous to children (suffocation).
MAX
MIN

17
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
8.2 ENVIRONMENTAL CONDITIONS
ATTENTION
A dry room that can be ventilated is the suitable location for the appliance’s installation. There should be
a good air flow around the compressor/condensing unit.Therefore the area around the unit should not be
obstructed by boxes or other objects.
Place the equipment away from sources of heat (radiators, heaters of any kind, etc.) and far from the
influence of continuous air movement (caused by fans, air conditioning units, etc.). If it is unavoidable to
install near a heat source, use a suitable insulating plate,
Also avoid exposure to direct sunlight; all of this causes the temperature inside the refrigerated
compartment to rise with negative consequences on operation and energy consumption. Do not use the
appliance outdoors and do not leave it exposed to rain.
8.3 INSTALLATION
ATTENTION
It is fundamental to respect the distances indicated (mm) for correct installation of the appliance.
8.4 ELECTRIC CONNECTION
ATTENTION
Check that the network voltage matches the one displayed on the identification plate of the appliance,
and that the power is adequate. Check on the socket that the power supply voltage provides rated voltage
(±10%) when you start up the compressor. The plug should be directly connected to the electrical socket.It
is forbidden to connect the plug to the socket by means of multiple socket extensions or adaptors.
the plant power supply socket must be fitted with a disconnection device from the mains electricity
(dimensioned to the load and in compliance with Standards in force), which guarantees complete
disconnection in category III (3) over-voltage conditions and therefore protects the circuits against earth
faults, overloads and short circuits. Do not route the electricity cable in passageways.
ATTENTION
Earthing is necessary and mandatory by law.

18
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
WARNING
After it is positioned, the appliance must be stabilised
on the floor by adjusting the feet until they do
not rest on the wheels.
8.5 POSITIONING / LEVELLING
WARNING
PIVOTING WHEELS WITH BRAKE (OPTIONAL)
The equipment is set up with pivoting wheels with brakes for easy handling and positioning.
It is absolutely necessary after placement stabilise the equipment on the floor.
WARNING
HEIGHT ADJUSTABLE FEET
The equipment is set up with adjustable leveling feet in height.
It is absolutely necessary after placement to level the equipment on the floor.

19
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
9. MAINTENANCE
The Staff in charge of the appliance must control and respect the expiry dates for maintenance, given in the table
below, calling the authorised Technical After-sales assistance when indicated.
OPERATION FREQUENCY
ORDINARY
EXTRAORDINARY
PERSONNEL
AUTHORISED
Depending on the
Use and Necessity
Monthly
six-month
Annual
CLEANING THE EXTERNAL SURFACES XX
USER
CLEANING THE ACCESSIBLE INTERNAL PARTS
(without the use of tools) XX
CONTROL POWER SUPPLY CABLE,
PLUGS AND / OR ELECTRICAL SOCKETS XX
INTEGRITY CONTROL SEAL XX
FILTER CLEANING CONDENSING UNIT
(whenever present) XX
CLEANING THE DEFROSTING WATER COLLECTION TRAY XX
TECHNICAL
ASSISTANCE
CONDENSER CLEANING XXX
CHECK COMPRESSORE OIL LEVEL
(whenever present) X
AIR TANK DRAINING
(whenever present) XX
CONTROL PNEUMATIC CONNECTIONS
(whenever present) XX
INTEGRITY CONTROL PIPE COOLING SYSTEM XX
INSPECTION OF CABLES
INTERNAL CONNECTIONS AND POWER XX
CLEANING CONDENSATE DRYING SPONGES
(whenever present) XX
LAMP / LED REPLACEMENT
(whenever present) X
CONTROL PANEL REPLACING
(electronic control unit - thermostat - etc) X
REPLACEMENT POWER SUPPLY CABLE, PLUGS AND / OR ELECTRICAL SOCKETS X
ATTENTION
After all maintenance it is mandatory to perform all electric safety tests in agreement
with the IEC EN 50106 Standard.

20
USE AND MAINTENANCE MANUAL
EN
428000843137 3DSHOW
10. FAULTS - TECHNICAL AFTER-SALES ASSISTANCE
If the appliance is not working properly or stops working, before contacting the Customer support centre,
check the following:
THE EQUIPMENT DOES NOT WORK
CAUSE SOLUTION PERSONNEL
AUTHORISED
Blown protective fuse Find the cause of the intervention of the switch first, and then
replace the new fuse. USER
The master switch is open Close the master switch.
The plug is not inserted Insert the plug.
Electrical black-out If the black-out should be prolonged, transfer the product
into an appropriate cold storage container.
THE INTERNAL TEMPERATURE IS NOT LOW ENOUGH
CAUSE SOLUTION PERSONNEL
AUTHORISED
Evaporator/s obstructed completely
by ice Carry out an additional defrosting cycle. USER
Wrong temperature setting Set the appropriate temperature.
The appliance is affected by draughts or is
exposed to direct or reflected sunlight Remove any draughts and prevent any direct or reflected sunlight.
Insufficient air flow for
cooling to the condenser Remove anything that may affect air flow inside the condens- ing unit (paper sheets, cardboard, grids with an insufficient
number of holes, etc.).
Internal fans at standstill or with fans damage TECHNICAL
ASSISTANCE
Internal ventilation is too high
Thermostat / Electrical base unit
not efficient Replace the electronic control board. If the control unit is set up especially for must R290 refriger-
ant, it must only be replaced with an original replacement
from ISA. Replace the temperature probes only after
checking which of the two is not operating efficiently.
Condenser unit blocked by dust
or dirt in general. Clean the condensing unit thoroughly. The air condenser or MAINTENANCE FREE, in particular heavy
environments (e.g. presence of dust, the presence of exces-
sive moisture, oiled vapours etc..) in order to avoid perfor-
mance loss, needs accurate cleaning.
Insufficient refrigerant
load in the cooling system Find the cause behind the lower amounts of coolant and eliminate it.Top up the coolant.If necessary, empty the sys-
tem before topping up.
THE COMPRESSOR DOES NOT START-UP OR OPERATES FOR A FEW MOMENTS
CAUSE SOLUTION PERSONNEL
AUTHORISED
No electric power supply to the appliance Check if there is a power cut.
Close the various switches on the power supply line. USER
Excessively low power voltage Check that the network voltage of the power supply cable is
220V +/- 10%.
Temperature set too high If the temperature is higher than the air temperature
in the display chamber, the compressor will not start.
Set the suited temperature if the current temperature
is not low enough.
Intervention of the maximum pressure
switch (where present) Check the cause of continuous intervention of the maximum pressure switch, which may be: air condenser blocked, con-
densing fan stopped, ambient
temperature too high, pressure switch defective.
TECHNICAL
ASSISTANCE
