Itek ST4 2NL User manual

INSTRUCTION MANUAL
Q U A LITY REFLECTED
®
2.1 BLUETOOTH SPEAKERS I58012
TO: CUSTOMER SERVICES DEPARTMENT ITEK SUTTON HOUSE BERRYHILL ROAD, FENTON STOKE ON TRENT ST4 2NL
Please place post-
age stamp here
Q U A LITY REFLECTED
®
Q U A LITY REFLECTED
®
Q U A LITY REFLECTED
®
Q U A LITY REFLECTED
®
QU A LITY REFLECTED
®

GUARANTEE
This product is guaranteed for 12 months from the date of the original purchase.
If any defect arises due to faulty materials or workmanship the faulty products must be returned
to the place of purchase. Refunds or replacement is at the discretion of the Retailer .
The following conditions apply:
The product must be returned to the retailer with the original proof of purchase.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
For domestic purposes. ONLY.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has no responsibility for incidental or consequential loss or damage.
Valid in the UK and Eire only.
Technical Specication.
Product Code I58012
2.1 Bluetooth Speaker
AC: 220V- 240V ~50Hz 0.35A
Power Input: DC 12V 1125mA
15Watts Sub-Woofer
2 x 5Watts Satellite Speakers
Total 25Watts Sound Output
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staffordshire,
ST4 2NL.
Parts Identication
1. LCD Indicator
2.Volume Control
3.Air Duct
4. Power On/Off Switch
5.AC Input Jack
6. Speaker Connection Jack
7. Microphone Input Jack
8. Headphone Jack
9.Auxiliary Jack
10. Satellite Connection Cable
11.Wireless Remote Control
REMOTE CONTROLLER
BUTTON FUNCTION OPERATION
Power ON/OFF Pressing this button Turns ON or OFF the unit
Mute Pressing this button mutes the system
Bluetooth® Pressing this button enables unit into Bluetooth Mode
AUX Pressing this button enables AUX Mode –Wired Connection
the computer or any other portable audio device connected
using wires, is activated.
Bluetooth Press this button once puts the unit
Pairing Modein Bluetooth Pairing Mode
Previous Track Press this button when you are paired with Bluetooth.
This will play previous track
Play/Pause Press this button when you are paired with Bluetooth.
This will Play or Pause the current track
Next Track Press this button when you are paired with Bluetooth.
This will play next track
VOL + IncreaseVolume This will increase theVolume
VOL - DecreaseVolume This will decrease theVolume
TRE + Increase Treble This will increase the Treble
TRE - Decrease Treble This will decrease the Treble
BASS + Increase Bass This will crease the Bass
BASS - Decrease Bass This will decrease the Bass
KEY FEATURES
Bluetooth® Multi Media Speakers
Compatible with all Bluetooth enabled devices such as Smart Phones,Tablets, Computers Etc.
Wired Connection also available for computers, netbooks, laptops etc
Syncs in Seconds
Digital Volume Indicator
Wireless Remote Controller Included
Wireless Range – 10 Meters (33 Feet)

