Iseki SXG15 User manual

LAWN MOWERS:
MOWER DECKS:
COLLECTOR:
SXG15
SCMA40
SBC400X
ISEKI LAWN MOWERS

ISEKI LAWN MOWERS
1
INTRODUCTION
Thank you very much for purchasing an ISEKI lawn mower.
This operation manual provides the information necessary for operating and maintaining the lawn mower safely
and properly.
SAFETY-DANGER,WARNING AND CAUTION
Every time you see the words and symbols shown below in the manual and on the safety
decals, you must take note of their instructions and warning.
DANGER: This symbol together with the words DANGER indicates an imminently hazadous situation that, if
not avoided, will result in VERY SERIOUS INJURY OR EVEN DEATH.
WARNING: This symbol together with the word WARNING indicates a potentially hazardous situation that, if
not avoided, could result in SERIOUS INJURY OR EVEN DEATH.
CAUTION: This symbol together with the word CAUTION is used to indicate a potentially hazardous
situation that,if not avoided,may result in MINOR INJURY.
IMPORTANT: The word IMPORTANT is used to provide instructions or advice in order to let
the lawn mower provide the optimum performance.
NOTE: The word NOTE is used to indicate points of particular interest for more efficient and
convenient repair or operation.
SAFETY INSTRUCTIONS: Essential items which you should observe while operating the
lawn mower
TECHNICAL INSTRUCTION: Items which are necessary to operate, adjust,and service the
lawn mower properly
Before starting to operate the lawn mower for the first time, you should read this operation manual thoroughly
and carefully until you are sufficiently familiar with the operation of the lawn mower in order to do jobs safely and
properly. You are advised to refer to it from time to time to refresh your understanding of the lawn mower.
The manual should be kept in a handy place so you can refer to it when required.
The parts employed in this lawn mower may be modified without notice for better performance and quality
and for safety purposes, which may lead to some inconsistency found on your lawn mower with the contents of this
manual.
The lawn mower is designed to be used on well-kept lawns. Using the lawn mower in other places is not
authorized. Besides, the manufacturer will not pay for any damage caused by unauthorized use and the risk is only
borne by the user. Proper use of the lawn mower also implies that the user follows the operational, adjusting,and
servicing instructions indicated in the operation manual.
When you have any question about your lawn mower, you are always welcome to ask your dealers.

SXG
2
CONTENTS
INTRODUCTION......................................................................................................................................................... 1
I. FOR SAFE OPERATION ......................................................................................................................................... 5
1. HOW TO BE A SAFE OPERATOR................................................................................................................... 5
2. BEFORE STARTING THE LAWN MOWER ..................................................................................................... 5
3. OPERATION OF THE LAWN MOWER ............................................................................................................ 6
4. OPERATION ON A SLOPE .............................................................................................................................. 7
5. DRIVING ON PUBLIC ROADS:........................................................................................................................ 8
6. LOADING ONTO OR UNLOADING FROM A TRUCK: .................................................................................... 8
7. WHEN FILLING WITH FUEL:........................................................................................................................... 9
8. MOUNTING AND DISMOUNTING OF THE MOWER DRIVE SHAFT............................................................. 9
9. LAWN MOWER MAINTENANCE:.................................................................................................................... 9
10. ELECTRICAL SYSTEM.................................................................................................................................... 10
11. TYRES AND WHEELS ..................................................................................................................................... 11
12. BEFORE STORING THE LAWN MOWER....................................................................................................... 11
13. LONG TERM STORAGE.................................................................................................................................. 12
14. CAUTION LABELS & THEIR POSITIONS....................................................................................................... 13
II. WARRANTY AND AFTER-SALE CARE ................................................................................................................ 19
III. SPECIFICATIONS.................................................................................................................................................. 20
LAWN MOWER
IV. NAMES OF MAJOR COMPONENTS.................................................................................................................... 22
V. CONTROLS AND METERS.................................................................................................................................... 23
1. CONTROL PANEL............................................................................................................................................ 23
1.1. STARTER SWITCH................................................................................................................................... 24
1.2. THROTTLE LEVER................................................................................................................................... 24
1.3. MONITOR LAMP ARRAY.......................................................................................................................... 24
1.4. PTO LEVER .............................................................................................................................................. 24
1.5. HOURMETER ........................................................................................................................................... 25
1.6. HEADLIGHT SWITCH............................................................................................................................... 25
2. FENDER (WING) PANEL ................................................................................................................................. 25
2.1. MOWER LIFT LEVER .............................................................................................................................. 25
2.2. FUEL GAUGE ........................................................................................................................................... 25
3. CONTROL PEDALS......................................................................................................................................... 25
3.1. MASTER BRAKE PEDAL.......................................................................................................................... 25
3.2. HST FORWARD TRAVEL PEDAL............................................................................................................. 25
3.3. HST REVERSE TRAVEL PEDAL.............................................................................................................. 25
4. OTHER CONTROLS ........................................................................................................................................ 26
4.1. SAFETY SWITCHES................................................................................................................................. 26
4.2. HEIGHT ADJUST DIAL ............................................................................................................................. 26
VI. PRE-OPERATIONAL ROUTINE INSPECTION .................................................................................................... 27
1. INSEPCTION ITEMS........................................................................................................................................ 27
2. WAY OF INSPECTION AND MAINTENANCE ................................................................................................. 27
VII. OPERATION......................................................................................................................................................... 28
1. BEFORE STARTING THE ENGINE ................................................................................................................. 28
2. STARTING THE ENGINE................................................................................................................................. 28
3. STOPPING THE ENGINE ................................................................................................................................ 29
4. TRAVELLING.................................................................................................................................................... 30
5. STOPPING ....................................................................................................................................................... 31

