Iseki SZ330 SSM60 User manual

ISEKI ZERO TURN MOWER
ZERO TURN MOWER:
MOWER DECKS:
SZ330SZ330
SSM60 & SSM72

1
INTRODUCTION
INTRODUCTION
Thank you very much for purchasing an ISEKI ZERO TURN MOWER.
This operator’s manual provides the information necessary for operating and maintaining
your tractor safely and properly. The contents are mainly composed of the following two
items:
Safety instructions: Essential items which you should observe while
operating the tractor
Technical instructions: Essential items which you should observe while
operating the tractor
Before starting to operate the machine for the first time, you should read this operation man-
ual thoroughly and carefully until you are sufficiently familiar with the operation of the
machine to do jobs safely and properly. The manual should be kept in a handy place so you
can refer to it when required. You are advised to refer to it from time to time to refresh your
understanding of the machine.
Your dealer has performed the pre-delivery service on your new machine.
He will discuss with you the operating and maintenance instructions gives in this manual,
and instruct you in the proper and varied applications of this machine. Call on him at any
time when you have a question, or need equipment related do the use of your machine.
Paragraphs in the manual and labels on the machine which are
accompanied by a caution particularly important information about
safe operation to avoid accidents. You should always keep precau-
tions in mind and follow them during operation.
Be sure to wear
personnel protective equipment
during operation
In some of the illustrations used in this operation manual, panels or
guards may have been remove for clarify. Never operate the machine
with these panels and guards removed.
If the removal of a shield is necessary to make a repair, it must be
replaced before operation
All information, illustrations, and specifications contained in this manual are based on the lat-
est information available at the time of publication. The right is reserved to make changes at
any time without notice.

