Italgi Dupla User manual

ITALGI S.r.l.
MACCHINE E IMPIANTI PER PASTA FRESCA E SECCA
MACHINES AND PLANTS FOR FRESH AND DRY PASTA
MÁQUINAS Y PLANTAS PARA PASTAS FRESCAS Y SECAS
Via Pontevecchio, 96A, 16042 Carasco (GE)
Tel.0039-0185350206 Fax 0039-0185350523
e-mail italgi@italgi.it web site: www.italgi.it
D
DU
UP
PL
LA
A
USE AND MAITENANCE MANUAL

ITALGI s.r.l. – DUPLA – Use and maintenance manual
2/28
1 - INTRODUCTION
1.1 - Warning
READ
CAREFULLY
BEFORE
INSTALLING
AND
USING
THE
MACHINE !
Thank you for chosing our Modula.
Read this manual carefully before installing and using the
machine.
This manual is to be considered part of the
machine and the machine should never be used
without reading the manual first.
Please save this manual for future reference.
Anyone using or maintaining the machine should read
this manual and have free access to it at any time.
Manufacturer and retailer decline any responsibility for
any damage to people or things caused by non-correct
installation, use of power supply that does not conform to
the one indicated on the identification tag at the back of
machine, removal of protections or use of the appliance
in a way that does not conform to the indications and
prescriptions in this manual.
Manufacturer will not be liable for any injury or damage
caused by the machine if it has not been used properly or
if it has been modified by anyone after installation.
Always wear suitable clothes: do not wear any unlaced
jacket, ties or loose clothes.
Always gather up your long hairs.
For your personal safety all the electrical connections
and installation must be carried out by a trained
electrician. The installation process described in
paragraph 2 of this manual, must be carried out by
specialized technicians authorized by manufacturers or
by the distributor of the machine.
Never use the machine for any purpose different from
those indicated in this manual.
Always turn machine off before cleaning or servicing it;
ABSOLUTELY never run the machine without the proper
supplied safety panels and covers.
Always keep children away from the machine.
Wash and clean accurately the parts in contact with food
before using the machine, as explained in this manual.
Always keep machine and surrounding environment
clean and sanitized.
For any further information, please contact your retailer
or us.
Do not allow the use of the machine to people younger
than the minimum allowed by local rules.
WARNING !!! Throughout the manual this
symbol indicates important information warning
you of any hazardous operation. Always read
the message that follows it.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
3/28
1.2 -Technical data
Ravioli sheet width [mm] 100
Ravioli group production [up to kg/h] 25
Gnocchi group production [up to kg/h] 20
Motor power [kW] 0.25
Electric consumption [kW] 0.4
DUPLA is a combined pasta machine for the
production of ravioli and gnocchi (with extra gnocchi
forming group GN20).
Innovative solutions and extreme care in machine
design assure the greatest safety for all users and a
long life of machine, just like all ITALGI machines.
The machine, designed by ITALGI, has been made
to simplify both use and cleaning and it has been
manufactured according to the latest hygienic and
safety standards.
All parts of DUPLA in contact with food are built in
AISI 304 stainless steel or in other material
compatible with food.
Dimensions and weight
VERSION DIMENSIONS [cm] WEIGHT [Kg]
DUPLA 50x45x100 H 47
DUPLA + GN20 50x55x100 H 55
It is possible to insert different interchangeable
moulds and the additional gnocchi and chicce
forming group GN20.
Some innovative technical solutions of machine are patented

ITALGI s.r.l. – DUPLA – Use and maintenance manual
4/28
1.3 -Description of machine
The main components of the combined pasta
machine DUPLA are the following:
PE - Emergency push button
P - Control panel
R - Filling container
L - Filling feeding lever
MR- Filling adjustment knob
S - Ravioli mould
PF - Ravioli fixing stud
Gnocchi and chicche forming group GN20
The main parts of the GN20 gnocchi and chicche
forming group are:
RF - Flour dispenser container
LF - Flour dispenser adjustment lever
S - Cutting group cover
SG - Product outlet chute
MR- Ruling adjustment knob