ISEKI LAWN MOWERS
3
VIII. MAINTENANCE................................................................................................................................................... 32
1. ENGINE OIL LEVEL......................................................................................................................................... 32
2. TRANSMISSION OIL LEVEL............................................................................................................................ 33
2.1. OIL CHECK ............................................................................................................................................... 33
2.2. TRANSMISSION OIL REPLACEMENT..................................................................................................... 33
2.3. AIR BLEEDING ......................................................................................................................................... 33
3. COOLANT LEVEL ............................................................................................................................................ 34
4. FUEL LEVEL..................................................................................................................................................... 34
5. AIR-CLEANER.................................................................................................................................................. 35
6. FUEL STRAINER ............................................................................................................................................. 35
7. INSPECTION OF FUEL HOSES ...................................................................................................................... 35
8. FAN BELT......................................................................................................................................................... 36
9. MAINTENANCE OF MID PTO.......................................................................................................................... 36
10. ADJUSTMENT OF BRAKE .............................................................................................................................. 37
11. NEUTRAL POSITION OF HST......................................................................................................................... 37
12. ADJUSTMENT OF SPEED .............................................................................................................................. 38
13. INSPECTION OF WHEEL TIGHTEN ING BOLTS AND NUTS ........................................................................ 38
14. BATTERY.......................................................................................................................................................... 38
15. TYRE PRESSURE (INFLATION) ..................................................................................................................... 39
16. INSPECTION OF STEERING WHEEL............................................................................................................. 39
17. ENGINE OIL REPLACEMENT ......................................................................................................................... 40
18. ENGINE OIL FILTER REPLACEMENT ............................................................................................................ 40
19. TRANSMISSION OIL REPLACEMENT............................................................................................................ 41
20. INSPECTION AND CLEANING OF AIR-INTAKE OPENINGS ......................................................................... 42
21. CLEANING OF THE RADIATOR...................................................................................................................... 42
22. COOLANT REPLACEMENT ............................................................................................................................ 42
23. INSPECTION OF FUSES AND WIRING.......................................................................................................... 43
24. MAINTENANCE OF HYDRAULIC SYSTEM PARTS ....................................................................................... 44
25. INSPECTION OF SAFETY SWITCHES........................................................................................................... 44
26. FILLING DIAGRAM .......................................................................................................................................... 45
27. PERIODICAL INSPECTION TABLE................................................................................................................. 46
IX. STORAGE ............................................................................................................................................................. 47
X. TROUBLESHOOTING............................................................................................................................................ 49
1. ENGINE............................................................................................................................................................ 49
2. MASTER BRAKE SYSTEM.............................................................................................................................. 51
3. LIFT SYSTEM................................................................................................................................................... 51
4. STEERING SYSTEM........................................................................................................................................ 51
5. HST (HYDROSTATIC TRANSMISSION).......................................................................................................... 52
6. ELECTRICAL ACCESSORIES......................................................................................................................... 52
XI. ELECTRIC WIRING............................................................................................................................................... 53
MOWER DECKS
I. NAMES OF MAJOR COMPONENTS...................................................................................................................... 55
II. ATTACHING AND DETACHING MOWER DECK................................................................................................... 56
1. ATTACHING THE MOWER DECK................................................................................................................... 56
2. DETACHING THE MOWER DECK .................................................................................................................. 57
III. MOWER OPERATION ........................................................................................................................................... 58
1. BEFORE OPERATION..................................................................................................................................... 58
2. CUTTING HEIGHT ADJUSTMENT .................................................................................................................. 58
3. STARTING MOWING OPERATION ................................................................................................................. 59
4. CLEANING A MOWER DECK AND CHUTE CLOGGED WITH GRASS.......................................................... 59
5. EMERGENCY STOP........................................................................................................................................ 60
6. STOPPING MOWING OPERATION................................................................................................................. 61
7. EFFICIENT MOWING....................................................................................................................................... 61

