ITSU IS0507 User manual

IS0507 User Manual
Version:2023/3/1

Page
Contents
1
SAFETY CAUTIONS------------------------------------------2
GROUNDING INSTRUCTIONS----------------------------3
ASSEMBLY INSTRUCTIONS------------------------------4
OPERATION GUIDE------------------------------------------7
EXPLODED DRAWING--------------------------------------14
PARTS LIST-----------------------------------------------------15
MAINTENANCE------------------------------------------------16
PRODUCT SPECIFICATION-------------------------------1 8
CONTACT US--------------------------------------------------1 9
Thank you for purchasing the IS0507.
Before operating this unit, please read this manual carefully to
ensure optimum performance and safety.
This manual should be kept available for future reference.
REMARK:
For product improvement, the company reserves the right to change
the design and specification at any time without prior notice.
Pictures are for reference use only and may differ from the actual
product.

Page
SAFETY CAUTIONS
2
When using this product, basic precautions should always be followed, including the
following:
Please read the instruction carefully before starting to use this product.
Danger – To reduce the risk of electric shock：
1. Always unplug this product from the electrical outlet immediately after using and
before cleaning.
Warning – To reduce the risk of burns, fire, electric shock, or physical injury：
1. The product should never be left unattended while plugged in. Unplug the product
from the outlet when not in use.
2. Close supervision is necessary when this product is used by or near children,
invalids, or disabled persons.
3. Be sure to use the product only for its intended use as described in this manual. Do
not use any attachment not recommended by the manufacturer in order to avoid
any danger or accidents.
4. Never operate the product if it has a damaged cord or plug, if it is not working
properly, if it has been damaged, or dropped into water. Please return the product
to the service center of seller for examination and repair.
5. Do not carry this product by the supply cord or use the cord as a handle.
6. Keep the cord away from hot surfaces or ground.
7. Never operate the product with the air vents blocked. Keep the air vents free of lint,
hair, etc.
8. Never drop or insert any objects into any openings.
9. Do not use or operate outdoors.
10. Do not operate where aerosol (spray) products are being used or where oxygen is
thin.
11. Before turning the product power off, turn all controls to the off position then
remove the plug from the outlet.
12. Connect the product to a properly grounded outlet only.
13. If the treadmill is foldable, when user finishes using the treadmill, the elevation
needs to be back to original position.
14. When user is using the treadmill, it can not be folded at the same time.
15. Keep a safety space of 2000mm x 1000mm away from the treadmill.
16. This machine is only intended for household use.
17. For the treadmill with folding function and electric elevation, be sure that the
elevation is 0 before folding (To avoid interference of the components).
18. Stop using the treadmill if you feel faint, dizzy, or short of breath.
19. Wear appropriate exercise clothes when using the treadmill. Do not wear loose
clothes that could become caught in the treadmill. Athletic support clothes are
recommended for both men and women. Always wear athletic shoes. Never use
the treadmill with bare feet, wearing only stockings, or in sandals.

Page3
The products must be grounded first. If malfunction or breakdown occurs, grounding
will provide a path of least resistance for electric current to reduce the risk of electric
shock.
The product is equipped with a cord having an equipment-grounding conductor and a
grounding plug.
The plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Danger –Improper connection of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified electrician or serviceman if you are in
doubt as to whether the products are properly grounded. Do not modify the plug
provided with the product – if it will not fit the outlet, have a proper outlet install by a
qualified electrician.
The products is for use on nominal 220-240 volt and has a grounding plug that looks
like the plug illustrated in the figure . Make sure that the product is connected to an
outlet having the same configuration as the plug.
There is no need to use any adapter for this product.
Figure
Grounding methods
GROUNDED PIN
GROUNDED OUTLET
OUTLET
GROUNDING INSTRUCTIONS

