M300
POCKET-SIZED DIGITAL MULTIMETER
OPERATOR'S INSTRUCTION MANUAL
01
Safety information
This meter has been designed according to EN61010-1,
EN61010-2-030,EN61010-2-033,EN61010-2-031, 600V
CAT II, 300V CAT III and pollution2.
Follow all safety and operating instructions to ensure the
meter is used safely and is kept in good condition With
proper use and care, your digital multimeter will give you
years of satisfactory service.
During use
• Never exceed the protection limit indicated in the
specifications for each range of measurement.
• Never use the meter to measure voltages that might
exceed 600V above earth ground in category II
installations
• Always be careful when working with voltages above
60v dc or 30v ac rms. keep fingers behind the probe
barriers while measuring.
• Do not perform resistance measurements on live circuits.
• Inspect test leads and probes for cracks, breaks or
crazes in the insulation before using the meter.
• If the equipment is used in a manner not specified by
manufacturer, the protection provided by equipment may
be impaired.
CATII
600V
CATIII
300V
Safety Symbols
Important safety information ,refer to the
instruction manual.
Earth(ground) TERMINAL
600V 200mA MAX
CAT III 300V
CAT II 600V
HIGH SAFETY
DMM
M300
V AV
2V
kΩ
20 V
kΩ
200V kΩ
mA
600V
2000kΩ

02 03
Front panel
1. Range switch
This switch is used to select desired ranges as well as to
turn on/off the meter .
2. Function switch
switch for selecting functions.
3. LCD display
3 1/2digit.7segment.maximum 1999 counts.
4. Test leads
Red test lead for positive (+) and black test lead for
negative (-).
Maintenance
• Before opening case .always disconnect test leads from
all energized circuits.
• For continuous protection against fire. Replace fuse only
with ratings : F 200mA H 600V
• Never use the meter unless the back cover is in place and
fastened completely.
• Do not use abrasives or solvents on the meter .to clean it
use only a damp cloth and mild detergent.
Fuse must be replaced with ratings specified
in the manual.
AC (Alternating Current)
DC (Direct Current)
Equipment protected throughout by double insulation.
CAT III
It is applicable to test and measuring circuits
connected to the distribution part of the building's
low-voltage MAINS installation.
European union directives
CONFORMS TO UL STD. 61010-1, 61010-2-030,
61010-2-033, 61010-031; CERTIFIED TO CSA STD.
C22.2 No.61010-1,61010-2-030, 61010-2-033,
61010-031.
CAT II
It is applicable to test and measuring circuits connected
directly to utilization points (socket outletsand similar
points) of the low-voltage MAINS installation.
3
2
4
1
600V 200mA MAX
CAT III 300V
CAT II 600V
HIGH SAFETY
DMM
M300
V AV
2V
kΩ
20 V
kΩ
200V kΩ
mA
600V
2000kΩ

04
Specification
Accuracy is guaranteed for 1 year .
23°C ±5°C, Less than 75%RH.
DC Voltage
Range Accuracy
Resolution
2V ±0.5% of rdg ±1dgt 1mV
20V
200mV
600V
±0.8% of rdg ±1dgt
±0.8% of rdg ±1dgt
±0.8% of rdg ±1dgt
10mV
100mV
1V
Overload protection: 600V dc or rms ac for all ranges
AC Voltage
Range Accuracy
Resolution
200V ±1.2% of rdg ±10dgts 100mV
600V ±1.2% of rdg ±10dgts 1V
Overload protection: 600V dc or rms ac for all ranges
Frequency range: 45Hz to 450Hz
Response: average responding .calibrated in rms of
a sine wave
General description
This compact digital multimeter is designed to
measure AC and DC voltages .DC current .Resistance .
Diode and to perform audible continuity checks with
accuracy and easy .
Small and lightweight .with a carrying case and test
leads wound on its body. This instrument will provide
you years of satisfactory service.
Resistance
Range Accuracy
Resolution
2kΩ±1.0% of rdg ±2dgts 1Ω
Maximum open circuit voltage : 0.65V
overload protection: 600V rms ac for all ranges
20kΩ
200kΩ
2000kΩ
±1.0% of rdg ±2dgts
±1.0% of rdg ±2dgts
±1.0% of rdg ±2dgts
10Ω
100Ω
1kΩ
Diode test
Range Description
Show the approx.
forward voltage drop of the diode.
Overload protection: 600V rms ac
Diode test
Range Description
Built-in buzzer sounds
when resistance is less than 50Ω.
Overload protection: 600V rms ac
05
DC Current
Range Accuracy
Resolution
200mA ±2.0% of rdg ±2dgts 0.1mA
Overload protection: F200mA H 600V fuse