SXG
4
IV. INSPECTION AND MAINTENANCE OF MAJOR PARTS .................................................................................... 62
1. INSPECTION AND REPLACEMENT OF BEVEL GEAR CASE....................................................................... 62
2. INSPECTION & REPLACEMENT OF BLADES ............................................................................................... 63
3. INSPECTION OF GAUGE WHEELS................................................................................................................ 64
4. INSPECTION OF ROLLERS............................................................................................................................ 64
5. CLEANING OF MOWER DECK ....................................................................................................................... 64
6. FILLING DIAGRAM .......................................................................................................................................... 65
7. PERIODICAL INSPECTION TABLE................................................................................................................. 66
V. STORING THE MOWER......................................................................................................................................... 67
VI. TROUBLESHOOTING........................................................................................................................................... 68
COLLECTOR
I. NAMES OF MAJOR COMPORNENTS................................................................................................................... 70
1. SBC400X-LAE (LOW DUMP COLLECTOR WITH ASSIST CYLINDER)......................................................... 70
2. SBC400X-LE (LOW DUMP COLLECTOR WITH MANUAL)............................................................................ 70
II. DETACHING AND ATTACHING COLLECTOR...................................................................................................... 71
1. DETACHING THE LOW DUMP COLLECTOR WITH ASSIST CYLINDER...................................................... 71
2. ATTACHING THE LOW DUMP COLLECTOR WITH ASSIST CYLINDER....................................................... 71
3. DETACHING THE LOW DUMP DOLLECTOR WITH MANUAL DUMP ........................................................... 71
4. ATTACHING THE LOW DUMP COLLECTOR WITH MANUAL DUMP............................................................ 71
III. COLLECTOR OPERATION................................................................................................................................... 72
1. BEFORE OPERATION..................................................................................................................................... 72
2. ADJUSTING THE GRASS LIMIT SENSOR ..................................................................................................... 72
3. INSPECTION BEFORE OPERATION.............................................................................................................. 72
IV. INSPECTION AND MAINTAINANCE OF MAJOR PARTS ................................................................................... 73
1. FILLING DIAGRAM .......................................................................................................................................... 73
2. PERIODICAL INSPECTION TABLE................................................................................................................. 74
V. STORING THE COLLECTOR................................................................................................................................. 75
VI. TROUBLESHOOTING........................................................................................................................................... 76
This manual explains about several types of the lawn mowers and mower decks as listed below. Please
confirm the type of yours by referring to the name plate.
Lawn mowers Mower decks Collectors
Seat Cutting width Dump system
SXG15E ×SCMA 40 1016 mm (40") SBC 400XLE Manual
SXG15SE ○SBC 400XLAE Assist cylinder
All information, illustrations, and specifications contained in this manual are based on the latest information available
at the time of publication

I. FOR SAFE OPERATION
5
I. FOR SAFE OPERATION
1.5. When operating, adjusting, or servicing the
lawn mower, always wear substantial shoes and
long trousers. Avoid wearing long loose clothes,
accessories or letting long hair hang loose, which
could be caught in rotating parts or on projections.
1.6. When you let someone else operate the lawn
mower, instruct this person how to operate the
lawn mower and also advise the reading of this
manual. Never lend the mower to anyone who
cannot understand the contents of this manual
and safety labels. Operation of the lawn mower
by a person unfamiliar with the lawn mower may
lead to an unexpected accidents.
1.7. Never permit the following persons to operate the
lawn mower:
- Persons not properly trained to operate the lawn
mower
- Persons who cannot understand the instructions
mentioned in this operation manual and on the
caution labels
- Pregnant women
- ChildrenLocal regulations may restrict the age of
the operator.
1.8. Inspect the lawn mower periodically. If not, this
may not only shorten the lawn mower's service
life but also make safe and efficient operation
impossible.
2. BEFORE STARTING THE LAWN MOWER
2.1. Set up an operation plan with sufficient time
allowance. A tight plan may result in unexpected
accidents. Especially when operating the lawn
mower under extremely hot, cold, or humid
circumstances, set up an operation schedule or
method which will ensure operational safety.
1. HOW TO BE A SAFE OPERATOR
1.1. Before starting the lawn mower for the first
time, read this manual thoroughly and carefully.
Especially abide by the instructions for safe
operation. If you do not, it may result in bodily
injuries.
1.2. Pay attention to the caution labels on the lawn
mower, mower deck and collector, and observe
the instructions they give to avoid physical
injuries.
1.3. Be sure to use necessary protective devices such
as headgear, safety glasses, safety shoes, ear
plugs, gloves, etc.
1.4. If you have consumed intoxicating beverages,
are drowsy from medication, ill, or tired, never
operate the lawn mower.