OPEN THE BOX YOU CAN FIND THE ALL PARTS AS BELOW.
Parts of assembly：
No. DESC. SPEC. Q’TY No. DESC. SPEC. Q’TY
1 Main Frame 1 5 Computer 1
13 Hexagon Socket Button Head
Bolt M8*45 4 16 Hexagon Socket Button Head Bolt M8*20 8
26 Cross Round Head Screw ST4*19 4 35 Flat Washer ￠88
37 Arc Washer ￠10 4 42 Left Base Cover 1
43 Right Base Cover 1 72 Safety Key 1
80 Power Cord 1 86 Silicon Oil 1
88 Allen Wrench 5# 1 89 Allen Wrench 6# 1
90 Cross Open End Wrench 1 97 MP3 Wire 1
98 Circular Tube Plug ￠25 4
ASSEMBLY INSTRUC TIONS
Installation tools:
Allen Wrench 5mm 5# 1pcs
Allen Wrench 6mm 6# 1pcs
Cross Open End Wrench 1pcs
Page4

STEP 1：
STEP 2:
STEP 3:
STEP 4:
Use allen wrench(88) to lock hexagon
socket head bolt(13),flat washer(35) ,arc
washer(37) and exagon Socket Head
Bolt(16) into uprights pipe and base
frame,but not firmly.
Use allen wrench(88) to lock flat
washer(35) and Hexagon Socket Head
Bolt(16) into uprights pipe and console
frame,but not firmly.
Take out from the carton, put the main
frame on the ground, and cut off the
packing tapes.
Connected signal wire from computer(69)
with signal wire from uprights(70).Please
be attention direction of them.
Page5

STEP 5: STEP 6:
Lock all screws of above steps firmly,then
use cross open end wrench(90) to lock
cross round head screw(26),left base
cover(42) and right base cover into base
STEP 7: frame firmly.
Hold one hand up to the arrow at B,kick
the gas spring with your foot at A, then
hear the gas spring sound.
Install plastic plug in locked
handrail (98)
Page6
STEP8
:
Hold one hand at B, kick the gas spring
with your foot at A, press the hand at B
slightly harder down to the rear end of the
armrest, let go of the rest of the arm, let
go of the machine, and then you can
automatically drop it down to the end of
the armrest.
NOTE: For your safety and comfort, please check if all screws are fastened
Congratulation! A brand new motorized treadmill has been successful assembled!

LCD Display Readout：
1. Function Button： START，STOP，PROGRAM，MODE，SPEED+/-，INCLINE+/-,Speed quick button,
Incline quick button, Volume+/- button, Switch music up and down buttons, Music start pause
button.
2. KEYBOARD FUNCTION：
A“ PROGRAM ”button ：In ready mode, press this button to select program ”0:00”,
”P01-P60”, and“U1-U5”; Manual mode is the default running mode, default speed
of manual mode is 1.0KM/H.
B “MODE” button：Press this button to select mode“0：00”、“30：00”、“5.0”、“100”
(“0：00”for manual mode，“30:00” for time countdown mode，“5.0”for distance countdown
mode，“100”for calories countdown mode.) When you are selecting any mode, please press
speed+/- button to set the relevant countdown value. When it is finished, press “START” button
to start running the treadmill.
Page
OPERATION GUIDE
7

C “START”button: When machine is stop, press this button to start.
D “STOP”button: When machine is working, press this button to stop.
E “SPEED+”“SPEED -”button: Press this button to adjust the speed when running, +/- 0.1KM
for each time. When it is at the ready mode, press the button to set parameter.
F “INCLINE+”“INCLINE-”button: Press this button to adjust incline, +/- 1 for each time. When
it is at the ready mode, press the button to set parameter.
G Quick speed button：When machine is running, press quick speed button“4,8,12”, it will be
matched to corresponding speed values.
H Quick incline button： When machine is running, press quick incline button“4,8,12”,it will be
matched to corresponding incline values.
I Volume+ button: When playing music, press this button to increase the volume.
J Volume- button: When playing music, press this button to reduce the volume.
K Switch music up button: Press this button when playing music to switch to the previous
music.
L Switch music down button: Press this button when playing music to switch to the next music.
M Music start pause button: Press this button when playing music to stop the music. Press
again, to start the music.
N Round knob: With the "START", "STOP"(need to press 5 seconds), "SPEED+" and "SPEED -"
functions.
Safety Key Function
When you take off the safety key, the LCD will display E07, and the treadmill will be stopped
immediately. Put the safety key into the safety key hole in the console, and then the treadmill will be
on start/ready
Page8
status.