2
ZERO TURN MOWER
INTRODUCTION .......................................................... 1
TABLE OF CONTENTS ............................................... 2
ABBREVIATION LIST................................................... 4
UNIVERSAL SYMBOLS ............................................... 5
SAFETY FIRST ............................................................. 6
1. FOR SAFE OPERATION ......................................... 7
1. HOW TO BE A SAFE OPERATOR ..................... 7
2. BEFORE STARTING
2. THE ZERO TURN MOWER ................................. 8
3. OPERATION OF THE ZERO TURN MOWER ..... 10
4. OPERATION ON A SLOPE.................................. 11
5. DRIVING ON PUBLIC ROADS:............................ 11
6. LOADING ONTO OR UNLOADING FROM A
TRUCK: ................................................................ 12
7. WHEN FILLING WITH FUEL:............................... 14
8. MOUNTING AND DISMOUNTING OF THE
MOWER DRIVE SHAFT ...................................... 14
9. ZERO TURN MOWER MAINTENANCE: ............. 14
10.MAINTENANCE OF THE ELECTRIC SYSTEM... 16
10.1.TO MAINTAIN ELECTRIC WIRING ............. 16
10.2.TO HANDLE THE BATTERY ....................... 16
10.3.TO HANDLE BOOSTER CABLES ............... 17
11. TYRES AND WHEELS ........................................ 17
12. BEFORE STORING THE ZERO TURN
MOWER.................................................... 18
13. LONG TERM STORAGE............................ 18
14. CAUTION LABELS & THEIR POSITIONS ......... 19
2. WARRANTY AND AFTER-SALE CARE ................. 25
WARRANTY ............................................................. 25
AFTER-SALE CARE................................................. 25
Zero turn mower .................................................. 25
Mower deck ......................................................... 25
SUPPLY LIMIT OF SPARE PARTS ......................... 25
3. SPECIFICATIONS .................................................... 26
ZERO TURN MOWER.............................................. 26
ACCESSORIES........................................................ 27
4. NAME OF MAJOR COMPONENTS ......................... 28
5. CONTROLS AND METERS ..................................... 29
1. CONTROL PANEL ............................................... 29
1.1. STARTER SWITCH...................................... 30
1.2. THROTTLE LEVER...................................... 30
1.3. MONITOR LAMP ARRAY ............................ 30
1.4. PTO SWITCH............................................... 31
1.5. HOURMETER .............................................. 31
1.6. LIFT LEVER ................................................. 31
1.7. FUEL GAUGE .............................................. 31
1.8. CUTTING HEIGHT ADJUST DIAL............... 31
2.1.BRAKE PEDAL.............................................. 32
2.2.PARKING BRAKE LEVER ............................ 32
2.3 DRIVE CONTROL LEVER ............................ 32
3. OTHER CONTROLS ............................................ 33
3.1. SAFTY SWITCHES...................................... 33
6. PRE-OPERATIONAL ROUTINE INSPECTION ....... 34
1.INSPECTION ITEMS............................................. 34
2.WAY OF INSPECTION AND MAINTENANCE...... 34
7. OPERATION ............................................................. 35
1. BEFORE STARTING THE ENGINE..................... 35
2. STARTING THE ENGINE..................................... 36
3. STOPPING THE ENGINE .................................... 37
4. TRAVELLING ....................................................... 38
5. STOPPING ........................................................... 39
6. PTO SWITCH ....................................................... 39
8. MAINTENANCE ....................................................... 40
1. ENGINE OIL LEVEL............................................. 41
2. HST OIL LEVEL.................................................... 42
3. COOLANT LEVEL ................................................ 42
4. FUEL LEVEL ........................................................ 43
5. AIR-CLEANER...................................................... 44
6. FUEL STRAINER ................................................. 45
7. INSPECTION OF FUEL HOSES.......................... 45
8. FAN BELT............................................................. 45
9. ADJUSTMENT OF BRAKE .................................. 46
10. ADJUSTMENT NEUTRAL OF HST CONTROL
LEVER................................................................ 47
11. ADJUSTMENT OF STRAIGHT DRIVE .............. 47
12. ADJUSTMENT PHASE OF DRIVE CONTROL
LEVER................................................................ 48
13. ADJUSTMENT CLEARANCE OF DRIVE CON-
TROL LEVER ..................................................... 48
14. INSPECTION OF WHEEL TIGHTEN ING BOLTS
AND NUTS ......................................................... 48
15. BATTERY ........................................................... 49
16. TYRE PRESSURE (INFLATION) ....................... 50
17. ENGINE OIL REPLACEMENT ........................... 50
18. ENGINE OIL FILTER REPLACEMENT.............. 51
19. REAR AXLE GEAR OIL REPLACEMENT.......... 52
20. REPLACEMENT OF HYDRAULIC OIL SUCTION
FILTER ............................................................... 52
21. INSPECTION AND CLEANING OF AIR-INTAKE
OPENINGS......................................................... 52
22. CLEANING OF THE RADIATOR........................ 53
23. COOLANT REPLACEMENT .............................. 53
24. INSPECTION OF FUSES AND WIRING............ 54
25. MAINTENANCE OF HYDRAULIC SYSTEM
PARTS ............................................................. 55
26. INSPECTION OF SAFETY SWITCHES........... 55
TABLE OF CONTENTS

3
TABLE OF CONTENTS
9. STORAGE ................................................................ 58
10. TROUBLESHOOTING ........................................... 59
1. ENGINE................................................................ 59
2. BRAKE SYSTEM.................................................. 61
3. LIFT SYSTEM....................................................... 61
4. DRIVE CONTROL SYSTEM ............................... 62
5. HST (HYDROSTATIC TRANSMISSION)............. 62
6. ELECTRICAL ACCESSORIES............................. 63
1. NAME OF MAJOR COMPONENTS ......................... 64
2. SPECIFICATIONS .................................................... 66
3. ATTACHING AND DETACHING MOWER DECK ... 67
1. ATTACHING THE MOWER DECK....................... 67
2. DETACHING THE MOWER DECK ...................... 68
3. ADJUSTMENT OF CUTTING HEIGHT................ 69
4. MOWER OPERATION ............................................. 70
1. BEFORE OPERATION......................................... 70
2. CUTTING HEIGHT ADJUSTMENT...................... 70
3. STARTING MOWING OPERATION..................... 71
4. EMERGENCY STOP............................................ 72
5. STOPPING MOWING OPERATION .................... 72
6. EFFICIENT MOWING........................................... 73
5. INSPECTION AND MAINTENANCE OF MAJOR
PARTS ...................................................................... 74
1. INSPECTION AND REPLACEMENT OF GEAR
CASE OIL ............................................................. 74
2. INSPECTION AND REPLACEMENT OF TIMING-
BELT..................................................................... 75
■ HOW TO JACK UP.............................................. 76
3. INSPECTION & REPLACEMENT OF BLADES ... 78
Blade Removal .................................................... 78
Shimming of Blades............................................. 78
4. INSPECTION OF GAUGE WHEELS &
ROLLERS ................................................. 79
5. CLEANING OF MOWER DECK ........................... 79
6. ADJUSTMENT OF DISCHARGE COVER
ANGLE ..................................................... 80
7. FILLING DIAGRAM .............................................. 80
8. PERIODICAL INSPECTION TABLE..................... 81
6. STORAGE ................................................................ 82
7. TROUBLESHOOTING ............................................. 83