SXG
6
2.2. Thoroughly inspect the area where the lawn
mower is to be used and remove all stones,
sticks, wires, and other foreign objects.
Otherwise, they will be hit by the mower blades,
which may lead to serious accidents.
2.3. The lawn mower is equipped with various safety
systems. All safety shields, guards, and covers
should always be in position and functioning
properly.
2.4. Be sure to operate the lawn mower equipped with
a standard mower deck and collector. Never mow
grass without the collector, or the lawn mower
scatters grass, stone and other flying debris,
which is very dangerous.
2.5. Before starting the engine, make sure that
everything is safe around the lawn mower and all
control levers are in the neutral or off positions,
the parking brakes applied, and the PTO lever
in the OFF position. Otherwise, unexpected
accidents may occur.
2.6. Start the engine with the starter switch only.
Never attempt to start the engine by shorting the
terminals, or the lawn mower may move abruptly,
and result in unexpected accidents.
2.7. Never start the engine in a closed place. Exhaust
fumes contain poisonous carbon monoxide, so
sufficient ventilation should be provided when
starting the engine indoors.
2.8. Make sure if safety around the lawn mower and
move slowly when starting. Abrupt starting may
cause unexpected accidents.
2.9. Become familiar with the operation, particularly,
the stopping of the lawn mower. You should be
skilful enough to be able to stop the lawn mower
at will.
2.10. When your lawn mower is equipped with an
inplement other than a standard mower deck
and collector, never fail to ask your dealers about
machine balance. Always follow their advice.
2.11. Keep in mind that the operator or user is
responsible for the accidents or hazards caused
by the lawn mower to other people or their
property.
2.12. Especially before starting the mower, be sure
to perform advised preoperation inspections
especially on the brakes and inspect visually
to see that the blade and blade tightening nuts
are not worn, damaged or loose. Replace worn
or damaged blade and nuts as an assembly to
preserve blade balance. Otherwise, poor braking
or scattered broken blades may result, which is
very dangerous.
2.13. Machine weight balance is a very important
factor for safe operation. When your machine
is equipped with an implement other than a
standard mower deck and collector, never fail to
ask your dealers about machine balance. Always
follow their advice.
3. OPERATION OF THE LAWN MOWER
3.1. During operation, never allow anyone, especially
children, and animals to be in the vicinity of the
lawn mower, especially near the discharge of the
mower deck.
3.2. When you are working with coworkers, be sure
to alert them by signalling before you take a new
action.
3.3. Be sure to mow only in daylight. Mowing in the
dark may cause unexpected accidents.
3.4. When operating the lawn mower, you should be
seated in the operator's seat properly, hold the
steering wheel by both hands, and look in the
direction in which the lawn mower advances.
Avoid looking aside or holding the steering wheel
by one hand during operation.
3.5. Always be sure to operate the lawn mower from
the driver's seat. Never attempt to get on or off
the lawn mower while it is travelling.
3.6. Never allow other persons to get on the lawn
mower during operation.
3.7. When turning the lawn mower, slow down
sufficiently. Turning at high speed may cause the
lawn mower to turn over.
3.8. Never attempt to depress the diflock pedal while
turning around the lawn mower. Turning with the
dif-lock on may cause the lawn mower to turn
over.