ITALGI s.r.l. – DUPLA – Use and maintenance manual
5/28
1.4 - Description of the control panel
WARNING !!! Never open main control
panel [Q] if you are not a qualified
electrician. Turn off main power switch
before opening main control panel [Q].
Main control panel [P] is positioned on the front part
of machine and includes the following devices:
PE -
EMERGENCY – Stops machine in case of
emergency
P1 -
START – Starts the machine
P2 -
MAN – Manual functioning button
P3 -
STOP – Stops the machine
R -
RETE – Shows that machine is on

ITALGI s.r.l. – DUPLA – Use and maintenance manual
6/28
2 - INSTALLATION (TO BE CARRIED OUT BY TRAINED
PERSONNEL)
2.1 - Positioning the machine
WARNING !!! Machine is very heavy. Always
use a forklift to move it (minimum capacity 100
kg).
Unload the pallet with the packed machine with a forklift
(minimum capacity 100 kg).
Reach the room where the machine will be operating,
remove the packing and place the machine on an horizontal
desk. It must be strong enough to support the weight of the
machine, according with the technical data table.
WARNING !!! Moving heavy machinery can be
very dangerous ! Make sure that the forklift or
the crane is strong enough to lift the load.
Always double check that the machine is
securely fastened and doesn’t shake. Never
walk underneath or nearby any lifted heavy
piece of equipment.
Avoid keeping heavy loads high while moving
them around; always keep them as close as
possible to the ground.
If you have not any safe lifting device, the machine can be
lifted by two strong people, as shown in picture.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
7/28
2.2 - Electric connections
WARNING !!! For your personal safety all the
electrical connections and installation must be
carried out by a trained electrician.
Verify that the electric power available is compatible with the
electric characteristic of your machine, as reported on the
identity plate placed on machine.
Connect machine to a power outlet with ground wires and
equipped with a differential breaker.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
8/28
3 - USE
WARNING !!! Before starting machine, be sure
that nobody is working on machine or is
cleaning it!
Before using the machine be sure that machine is properly
cleaned and sanitized (according to your local regulations).
Be sure that machine is properly connected to electric
source.
Verify that nobody is working on machine or is cleaning it.
3.1 - Making ravioli
Open the cover [1] and insert the desired ravioli mould [2],
as shown in picture.
Check that the ravioli mould [2] is properly inserted till the
end of its seat; this must allow the closing of the cover [1] (if
there are any difficult, extract the mould and turn its rolls of
some degrades to make easier its gearing wheels coupling
with the other gears inside the ravioli group) and fix it
inserting the pin [3] into its seat by screwing the knob [4].
WARNING !!! Always insert properly and
carefully the ravioli mould. Otherwise the
machine could be seriously damaged!