4
ABBREVIATION LIST
Abbreviations
PTO
PT
RH / LH
ROPS
RPM
SAE
SSM
Definitions
Power Take Off
Permanent Type
Right - hand and Left - hand sides are determined by facing in the direction of
forward travel
Roll - Over Protective Structure
Revolutions Per Minute
Society of Automotive Engineers
Side discharge Mower
ZERO TURN MOWER

5
UNIVERSAL SYMBOLS
Safety Alert Symbol
Operation manual
Preheat
Engine - Stop
Engine - Run
Starter Control
Engine - Revolution
Fast
Slow
Mower - deck
Mower -Lowered position
Mower - Raised position
Cutting Height
Power Take - Off Clutch Control - Off position
Power Take - Off Clutch Control - On position
Battery
Diesel Fuel
P
Parking Brake
UNIVERSAL SYMBOLS

6
Every time you see the words and symbols shown below in the manual and on the safety decals, you must take note
of their instructions and warning.
DANGER: This symbol together with the words DANGER indicates an imminently hazadous situation that, if
not avoided, will result in VERY SERIOUS INJURY OR EVEN DEATH.
WARNING: This symbol together with the word WARNING indicates a potentially hazardous situation that, if
not avoided, could result in SERIOUS INJURY OR EVEN DEATH.
CAUTION: This symbol together with the word CAUTION is used to indicate a potentially hazardous situation
that, if not avoided, may result in MINOR INJURY.
IMPORTANT: The word IMPORTANT is used to provide instructions or advice in order to let the Zero turn mower pro-
vide the optimum performance.
NOTE: The word NOTE is used to indicate points of particular interest for more efficient and convenient repair or oper-
ation.
SAFETY INSTRUCTION: Essential items which you should observe while operating the Zero turn mower.
TECHNICAL INSTRUCTION: Items which are necessary to operate, adjust, and servise the Zero turn mower properly.
Before starting to operate the Zero turn mower for the first time, you should read this operation manual thoroughly
and carefully until you are sufficiently familiar with the operation of the Zero turn mower in order to do jobs safely and
properly. You are advised to refer to it from time to time to refresh your understanding of the Zero turn mower.
The manual should be kept in a handy place so you can refer to it when required.
The parts employed in this Zero turn mower may be modified without notice for better performance and quality
and for safety purposes, which may lead to some inconsistency found on your Zero turn mower with the contents of
this manual.
The Zero turn mower is designed to be used on well-kept lawns. Using the Zero turn mower in other places is not
authorized. Besides, the manufacturer will not pay for any damage caused by unauthorized use and the risk is only
borne by the user. Proper use of the Zero turn mower also implies that the user follows the operational, adjusting, and
servicing instructions indicated in the operation manual.
When you have any question about your Zero turn mower, you are always welcome to ask your dealers.
ZERO TURN MOWER
SAFETY FIRST

7
1. HOW TO BE A SAFE OPERATOR
1.1. Before starting the Zero turn mower for the first time,
read this manual thoroughly and carefully. Especially
abide by the instructions for safe operation. If you do
not, it may result in bodily injuries.
1.2. Pay attention to the caution labels on the Zero turn
mower and mower deck and observe the instructions
they give to avoid physical injuries.
1.3. Be sure to use necessary protective devices such as
headgear, safety glasses, safety shoes, ear plugs,
gloves, etc.
1.4. If you have consumed intoxicating beverages, are
drowsy from medication, ill, or tired, never operate
the Zero turn mower.
1.5. When operating, adjusting, or servicing the Zero turn
mower, always wear substantial shoes and long
trousers. Avoid wearing long loose clothes, acces-
sories or letting long hair hang loose, which could be
caught in rotating parts or on projections.
1.6. When you let someone else operate the Zero turn
mower, instruct this person how to operate the Zero
turn mower and also advise the reading of this manu-
al. Never lend the mower to anyone who cannot
understand the contents of this manual and safety
labels. Operation of the Zero turn mower by a person
unfamiliar with the Zero turn mower may lead to an
unexpected accidents.
1.7. Never permit the following persons to operate the
Zero turn mower:
-Persons not properly trained to operate the Zero turn
mower
-Persons who cannot understand the instructions
mentioned in this operation manual and on the cau-
tion labels
- Children
Local regulations may restrict the age of the operator.
1.8. Inspect the Zero turn mower periodically. If not, this
may not only shorten the Zero turn mower's service
life but also make safe and efficient operation impos-
sible.
CHAPTER 1. FOR SAFE OPERATION
CHAPTER 1. FOR SAFE OPERATION