I. FOR SAFE OPERATION
7
3.9. When reversing the lawn mower, make sure of
the safety conditions behind.
3.10. Never operate the lawn mower in terrain where
there are ditches, holes, or steps easy to
collapse. In such a place, the lawn mower could
turn over or fall.
3.11. Befor making access to moving parts, stop the
engine, and keep your hands, feet, clothing,
accessories and etc. away so as not to be caught
in the moving parts of the lawn mower
3.12. Always pay attention in lawn of the lawn mower
to avoid obstacles such as corner stones, stubs,
sprinkler heads, etc. When there is an obstacle
that cannot be removed, provide a marker flag
as a warning to keep away from it when mowing.
When approaching the obstacle, slow down the
lawn mower sufficiently to avoid it.
3.13. Never rest a foot on the brake pedal. If so, the
brakes wear rapidly, which may lead to serious
accidents.
3.14. Adjust the cutting height with the gauge wheels
in accordance with the condition of the ground
surface at the working site. Mowing on rough
ground with low cutting height may cause
the blades to hit soil or stones, which is very
dangerous.
3.15. After striking a foreign object, stop the engine
and inspect the lawn mower and the mower deck
for damage and be sure to make repairs before
mowing again.
3.16. Be sure to keep the grass discharging part
clean. A clogged discharging part may cause the
discharge cover to open, resulting in scattering of
grass and stones, which is very dangerous.
3.17. Never allow grass or leaves to accumulate
around heated parts such as the engine and the
muffler, or this may cause a fire.
3.18. Before moving the lawn mower to another place,
be sure to stop the mower blades and lift up the
mower deck. Otherwise, they may hit stones and
scatter them around, which is very dangerous.
3.19. When driving over a levee or a step, stop the
mower blades, lift up the mower deck, and move
the lawn mower straight to the levee and make it
climb over slowly. Avoid climbing over a levee too
high, or the lawn mower may fall sideways or turn
over.
3.20. Before stopping the engine, be sure to lower the
mower deck onto the ground, apply the parking
brakes, and shift the PTO lever to the OFF
position.
3.21. Before leaving the lawn mower, stop the engine,
lower the mower deck onto the ground, draw the
engine key, apply the parking brakes, and chock
the wheels. The lawn mower should be parked in
a place which is flat and spacious, and has hard
surface in order to avoid unexpected moving of
the lawn mower.
3.22. Never attempt to use the lawn mower to draw an
implement or a trailer. It is not designed to draw a
load.
3.23. Never attempt sudden starting and stopping,
otherwise it causes not only damaged lawn but
deterioration of durability of lawn mower.
4. OPERATION ON A SLOPE
We cannot recommend this lawn mower be operated on
a slope, but advise you to use a lawn mower designed
for slope operation. On a slope, various elements of
operation such as slope angles, ground conditions, way
of operation, grass conditions, etc. may lead to slipping,
or over-turning of the lawn mower, which may result in
bodily injury.
If the lawn mower has to be used on a slope, remember
there is on such thing as a "safe" slope. Never use it on
a slope of more than "12°", and be sure to abide by the
following instructions. Even if using it on a slope of less
than "12°", be sure to abide by the following instructions.
･ A slope angle of 12°s specified with the
lawn mowers equipped with the attachments
mentioned respectively.
- The lawn mower is not equipped with any
attachments or a cabin than a standard mower
deck and collector.
- The lawn mower is equipped with a standard
mower deck and collector.
When your lawn mower is equpped with an
imprement other than a standard mower deck
and collector, never fail to ask your dealers about
machine balance. Always follow their advice.

SXG
8
4.1. Be sure to wear a helmet during operation.
4.2. Operate at sufficiently low speeds.
4.3. When turning, be sure to slow down sufficiently.
4.4. Avoid sudden starting and stopping.
4.5. Operate the lawn mower up and down across the
contour lines of the hill. Never operate along the
contour lines.
4.6. Never perform mowing operation on wet grass.
4.7. Never park the lawn mower on a slope.
4.8. Pay attention to other possible causes of danger
which could lead to overturning, etc.
5. DRIVING ON PUBLIC ROADS:
5.1. This lawn mower cannot be driven on a public
road without authorization by a local goverment
agency. etc. Therefore it may be illegal for the
lawn mower not only to travel on but also to cross
a public road.
5.2. When transporting the lawn mower on a public
road, load it on a truck.
6. LOADING ONTO OR UNLOADING FROM A TRUCK:
6.1. When loading the lawn mower onto a truck, turn
off the truck's engine, apply the parking brakes
to the truck, and chock the wheels to avoid
unexpected moving of the truck.
6.2. Pay sufficient attention to safety conditions
around the lawn mower and have it guided by
someone to assist the operator. Never allow other
persons to approach the lawn mower, especially
in lawn of or behind it.
6.3. When loading the lawn mower onto a truck, lift up
the mower deck fully and reverse it straight back
at sufficiently low speeds. Drive it forward when
unloading it from the truck.
6.4. If the engine stalls unexpectedly on the ramps,
depress the brake pedals immediately and roll
the lawn mower to the ground by releasing the
brakes gradually. Then start the engine and try
again.
6.5. Use ramps with the same or better specifications
mentioned below. When the lawn mower is
equipped with the attachments other than those
included in the specifications mentioned below,
ask your dealers for advice.
Specification of the ramps for the SXG15
･ Length............More than 4 times the height of the
platform of the truck.
･ Width(effective width) .................more than 30 cm
･ Required quantity......................................2 ramps
･ Capacity (one ramp) ..................more than 750 kg
･ Ramps should have anti-skid surfaces.
･ The above specifications are effective with the
lawn mower with the following conflgurations.
- The lawn mower is not equipped with any
attachments or a cabin than a standard mower
deck and collector.
- The lawn mower is equipped with a standard
mower deck and collector.

