Issendorff LCN-AT2 User manual

Active transponder with two push-buttons - LCN-AT2
The LCN-AT2 has the form of a keyring. W
reader, it wakens up from its current saving mode and transfers its identification number
(ID) to the reader (per HF-signal, 866MHz).
The HF-transmitter in the LCN-AT2 can also
be activated manually by pressing a push-
button. The range to the reader LCN-ATW
will then be around 50m.
Each of the push-buttons can trigger its
own function in the LCN-system.
Function of the LED´s on the LCN-AT2
LED operation/push-button pressed
LED battery change required
hen it comes in the range of an LCN-ATW
green
red
LCN-AT2 Installation guide
Local Control Network - building controls in perfection
®
key A
caption area
LED red
key B
LED green
1

LCN-AT2
Installation guide Local Control Network - building controls in perfection
®
How it functions
The transponders (LCN-AT2´s) are activated automatically through the field of an LCN-
ATW, without having to press a button. For this it is enough to enter the detection zone
(max. 4m range) of the reading device. The LCN-AT2 answers the LCN-ATW with its own
ID-Nr. It adds its recognition (LF-ID) when sending to the reader, to which it answers.
When the transponder-ID is stored in the LCN-module of the LCN-ATW, the module will
then carry out the LONG-COMMAND. When the LCN-AT2 leaves the detection zone , the
module carries out the RELEASE-
COMMAND with a delay of approx. 10s.
Additionally the number of the transponder
is sent to the LCN-Bus, so that access
control systems can react to it.
The transponders (LCN-AT2´s) can send
wireless commands to the reader over 2
push-buttons, without having to be within
the set detection field of the antenna. When
the push-button A is pressed, the LCN-AT2
sends an information over the wireless
receiver in the reader to the Bus module,
that carries out the HIT function of the
chosen key in the transponder table.
LCN-ATW
LCN-AT2
2

The push-button B on the LCN-AT2 carries out the HIT function on the subsequent key.
The range with HF transfer (when pressing push-button) has a maximum of 50m in free
environment. Please make sure, that the commands on both push-buttons from all of the
LCN-ATW´s in the wireless receiving area are detected and redirected to the connected
Bus module - see also installation guide LCN-ATW.
(LF = low frequency with 125kHz, communication ATW -> AT2
HF = high frequency with 868MHz, communication AT2 ->ATW)
Further functions
The transponders have in addition to their active chip, a
second passive transponder chip.
The passive transponder is coded with the same ID, so
that it is possible to combine an access control system
with LCN-ATW and -ULT.
The range when detected by the LCN-ULT, is approx.
10-20mm - see illustration.
transponder reader LCN-ULT
LCN-AT2
approx.
10-20mm
passive
transponder
LCN-AT2 Installation guide
Local Control Network - building controls in perfection
®
3

LCN-AT2
Installation guide Local Control Network - building controls in perfection
®
ISSENDORFF KG, 31157 Sarstedt
LCN-AT2 D12-2012
4
3V DC
7,5µA, 14,3mA for each 14ms
lithium-cells 2450 / 4-5 years. When used permanently in
the LF-field approx. 2 years
2/Hit functions with control LED
125kHz (globe formed detection range)
3D
depending on the settings of the LCN-ATW
up to 50m in an open environment
IP65
-20°C to +70°C
47mm x 63mm x 17mm
black/PA6 GF10 GK20/29g
eyelet for keys, 15 x 5mm, oval
868MHz (free of charge, usable ISM Band)
connection
operating voltage:
operating current:
battery/life expectancy:
inputs/push-button functions
LF-/HF-technic
LF (low frequency-magnet field):
reception characteristic:
range (LF, passive transfer):
HF (high frequency-magnet field):
Installation
protection art:
operating temperature:
dimensions (W x H x D):
colour/material/weight:
fixing:
HF
range (HF, active transfer)
Technical data LCN-AT2
Technical information and images are non binding. Changes are reserved.
Technical hotline: [phone] or www.LCN.de
Notes about duties according to battery laws
Old batteries do not belong in the waste bin. If batteries get into the environment, they can cause
environmental and health damages.
You can give used batteries back to your dealer or collection point free of charge. You are
commited as a user by law, to return old batteries.
