iSys iTerra IJ1800 User manual

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1
0
Page 1
T
T
T
h
h
h
e
e
e
I
I
I
m
m
m
a
a
a
g
g
g
i
i
i
n
n
n
g
g
g
S
S
S
y
y
y
s
s
s
t
t
t
e
e
e
m
m
m
s
s
s
G
G
G
r
r
r
o
o
o
u
u
u
p
p
p
I
I
I
n
n
n
c
c
c
.
.
.
i
i
iT
T
Te
e
er
r
rr
r
ra
a
a
I
I
IJ
J
J1
1
18
8
80
0
00
0
0
R
R
Re
e
ef
f
fe
e
er
r
re
e
en
n
nc
c
ce
e
e
G
G
Gu
u
ui
i
id
d
de
e
e

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 2

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 3
Table of Contents
Page
1. Unpacking the Printer Box 5
2. Assembling the Printer Pedestal 7
3. Unwrapping the Printer 11
4. Assembling the Media Basket 15
5. Removal of Printer Packaging 17
6. Installing Ink Cartridges 19
7. Installing the Printheads 21
8. Loading Fanfold Paper 25
9. IP Configuration and Driver Installation 29
10. Manually Installing the IJ1800 Driver 39
11. Installation of Printer Monitor Application 47
Appendix
A. Operating the Front Panel 57
B. Unloading Fanfold Paper 63
C. Paper Jam 66
Limitation of Liability
The Imaging Systems Group’s total liability to the purchaser, or to any third
party, for damages from any and all causes whatsoever, regardless of the form
of action, whether in contract or in tort, including negligence, and any
infringement of proprietary rights or any misappropriation or unlawful use of
any proprietary rights or property of any third party shall, in the aggregate, be
limited to purchase price actually paid by the purchaser for the product relating
to the damages. The limitation of liability provisions of this agreement reflect
an informed voluntary allocation of the risks (known and unknown) that may
exist in connection with the provisions of the goods and services provided
hereunder by The Imaging Systems Group Inc., and that such voluntary risk
allocation represents a fundamental part of the agreement reached between
The Imaging Systems Group Inc. and the purchaser.
The Imaging Systems Group Inc. shall not be liable for any special, direct or
indirect, incidental, consequential, exemplary, punitive or any similar or other
damages of any nature suffered by the purchaser whatsoever including, without
limitation, loss of use or lack of availability of the purchaser facilities, including
its computer resources and any stored data, loss of profits or revenue, or other
commercial loss, or any claim for contribution or indemnity in respect of any
claims against the purchaser, regardless of whether The Imaging Systems
Group Inc. has been advised of the possibility of such damages.
iSys - The Imaging Systems Group Inc.
911 - 28th Street N.E. Calgary, AB CANADA T2A 7X1
Phone [phone] Fax: [phone]
e-mail: [email protected]
www.isys-group.com

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 4

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 5
1 Unpacking the Printer Box
STEP 1.1 STEP 1.2 STEP 1.3
The iTerra IJ1800 Printer will be shipped
on a skid.
Unwrap the packaging and remove lid
from printer box.
Remove the outer shell of the box.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 6
1 Unpacking the Printer Box - continued
STEP 1.4 STEP 1.5 STEP 1.6
The printer pedestal box should be
located underneath the printer box.
Remove the printer from the box and
place it on the floor. Store the box and printer packaging in case future shipping is required.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 7
2 Assembling the Printer Pedestal
STEP 2.1 STEP 2.2
Use parts 2 and 3 to attach the printer to the pedestal. Assemble pedestal legs left and right.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 8
2 Assembling the Printer Pedestal - continued
STEP 2.3 STEP 2.4
Install cross beam into left and right legs. Install printer left and right supports onto the cross beam.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 9
2 Assembling the Printer Pedestal - continued
STEP 2.5 STEP 2.6
Install the media locator plate onto the right leg. Once you have the printer unwrapped, attach the iTerra
IJ1800 printer to the pedestal.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 10

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 11
3 Unwrapping the Printer
STEP 3.1 STEP 3.2 STEP 3.3
Place the printer on the floor near the
assembled pedestal.
Make sure both packaging end caps are
removed from the printer.
Remove the printer from the plastic bag.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 12
3 Unwrapping the Printer - continued
STEP 3.4 STEP 3.5 STEP 3.6
The printer is now ready to be placed on
the pedestal. The printer weight is
44 lbs (19.96 kg).
Printer with Pedestal dimensions:
Width = 35" (890mm)
Depth = 29.95" (743mm)
Height = 39.18" (996mm)
Two people should place the printer on
the pedestal. Make sure you lock the
wheels. If you do not wish to use the
pedestal, place the printer on a stable
surface, respecting the weight and
dimensions of the iTerra IJ1800
(described in previous step).
To secure the printer to the pedestal
make sure you use the parts provided
along with the Allen Key. See illustration
in Step 2.6.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 13
3 Unwrapping the Printer - continued
STEP 3.7
Once the printer is secured to the
pedestal remove tape and the little
storage bags from the printer.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 14

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 15
4 Assembling the Media Basket
STEP 4.1
Attach basket to the mounting bracket.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 16
4 Assembling the Media Basket - continued
STEP 4.2 STEP 4.3
Once the printer is mounted onto the pedestal, attach the
basket to the pedestal cross support beam. Ensure the locator pin of the pedestal crossbeam sticks through the slot of the basket bracket.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 17
5 Removal of Printer Packaging
STEP 5.1 STEP 5.2 STEP 5.3
Open the hinged flaps on the right side
of the printer. Remove the foam
packaging.
Close the hinged flaps at the right of the
printer.
Insert the power cable into the printer
and then, into the power socket. Wait
15 seconds before turning on the printer.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 18
5 Removal of Printer Packaging - continued
STEP 5.4 STEP 5.5
Press the Power key to switch the printer
on.
The front panel and yellow light will start
to flash. Wait until the timer icon
disappears.
WAIT
UNTIL TIME
R
DISAPPEARS

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 19
6 Installing Ink Cartridges
STEP 6.1 STEP 6.2 STEP 6.3
Open the hinged flaps at the right of the
printer.
The ink cartridges for the iTerra IJ1800
are available through iSys Media. They
can be ordered by calling:
1-866-415-4797
or visit
www.isys-media.com
Match the color of the cartridge to the
slot in the printer. Insert the cartridge
until it clicks into place. As the ink
cartridges are inserted, the front panel
will display the ink levels.

© 2007 iSys – The Imaging Systems Group Inc.
iTerra IJ1800 Reference Guide Rev 1.1 Page 20
6 Installing Ink Cartridges - continued
STEP 6.4
Once the last ink cartridge is inserted
only the printhead icons should be
flashing.
