Isiler CHK-CCA02 User manual

User Manual
Induction Cooktop
CHK-CCA02

2
1
Thank you for purchasing this product. To ensure proper use and
trouble-free operation, please read this manual carefully and store it
in a safe place for future reference.
About Induction Cooking
How does induction heating work?
Induction cooking uses electromagnetic energy to heat cookware. When
cookware is placed on an induction cooktop and the cooktop is turned on, the
coil inside the induction unit produces and alternates magnetic fields, which
flow through the cookware. Iron molecules in the cookware then rapidly vibrate,
causing instant heat and keeping your energy costs down.
What types of cookware can be used?
Induction cooktops will only operate when using certain cookware. As explained
in the paragraph above, induction cooking works using electromagnetic energy,
therefore the contact surface of the cookware must be made from a ferrous
magnetic material such as cast iron, enameled steel or magnetic stainless steel.
Ensuring this is the case, the interior or cooking surface of the cookware can then
be made from aluminum or other non-ferrous materials, with or without a non-
stick coating.
It is very easy to check whether or not your cookware will be suitable for use with
the cooktop, by using a fridge magnet or any other permanent magnet. If the
magnet sticks to the bottom of your chosen cookware, it can be used for cooking
on the induction cooktop.
Important Safeguards
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Check your power supply and make sure it is 120V before using the induction
cooktop.
2. Do not touch hot surfaces.
3. To protect against electrical hazards, do not immerse cord, plugs, or the
appliance in water or other liquids.
4. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
5. Close supervision is necessary when any appliance is used by or near children.
Children should be supervised to ensure that they do not play with the
appliance.
6. Before cleaning, first unplug from outlet and make sure the appliance has
cooled down.
7. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
the appliance to the manufacturer for examination, repair or electrical
or mechanical adjustment. All servicing, other than cleaning, should be
performed by an authorized service representative.

4
3
emitted by induction cooktops.
18. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will only fit one way in a polarized
outlet. If the plug does not completely fit in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not modify the plug in any way.
Buttons
1.Power indicator light
2. Temperature indicator light
3. Child safety lock
4. Timer button
5. “-”button
6. Display window
7. “+”button
8. Function selection button
9. On/Off button
8. If the appliance is not working as described in this instruction booklet, please
discontinue use and contact us.
9. The use of accessories or attachments not recommended by us may cause
hazards.
10. Do not use outdoors.
11. Do not let the power cord hang over the edge of a table or counter.
12. A fire may occur if the surface is covered with, or touching, flammable
material such as curtains, draperies, walls and the like when in operation.
13. Always disconnect the appliance from the outlet when not in use. To
disconnect, turn off the appliance first and then remove the plug from the
outlet.
14. Do not use the appliance for anything other than its intended use.
15. Do not place on or near a hot gas or electric burner, or in a heated oven.
16. Extreme caution must be taken when moving the appliance with cookware
containing hot liquids. Do not overfill cookware used on the appliance to avoid
spilling when contents are boiling.
17. People with pacemakers or similar medical devices should be careful
when standing near this induction cooktop while it is powered on. The
electromagnetic field may affect pacemakers or similar devices. Consult your
doctor, or the manufacturer of the pacemaker, or similar medical device for
additional information regarding the possible effects of electromagnetic fields
1 2
3 4 5 6 7 8 9

6
5
Note: There are a total of 9 power levels (P1: 100W, P2: 300W, P3: 600W, P4: 800W,
P5: 1000W, P6: 1200W, P7: 1400W, P8: 1600W, P9: 1800W).
7. Press the function selection button again to switch to temperature mode. The
temperature indicator light will turn on and the display window
will show the default temperature of 380°F . Press the“+”or“-”button to
increase or decrease the temperature.
Note: There are a total of 8 temperature levels (140°F, 180°F, 260°F, 300°F, 340°F,
380 °F, 420°F, 460°F).
8. Press the timer button to set the timer. The display window will show
the default time of“0:30” , and the timer indicator light will turn on.
Press the“+”or“-”button to adjust the timer. Once the desired period is selected,
press the timer button again or wait 5 seconds to set the new timer. The display
window will now alternate between the timer and power level (or timer and
temperature level if in temperature mode). When the programmed time has
elapsed, the induction cooktop will beep once and shut off automatically.
Note: If at any time during the cooking cycle you would like to cancel the timer,
simply press the timer button again.
9.Press and hold the child safety lock for 3 seconds to access the child
and the child lock indicator light will turn on.safety lock function, Only the
child safety lock and On/Off buttons can be used at this time. Press and hold
the child safety lock button for a further 3 seconds to cancel the lock function
and return the cooktop to normal.
Technical Specifications
Model CHK-CCA02
Voltage 120V
Frequency 50/60Hz
Material PP
Power range 100-1800W
Temperature range 140-460°F/60-238°C
Power cable length 3.9ft/1.2m
Size 11.6 × 14.2 × 2.2in/29.5 × 36 × 5.7cm
Weight 91.7oz/2.6kg
Operating Instructions
1. Place the induction cooktop on a dry and level surface.
2. Add food to the cookware.
3. Place the cookware within the circle indicated on the induction cooktop
surface.
4. Plug the power cord into a 120V outlet. The unit will beep and the On/Off
button indicator light will flash.
5. Press the On/Off button to turn on the unit.
6. Press the function selection button to switch to power mode, the power
indicator light will turn on and the display window will show
“1200” , indicating the default power. Press the“+”or“-”button to
increase or decrease the power level.