8
2. BEFORE STARTING THE ZERO TURN MOWER
2.1. Set up an operation plan with sufficient time
allowance. A tight plan may result in unexpected
accidents. Especially when operating the Zero turn
mower under extremely hot, cold, or humid circum-
stances, set up an operation schedule or method
which will ensure operational safety.
2.2. Thoroughly inspect the area where the Zero turn
mower is to be used and remove all stones, sticks,
wires, and other foreign objects. Otherwise, they will
be hit by the mower blades, which may lead to seri-
ous accidents.
2.3. The Zero turn mower is equipped with various safety
systems. All safety shields, guards, and covers
should always be in position and functioning properly.
2.4. Before starting the engine, make sure that everything
is safe around the Zero turn mower and all control
levers are in the neutral or off positions, the parking
brakes applied, and the PTO lever in the OFF posi-
tion. Otherwise, unexpected accidents may occur.
2.5. Start the engine with the starter switch only. Never
attempt to start the engine by shorting the terminals,
or the Zero turn mower may move abruptly, and
result in unexpected accidents.
2.6. Never start the engine in a closed place. Exhaust
fumes contain poisonous carbon monoxide, so suffi-
cient ventilation should be provided when starting the
engine indoors.
ZERO TURN MOWER

9
2.7. Make sure of safety around the Zero turn mower and
move slowly when starting. Abrupt starting may
casue unexpected accidents.
2.8. Become familiar with the operation, particularly, the
stopping of the Zero turn mower. You should be skil-
ful enough to be able to stop the Zero turn mower at
will.
2.9. When your Zero turn mower is equipped with an
implement other than a standard mower deck, never
fail to ask your dealers about machine balance.
Always follow their advice.
2.10.Keep in mind that the operator or user is responsible
for the accidents or hazards caused by the Zero turn
mower to other people or their property.
2.11.Especially before starting the mower, be sure to per-
form advised pre-operation inspections especially on
the brakes and inspect visually to see that the blade
and blade tightening nuts are not worn, damaged or
loose. Replace worn or damaged blade and nuts as
an assembly to preserve blade balance. Otherwise,
poor braking or scattered broken blades may result,
which is very dangerous.
2.12.When operating the Zero turn mower equipped with
attachment which is not ISEKI made at the slope, be
sure to equip with Zero turn mower with balance
weights. Order the following parts to secure your
safety at the slope and install suitable weights with
the Zero turn mower.
2.12.•Front hitch (Opt.)
2.12.(1725-433-003-0A)...........................1pc
2.12.If you have any question, please consult your dealer.
2.13.Machine weight balance is a very important factor
for safe operation. When your machine is equipped
with an implement, never fail to ask your dealers
about machine balance. Always follow their advise.
CHAPTER 1. FOR SAFE OPERATION

