ISOL-8 SubStation 3 User manual

Isolate, I SO-lat, v.t. to render free from external influence
-
I S O L 8
SubStation³
User Manual

Welcome
Firstly, thank you for purchasing your ISOL-8 SubStation³ we value your
custom.
We strive to design and build world class products that stand the test of
time.
By reading this manual you can gain clear understanding of its operation
and learn to care for it correctly. In turn, it will reward you with a
lifetime of outstanding performance.
Should any part of this manual or the operation of the SubStation³ not
be clear to you, please do not hesitate to contact your ISOL-8 dealer. If
this is not convenient, please contact ourselves directly.
To find out more about the importance of power supply in high
resolution systems, and to view our full range of mains distribution and
power conditioning solutions please visit our website:
www.isol-8.co.uk
Thank You

Unpacking
WARNING! SubStation³
13Kg. Seek assistance if necessary.
Store the packaging safely for future use. It is the ideal method of protecting it
from damage during transport.
Environment
The SubStation³ is cooled by convection. Make sure room temperature air can
circulate under and around it.
Do not place objects directly on top of the unit. Allow 20mm of clear space
above.
Do not enclose in an unventilated cupboard.
Do not place directly on carpet.
Do not place the unit near sources of heat such as radiators or in direct
sunlight.
Avoid abrasive surfaces as they may damage the finish.
A flat, smooth surface is required. A dedicated high performance equipment
platform sited away from other appliances is the optimum location.
Make sure the support for the SubStation³ is capable of carrying the13Kg
weight.
WARNING! Do not place the SubStation³ near liquids, or place liquid-filled
containers near the unit.
If liquid does come into contact with the unit there is serious
potential for an electric shock and / or fire hazard. Immediately pull
out the mains plug from the wall socket.
Contact your dealer to arrange an inspection before further use.
Be careful when unpacking your ISOL-8 . It is heavy;

Connections
Check the voltage marked on the back of the unit matches your mains supply.
Locate the SubStation³ as close to a wall outlet as possible. We recommend
using high quality power cables to make the connections to and from your
SubStation³.
Note that a Neurtik Powercon type input cable is needed. The ISOL-8
IsoLink Neutrik 20 cable is designed specifically to complement the
SubStation³ and is ideal for this purpose.
Cables using woven, unscreened construction may interact with the on board
filters and degrade performance.
Avoid adapters and extension cables and keep overall cable lengths as short as
is practical for best results.
The SubStation³ has dedicated, high performance filters for each connected
equipment type. Make sure you connect each system component to the
appropriate labelled outlet:
High power outlet
Circuit breaker
Earth binding post
Power input connector
Low/medium power outlet
5
4
3
2
1
Rear Panel View
12 3 4
15 5 55

It is recommended that all connections are made and checked before applying
power.
Equipment connected to the SubStation³ should not exceed a total maximum
continuous current draw of 16A.
Outputs 1 & 2 are “High power outlets” and specifically for integrated
and power amplifiers, receivers, video projectors, subwoofers, media
servers or any other product that may require heavy continuous or
transient power.
The “Circuit breaker” serves as an on/off switch and protects the unit
against over-current or fault conditions. When equipment is connected the
breaker will trip if an over-current or fault condition is encountered.
The “Earth Binding Post” allows separate earth wires to be connected.
An external earth spike may also be connected here. This terminal is
connected to the mains earth internally.
The “Power input connector” provides power to the unit via a Neutrik
20A connector. To connect the input cable; align the two spigots, push
firmly in and then rotate clockwise until a latching “click” is heard. To
disconnect; grip the plug and pull the silver lever towards you with your
thumb and gently twist the plug anti clockwise. Then pull out. For
maximum performance it should be connected directly to a wall outlet.
Avoid using adaptors or extension cables.
Outputs 3 to 6 are “Low/medium power outlets” and are for medium
to low power source components such as pre amplifiers, optical disc
players, DACs, tuners, phono stages or turntables. Connect equipment
types in adjacent pairs for maximum performance (analogue 3&4, digital
5&6 for example).
5
4
3
2
1