I. FOR SAFE OPERATION
9
6.6. Park the truck on hard level ground. Hook the
ramps securely on the platform of the truck with
the top of the ramp level with the platform.
6.7. Drive the lawn mower carefully at the moment
the lawn mower moves from the ramps onto the
platform, for it changes angles abruptly.
6.8. When the lawn mower is loaded on the truck, stop
the engine, apply parking brakes, and withdraw
the starter key, chock the wheels, and rope it
securely to the truck. Refrain from unnecessary
abrupt starting, stopping, and turning during
transportation, or the lawn mower may shift
position on the truck, which is very dangerous.
7. WHEN FILLING WITH FUEL:
7.1. Never smoke while refilling with fuel, nor allow
any open flames near the lawn mower.
7.2. Never open the fuel tank cap while the engine is
running or while it is still hot after operation. Wait
until the engine cools down sufficiently.
7.3. Provide adequate measures to prevent fuel from
spilling when pouring it into the fuel tank. Spilt
fuel should be wiped off completely.
7.4. Avoid refueling indoors. If this is inevitable,
provide sufficient ventilation.
7.5. Replace the fuel tank and container caps
securely.
7.6. Store fuel in containers specifically designed for
this purposes.
8. MOUNTING AND DISMOUNTING OF THE MOWER
DRIVE SHAFT
The mower gear box is driven through a drive shaft with
universal joints from the lawn mower. When connecting
or disconnecting the shaft, follow the next instructions.
8.1. Lower the mower deck onto the gournd, stop
the engine, draw the engine key, and apply the
parking brakes before mounting or dismounting
the drive shaft.
8.2. Shift the PTO lever to the OFF position( ).
8.3. Make sure that the PTO shaft and mower blades
stop completely.
8.4. The drive shaft should be mounted or dismounted
at the lawn mower side. Never leave the shaft
connected only at the lawn mower side. If the
PTO shaft be driven unexpectedly, the shaft will
be swung around and damage the lawn mower or
cause serious accidents.
9. LAWN MOWER MAINTENANCE:
9.1. Never start the engine in a closed place. Exhaust
fumes contain poisonous carbon monoxide, so
sufficient ventilation should be provided when
starting the engine indoors.
9.2. Be sure to wear safety glasses and gloves when
servicing the lawn mower.
9.3. When servicing the lawn mower or mounting or
dismounting the mower deck, place the lawn
mower on level, hard ground.
9.4. Service the lawn mower in a place sufficiently
illuminated, or darkness may cause unexpected
accidents.
9.5. When servicing the lawn mower or mounting or
dismounting the mower deck, stop the engine
and remove the engine key and apply the parking
brakes.
9.6. The engine, muffler, radiator, etc. are very hot just
after operation, so wait until those heated parts
cool down sufficiently to avoid burns.
9.7. Never remove the radiator cap while the engine
is hot or running. Wait until the engine cools
down and then relieve the radiator pressure by
releasing the radiator cap. Carelessly pouring

SXG
10
cooling water into the heated radiator can cause
serious damage to the radiator and the engine.
Careless removal of the radiator cap can cause
serious injury because of superheated water
vapor.
9.8. Before servicing the lawn mower, be sure to shift
the PTO lever to the OFF position and make sure
that the mower blades have stopped completely.
Rotating blades may cause serious accidents.
9.9. When servicing the lawn mower, use proper
tools. Using makeshift tools may lead to injuries
or poor service, which may result in unexpected
accidents during operation.
9.10. When removing a tyre, chock other tyres and
support the lawn mower securely. When installing
tyres, be sure to tighten the wheel nuts to the
specified torque. Loose nuts may cause serious
accidents.
9.11. When servicing the mower blades, pay sufficient
care so your hands or fingers are not cut by them.
As the three blades are driven by one belt, turning
one blade will cause the other blades to turn.
9.12. Never step on the mower deck, or the mower
deck may be damaged or deformed, which may
lead to breakdown or accidents.
9.13. A first aid kit and a fire extinguisher should be kept
in a place always in instant access.
9.14. Avoid high-pressure fluids. Escaping fluid under
pressure can penetrate the skin and cause
serious injury, so keep hands and body away
from pin holes and nozzles ejecting such fluids.
Be sure to consult your dealer about the hydraulic
and fuel injection system troubles.
9.15. If any hydraulic fluid is injected accidentally into
the skin, it must be removed within a few hours
by a doctor familiar with this type of injury.
9.16. Never allow grass or leaves to accumulate
around heated parts such as the engine and the
muffler, or this may cause a fire.
9.17. Be sure to reinstall the removed parts in place.
Never attempt to start the engine with any parts
removed.
9.18. Never attempt unauthorized modification of the
lawn mower as this could be very hazardous.
Damaged or worn parts should be replaced
with ISEKI genuine spare parts. Unauthorized
parts may cause breakdown of the lawn mower,
accidents, and ISEKI warranty to expire.
Parts code of blade Punched ID
SCMA 40 Left 8670-306-001-00 8670 A
Right 8670-306-002-00 8670 B
9.19. Keep all nuts, bolts and screws tight to be sure
that the equipment is in safe working condition.
10. ELECTRICAL SYSTEM
10.1. Before servicing the electrical system, be sure
to stop the engine, lower the mower deck on the
ground, draw the starter key, shift the PTO lever
to the OFF position, and apply parking brakes.
10.2. Before inspecting the connections of the electrical
system, be sure to disconnect the negative
terminal of the battery to avoid short circuits and
electric shocks.
(1) Negative cord
10.3. Loose connections, terminals, and damaged
wiring should be repaired as soon as possible.
They will not only deteriorate the performance of
electric parts but also may cause short circuits,
leading to fires.
10.4. The surroundings of the wiring and the battery
should be kept clean, or accumulated grass or
chaff may catch fire.
10.5. Never smoke nor allow any open flames nearby
or sparks, which may be caused by short
circuits during servicing the battery. The battery
generates explosive gases(hydrogen and oxygen)
during charging, so the battery should becharged
in a place well ventilated to let such explosive
gases diffuse smoothly. Otherwise settled gases
may catch fire.