10
3. OPERATION OF THE ZERO TURN MOWER
3.1. During operation, never allow anyone, especially
children, and animals to be in the vicinity of the
Zero turn mower, especially near the discharge of
the mower deck.
3.2. When you are working with co-workers, be sure to
alert them by signalling before you take a new
action.
3.3. Be sure to mow only in daylight. Mowing in the dark
may cause unexpected accidents.
3.4. When operating the Zero turn mower with the
ROPS turned up, you should be seated in the oper-
ator's seat properly with seatbelt, hold the Control
lever by both hands, and look in the direction in
which the Zero turn mower advances.
3.5. Always be sure to operate the Zero turn mower
from the driver's seat with seat belt. Never attempt
to get on or off the Zero turn mower wihile it is trav-
elling.
3.6. Never allow other persons to get on the Zero turn
mower during operation.
3.7. When turning the Zero turn mower, slow down suffi-
ciently. Turning at high speed may cause the Zero
turn mower to turn over.
3.8. When reversing the Zero turn mower, make sure of
the safety conditions behind.
3.9. Never operate the Zero turn mower in terrain where
there are ditches, holes, or steps easy to collapse.
In such a place, the Zero turn mower could turn
over or fall.
3.10. Before making access to moving parts, stop the
engine, and keep your hands, feet, clothing, acces-
sories and etc. away so as not to be caught in the
moving parts or the Zero turn mower.
3.11. Always pay attention in front of the Zero turn mower
to avoid obstacles such as corner stones, stubs,
sprinkler heads, etc. When there is an obstacle that
cannot be removed, provide a marker flag as a
warning to keep away from it when mowing. When
approaching the obstacle, slow down the Zero turn
mower sufficiently to avoid it.
3.12. Never rest a foot on the brake pedal. If so, the
brakes disc wear rapidly, which may lead to serious
accidents.
3.13. Adjust the cutting height with the gauge wheels in
accordance with the condition of the ground surface
at the working site. Mowing on rough ground with
low cutting height may cause the blades to hit soil
or stones, which is very dangerous.
3.14. After striking a foreign object, stop the engine and
inspect the Zero turn mower and the mower deck
for damage and be sure to make repairs before
mowing again.
3.15. Be sure to keep the grass discharging part clean. A
clogged discharging part may cause the discharge
cover to open, resulting in scattering of grass and
stones, which is very dangerous.
3.16. Never allow grass or leaves to accumulate around
heated parts such as the engine and the muffler, or
this may cause a fire.
3.17. Before moving the Zero turn mower to another
place, be sure to stop the mower blades and lift up
the mower deck. Otherwise, they may hit stones
and scatter them around, which is very dangerous.
3.18. When driving over a levee or step, stop the mower
blades, lift up the mower deck, and move the Zero
turn mower straight to the levee and make it climb
over slowly. Avoid climbing over a levee too high, or
the Zero turn mower may fall sideways or turn over.
3.19. Before stopping the engine, be sure to lower the
mower deck onto the ground, apply the parking
brakes, and turn off the PTO switch to the OFF
position.
3.20. Before leaving the Zero turn mower, stop the
engine, lower the mower deck onto the ground,
draw the engine key, apply the parking brakes, and
chock the wheels. The Zero turn mower should be
parked in a place which is flat and spacious, and
has hard surface in order to avoid unexpected mov-
ing of the Zero turn mower.
3.21. Never attempt to use the Zero turn mower to draw
an implement or a trailer. It is not designed to draw
a load.
ZERO TURN MOWER

11
4. OPERATION ON A SLOPE
We cannot recommend this Zero turn mower be operated
on a slope, but advise you to use a Zero turn mower
designed for slope operation. On a slope, various ele-
ments of operation such as slope angles, ground condi-
tions, way of operation, grass conditions, etc. may lead to
slipping, or over-turning of the Zero turn mower, which
may result in bodily injury.
If the Zero turn mower has to be used on a slope, remem-
ber there is no such thing as a "safe" slope. and be sure
to abide by the following instructions.
•When your Zero turn mower is equipped with an
implement other than standard, such as a collector, a
cabin, etc., never fail to ask your dealers about
machine balance. Always follow their advice.
-The Zero turn mower is not equipped with any attach-
ments or a cabin.
-The Zero turn mower is equipped with a standard
mower deck.
4.1. Be sure to wear a helmet during operation.
4.2. Operate at sufficiently low speeds.
4.3. When turning, be sure to slow down sufficiently.
4.4. Avoid sudden starting and stopping.
4.5. Operate the Zero turn mower up and down across
the contour lines of the hill. Never operate along the
contour lines.
4.6. Never perform mowing operation on wet grass.
4.7. Never park the Zero turn mower on a slope.
4.8. Pay attention to other possible causes of danger
which could lead to overturning, etc.
5. DRIVING ON PUBLIC ROADS:
5.1. This Zero turn mower cannot be driven on a public
road without authorization by a local government
agency. etc. Therefore it may be illegal for the Zero
turn mower not only to travel on but also to cross a
public road.
5.2. When transporting the Zero turn mower on a public
road, load it on a truck or trailer.
CHAPTER 1. FOR SAFE OPERATION

