ISTblast RCM12 User manual

InstructIon manual
2019-06-14
T he reference in surface TreaTmenT
www.istsurface.com
REMOTE CONTROL
RCM12

2
RCM12 - Instruction Manual & Parts
L a référence en TreaiTemenT de surface
1. Place remote control handle in working position and press down rapidly the control handle (2). When
control handle (2) is completely pressed, the block (3) will remove itself from nozzle (9) and allow
blasting action to begin.
IMPORTANT: RCM-12 remote control handle must be operated rapidly, i.e. the operator must start or
stop blasting action rapidly. Any slow movement of remote control will prematurely wear-out block.
1. Remove nozzle adaptator (12) from nozzle (9). See gure B.
2. Insert nozzle (9) and protective washer (10) inside the remote control body (1). SZee gure C.
3. Screw control body (1) to nozzle coupling NC 1/2”(11) situated on blast hose. Nozzle coupling (10) must be
tightly secured on to control body (1) in order to insure air-tightness.
4. Press rmly the block (3) against the end of nozzle (9). When block (3) is well centered on nozzle (9), use Allen
key (8) to tighten screw (7). Since the lenght of each nozzle (9) may vary, block (3) must be adjusted each
time nozzle (9) is changed.
1. When the side of block (3) is worn-out by blasting action, loosen screw (7) and rotate block (3) to new
position. Press rmly against nozzle (9) and reset screw (7). Always keep in stock at least one spare block
(3)
2. Check frequently for worn parts and replace at once if needed. Special attention must be given to nozzle
washer (10). A worn out washer will deteriorate handle body (1) and require costly repairs.
3. Always use ISTblast nozzle (9) model CN3-2 with inside maximum orice of 1/8”
INSTALLATION
SET UP
MAINTENANCE

3
RCM12 - Instruction Manual & Parts
L a référence en TreaiTemenT de surface
PARTS
Items non-included with RCM-12
# STOCK DESCRIPTION
1
602121
Body
2
602123
Handle only
3
602126
Block
4
602122
Spring
# STOCK DESCRIPTION
9
605031
Ceramic Nozzle CN3-2
10
618015
Washer NW-0
# STOCK DESCRIPTION
5
602124
Axle
6
613301
Pin
7
608230
Allen screw
8
608220
Allen key
# STOCK DESCRIPTION
11
607050
Nozzle coupling NC-1/2
12
6607040
Nozzle adaptor NA-1
9
1
2
5
6
10
8
4
7
3
Fig. B Fig. C
11 11
12
99
Non-included
with RCM-12

2019-06-14
T : 1 800 361-1185
F : 450 963-5122
[e-mail]
ISTblast est une marque de commerce
enregistrée de
International Surface Technologies
4160, boul. Industriel
Laval, Québec
H7L 6H1 Canada