8
7
no more than 8.7in/22cm in order to work correctly. If the cookware is larger than
the circle indicated on the induction cooktop surface, the outside area will not be
heated, causing inconsistent cooking.
4. Make sure that the base of the cookware is clean, as dirt may cause the bottom
to stick to the induction cooktop.
5. Never heat empty cookware. This will cause the unit to overheat, damage the
cookware and/or cause the unit to shut off.
Cleaning & Maintenance
1. Unplug the appliance from the electrical outlet when it is not in use.
2. Clean the induction cooktop and the control panel with a damp cloth.
Notes:
-Do not use a brush or abrasive cleaners. This may damage the cooktop.
-Do not immerse the unit in water or any other liquids.
3. Dry with a soft cloth.
4. Clean the unit after each use.
10. Press the On/Off button to turn off the unit when cooking is finished.
Important Notes
1. If the cookware is removed from the cooktop at any time during the cooking
cycle, the unit will beep continually for 30 seconds, error code E0 will appear
in the display window and the unit will shut off automatically. In order to
re-activate the unit, place the cookware back on the cooktop and follow steps
5-10 from the operating instructions.
2. When the unit is turned off, the built-in fan will continue running to cool down
the appliance, and the display window will display“H” until the temperature of
the induction cooktop is below 120°F.
3. This induction cooktop will only operate with suitable cookware. The most
common types are those made from cast iron, enameled and stainless steel.
The induction cooktop will not operate when using aluminum, ceramic,
copper, glass or Pyrex cookware that has a concave bottom.
Note: The cookware base should have a diameter of no less than 4in/10cm and

10
9
Problems Causes Solutions
The appliance stops
working while
heating.
Is the cookware empty or the
temperature too high?
Check whether the appliance
is being misused.
Is the air intake clogged or has dirt
accumulated within it?
Unclog the air intake. Wait for
the appliance to cool down
then switch it on again.
Is the appliance working for long periods
of time without accepting manual
operations?
Reset cooking modes or use
the timer function.
Error codes are
reported.
E0: No pot
E1: Low voltage
E2: Over voltage
E3: Thermistor module open
If the error code E0 is
reported, please check if the
cookware you are using is
suitable for induction cooking
or wait for the appliance to
cool down and then switch
it on again. If error codes
E1-E9 are reported, please
contact the service center for
inspection and repair.
E4: Thermistor module short
E5: Thermistor to IGBT open
E6: Thermistor to IGBT short
E7: Thermistor module failure
E8: Inner failure
E9: Thermistor to IGBT overheating
Warranty and Contact
To ensure peace of mind, we provide you with a 12-month warranty from the
date of purchase. This warranty covers any defects in materials, workmanship
and malfunctions under normal use. If you have any problems concerning the
product, please contact us via our after-sales service email and we will respond to
you as soon as possible.
Email: [email protected]
Troubleshooting
Problems Causes Solutions
The appliance is
plugged into a
power outlet and
activated using the
On/Off button, but
there is no response
from the appliance.
Is there a power supply failure?
Wait for the power supply to
resume.
Is the fuse blown or circuit breaker tripped?
Is the plug firmly connected?
Check the root causes
carefully. If the problem
cannot be fixed, please
contact our service center for
inspection and repair.
Heating is
interrupted during
normal use and a
“beep”is heard.
Is the cookware suitable for the
induction cooktop and is there cookware
placed on the cooktop?
Replace the cookware that
is suitable for the induction
cooktop.
The cookware is not placed within the
center of the indicated heating zone.
Place the cookware within
the center of the indicated
heating zone.
Is the cookware being heated but is
continually being removed?
Place the cookware within
the heating zone and do not
continually remove.