12
6. LOADING ONTO OR UNLOADING FROM A TRUCK:
6.1. When loading the Zero turn mower onto a truck,
turn off the truck's engine, apply the parking brakes
to the truck, and chock the wheels to avoid unex-
pected moving of the truck or trailer.
6.2. Pay sufficient attention to safety conditions around
the Zero turn mower and have it guided by some-
one to assist the operator. Never allow other per-
sons to approach the Zero turn mower, especially in
front of or behind it.
6.3Use a wide ramp for loading and unloading the
mower. Avoid switching from forward motion to
backward motion (or vice-versa) as this will cause
the front wheels to rotate sideways. Sideway rota-
tion of the front wheels poses some danger when
the mower is on the ramp.
6.4. When loading the Zero turn mower onto a truck, lift
up the mower deck fully and rearward it straight at
sufficiently low speeds. Drive it advance when
unloading it from the truck or trailer.
ZERO TURN MOWER

13
6.5. If the engine stalls unexpectedly on the ramps,
depress the brake pedals immediately and roll the
Zero turn mower to the ground by releasing the
brakes gradually. Then start the engine and try
again.
6.6. Use ramps with the same or better specifications
mentioned below. When the Zero turn mower is
equipped with the attachments other than those
included in the specifications mentioned below, ask
your dealers for advice.
Specifications of the ramps for the SZ330
• Length......more than 4 times the height of the platform
of the truck
•Width (effective width)........................more than 30 cm
• Required quantity ............................................2 ramps
• Capacity (one ramp)..........................more than 750 kg
• Ramps should have anti-skid surfaces.
•The above specifications are effective with the Zero
turn mower with the following configurations.
•The Zero turn mower is not equipped with any attach-
ments or a cabin.
•The Zero turn mower is equipped with a standard
mower deck.
6.7. Park the truck on hard level ground. Hook the
ramps securely on the platform of the truck with the
top of the ramp level with the platform.
6.8. Drive the Zero turn mower carefully at the moment
the Zero turn mower moves from the ramps onto
the platform, for it changes angles abruptly.
6.9. When the Zero turn mower is loaded on the truck,
lower the mower deck onto the truck bed, stop the
engine, apply parking brakes, and withdraw the
starter key, chock the wheels, and rope it securely
to the truck. Refrain from unnecessary abrupt start-
ing, stopping, and turning during transportation, or
the Zero turn mower may shift position on the truck,
which is very dangerous.
CHAPTER 1. FOR SAFE OPERATION

14
7. WHEN FILLING WITH FUEL:
7.1. Never smoke while refilling with fuel, nor allow any
open flames near the Zero turn mower.
7.2. Never open the fuel tank cap while the engine is
running or while it is still hot after operation. Wait
until the engine cools down sufficiently.
7.3. Provide adequate measures to prevent fuel from
spilling when pouring it into the fuel tank. Spilt fuel
should be wiped off completely.
7.4. Avoid refueling indoors. If this is inevitable, provide
sufficient ventilation.
7.5. Replace the fuel tank and container caps securely.
7.6. Store fuel in containers specifically designed for this
purposes.
8. MOUNTING AND DISMOUNTING OF THE MOWER
DRIVE SHAFT
The mower gear box is driven through a drive shaft with
universal joints from the Zero turn mower. When connect-
ing or disconnecting the shaft, follow the next instructions.
8.1. Lower the mower deck onto the gournd, stop the
engine, draw the engine key, and apply the parking
brakes before mounting or dismounting the drive
shaft.
8.2. Shift the PTO switch to the OFF position (N).
8.3. Make sure that the PTO shaft and mower blades
stop completely.
8.4. The drive shaft should be mounted or dismounted
at the Zero turn mower side. Never leave the shaft
connected only at the Zero turn mower side. If the
PTO shaft be driven unexpectedly, the shaft will be
swung around and damage the Zero turn mower or
cause serious accidents.
9. ZERO TURN MOWER MAINTENANCE:
9.1. Never start the engine in a closed place. Exhaust
fumes contain poisonous carbon monoxide, so suf-
ficient ventilation should be provided when starting
the engine indoors.
9.2. Be sure to wear safety glasses and gloves when
servicing the Zero turn mower.
9.3. When servicing the Zero turn mower or mounting or
dismounting the mower deck, place the Zero turn
mower on level, hard ground.
ZERO TURN MOWER