ITALGI s.r.l. – DUPLA – Use and maintenance manual
9/28
Turn the handle [6] into a vertical position, as shown in
picture.
This operation unhooks the movement of the piston [7] for
the filling pressing.
Rotate the handle [6] clockwise till the piston [7] reaches the
top position; remove the filling container [8] and fill it with the
desired stuffing.
The stuffing has to be soft. It is necessary to pass it through
a meat chopper and it must not have any filament or crumb.
These pieces could obstruct the holes of the mould’s
stuffing distributor and they could compromise the proper
filling of the ravioli.
The filling must not be fat or greasy as it could make difficult
the closing of ravioli.
WARNING !!! If the handle [6] is unhooked, the
automatic movement of the piston [8] is not
active and it will be then possible to lift it up or
down by rotating the handle [6].
To make work the automatic movement of the
piston [8], hook the handle [6] lowing it to the
horizontal position.
Insert the stuffing distributor [10] into its seat [9].
Remember each mould has its own distributor: use the
proper one.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
10/28
Replace the filling container, keeping the shaped side on
the left side, as shown in picture.
Turn the handle [6] counter-clockwise to lift down the piston
[8] for some centimetres inside the filling container [7].
Turning the handle [6] into the horizontal position as shown
in the picture, to activate the automatic movement of the
piston [7].
Start ravioli machine pressing the button [P1], “START”,
untill you see, through the lateral fissure [11], some stuffing
coming out from the filling distributor.
As soon as you see the filling coming out, stop the machine
pressing the button [P3], “STOP”, to save from dirtying the
mould.
For the first use of the day, it is suggested to fill the
distributor before beginning to make ravioli.
This operation can be carried out by removing the mould,
place a container under the ravioli outcome and get some
filling coming out from the distributor, then stop the machine
and take away the filling from the distributor outlet.
In this away you will have an homogeneous outlet of the
filling from the different holes of the distributor and already
the first ravioli will have the same quantity of filling.
WARNING !!! If the filling dirties the mould’s
rolls, it won’t work properly! In this case it will
be necessary to take away the mould and
clean it carefully.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
11/28
Unhook the handle [6] turning it as shown in the picture.
This will avoid the piston to push the filling while machine is
working.
Prepare two paste rolls (width 100mm).
Place the sheet rolls on the their supports, start ravioli
machine pressing the button [4], “RAVIOLI”, and insert the
ends of the sheets into the front and rear calibrating
rolls[13].
As soon as you see the formed sheets out-coming from the
mould. Turn the handle [6] into the horizontal position,
This operation will activate the pushing of the filling into the
mould.
If during this phase you will see the sheets are stick to the
mould’s rolls, open the front cover of ravioli machine and
remove the sheet from the mould.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
12/28
When the machine produces stuffed ravioli, the weight of
the ravioli belt will avoid them to stick to the mould.
We recommend to not detach the ravioli as soon as they
come out from the mould and we suggest to leave a belt
coming out to make easier their detach, as shown in the
picture.
WARNING !!! Lifting up the cover [1] of ravioli
machine, the machine stops automatically. To
re-start the machine, check the cover is
completely lift down and press the starting
button [P1], “START”.
It is possible to adjust the quantity of filling by rotating the
knob [14] and it is possible to check the quantity through the
indicator [15].
We recommend to take note of the quantity of filling you
use.
This will make easier to know the desired quantity of filling
you prefer according to the kind of mould and filling.
When the stuffing ends, stop the machine by pressing the
button [P3], “STOP”, turn the handle [6] to the vertical
position to unhook the automatic lowering of the piston.
Then rotate the handle [6] to lift up the piston till the top
position and to allow the extraction of the filling container [7]

ITALGI s.r.l. – DUPLA – Use and maintenance manual
13/28
Remove the filling container [7] and fill it.
Re-insert, and lift down for some centimetres the stuffing
piston [8] turning counter-clockwise the handle [6].
Turn into the horizontal position the handle [6] to hook the
automatic lowering of the piston and re-start the machine by
pressing the button [P1], “START”.
Once you finish the production of ravioli, always stop before
the filling, rotating the handle [6] into the vertical position
and let the double sheet coming out for some seconds more
till the ravioli will come out without any stuffing.
This operation avoids to dirty the mould with the stuffing
After unhooking the automatic lowering of the piston, let the
machine on, till the two sheets of pasta will completely come
out from the mould.
Stop ravioli machine pressing the button [P3], “STOP”.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
14/28
3.2 - Gnocchi and Chicche production (Gnocchi machine GN20)
Suggested mixture
Dried potato flakes
1 kg
Wheat flour 400 g
Water 1,6 kg
Salt 80 g
For the preparation of the potato mixture you can use a
ready mixed product for gnocchi or dried potato flakes.
If you use a prepared mix it is necessary to follow the
directions given by the producer of the product.
If you use dried potato flakes you can mix the ingredients in
a mixer according to the proportions given in the table on
the side. The mixture will be ready in 15 - 20 minutes.
The mixture must be soft and well mixed and not show clots
(too dry). A wrong mixture can avoid the good functioning of
machine and seriously damage it.
Unscrew the mould’s fixing pin [3] by turning the knob [4]
and remove the pin completely.
Open the cover [1] and remove the ravioli mould [2].
Remove the sheet rollers support [5] from the front side of
the machine.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
15/28
Insert the gnocchi group GN20 into the ravioli mould’s
position, as shown in the picture.
Keep closed the cover of the ravioli group and insert the two
sides of the gnocchi group through the opened sides of the
cover [6].
Use the supplied tool [7] to turn anticlockwise the nut [8]
located on the side of the GN20 gnocchi group till it is
completely inserted into its seat inside the ravioli group.
Insert the fixing pin [9] into the hole [10] on the side of
gnocchi group GN20 turning it till the end.
When the gnocchi group GN20 is properly inserted, the
cover [S] is mechanically blocked.
To open the gnocchi group GN20 it is necessary to remove
it from its seat inside the ravioli group.
Insert on the gnocchi dough container [RG] the distributor
[12] – use the one with the single hole for gnocchi and the
one with two holes for chicche – and turn it clockwise to fix it
with the two pins on the pipe [13].

