iStarUSA D-400-7P User manual

Product Quick Guide
Model Number: D-400-7P
4U Rackmount Chassis

Tel:[phone] lFax: 1-626-301-0588 lEmail: [email protected] lwww.istarusa.com
Product Quick Guide:
Hardware Guide
D-400-7P
1. Plastic Bezel
2. Power LED
3. Alarm reset
4. HDD LED
5. Temp Sensor 1 LED (TC-ISF08 require)
6. Fan LED (TC-ISF08 require)
7. Temp Sensor 2 LED (TC-ISF08 require)
8. Handle
9. 5.25” Bay X7
10. Key lock
11. USB 2.0
12. Reset button
13. Power button
14. 3.5” Bay X1
15. Ear Mount
16. For 4U Power Supply
17. Expansion slot
18. 1x 80mm Fan
19. Cross bar/ Fan bar
20. For ATX, micro-ATX MB
21. For Optional Sensor Board TC-ISF08
22. Removable Air Filter
Front View
Front Open View
1
23
Rear View
Top View
16 17
18
4 6
5 7
19
20
21
23
22
8 9 10 15
11 12 13 14

Tel:[phone] lFax: 1-626-301-0588 lEmail: [email protected] lwww.istarusa.com
Product Quick Guide:
Package Contents
Optional/ Related Items
D-400-7P
1. Expansion slots cover
2. Cable tie
3. Screws kit x 2
4. Key
T5PF-SA
1 x 5.25” Bay Trayless
Anti-vibration SATA Mobile
Rack
T-7M1-SATA
1x5.25” Bay Audio SATA/
SAS 6.0 Gb/s Mobile Rack
BPU-2535V2
1 x 3.5” to 2 x 2.5” SATA I/
II Hot-Swap Drive Cage
T5F-SS
1x5.25” Bay Trayless Anti-
vibration SAS/SATA Mobile
Rack
RP-HUB-SAUF
3.5” Combo Hub for
USB2.0/ Firewire/ e-SATA
T-7-SA
1x5.25” Bay Military Series
SAS/SATA 6.0Gb/s Mobile
Rack
BPU-124V2-SS
1 x 5.25” to 4 x 2.5” SATA/
SAS 6.0 Gb/s Hot-Swap
Cage
TC-RAIL-26
26” Sliding Rail Kit for Most
Rackmount Chassis