15
9.4. Service the Zero turn mower in a place sufficiently
illuminated, or darkness may cause unexpected
accidents.
9.5. When servicing the Zero turn mower or mounting or
dismounting the mower deck, stop the engine and
remove the engine key and apply the parking
brakes.
9.6. The engine, muffler, radiator, etc. are very hot just
after operation, so wait until those heated parts cool
down sufficiently to avoid burns.
9.7. Never remove the radiator cap while the engine is
hot or running. Wait until the engine cools down and
then relieve the radiator pressure by releasing the
radiator cap. Carelessly pouring cooling water into
the heated radiator can cause serious damage to
the radiator and the engine. Careless removal of
the radiator cap can cause serious injury because
of superheated water vapor.
9.8. Before servicing the Zero turn mower, be sure to
turn off the PTO switch to the OFF position and
make sure that the mower blades have stopped
completely. Rotating blades may casue serious
accidents.
9.9. When servicing the Zero turn mower, use proper
tools. Using makeshift tools may lead to injuries or
poor service, which may result in unexpected acci-
dents during operation.
9.10. When removing a tyre, chock other tyres and sup-
port the Zero turn mower securely. When installing
tyres, be sure to tighten the wheel nuts to the speci-
fied torque. Loose nuts may cause serious acci-
dents.
9.11. When servicing the mower blades, pay sufficient
care so your hands or fingers are not cut by them.
As the three blades are driven by one belt, turning
one blade will cause the other blades to turn.
9.12. A first aid kit and a fire extinguisher should be kept
in a place always in instant access.
9.13. Avoid high-pressure fluids. Escaping fluid under
pressure can penetrate the skin and cause serious
injury, so keep hands and body away from pin holes
and nozzles ejecting such fluids. Be sure to consult
your dealer about the hydraulic and fuel injection
system troubles.
CHAPTER 1. FOR SAFE OPERATION

16
9.14. If any hydraulic fluid is injected accidentally into the
skin, it must be removed within a few hours by a
doctor familiar with this type of injury.
9.15. Never allow grass or leaves to accumulate around
heated parts such as the engine and the muffler, or
this may cause a fire.
9.16. Be sure to reinstall the removed parts in place.
Never attempt to start the engine with any parts
removed.
9.17. Never attempt unauthorized modification of the
Zero turn mower as this could be very hazardous.
Damaged or worn parts should be replaced with
ISEKI genuine spare parts. Unauthorized parts may
cause breakdown of the Zero turn mower, acci-
dents, and ISEKI warranty to expire.
9.18. Keep all nuts, blots and screws tight to be sure that
the equipment is in safe working condition.
10.MAINTENANCE OF THE ELECTRIC SYSTEM
10.1. TO MAINTAIN ELECTRIC WIRING
(1) When servicing the electric wiring, stop the engine
without fail. Otherwise your hands or clothes may
be caught in or sandwiched between rotating parts.
(2) Before manipulating electric parts, be sure to dis-
connect the earth battery cable (-), or you may get
an electric shock or be injured by sparks.
(3) Loose electric terminals or connectors may not only
lower electrical performance but also cause short
circuit or leakage of electricity, which may lead to a
fire. Promptly repair or replace damaged wiring.
(4) Remove chaff or dust from the battery, wiring, muf-
fler or engine. Otherwise it could result a fire.
10.2. TO HANDLE THE BATTERY
(1) When working around the battery, avoid smoking.
The battery generates explosive hydrogen and oxy-
gen gases when it is being charged. Keep the bat-
tery away from sparks or open flames.
(2) The battely should be inspected before starting the
engine. Be careful not to touch the electrolyte
makes contact with the skin or clothing, wash it off
immediately with water and then consult a doctor.
ZERO TURN MOWER