Heart Rate Function
When holding the hand pulse by both hands, the pulse window will show your hear rate. In order
to get the heart rate more accurately, please stand on the treadmill when the machine is stop and
holding on the hand pulse more than 30 seconds. The range of heart rate is 50-200 / second. The
heart rate data is just for reference only, not as medical data.
The input parameter display and setting range
Initial Setting
initial value Setting range Show range
Prog. Time(min:sec) 0:00 30:00 5:00-99:00 0:00~99:59
Speed(km/h) 0.0 1.0 1.0-20.0 0.0-20.0
Incline(%) 0.0 00-18% 0-18%
Distance(km) 0.0 1.0 0.5－99.9 0.0－99.9
Calories(Cal.) 0 50 10-999 0-999
Mode Time(min:sec) 0:00 15:00 5:00-99:00 0:00-99:59
Program Instruction：schedule
Each program divided running time into 20 intervals; the speed and incline on each interval has
been preset in the factory.
TIME
PROG.
Time set/20 intervals=running duration
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
P01 SPEED 2 3 3 4 5 3 4 5 5 3 4 5 4 4 4 2 3 3 5 3
INCLINE 1 1 2 2 2 3 3 3 2 2 1 2 2 1 1 3 3 2 2 2
P02 SPEED 2 4 4 5 6 4 6 6 6 4 5 6 4 4 4 2 2 5 4 2
INCLINE 1 2 2 2 2 3 3 2 2 2 2 2 3 3 3 4 4 3 2 2
P03 SPEED 2 4 4 6 6 4 7 7 7 4 7 7 4 4 4 2 4 5 3 2
INCLINE 2 3 3 2 2 3 3 3 2 2 2 2 4 4 4 6 6 3 2 2
P04 SPEED 3 5 5 6 7 7 5 7 7 8 8 5 9 5 5 6 6 4 4 3
INCLINE 2 3 3 2 2 3 3 3 2 2 2 2 4 4 4 6 6 3 2 2
P05 SPEED 2 4 4 5 6 7 7 5 6 7 8 8 5 4 3 3 6 5 4 2
INCLINE 3 3 3 4 4 3 6 5 4 4 4 4 5 6 3 6 3 2 2 2
P06 SPEED 2 4 4 4 5 6 8 8 6 7 8 8 6 4 4 2 5 4 3 2
INCLINE 3 5 5 5 4 4 4 3 3 3 3 4 4 4 3 3 3 4 3 2
P07 SPEED 2 3 3 3 4 5 3 4 5 3 4 5 3 3 3 6 6 5 3 3
INCLINE 4 4 4 4 3 3 435 7 7 8 8 9 9 6 6 5 4 4
Page9

