ISkin CE-TX1000 User manual

BLUETOOTH WIRELESS STEREO
TRANSMITTER (TX) FOR IPOD
iSkin CE-TX1000
USER GUIDE

1. Introduction
Bluetooth wireless technology is a short-range communications technology intended
to replace the cables connecting portable and/or fixed devices while maintaining high
levels of security. It is designed to communicate data/voice within short-range
distance of 10m to 100m. Bluetooth technology has achieved global acceptance such
that any Bluetooth enabled device, almost everywhere in the world, can connect to
other Bluetooth enabled devices in proximity.
A fundamental Bluetooth wireless technology strength is the ability to simultaneously
handle both data and voice transmissions. This enables users to enjoy variety of
innovative solutions such as a hands-free headset for voice calls, printing and fax
capabilities, and synchronizing PDA, laptop, and mobile phone applications to name
a few.
2. Package Contents
BT-TD01 TX for iPod Power and Audio Adaptor User Manual

3. Feature
4. Getting stared
Remove all components from the package. Items in the package include: Bluetooth
Transmitter for iPod, User manual, and Audio and Power Adaptor. (Optional) Please
check the contents carefully and contact your local dealer immediately if there is any
shortage.
5. Getting to know the Tx
This Bluetooth Tx for iPod offers the latest innovation in Bluetooth technology. It can
transfer audio from Apple iPod to Bluetooth Stereo Headset or receiver wirelessly. As
a kind of easy control product, Tx will finish searching, pairing, and connecting by
itself automatically. User just needs to plug into iPod to start the operation.
6. Pair TX to your Bluetooth Stereo Headset
Pairing is the process of linking the Tx with your Bluetooth stereo headset or receiver.
Before you using the Tx with Bluetooth stereo headset, you should pair both devices.

After pairing completed, you should use the Tx only with the paired Bluetooth stereo
headset/Audio receiver. If you want to use Tx with a different Bluetooth stereo
headset/Audio receiver, you need to redo the pairing process with the new devices.
In this case, the Tx will no longer work with the previous Bluetooth stereo
headset/audio receiver.
To pair the Bluetooth Receiver Device.
1. plug into the iPod, the white LED will flash in slow speed. It is in searching
new device mode. When Tx find the device, the LED will flash in fast speed. It
is in paring mode.
2. Turn on the Bluetooth stereo headset and make sure Tx in pairing Mode (See
the Bluetooth stereo headset’s User manual)
3. If the Tx is paired with the Bluetooth stereo headset, the LED will flash in slow
speed again.
Tips: Please make sure the pin code of Bluetooth stereo headset / Audio receiver is
“0000”. Otherwise, the Tx will not pair with it. For this part, Please refer the Bluetooth
stereo headset venders.
7. Tx User Interface Definition
1) Device Action Status
Method Tx Status
Action
Method Status
Power
Save
Idle not
connect
ed
Idle
connect
ed
Pairing
Mode
AV
Note
iPod Detect Auto Power
ON
- - - - -
Power On
Cradle Detect Auto Power
ON
- - - -
Discovered X ○ ○ X X
New Device
Search
Paring
Mode-
Enter
Auto Pairing
Connected X ○ X X X
Last Device
Search

* Device Search & Pairing time
1. Searching Mode: 60sec
2. Connecting Mode: 15sec
2) LED Definition
LED White
Action
Status
On
Time(se
c)
Off
Time(sec)
Notes
Paring Blink Mode 1 0.2 0.2
0.05
A2DP Discovered Blink Mode 2 0.05
1
A2DP Streaming Blink Mode 3 0.5 3.0
* Blink Mode
Blink Mode 1 : On-Off-On-Off…..
Blink Mode 2 : On-Off-On-Off …..time delay (1sec)….. On-Off-On-Off
Blink Mode 3 : On1-Off…time delay(3sec)….On-Off…..
Paring
Mode-
Exit
- - X X X ○ X
Streaming
Mode
- - X X X X ○
Auto Power
Off
- X X X X X
After Pairing
60sec
Power Off
iPod Power
Off Key
- X X X X X

3) Tx Mode Changing Method
8. Products Specification
Bluetooth Version Version 2.0, Class II
Bluetooth Support Profile A2DP, AVRCP
RF Frequency 2,4GHz / 79 Channel / AFH
Coverage Range* Bluetooth standard 33 feet (10 meters)
Power Methods Audio and Power Adaptor for Tx
Advanced Audio Distribution Profile (A2DP), and Audio/Video Remote Control Profile
(AVRCP) *Performance may vary by device.
9. Troubleshooting
1. Please note that you should also be familiar with the operation of your
Bluetooth stereo headset / Audio receiver.
2. Please read you Bluetooth stereo headset user guide carefully.
3. Please note that the Tx will only work with Bluetooth stereo headset / Audio
receiver with support the Bluetooth AV profiles.
Tips: If disconnection or lost link occurs, it maybe due to the following reason.
1. The range is over 10 meters between both Bluetooth stereo headset and Tx.
(Please keep the distance within 10 meters)
Connection Note
Action
iPod xx TX Cradle
Audio Jack
Analog Mode ○ X ○
USB Mode X ○ X

2. Bluetooth stereo headset / Audio receiver disconnected the link for some
certain condition.
3. Either device has been switched off. (Please make sure the devices turned on.
10. Warranty
zThis warranty lasts for one year from the date of purchase of the products.
zThis warranty extends to you only if you are the end users with the original
purchase receipt.
zWe will, at our option, repair or replace the products that do not conform to
the warranty.
zThe manufacturer or the seller shall not be liable for any incidental
consequence or damages by the end users.
zThis warranty gives you specific legal right. You may also have other rights
which vary from state to state.
11. Need more help?

Additional page
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
Including interference that may cause undesired operation
Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio Frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver- Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Do not
Any changes or modifications to the equipment not expressly approved by the party responsible for
compliance could void user’s authority to operate the equipment.