SAFETY INSTRUCTIONS
Keep the unit away from heat sources, direct sunlight, humidity, water and any other liquids.
Do not operate the unit if it has been exposed to water, moisture or any other liquids to pre-
vent against electric shock, explosion and/or injury to yourself and damage to the unit.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualied electrician. Improper
repairs may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended purpose.
Keep the unit out of reach of children.
This appliance is not a toy.
This produt is not intended for use by children or the inrm without adequate supervision or
training by the person responciable for their safety.
Do not use the handset at excessive levels as damage to hearing may occur.
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat place, such
as sunshine, re or the like.
Prolong use at high sound levels may damage hearing permantly caution is recommended
PACKAGE CONTENTS
Sub-Woofer
Satellite Speakers – Left & Right
Remote Control
Power Adaptor
Instruction Manual
GETTING STARTED
Remove the unit from the box.
Remove any packaging from the product.
Please retain all packaging until you have checked and counted all the parts and the contents
against the parts list.
INSTALLATION
Place the Left and Right satellite speakers next to the Sub-Woofer
Connect the satellite speakers to the appropriate connector on the back of the sub-woofer. It
should be connected on the #6 (Shown on Figure 1) speaker connection jack.
Connect the power adapter to the DC input jack #5 (Shown on Figure 1) and to a standard AC
electrical outlet (A Surge protector is recommended to protect your new Bluetooth® Multi
Media Speaker System).
Power ON the Unit using the Power On/Off Switch #4 (Shown on Figure 1) on the back of the
sub-woofer.Also press Power ON button on the remote controller.
You can now start using the BLUETOOTH 2.1 MULTI MEDIA SPEAKER SYSTEM
INSTRUCTION FOR USE
CONNECT USING BLUETOOTHTECHNOLOGY
Turn ON the unit
Press Bluetooth button on the Remote Controller
Press “SYNC” on the Remote Controller to go into Pairing Mode. LED Indicator lights keep
blinking once the unit goes on pairing mode.
Activate the Bluetooth function on your Bluetooth Device (Mobile Phone or Tablet).
Please refer to manufacturer’s instructions for instructions on enabling Bluetooth
on your device.
Once you have activated Bluetooth on your device, select the “2.1 SPEAKER” from
the list of available Bluetooth devices.
If required, enter the password ‘0000’ to conrm pairing.
Once paired successfully, the LED ashes green, until the unit remains paired.
Choose music from your Bluetooth® device and play music wireless through the speakers.
CONNECTING TOYOUR COMPUTER
Turn ON the unit
Connect the 3.5mm stereo cables to the output port on your MP3 / MP4 / Cell Phone /
Tablet / Computer sound card (The cable end is color coded to match the output jack
on most sound cards –Green color for Speaker and Red color for Microphone).
Note:While connecting through auxiliary, Green jack should be connected to the auxiliary port
of your music device.
Turn on your Computer (Or Portable Audio Device). Open media player such as Windows
Media Player®, etc. Click on PLAY to start playing your music.
Adjust the volume, bass and treble using the Remote Controller to a comfortable
listening level. Make sure the volume on your speaker system, in your music software and the
main volume control in your operating system are all at an audible level (if any one of these
volume levels are set to the lowest settings, you will not have sound coming from the speakers).
Note:
While connected through auxiliary, all the media (Previous Track / Next Track) can be controlled
using the source device (MP3 / MP4 / Cell Phone / Tablet etc.)
CARE AND MAINTENANCE
Read the following recommendations before using the Bluetooth Multi Media Speaker System.
Following these you will be able to enjoy the product for many years.
Do not expose the unit to liquid, moisture or humidity to avoid the product’s internal circuit
being affected.
Don’t use abrasive cleaning solvents to clean the unit.
Do not expose the unit to extremely high or low temperature as this will shorten the life of
electronic devices, destroy the battery or distort certain plastic parts.
Don’t dispose of the unit in re as it will result in an explosion.
Don’t expose the unit to contact with sharp objects as this will cause scratches and damage.
Don’t let the unit fall down onto the oor. The internal circuit might get damaged.
Don’t attempt to disassemble and repair the unit. Only qualied Personnel

Model no: Serial no: Batch no: Name: Address: Date Purchased: E-mail Address: IMPORTANT This warranty is invalid if alterations have been made to this certicate
Dealer Stamp/Details: If you would NOT like to receive special offers and promotions from PFD and it’s associated companies please tick this box
Q U A LITY REFLECTED
®
DISPOSAL OF UNIT
Disposal instructions for Itek items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.You are required to dispose
of old electrical and electronic appliances like this separately.
Please visit www.recyclemore.co.uk, or www.recylcenow.co.uk for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather than taken to
landll. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end
of its life.
Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC.The Electromagnetic compatibility Directive
2006/95EC.The LVD directive (LowVoltage Directive)
2002/95/EC.The RoHS. Directive. (Restriction of Hazardous substances Directive)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent, Staffordshire, ST4 2NL.
BATTERY DISPOSAL
The crossed out wheelie bin symbol on this item indicates that this appliance needs
to be disposed of in an environmentally friendly way when it becomes of no further use
or has worn out. Contact your local authority for details of where to take the item
for re-cycling.
SPECIFICATIONS
15Watts Sub-Woofer
2 x 5Watts Satellite Speakers
Total 25Watts Sound Output
Power Input: DC 12V
Digital Volume Indicator
Bluetooth® Music Receiver
Bluetooth® Version: 2.0
Bluetooth Proles: A2DP, ACRCP