P08 SPEED 2 3 3 6 7 7 4 6 7 4 6 7 4 4 4 2 3 4 4 2
INCLINE 4 5 5 5 6 6 6 7 8 9 9 9 10 10 10 12 12 8 6 3
P09 SPEED 2 4 4 7 7 4 7 8 4 8 9 9 4 4 4 5 6 3 3 2
INCLINE 5 5 5 6 6 6 4 4 6 6 5 5 8 8 9 9 9 7 4 2
P10 SPEED 2 4 5 6 7 5 4 6 8 8 6 6 5 4 4 2 4 4 3 3
INCLINE 5 6 6 6 7 5 8 8 4 4 4 5 5 8 8 10 10 8 6 3
P11 SPEED 2 5 8 10 7 7 10 10 7 7 10 10 5 5 9 9 5 5 4 3
INCLINE 4 5 3 2 6 6 2 2 2 2 2 4 5 6 3 2 5 5 2 0
P12 SPEED 3 4 9 9 5 9 5 8 5 9 7 5 5 7 9 9 5 7 6 3
INCLINE 1 2 3 2 3 5 5 0 0 2 3 5 7 3 3 5 6 5 3 3
P13 SPEED 3 6 7 5 9 9 7 5 5 7 9 5 8 5 9 5 9 9 4 3
INCLINE 3 3 5 6 5 3 3 7 5 3 2 0 0 5 5 3 2 3 2 1
P14 SPEED 2 2 4 5 6 5 4 3 2 1 2 3 4 5 6 5 4 3 2 1
INCLINE 4 4 4 4 3 3 6 6 6 7 7 8 8 9 9 6 6 5 4 4
P15 SPEED 2 4 6 8 6 6 4 4 2 2 2 4 6 8 6 6 4 4 2 2
INCLINE 3 3 3 4 4 5 6 3 6 3 4 4 5 5 3 3 3 2 2 2
P16 SPEED 2 4 6 8 10 8 6 4 2 2 2 4 6 8 6 6 4 4 2 2
INCLINE 5 5 5 6 6 6 4 4 6 6 5 5 8 8 9 9 9 7 4 1
P17 SPEED 2 2 6 6 8 10 6 6 2 2 2 2 6 6 8 10 6 6 2 2
INCLINE 4 5 5 5 6 6 6 7 8 9 9 9 10 10 10 12 12 8 6 3
P18 SPEED 2 3 4 5 2 3 4 5 3 2 2 3 4 5 2 3 4 5 3 2
INCLINE 4 4 4 4 3 3 6 6 6 7 7 8 8 9 9 6 6 5 3 2
P19 SPEED 2 4 6 2 4 6 2 4 6 2 2 4 6 2 4 6 2 4 6 2
INCLINE 3 5 5 5 4 4 4 3 3 3 3 4 4 4 3 3 3 4 3 2
P20 SPEED 1 3 4 5 6 5 4 3 2 1 1 3 4 5 6 5 4 3 2 1
INCLINE 3 3 3 4 4 5 5 4 3 3 3 4 5 5 3 3 3 2 2 2
P21 SPEED 4 5 4 4 4 2 3 3 5 3 2 3 3 4 5 3 4 5 5 3
INCLINE 1 2 2 1 1 3 3 2 2 2 1 1 2 2 2 3 3 3 2 2
P22 SPEED 5 6 4 4 4 2 2 5 4 2 2 4 4 5 6 4 6 6 6 4
INCLINE 2 2 3 3 3 4 4 3 2 2 1 2 2 2 2 3 3 2 2 2
P23 SPEED 2 4 4 4 4 2 4 5 3 2 2 4 4 6 6 4 7 7 7 4
INCLINE 2 2 4 4 4 6 6 3 2 2 2 3 3 2 2 3 3 3 2 2
P24 SPEED 3 5 9 5 5 6 6 4 4 3 3 5 5 6 7 7 5 7 7 8
INCLINE 2 2 4 4 4 6 6 3 2 2 2 3 3 2 2 3 3 3 2 2
P25 SPEED 3 4 5 4 3 3 6 5 4 2 2 4 4 5 6 7 7 5 6 7
INCLINE 4 4 5 5 3 3 3 2 2 2 3 3 3 4 4 5 5 5 4 4
P26 SPEED 1 3 6 4 4 2 5 4 3 2 2 4 4 4 5 6 8 8 6 7
INCLINE 3 4 4 4 3 3 3 4 3 2 3 5 5 5 4 4 4 3 3 3
P27 SPEED 4 5 3 3 3 6 6 5 3 3 2 3 3 3 4 5 3 4 5 3
INCLINE 2 4 8 9 9 6 6 5 4 4 4 4 4 4 3 3 6 6 6 7
P28 SPEED 1 3 4 4 4 2 3 4 4 2 2 3 3 6 7 7 4 6 7 4
INCLINE 3 2 2 4 3 2 2 4 6 3 4 5 5 5 6 6 6 7 8 9
P29 SPEED 2 5 5 5 4 5 6 3 3 2 2 4 4 7 7 4 7 8 4 8
INCLINE 5 5 8 8 9 9 9 7 4 2 5 5 5 6 6 6 4 4 6 6
P30 SPEED 6 6 5 4 4 2 4 4 3 3 2 4 5 6 7 5 4 6 8 8
INCLINE 4 5 5 8 8 10 10 8 6 3 5 6 6 6 7 5 8 8 4 4
Page10

