Isel iPC25 - F User manual

iPC25 - F
Operating instructions

iPC25 operating instructions
The information, technical data and measurements contained in this publication are based on the
state of the art at the time of publication. However, any printing errors and errors that may be
present can not be excluded. We would be grateful for any suggested improvements or references
to errors.
It should be noted that the software and hardware names used in our publications are generally
the subject of protection as trademarks, or under proprietary rights, or patent law.
All rights reserved. No part of our publications may be reproduced in any form (print, photocopy or
any other process) without the written permission of isel Germany AG or processed, reproduced or
distributed using electronic systems.
The information contained in this manual is subject to change without notice. The contents are
subject to change without notice.
Manufacturer: isel Germany AG
Bürgermeister-Ebert-Straße 40
D-36124 Eichenzell
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
http://www.isel.com
Review index
Date of
change
Reason for change
Changed by
04/05/2015
First edition
RL
a
29/05/2017
Supplement D3313-S4
HG
b
17/07/2017
EMC / low voltage directive
RL
Current operating guides for download can be found under:
www.isel.com/en/support-downloads/manuals.html

iPC25 operating instructions
Contents
1General notices................................................................................................................... 1
1.1 Safety symbols ................................................................................................................. 1
1.2 Safety notices................................................................................................................... 1
2Product description ............................................................................................................ 2
2.1 Technical data .................................................................................................................. 2
2.2 Interfaces iPC25 - F........................................................................................................... 4
3Assembly and start-up ....................................................................................................... 6
3.1 Installation dimensions..................................................................................................... 6
3.2 Switching on the control unit ............................................................................................ 7
4Recovering the operating system Windows® Embedded Standard 7 ............................. 8
5Maintenance and repair..................................................................................................... 9
6EG-Konformitätserklärung........................................................................................ 10

iPC25 operating instructions
Page - 1
1General notices
Carefully read the operating instructions to the end and follow the instructions given. Failure
to observe these operating instructions can result in property damage, serious personal injury or
death.
1.1 Safety symbols
Attention
This symbol indicates that there is a risk to the life and health of personnel.
Danger
This symbol indicates that there is a risk to the material, machine and the
environment.
Information
This symbol highlights important information.
1.2 Safety notices
▪The industrial PCs iPC25 are based on the latest state of the art and the
recognised safety regulations.
▪The device may only be used for its intended use.
▪The device may only be operated in an impeccable technical condition. Faults
must be removed immediately. Children and unauthorised persons must not
operate the device.
▪All work must be carried out exclusively by authorised personnel and taking into
account the regulations of the electrical industry and accident prevention
regulations.
▪Installation and use of the equipment must be carried out according to the
standards of the declaration of conformity. The regulations and limits set by the
manufacturer do not protect the device from improper use of the equipment.
▪The device must not be exposed to high humidity and high vibrations.
▪Keep these operating instructions carefully and make sure each user observes
them!

iPC25 operating instructions
Page - 2
2Product description
2.1 Technical data
Item number 371066 xxxx
4001 (E)
4001 P (E)
Dimensions (W x H x D):
210 x 90 x 190 mm
Weight:
1.2 kg.
Ambient temperature:
0°C to 35°C
Relative humidity:
max. 90% non condensing
Protection type
IP20
Supply voltage:
on the interface 8 (see 2.2)
12 VDC/min. 100W (external power supply 12V/ 100W required)
Use:
Industrial area / Home- Office area
Form-Factor:
Mini-ITX
CPU:
AMD GX-222GC
Main memory
2xSO DIMM Socket (1.5V/ 1.35V), max. 16GB, SC, DDR-1333/ DD3-1600

iPC25 operating instructions
Page - 3
Hard drive:
2,5“ HDD

500GB
2,5“ SSD

256GB MLC/MTPF 2mill. Std.
Operating system:
Windows 7 Embedded standard 64bit
Connections:
external
1 x DVI-I, 1xDisplayPort
1 x PS/2 keyboard, 1 x PS/2 mouse
5 x USB 2.0
2 x LAN 1GBit
2 x serial Port RS 232
1 x Sub-D9-pin connection for iBP10 / iBP17 / iOP-19-TFT
Audio Line in, Line out
12 V,DC power supply
internal
PCI Express x4 Slot
1 x Mini PCI Express Slot x4 (incl. USB2.0)
USB 2.0 / USB 3.0 channels
LVDS Dual Channel / Backlight Inverter
other internal connections, see data sheet Mainboard
Optional connections:
USB
DVI-I/VGA interface / DVI-I/HDMI via Interface-Connector

iPC25 operating instructions
Page - 4
2.2 Interfaces iPC25 - F
No.
Interface
1
DVI-I connection,optional adapter DVI-I available on VGA
2
RS 232 connection
Serial interface RS232 –COM1 + COM2
3
LAN connection
2x RJ45 socket for network
4
USB interfaces
4 x USB 2.0 interfaces for the connection of peripherals
5
Mouse, Keyboard Connection
Connection socket for mouse and keyboard
6
Audio connection
Jack socket Line In, Line Out
7
1 x CAN connection
CAN-Bus connection RJ45, optional CAN Duo – 2 x separate CAN-Bus
8
Connection of the power supply for cabinet mounting
with 2-core cable (+ 12VDC white / GND brown)
12 VDC/100W supply voltage

iPC25 operating instructions
Page - 5
9
SubD-9-pin socket for connection iBP10 / iBP17 / iOP-19-TFT
only for cabinet mounting
Pin
Description
Description
1
PWR BTN +
Connection for Power key +
2
PWR BTN GND
Connection for Power key GND
3
PWR LED +5VDC
Connection for power indicator LED +
4
PWR LED GND
Connection for power indicator LED GND
5
HDD LED +5VDC
Connection for HDD power indicator LED +
6
+12VDC
Supply voltage for TFT +12V
7
GND
Supply voltage for TFT GND
8
n.v.
9
HDD LED GND
Connection for HDD power indicator LED GND
Power supply for computers and monitors only possible in connection
with a sufficiently dimensioned power supply, with iBP10 / iBP17 /
iOP-19-TFT at least 100W.
10
Multifunction screen for additional optional connections
11
Connector for power supply 2-pin plug when used with external plug-in power
supply 12 VDC/5A hollow plug 5.5/2.5mm (+ pole inside)
Attention: Only one power supply connection is available at all times.
Based on the variants/item numbers
12
Connection for monitors with display port
13
additional USB interface
1 x USB 2.0 interfaces for the connection of peripherals

iPC25 operating instructions
Page - 6
3Assembly and start-up
3.1 Installation dimensions
Make sure that there is always sufficient clearance for the air circulation on the
ventilation slots of the iPC. Failure to observe this measure will result in overheating
and possible defects in the control computer.
Avoid, as far as possible, extreme environmental conditions.
Protect the PC from dust, moisture and heat.
The ventilation slots of the PC must not be covered.
Scale drawing iPC25- F

iPC25 operating instructions
Page - 7
3.2 Switching on the control unit
The control unit is switched on via the contacts of the sub-D9-pin socket connection in the slot of
the iPC (see chapter 2.2).
When a 12V DC supply voltage is applied, the computer can also power up the
operating system independently. This is the default setting in the BIOS of the computer.
On delivery, the IPC25 computers are set up, so that the standalone start-up
is disabled.
The BIOS setting can be found under "POWER Power Failure Recovery“
Important notice!
If the start-up of the control computer is set up in the BIOS when the supply voltage is applied, the
computer must be shut down properly before the machine is switched off. Otherwise there is the
risk of a loss of data as well as a damaged, operating system that can no longer be booted.
