IsEasy JC-32AW User manual

PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR FUTURE REFERENCE
WINE COOLER USER MANUAL
Model: JC-32AW

1. Before use, please read this manual carefully.
2. The range of storage temperature is from 46℉ to 66℉, but the test condition
for energy consumption is equal to 63℉ or higher at the ambient Temperature
77℉.
3. Do not use if supply cord is damaged.If damaged,It must be replaced by the
manufacturer or a similarly qualified person in order lo avoid hazard.
4. This appliance is not intended for use by persons （including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safely.
5. Children should be supervised to ensure that they do not play with the
appliance.
6. Ensure the cooler is unplugged before cleaning or if the cooler is not in use.
7. To clean the cooler use only mild detergents or glass cleaning proucts. Never
use harsh detergents or solvents.
8. It is not recommended to use this thermoelectric cooler with an extension
cord or power board.Please ensure that the appliance is plugged directly
into the electrical outlet.
9. When positioning the thermoelectric cooler,ensure that there is at least a
5cm clearance at the sides and a 10cm clearance at the back of the cooler
as this is the main outlet for heat. This will allow for adequate ventilation.
READ ALL INSTRUCTIONS BEFORE USING THIS
When using an electrical appliance, basic precautions should always
be followed, Including the following:
IMPORTANT SAFEGUARDS
02

10. This cooler is designed to store wine bottles.
11. Don’t place hot food or drink into the thermoeectric cooler before cools
down to room temperature.
12. Close the cooler door immediately after putting any items so the inside
temperature will not rise dramatically.
13. Keep appliance away from any heat source or direct sunlight.
14. To fix stably, the appliance must be placed on a flat and solid surface.
Should not be laid on any sot material .
15. Do not place any other appliance on top of the thermoelectric cooler.
16. The Thermoectric cooler is an electrical appliance, To avoid injury or death
from electrical shock, do not operate the thermoelectric cooler with wet
hands, while standing on a wet surface of while standing in Water.
17. Never pull the cord to disconnect it from the outlet. Grasp the plug and pull It
from the outlet.
18. Never lift or carry the Thermoelectric cooler by the cord.
19. Keep the cord away from heated surfaces.
20. This Thermoelectric cooler is for household use only. Any other use will void
the warranty.
21. An empty cooler can be a dangerous attraction to children. If disposing of
the cooler remove gaskets, latches, lids or the entire door from your unused
appliance, or take other action to ensure the cooler is harmless.
22. Do not store food in your thermoelectric cooler as interior temperature may
not get cool enough to prevent spoilage. In summer months or areas of high
humidity, the glass door may build up moisture. To remove the moisture,
wipe it away.
03

1. Keep ventilation openings in the appliance enclosure or in the built-in struc
ture clear of obstruction.
2. Do not use mechanical devices or other means to accelerate defrosting
process, other than those recommended by the manufacturer.
3. Do not damage the refrigerant circuit.
4. Do not use electrical appliance inside the food storage compartments of the
appliance, unless they of the type recommended by the manufacturer.
5. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarity qualified person in order to avoid a hazard.
6. The appliance shall be used for indoor only. Do not use outdoors or in wet
conditions.
7. When disposing of the appliance, do so only at an authorized waste disposal
centre. Do not expose to flame.
8. Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
WARNING
04

• Dark interior
• Soft light inside
• Adjustable feet
• Vibration-free
• Removable shelves
• Thermoelectric cooling
• Adjustable temperature
• Double-glazed glass door
• Variable temperature from 46°F to 66°F
• Capacity of 12 bottles x 750 mL (25 fl. oz.)
FEATURES
• Power requirement: AC 110-127V
60Hz 55W
• Maximum temperature: 18°C +/- 3°C
(66°F +/- 5°F) at 22°C (72°F) temp.
ambient air
• Minimum temperature: 8°C +/- 3°C
(46°F +/- 5°F) at 22°C (72°F) temp.
ambient air
SPECIFICATIONS
STRUCTURE
④
③
①
②
① Lamp cover
② Fan mask
③ Shelf
④ Water tray
INTRODUCTION FOR USE
05