P31 SPEED 4 2 4 4 3 4 5 5 4 3 2 5 8 10 7 7 10 10 7 7
INCLINE 2 4 5 6 3 2 5 5 2 0 4 5 3 2 6 6 2 2 2 2
P32 SPEED 5 5 2 2 4 5 5 7 6 3 3 4 9 9 5 9 5 8 5 9
INCLINE 3 5 7 3 3 5 6 5 3 3 1 2 3 2 3 5 5 0 0 2
P33 SPEED 2 3 2 1 3 2 9 9 4 3 3 6 7 5 9 9 7 5 5 7
INCLINE 2 0 0 5 5 3 2 3 2 1 3 3 5 6 5 3 3 7 5 3
P34 SPEED 2 3 4 5 6 5 4 3 2 1 2 2 4 5 9 9 4 4 4 5
INCLINE 4 2 2 4 2 6 6 5 4 4 4 4 4 4 3 3 6 6 6 7
P35 SPEED 2 4 6 8 6 6 4 4 2 2 2 4 6 8 6 6 4 4 2 2
INCLINE 4 4 5 5 3 3 3 2 2 2 3 3 3 4 4 5 5 5 4 4
P36 SPEED 2 4 6 8 6 6 4 4 2 2 2 4 6 8 10 8 6 4 2 2
INCLINE 5 5 8 8 9 9 9 7 4 1 5 5 5 6 6 6 4 4 6 6
P37 SPEED 2 2 6 6 8 10 6 6 2 22 2 6 6 8 10 6 6 2 2
INCLINE 4 2 2 6 8 10 12 8 6 3 4 5 5 5 6 6 6 7 8 9
P38 SPEED 2 3 4 5 2 3 4 5 3 2 2 3 4 5 2 3 4 5 3 2
INCLINE 7 8 8 9 9 6 6 5 3 2 4 4 4 4 3 3 6 6 6 7
P39 SPEED 2 4 6 2 4 6 2 4 6 2 2 4 6 2 4 6 2 4 6 2
INCLINE 3 4 4 4 3 3 3 4 3 2 3 5 5 5 4 4 4 3 3 3
P40 SPEED 1 3 4 5 6 5 4 3 2 1 1 3 4 5 6 5 4 3 2 1
INCLINE 4 4 5 5 3 3 3 2 2 2 3 3 3 4 4 5 5 5 4 4
P41 SPEED 3 4 5 5 3 4 5 4 4 4 2 3 3 4 5 2 3 3 5 3
INCLINE 3 3 3 2 2 1 2 2 1 1 1 1 2 2 2 3 3 2 2 2
P42 SPEED 4 6 6 6 4 5 6 4 4 4 2 4 4 5 6 2 2 5 4 2
INCLINE 3 3 2 2 2 2 2 3 3 3 1 2 2 2 2 4 4 3 2 2
P43 SPEED 4 7 7 7 4 7 7 4 4 4 2 4 4 6 6 2 4 5 3 2
INCLINE 3 3 3 2 2 2 2 4 4 4 2 3 3 2 2 6 6 3 2 2
P44 SPEED 7 5 7 7 8 8 5 9 5 5 3 5 5 6 7 6 6 4 4 3
INCLINE 3 3 3 2 2 2 2 4 4 4 2 3 3 2 2 6 6 3 2 2
P45 SPEED 7 7 5 6 7 8 8 5 4 3 2 4 4 5 6 3 6 5 4 2
INCLINE 5 5 5 4 4 4 4 5 5 3 3 3 3 4 4 3 3 2 2 2
P46 SPEED 6 8 8 6 7 8 8 6 4 4 2 4 4 4 5 2 5 4 3 2
INCLINE 4 4 3 3 3 3 4 4 4 3 3 5 5 5 4 3 3 4 3 2
P47 SPEED 5 3 4 5 3 4 5 3 3 3 2 3 3 3 4 6 6 5 3 3
INCLINE 3 6 6 6 7 7 8 8 9 9 4 4 4 4 3 6 6 5 4 4
P48 SPEED 7 4 6 7 4 6 7 4 4 4 2 3 3 6 7 2 3 4 4 2
INCLINE 6 6 7 8 9 9 9 10 10 10 4 5 5 5 6 12 12 8 6 3
P49 SPEED 4 7 8 4 8 9 9 4 4 4 2 4 4 7 7 5 6 3 3 2
INCLINE 6 4 4 6 6 5 5 8 8 9 5 5 5 6 6 9 9 7 4 2
P50 SPEED 5 4 6 8 8 6 6 5 4 4 2 4 5 6 7 2 4 4 3 3
INCLINE 5 8 8 4 4 4 5 5 8 8 5 6 6 6 7 10 10 8 6 3
P51 SPEED 4 4 3 6 6 10 10 5 5 9 2 5 8 10 7 9 5 5 4 3
INCLINE 6 2 2 2 2 2 4 5 6 3 4 5 3 2 6 2 5 5 2 0
P52 SPEED 5 6 6 5 6 7 5 5 7 9 3 4 9 9 5 9 5 7 6 3
INCLINE 5 5 0 0 2 3 5 7 3 3 1 2 3 2 3 5 6 5 3 3
P53 SPEED 4 4 3 6 7 9 5 8 5 9 3 6 7 5 9 5 9 9 4 3
INCLINE 3 3 7 5 3 2 0 0 5 5 3 3 5 6 5 3 2 3 2 1
Page11