Operation
The maximum continuous total load connected to the unit must not exceed 16A.
Once all connections are made and checked the circuit breaker may be switched
on. Press the green button firmly in. To switch off press the red button.
The“feel”of the red and green buttons are different; this is normal.
During normal operation the front blue indicator will light on the front panel
indicating power is present on both high power and low/medium power sections.
The SubStation³ can be left powered on a day-to-day basis, but should be
switched off if the system is not being used for a significant period of time.
Fault Finding
Front panel indicator not lit and all outputs do not work;
Check that the circuit breaker is in the on position (green button in).
Check that the mains inlet cable is plugged into a wall socket and that
the socket's switch is on.
Check that the fuses in the mains lead (if applicable) and consumer unit
are intact.
If the SubStation³'s circuit breaker has tripped, the green button will have popped
out. This is the same state as when switched off. To reset push the green button in.
If the circuit breaker repeatedly trips, there are two possible causes:
1. The connected equipment has a fault: In turn, unplug each product and
turn on the circuit breaker. When the circuit breaker turns on without
tripping, then the product just unplugged is either faulty or is simply
drawing too much current.
2. The unit contains devices that protect against mains power surges and
high voltage spikes. In very rare cases an unusually severe event, such as a
lightning strike, can cause the unit to repeatedly trip. If the breaker
repeatedly trips once the connected equipment has been eliminated as a
cause; do not use the unit and contact your ISOL-8 dealer for service.
Your SubStation³ should not need servicing during normal operation. There are no
user serviceable parts inside. Do not open or attempt to repair the unit.

If you are in any doubt about any aspect of installation or operation, please
consult your dealer, a qualified electrician or contact ISOL-8 directly for
advice.
Cleaning
Dust the unit regularly with a soft cloth or soft brush. For more stubborn
marks use a slightly damp cloth with a very small amount of mild detergent
such as washing up liquid.
Do not use a wet cloth. Other cleaning or polishing agents should not be used.
Never use abrasives or alcohol based agents, they will harm the surface finish.
Do not allow the unit to become wet when cleaning.
Specification (subject to change)
Number of outlets: 6
Dimensions: 445*122*420mm (W*H*D)
Weight: 13Kg
Input Voltage: 200-260VAC (European versions)
Input frequency: 48Hz – 62Hz
Input socket: 20A Neutrik Powercon (NAC3FCA)
Maximum total continuous current: 16Amps (shared across all outlets)
Protection: Double pole circuit breaker
High power section
Outputs 1 & 2
Number of outlets: 2
Maximum total continuous current: 16 Amps (any one outlet Schuko version)
13 Amps (any one outlet other versions)
Medium/low power section
Outputs 3 – 6
Number of outlets: 4
Maximum total continuous current: 16 Amps (any one outlet Schuko version)
13 Amps (any one outlet other versions)

Returns
Should it be necessary for your to be serviced, please send it in
the original packaging to your dealer. If this is not possible please contact us to
obtain a Return Authorisation Number. Returns without this number will not
be accepted. If it is not returned to us in its original packaging, ISOL-8 reserve
the right to make a nominal charge for packaging by return.
Disposal and Recycling
At the end of the units working life it must be disposed of correctly. It is made
to the highest standards with materials which can be recycled wherever
possible. Do not dispose to landfill, contact your dealer or ISOL-8 for
information regarding return for correct disposal.
Declarations
Information given in this document is correct at the time of printing. Our
policy of continuous development means any changes might not be indicated in
the specification.
This product is guaranteed against defects in material and workmanship for 5
years from the date of purchase in the UK only. Proof of purchase is required.
The Guarantee is not transferable and is offered to the original purchaser only.
This guarantee does not limit your statutory rights within the country of
purchase.
Failure to comply with any of the above instructions during installation or
operation will render the manufacturer’s warranty null and void.
Marking by the “CE” symbol indicates compliance of this device with the EMC
(Electromagnetic Compatibility) and LVD (Low Voltage Directive) standards of
the European Community
Isol-8 Teknologies Ltd
PO Box 56402
London SE3 7WQ
fax: [phone]
email: [email protected].uk
Please visit our web site: www.isol-8.co.uk © Isol-8 Teknologies 2010
