ITC T-775H User manual

OWNER'S MANUAL
Wall Mount Speaker
Wall Mount Speaker
T-775H/775HWT-775H/775HW
T-775H/775HW
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
Please be sure to use the former reading detailed notes.
Really pay attention to this manual and a safety with the important warning.
Recommend that you keep this manual for future reference.
When installed loudspeakers
Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
Restricted by the provisions of the speakers on the voltage, such as the
use of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
Wet hands must not be admitted into or plugs, may lead to electric shocks.
The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
Avoid speakers installed in the humidity or dust, direct contact with the sun,
from the near-electric, or smoke or steam, may cause fire or electric shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.

Model
Power Taps@100V
Power Taps@70V
Impedance
Sensitivity
Freq Resp
Wall Mount Speaker
T-775H
3.75W,7.5W,15W,30W
1.9W,3.75W,7.5W,15W,30W
2.6K /1.3K /670 /330 /165 /8
88dB
100-18KHz
T-775HW
20.00 mm
40.00 mm
Dimension
Installation
Specifications
Label Stickers
10mm 4mm
13.5mm 144mm
(Figure:Speaker hole size)
5
5. The completion of speakers in the
walls of the entire installation
process.
12
34
Wall Wall
Wall Wall Wall Wall
2. (Figure) Withmeasuring tools, measure
parts speaker holeand the holesize and
the distance betweenplaces, and selected
in line with thescrew hole will befixed for-
tunately, speakerwall accessories.
1. Speaker weightof 2.7Kg,
must be chosenby our
body strong andavoid
unstable speakers falling
or injuries.
3. Wall speakerinstallation method to
choose any ofthe two.
4. The horngently into the accessories
have been installedon the walls,the
speakers up anddown with twoholes
the other two partsalign with the nut.
selected in linewith the hornscrew
hole bit, fixed.
T-775H/775HW
Input
T-775H
70V/100V/8
88dB
100-18KHz
285 180 186 mm
2.6K /1.3K /670 /330 /165
3.75W/7.5W/15W/30W
1.9W/3.75W/7.5W/15W/30W
T-775HW
Model
Power Taps@100V
Power Taps@70V
SPL(1W/1M)
Freq Response
2.7Kg
Weight
Dimensions
Impedance
285 mm
186mm
180mm
5mm
60mm
T-775H/T-775HW