P54 SPEED 5 4 3 2 1 2 3 4 5 6 2 2 4 5 6 5 4 3 2 1
INCLINE 3 6 6 6 7 7 8 8 9 9 4 4 4 4 3 6 6 5 4 4
P55 SPEED 6 4 4 2 2 2 4 6 8 6 2 4 6 8 6 6 4 4 2 2
INCLINE 5 5 5 4 4 4 4 5 5 3 3 3 3 4 4 3 3 2 2 2
P56 SPEED 8 6 4 2 2 2 4 6 8 6 2 4 6 8 10 6 4 4 2 2
INCLINE 6 4 4 6 6 5 5 8 8 9 5 5 5 6 6 9 9 7 4 1
P57 SPEED 3 4 4 3 2 2 2 6 6 8 2 2 6 6 8 10 6 6 2 2
INCLINE 6 6 7 8 9 9 9 10 10 10 4 5 5 5 6 12 12 8 6 3
P58 SPEED 3 4 5 3 2 2 3 4 5 2 2 3 4 5 2 3 4 5 3 2
INCLINE 3 6 6 6 7 7 8 8 9 9 4 4 4 4 3 6 6 5 3 2
P59 SPEED 6 2 4 6 2 2 4 6 2 4 2 4 6 2 4 6 2 4 6 2
INCLINE 4 4 3 3 3 3 4 4 4 3 3 5 5 5 4 3 3 4 3 2
P60 SPEED 5 4 3 2 1 1 3 4 5 6 1 3 4 5 6 5 4 3 2 1
INCLINE 5 5 5 4 4 4 4 5 5 3 3 3 3 4 4 3 3 2 2 2
User Manual Program
There are 5 user manual programs besides 60 built-in workout programs:U1、U2、U3、U4、U5.
1.User manual program setting: At the ready mode, press PROGRAM button continuously until your
desired program （U1-U5）.Press MODE button to set speed and incline in total 10 intervals.
2. User manual program starting:
At the ready mode, press PROGRAM button continuously until your desired program（U1-U5）,and set
running time then start.
Body Fat Scale Function
In ready mode, press PROGRAM button, window will indicate FAT to BODY FAT analysis function. Press
MODE button to select parameters of the category(gender, age, height, weight) .Corresponding window
can indicate F1,F2,F3,F4.Each one parameter selected category, press SPEED+/- button to adjust
parameter value. When all of parameters are adjusted, press MODE button again, corresponding window
will indicate F5，to enter the state of under test, then hold both hands on the handrail pulse kits for 8
seconds and the body fat data will be displayed on the corresponding window.
Parameter
Class Default Value Setting Range Remark
Gender（F1） 1（Male） 1—2 1=Male 2=Female
Age（F2） 25 years old 10—99 years old
Height（F3） 170 CM 100—200 CM
Weight（F4） 70KG 20—150KG
Result（F5） As below
By Asian Standards： FAT ≤19 -- Under weight
19<FAT ≤25 -- Normal weight
25<FAT ≤29 -- Over weight
FAT≥30 -- Obesity
This data is for reference only, not as medical data.
Page12