I. FOR SAFE OPERATION
11
10.6. Battery electrolyte is diluted sulphuric acid, so it
is corrosive and naturally poisonous. Never allow
acid to contact skin or clothing, or it may cause
burns. Always wear a face shield to avoid acid
getting in eyes. If acid contacts skin or clothing,
wash off immediately with clean water. If acid
contacts eyes, flush immediately with clean water
and get medical attention.
10.7. Before servicing and mounting or dismounting
the battery, stop the engine, draw the starter key,
and apply the parking brakes. Otherwise, electric
parts may be damaged.
10.8. When disconnecting the battery, disconnect
the negative(-) cable first, while connect the
positive(+) cable first when connecting the
battery. Wrong order of disconnecting or
connecting the battery will cause sparks, which is
very dangerous.
(1) Negative cord (2) Positive cord
10.9. When using booster cables, observe the following
instructions to avoid accidents:
･ Remove the filler caps of battery cells ahead of
time to lessen explosive power of gases if they
should catch fire.
･ Before connecting booster cables, be sure to stop
the engine.
･ Use booster cables of sufficient capacity, or they
may be heated or burnt out.
11. TYRES AND WHEELS
11.1. Be sure to keep tyre pressures at the levels
specified in this manual. Excessively high tyre
pressure may result in explosion, which may lead
to physical accidents.
11.2. If a cut is found in a tyre and the cut reaches the
cords, do not use it. Such a tyre may explode.
11.3. Before replacing or repairing tyres, tubes, or
rims, consult your dealers ahead of time. Such
operation should be performed by trained
mechanics.
12. BEFORE STORING THE LAWN MOWER
12.1. After opeation, be sure to close the fuel cock
to prevent fuel from spilling, as spilled fuel may
catch fire.
12.2. Never allow grass or leaves to acoumulate
around heated parts such as the engine and the
muffler, or this may cause a fire.
12.3. Be sure to remove the ignition key to prevent
unexpected accidents caused by engine starting
by untrained persons or children.
12.4. When storing the lawn mower with the mower
deck attached, be sure to lower the mower deck
on the ground. Otherwise manipulation of the lift
lever by untrained person or children may cause
unexpected accidents.
12.5. Store the lawn mower in a place provided with

SXG
12
sufficient illumination. Inspection and moving
of the lawn mower in a dark place may lead to
unexpected accidents.
12.6. When the lawn mower is to be stored in a closed
place like a garage or a barn, provide sufficient
ventilation for exhaust gases. Exhaust fumes can
be lethal.
12.7. To avoid fire hazard, keep the engine, muffler,
battery, and fuel storage area free of grass,
leaves, or excessive grease.
12.8. Never cover a hot lawn mower just after operation
with a tarpaulin or the like, or the heated engine
and related parts may cause a fire.
13. LONG TERM STORAGE
13.1. Before storing the lawn mower for long period
of time, disconnect the battery cables to prevent
them, in case they are gnawn by rats, from
causing a short circuit, which may lead to a fire.
When disconnecting the battery, disconnect
the negative(-) cable first, while connecting
the positive(+) cable first when connecting
the battery. Wrong order of disconnecting on
connecting the battery will cause sparks, which is
very dangerous.