ITALGI s.r.l. – DUPLA – Use and maintenance manual
16/28
Prepare the gnocchi dough with a proper mixer and fill the
container [RG] with the dough.
Insert the container [RG] by the back side of the machine,
taking care to insert properly the distributor [12] into the hole
[14], as shown in the picture.
Push the filling container [RG] till it fits into its seat.
Turn the handle [L] clockwise to lower the piston [15] for
some centimetres inside the container [RG].

ITALGI s.r.l. – DUPLA – Use and maintenance manual
17/28
Turn the handle [L] into the horizontal position as shown in
the picture, to activate the automatic movement of the
piston.
Fill the flour dispenser container [RF] with a proper flour. It
is suggested the use of rice flour, which is particularly
suitable to avoid the sticking of gnocchi.
Pull the lever [LF] to adjust the quantity of dispensed flour
on the product.
The lever [LF] has three positions:
1) If is it completely inserted, the dispenser does not
work
2) If the lever is in the mid position, the dispenser
pours a medium quantity of flour
3) If the lever is in the more external position, the
dispenser pours the maximum quantity of flour
WARNING !!! ALWAYS USE THE FLOUR
DISPENSER WHEN YOU MAKE GNOCCHI OR
CHICCE. OTHERWISE THE CUTTING GROUP
COULD BE SERIOUSLY DAMAGED!

ITALGI s.r.l. – DUPLA – Use and maintenance manual
18/28
Turn anticlockwise the ridge gnocchi adjustment knob [MR].
This will make easier the exit of the product in the first
phase of production.
Start the machine pressing the button [4], “RAVIOLI”. After
some seconds gnocchi will come out through the chute
[SG].
To adjust the size of gnocchi, turn the knob [16] on the top
of the machine.
The [17] indicator, displays the value corresponding to the
size of the product, according with the adjustment of the
know [16].
Take note of that value, to be able to make the product.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
19/28
Turn the ridge gnocchi knob [MR] to adjust the
smooth/ridged surface of gnocchi and chicche.
When the gnocchi dough finishes, stop the machine
pressing the button [P3], “STOP”, turn the handle [L] to the
vertical position to unhook the automatic lowering of the
piston.
Then rotate clockwise the handle [L] to lift up the piston till
the top position and to allow the extraction of the container
[15].
Remove the container [RG] and fill it again.
Insert the container [RG] by the back side of the machine,
taking care to insert properly the distributor [12] into the hole
[14], as shown in the picture.
Push the filling container [RG] till it fits into its seat.

ITALGI s.r.l. – DUPLA – Use and maintenance manual
20/28
Turn the handle [L] anticlockwise to lift down the piston [15]
for some centimetres inside the container [RG].
Turn into the horizontal position the handle [L] to hook the
automatic lowering of the piston and re-
start the machine
pressing the button [P1], “START”.
To make chicche, put the two holes distributor [12] onto the
gnocchi dough container [RG]
It is necessary to repeat the previous steps to adjust the
size of the product each time you use another distributor
[12].
When you finish the production of gnocchi and chicche, stop
the machine pressing [P3], “STOP”, turn the handle [L] to
the vertical position to unhook the automatic lowering of the
piston.
Then rotate clockwise the handle [L] to lift up the piston till
the top position [15].
Table of contents
Popular Pasta Maker manuals by other brands

Royal Catering
Royal Catering RC-PM150Q user manual

Lotus
Lotus CP-558ET Installation and operating instructions

Philips
Philips HR2345/19 user manual

Rommelsbacher
Rommelsbacher PM 220 instruction manual

Electrolux
Electrolux 200396 (NCPG400U) Specification sheet

Keating Of Chicago
Keating Of Chicago Gas Custom Pasta System Service manual

gourmetmaxx
gourmetmaxx Z 09952 instruction manual

Marcato
Marcato AtlasMotor Wellness Instructions for use and maintenance

Moffat
Moffat Blue Seal Evolution E47 Installation and operation manual

Gastroback
Gastroback 90763 operating instructions

Pitco
Pitco and RSE14 Installation & operation

MBM
MBM MINIMA Series Installation, use and maintenance instructions