IF THE METER DISPLAYS AS BELOW:
Fault
Code
Reason FIRST INSPECT
ER-1
No signal
received by the
computer for 30
seconds
Signal wire error between the console and
controller
Check and change signal wire
Motor disturb
Add magnet ring for signal wire and
motor wire
The whole set of controller broken Replace computer or controller
ER-3 overvoltage
The input ac voltage is higher than 265V Adjust to AC220V±20%
Controller broken Replace controller
ER-4
Driving tube
failure
Controller IGBT short out Replace controller
ER-5 Overload
The load is too big Reduce the load
Too many frictions of treadmill Add silicon oil
Setting wrong parameter Adjust parameter again
ER-6
The motor did not
connect well
Motor broken or motor wire fall out Replace motor or check motor wire
IGBT broken Replace IGBT
ER-7
No signal
received by main
board
Signal wire broken Check and replace signal wire
The whole set of controller broken Replace computer or controller
Page13

EXPLODED DRAWING
Page14

No. DESC. SPEC. Q’ty No. DESC. SPEC. Q’ty
1 Base Frame 1 50 Left Cap Foam 1
2 Main Frame 1 51 Right Cap Foam 1
3 Uprights 252 IPAD Rack 1
4 Console Rack 153 Computer Fixed Buckle 3
5 Incline Rack 1 54 Left Handrail Foam 1
6 Runnig Deck Pipe 1 55 Right Handrail Foam 1
7 Motor Base Board 1 56 Running Belt 1
8 Front Roller 1 57 Running Board 1
9 Rear Roller 1 58 Side Rail 2
10 Gas Spring 1 59 Cushion 4
11 Hex Head Cap Bolt M10*45 5 60 Adjust Foot Mat 4
12 Hex Head Cap Bolt M10*55 1 61 Moving Wheel 2
13 Hexagon Socket Pan Head Bolt M8*45 5 62 Magnetic ring sponge sheath 1
14 Hexagon Socket Pan Head Bolt M8*40 4 63 Rubber Cushion 2
15 Hexagon Socket Pan Head Bolt M8*25 1 64 Motor Belt 1
16 Hexagon Socket Pan Head Bolt M8*20 8 65 Adjust Wheel 2
17 Cylindrical Head Bolt M8*75 1 66 Computer 1
18 Cylindrical Head Bolt M8*65 3 67 Membrane keyboards 1
19 Cylindrical Head Bolt M8*15 2 68 Controller 1
20 Cylindrical Head Bolt M8*20 4 69 Top Signal Wire 1
21 Cross Bolt M5*10 5 70 Middle Signal Wire 1
22 Countersunk Bolt M6*12 2 71 Lower Signal Wire 1
23 Countersunk Bolt M6*20 6 72 Safety Key 1
24 Cross Countersunk Screw ST4*12 2 73 Safety Key Sensor 1
25 Cross Countersunk Screw ST4*55 4 74 Right Hand Pulse 1
26 Cross Round Head Screw ST4*19 4 75 Left Hand Pulse 1
27 Cross Screw ST4*15 14 76 DC Motor 1
28 Cross Screw ST4*12 12 77 Incline Motor 1
29 Cross Pan Head Screw ST4*10 28 78 Rocker Switch 1
30 Cross Pan Head Screw ST4*15 30 79 Circuit Breaker 1
31 Cross Big Flat Head Screw ST2.9*10 10 80 Power Line 2
32 Locknut M10 6 81 Socket 1
33 Locknut M10 6 82 Blue Single Line 2
34 Flat Washer ￠10 6 83 Brown Single Line 2
35 Flat Washer ￠10 21 84 Brown Single Line 1
36 Spring Lock Washer ￠８ 6 85 Grounding Line 1
37 Arc Washer ￠８ 4 86 Silicon Oil 2
PARTLIST LIST
Page21