I. FOR SAFE OPERATION
13
14. CAUTION LABELS & THEIR POSITIONS
･Caution labels on the lawn mower and the mower deck and the lawn collector
The following labels are stuck on the lawn mower and mower deck. You should of course read the caution
instructions in the manual. But never fail to read the labels on the lawn mower and mower deck as well. Their
respective code numbers are also mentioned below, so order them from your dealer if any of them are lost or
damaged.
On the lawn mower
㪘
㪙
㪚
㪙
㪘㪚
㪈
㪉
㪊
㪋
㪌
㪈㪇
㪍
㪎
㪏
㪐

SXG
14
(1) Caution label
(Code No.1705-904-004-0)
a. Read the manual thoroughly.
b. Shut off the engine and remove the starter key
before servicing or repairing the machine.
c. The negative terminal of the battery should be
disconnected before servicing or repairing the
machine.
d. When leaving the machine, Apply the parking
brakes, Shut off the engine, and Remove the engine
key.
e. Risk of injury
Keep all safety devices such as guards, safety
switches, etc in place and working properly.
f. Risk of injury
Remove objects from around the machine that
could be thrown by blades and keep people away
from the machine before starting the machine.
g. Risk of running over a person
Watch behind before reversing the machine and
keep people from around the machine before
starting the machine.
h. Risk of running over a person
Don't allow any other person to ride on a wheel
fender or any place other than the driver's seat of
the machine.
i. Risk of overturning or crushing
Do not operate the machine in any place where it
could slip or tip over.
j. Rist of overtuning or crushing
Avoid operating the machine on a slope of over 12°
(2) Battery label
(Code No. 1705-904-002-0)
a. Avoid sparks and flames.
b. Wear a eye protection gear.
c. Keep battery out of reach of children.
d. Beware of sulphuric acid.
e. Beware of explosion.
f. Read the manual thoroughly.
Handle the battery carefully:
- Improper handling of the battery may lead to
explosion. Never short the poles. Keep away from
sparks or flames. When charging or using, provide
sufficient ventilation. Watch out when using booster
cables.
- Battery electrolyte(sulphuric acid) may cause
blindness or burns. Avoid allowing electrolyte to
contact eyes, skin or clothing. In the event of an
accident flush area immediately with plenty of water.
If acid gets into the eyes, rinse with plenty of water
any get medical attention.
- Never use the battery with the electrolyte level
below the "LOWER" limit, or it may explode.
- Never replenish exceeding the "UPPER" limit or the
electrolyte may spill out.
(3) Fuel label
(Code No. 1705-904-001-0)
Use diesel fuel only. No open flame.
(4) Belt caution label
(5) (Code No. 8595-901-006-0)
(6)
Stay clear of the belt while it is running.

I. FOR SAFE OPERATION
15
(7) Hot-part caution label
(Code No. 8595-901-007-0)
Stay clear of the heated parts while they are hot.
(8) Fan caution label
(Code No.1705-902-006-0)
Stay clear of the fan while it is running.
(9) Starter caution label
(Code No. 1705-902-007-0)
Start engine only with key from seat.
(10) Radiator caution label
(Code No. 1705-902-008-0)
Hot pressurized system. Do not open cap while
radiator is hot.

SXG
16
On the mower deck
(1) Hot-part caution label
(Code No. 8595-901-007-0)
Stay clear of the heated parts while they are hot.
(2) Danger label
(Code No. 2500-901-014-3D)
Stay clear of the mower blades while the engine
running.
(3) PTO label
(Code No. 8654-901-002-0)
Stay clear of the PTO shaft while the engine running.
䋱䋲
䋳
䋴

I. FOR SAFE OPERATION
17
(4) Maintenance label
(Code No. 1593-901-015-0)
Shut off the engine and remove the starter key
before performing maintenance or repair work.
･Maintenance of the caution labels
- The labels should always be clearly seen, that is,
nothing should obscure them.
- When they have become dirty, wash them with soapy
water and wipe off with soft cloth.
- If any of them are torn or lost, order new labels from
your dealer.
- A new label should be placed in the same place where
the old one was located.
- When sticking on a new label, clean the place to
enable the label to stick and squeeze out all air
bubbles trapped under it.
- When replacing a part with a caution label stuck on, a
new caution label should also be ordered.

SXG
18
On the collector
(1) Link Caution label
(Code No. 8664-905-003-0)
Stay clear of the collector frame while the container
dumping.
(2) Discharge label
(Code No. 8595-901-005-0)
Stay away of the discharge opening of the mower
desk because stones or other hard objects ejected
from the mower may hit you.
(3) Maintenance label
(Code No. 1593-901-015-0)
Shut off the engine and remove the starter key
before performing maintenance or repair work.
㪈
㪉
㪘
㪘
䋳

II. WARRANTY AND AFTER-SALE CARE
19
II. WARRANTY AND AFTER-SALE CARE
WARRANTY
On the warranty of this lawn mower and mower deck, please ask to your dealer.
AFTER-SALE CARE
As for breakdown or questions about the lawn mower and mower deck, consult with your dealers identifying the
model and serial number of your lawn mower.
Lawn mower
(1) Model name and serial number
(2) Engine model name and serial number
Mower deck
(3) Model name and serial number
Collector (SBC400X)
(4) Model name and serial number