• This unit is designed for free standing installation. Ensure 50mm of space
between the side of the wine cooler and the wall, and 100mm between the back
and the wall.
• Place your wine cooler on a floor strong enough to support it when fully loaded.
To level your wine cooler, adjust the front leveling leg on the bottom of the wine
cooler.
• Make sure it is placed away from the sun and sources of heat (stove, heater,
radiator, etc.). Direct sunlight can affect the acrylic coating and heat sources can
increase the power consumption of the wine cooler. Extremely cold ambient
temperatures can also cause operational problems.
• Avoid placing the device in humid places.
• Plug the wine cooler into an exclusively dedicated grounded wall outlet for its
power supply. Do not under any circumstances cut or remove the third prong
( ground ) from the power cord plug.
INSTALLING YOUR WINE COOLER
• Remove the outer and inner packaging.
• Clean the interior surface with lukewarm water using a soft cloth.
• Brand new plastic products may have peculiar smell, please ventilate for 2-3
days.
BEFORE USING YOUR WINE COOLER
50mm
2 in
50mm
2 in
100mm
4 in
06

1. Insert the power plug into the power socket.Make sure the power socket is
110V AC/60Hz.
2. Allow the empty thermoelectric cooler to operate for approx.one hour. This will
allow the thermoelectric cooler to reach the desired temperature.
3. Temperature Control To control the internal temperature, adjust the
Temperature adjustor Button and Light button.
The Cooler Light Switch controls the lighting on/off within cooler.
The temperature rang for Thermoelectric cooler is 46℉-66℉.
When the temperature is set on one certain point and the temperature inside
reaches this point, the automatic temperature control system begins to work and
the cooling system goes into linear temperature keeping status.
OPERATION GUIDE
If the Thermoelectric cooler's power cord is damaged, have it replaced by a
qualified repair agent.
Any questions regarding electrical supply and/or grounding should be directed to
a licensed electrician or authorized service center.
POWER CORD REPLACEMENT
F
Temperature
display
Temp.Up Temp.Down Light
07

• Short term: Leave the device running if you leave for less than 3 weeks.
• Long term: If the device will not be used for several months, remove all content
and turn off the device. Thoroughly clean and dry the interior of the cabinet. To
prevent mildew, leave the door partially open, blocking it if necessary.
HOLIDAYS
Most power outages recover within a few hours and shouldn't affect your cooler's
temperature if you open the door as little as possible. If the power does not
recover after a long period of time, take care to protect the contents of the device.
POWER OUTAGE
• Turn off the power, unplug the device and empty the contents including the
shelves.
• Wash interior surfaces with warm water and a baking soda solution (2 scoops to
¼ of water).
• Wash the shelves with a mild detergent.
• Wring the sponge or cloth well before cleaning the control parts or any electrical
part.
• Wash the exterior of the appliance with warm water and mild liquid detergent.
• Rinse well and dry everything with a soft, clean cloth.
CLEANING THE APPLIANCE
ENTRETIEN
When the temperature control is adjusted, the temperature will be balance again
in a certain period. The range of the change and the temperature of the
environment determine this period.
08

Customer Service Email: [e-mail]
Website: https://iseasy.store/
Please send relevant videos and pictures to our email address, and attach your
order number. After confirming the problem, we will definitely give you a
satisfactory solution.
WARRANTY
The appliance should be placed in the coolest part of the room, away from
appliances that give off heat and direct sunlight.
ENERGY EFFICIENT TIPS
• Empty the device.
• Screw in the adjustable feet as far as possible.
• Close the door with adhesive tape.
• Take care to secure all loose parts (shelves) inside the unit with adhesive tape.
• Make sure that the device is positioned vertically during transport. Protect the
exterior with a blanket, drop cloth, or the like.
MOVING THE DEVICE
09

PROBLEM POSSIBLE CAUSE SOLUTIONS
The device is not leveled.
The door was knocked over and not
installed correctly.
The gasket is dirty.
The shelves are not well positioned.
The bulb is burnt out.
Circuit breaker tripped or fuse
blown.
Not plugged in.
The light does not
turn on.
Check the temperature setting.
An outdoor environment may
require a higher setting.
The door is opened too often.
The door is not completely
closed.
Door gasket not sealing properly.
The device is not
cold enough.
Circuit breaker tripped or fuse
blown.
Not plugged in.
Replace the broken fuse in your meter
box.
Ensure the cooler is plugged in and the
power socket is turned on.
Place the thermoelectric cooler in good
ventilation and keep any items away
from the fans.
Close the door tightly and do not open
the door too frequently or for a long
period of time.
Keep the cooler away from sunshine or
other heat sources.
The device does
not work.
Be sure to check the leveling of the
device.
The device is not leveled.
Vibes.
The device seems
to make too much
noise.
The door does not
close properly.
TROUBLESHOOTING GUIDE
10