17
(3) When replacing or inspection the battely stop the
engine and turn the main switch off, or electrical
parts may be damaged or unexpected accident may
occur.
(4) When disconnecting the battery cables, disconnect
the earth cable (-) first without fail. When connect-
ing the battery cables, connect the positive cable
(+) first. Disconnecting or connecting in wrong order
may lead to a short circuit or sparks.
10.3. TO HANDLE BOOSTER CABLES
When using booster cables, pay attention to the fol-
lowing items for safe operation:
(1) Before connecting cables, remove the vent plugs.
This will lower the force in case of explosion.
(2) Before connecting cables, be sure to stop the
engines Otherwise unexpected accidents may occur.
(3) Use booster cables with sufficient electrical capacity.
A cable of inadequate capacity will cause generation
of heat, which may lead to a fire.
11. TYRES AND WHEELS
11.1. Be sure to keep tyre pressures at the levels speci-
fied in this manual. Excessively high tyre pressure
may result in explosion, which may lead to physical
accidents.
11.2. If a cut is found in a tyre and the cut reaches the
cords, do not use it. Such a tyre may explode.
11.3. Before replacing or repairing tyres, tubes, or rims,
consult your dealers ahead of time. Such operation
should be performed by trained mechanics.
CHAPTER 1. FOR SAFE OPERATION

18
12. BEFORE STORING THE ZERO TURN MOWER
12.1. After opeation, be sure to close the fuel cock to pre-
vent fuel from spilling, as spilled fuel may catch fire.
12.2. Never allow grass or leaves to accumulate around
heated parts such as the engine and the muffler, or
this may cause a fire.
12.3. Be sure to remove the ignition key to prevent unex-
pected accidents caused by engine starting by
untrained persons or children.
12.4. When storing the Zero turn mower with the mower
deck attached, be sure to lower the mower deck on
the ground. Otherwise manipulation of the lift lever
by untrained peroson or children may cause unex-
pected accidents.
12.5. Store the Zero turn mower in a place provided with
sufficient illumination. Inspection and moving of the
Zero turn mower in a dark place may lead to unex-
pected accidents.
12.6. When the Zero turn mower is to be stored in a
closed place like a garage or a barn, provide suffi-
cient ventilation for exhaust gases. Exhaust fumes
can be lethal.
12.7. To avoid fire hazard, keep the engine, muffler, bat-
tery, and fuel storage area free of grass, leaves, or
excessive grease.
12.8. Never cover a hot Zero turn mower just after opera-
tion with a tarpaulin or the like, or the heated engine
and related parts may cause a fire.
13. LONG TERM STORAGE
13.1. Before storing the Zero turn mower for a long period
of time, disconnect the battery cables to prevent
them, in case they are gnawn by rats, from causing
a short circuit, which may lead to a fire. When dis-
connecting the battery, disconnect the negative (-)
cable first, while connecting the positive (+) cable
first when connecting the battery. Wrong order of
disconnecting or connecting the battery will cause
sparks, which is very dangerous.
ZERO TURN MOWER

19
14. CAUTION LABELS & THEIR POSITIONS
• Caution labels on the zero turn mower and the mower deck
The following labels are stuck on the zero turn mower and mower deck. You should of course read the caution
instructions in the manual. But never fail to read the labels on the zero turn mower and mower deck as well. Their
respective code numbers are also mentioned below, so order them from your deal if any of them are lost or dam-
aged.
CHAPTER 1. FOR SAFE OPERATION
１７０５−９０４−００４−０
１２°＋
１．
２．
ＳＴＯＰ
３．
1
2
(1) Caution label
a. Read the manual thoroughly.
b. Shut off the engine and remove the starter key
before servicing or repairing the machine.
c. The negative terminal of the battery should be dis-
connected before servicing or repairing the machine.
d. When leaving the machine, apply the parking
brakes, shut off the engine, and remove the engine
key.
e. Risk of injury
Keep all safety devices such as guards, safety
switches, etc in place and working properly.
f. Risk of injury
Remove objects from around the machine that
could be thrown by blades and keep people away
from the machine before starting the machine.
g. Risk of running over a person
Watch behind before reversing the machine and
keep people from around the machine before start-
ing the machine.
h. Risk of running over a person
Don't allow any other person to ride on a wheel
fender or any place other than the driver's seat of
the machine.
i. Risk of overturning or crushing
Do not operate the machine in any place where it
could slip or tip over.
j. Risk of overturning or crushing
Avoid operating the machine on a steep slope.
(2) Fuel label
Use diesel fuel only. No open flame.
１７０５−９０４−００４−０
１２°＋
１．
２．
ＳＴＯＰ
３．