38 Motor Upper Cover 1 87 Magnet Ring 1
39 Motor Lower Cover 1 88 Allen Wrench 5# 1
40 Left End Cap 1 89 Allen Wrench 6# 1
41 Right End Cap 1 90 Cross Open End Wrench 1
42 Left Base Cover 1 91 Fitshow Module optional 1
43 Right Base Cover 1 92 Inductors optional 1
44 Computer Upper Cover 1 93 Filter 1
45 Computer Lower Cover 1 94
46 Computer Panel 1 95 USB Module 1
47 Computer Console Back Cover 1 96 Speaker 2
48 Left Water Bottle Box 1 97 MP3 Wire 1
49 Right Water Bottle Box 1 98 Circular Tube Plug ￠25 4
Page15

LUBRICATIO
MAINTENANCE
N
Lubricating under the running belt will ensure superior performance and extend its life
expectancy. After the first 25 hours of use (or 2-3 months) apply some lubricant, and repeat
for every following 50 hours of use (or 5-8 months).
How to check running belt for proper lubrication
Lift one side of the running belt and feel the top surface of the running deck. If the
surface is slick to the touch, then no further lubrication is required.
If the surface is dry to the touch, apply some lubricant.
How to apply lubricant
Lift one side of running belt.
Pour some lubricant under the centre of the running belt on the top surface of the running deck.
Run on the treadmill at a slow speed for 3 to 5 minutes to evenly distribute lubricant.
NOTE: DO NOT over lubricate running deck. Any excess lubricant that comes out
should be wiped off.
Lubricant Oil
BELT ADJUSTMENT
The running belt is pre-adjusted to the running deck at the factory, but after prolonged use it can
stretch and require readjustment. To adjust the belt, turn on the main power switch of the treadmill
Page16

and let the belt run at a speed of 8-10 KPH. Use the 6 mm Allen Wrench provided to turn the rear
roller adjustment bolts in order to centre the belt. If the running belt is shifting to the left, turn the
left adjustment bolt 1/4 turn clockwise, and the running belt should start to correct itself.
Tool:
6 mm Allen Wrench
If the running belt is shifting to the right, then turn the right adjustment bolt 1/4 turn clockwise, and
the belt should start to correct itself. Keep turning the adjustment bolts until the running belt is
properly centered.
Tool:
6 mm Allen Wrench
If the running belt is slipping during use, turn off and unplug the treadmill. Using the 6 mm Allen
Wrench provided, turn both left and right rear roller adjustment bolts 1/4 turn clockwise, then turn
the main power switch back on and run the treadmill at a speed of 8-10 KPH. Run on to the
running belt to determine if the belt is still slipping. Repeat this procedure until the belt no longer
slips.
Tool:
6 mm Allen Wrench
Page17

Page
PRODUCT SPECIFICATION
18
