iStarUSA D-200A-T User manual

Product Quick Guide
Model Number: D-200A-T
2U Rackmount Chassis

Tel:[phone] lFax: 1-626-301-0588 lEmail: [email protected] lwww.istarusa.com
Product Quick Guide:
Hardware Guide
D-200A-T
1. Aluminum Bezel
(3 color Options: Red, Blue, Silver)
2. Power LED
3. Alarm reset
4. HDD LED
5. Temp Sensor 1 LED (TC-ISF08 require)
6. Fan LED (TC-ISF08 require)
7. Temp Sensor 2 LED (TC-ISF08 require)
8. Handle
9. 5.25” Bay X2
11. Key lock
12. USB 2.0
13. Reset button
14. Power button
15. 3.5” Bay X1
16. Ear Mount
18. For 2U Power Supply
17. Expansion slot
20. Cross bar/ Fan bar
19. For ATX, micro-ATX MB
21. 1x 80mm Fan
22. For Optional Sensor Board TC-ISF08
23. Removable Air Filter
Front View
Front Open View
1
23
Rear View
Top View
17 18
19
4 6
5 7 20
21
22
23
8 9
13 14 15
11 161210
10. 5.25” Slim Optical Drive X1

Tel:[phone] lFax: 1-626-301-0588 lEmail: [email protected] lwww.istarusa.com
Product Quick Guide:
Package Contents
Optional/ Related Items
D-200A-T
1. Screws kit x1
2. Cable tie
3. Key
T5PF-SA
1 x 5.25” Bay Trayless
Anti-vibration SATA Mobile
Rack
T-7M1-SATA
1x5.25” Bay Audio SATA/
SAS 6.0 Gb/s Mobile Rack
BPU-2535V2
1 x 3.5” to 2 x 2.5” SATA I/
II Hot-Swap Drive Cage
T5F-SS
1x5.25” Bay Trayless Anti-
vibration SAS/SATA Mobile
Rack
RP-HUB-SAUF
3.5” Combo Hub for
USB2.0/ Firewire/ e-SATA
T-7-SA
1x5.25” Bay Military Series
SAS/SATA 6.0Gb/s Mobile
Rack
BPU-124V2-SS
1 x 5.25” to 4 x 2.5” SATA/
SAS 6.0 Gb/s Hot-Swap
Cage
TC-RAIL-26
26” Sliding Rail Kit for Most
Rackmount Chassis