06
General characteristics
Maximum voltage between CAT III 300V, CAT II 600V
Terminals and earth ground
Fuse protection F 200mA H 600V
Power supply
Display
Measuring method
Over range indication
Polarity indication
Operating temperature
Storage temperature
Low battery indication
Size
Weight
12V battery .GP -23AX1
LCD .1999 counts .updates 2-3/sec
dual-slope integration A/D converter
only figure “1” on the display
“ - ” displayed for negative polarity
0°C to 40°C (32°F to 104 °F)
-10°C to 50°C (10°F to 122°F)
120x70x18mm
approx.110g
Operating instruction
DC Voltage measurement
1. Set the function switch at V position
2. Set the range switch at desired position. If the magnitude
of voltage to be measured is unknown beforehand .
set the range switch at the highest position and then
reduce until satisfactory reading is obtained.
3. Connect test leads across the source or load being
measured. The polarity of red lead connection will be
indicated at the same time as the voltage value.
4. When the range switch is set at position. “HV”sign 600V
will appear on the display to remind user of high voltage
measurement. Special attention should be paid.
07
AC Voltage measurement
1. Set the function switch at V~ position
2. Set the range switch at desired position .measurement
reading can be obtained at 2V and 20V positions, but
the accuracy is not guaranteed.
3. Connect test leads across the source or load being
measured and read the voltage value on the LCD display.
4. When the range switch is set at position , a “HV” 600V
sign will appear on the display to remind user of high
voltage measurement.
DC Current measurement
1. Set the function switch at A position.
2. Set the range switch at 200mA position .measurement
reading can be obtained at other positions. But the
decimal point will be at the incorrect place.
3. Open the circuit in which the current is to be measured.
And connect test leads in series with the circuit.
4. Read current value on the LCD display along with the
polarity of red lead connection.
Resistance measurement
1. Set the function switch at Ω position .(note: the polarity
of red lead is positive “+”)
2. Set the range switch at desired position
3. Connect test leads across the resistor to be measured
and read LCD display.
4. If the resistor was being measured is connected to a
circuit .turn off power and discharges all capacitors
before applying test leads.
I
appears on the display

00-05-4334
08
Diode test
1. Set the function switch at Ω position .(note: the polarity
of red lead is positive “+”)
2. Set the range switch at position.
3. Connect the red test lead to the anode of the diode to
be tested and the black lead to the cathode of the diode.
4. The approx. forward voltage drop of the diode will be
displayed in mv.if the connection is reversed. Only figure
“1”will be shown
Audible continuity test
1. Set the function switch at Ω position.
2. Set the range at position.
3. Connect test leads to two points of the circuit to be tested.
if the resistance is less than 50Ω. Buzzer will sound.
Battery & Fuse Replacement
If the sign appears on the LCD display .it indicates that
the battery should be replaced. Remove the screw on the
back cover and open the case .replace the exhausted
battery with a new one of the same type.
Fuse rarely need replacement and blow almost always
as a result of operator's error. open the case and replace
the blown fuse with the ratings specified: F 200mA H 600V.
09
WARNING
To avoid electric shock, make sure the probes are
disconnected from the measured circuit before removing
the rear cover. Make sure the rear cover is tightly screwed
before using the instrument.
Battery
Carrying Case
Operating manual
Accessories
1pcs (12V GP-23A)
1pcs
1pcs
