iVue Robotics LLC
Develop Air
Operating Manual
iVue Robotics LLC
925 Sanders Road, Suite C
Cumming, GA 30041
Page of1 8
V1.0

iVue Robotics LLC
Introduction
Develop Air is a drone designed for conveniently developing, integrating, and deploying
hardware and software to take flight on a drone. Develop Air can be equipped with
sensors, processors, IoT devices, gimbals, tethers, sprayers, deployment mechanisms,
or just about any hardware and software the user can create and integrate via the side
plates or quick release project rail.
A complete ready to fly and modify drone, Develop Air is accessible to makers at nearly
any level, like tech enthusiasts or hobbyists creating a high flying passion project,
professional hardware or software engineers developing drone systems in the lab, or
STEM students and educators facilitating the world of research and education.
In this manual, operators will find specifications for Develop Air, learn how to get
Develop Air off the ground, understand the use of Develop Air’s internal components,
and discover how to expand Develop Air’s capabilities with hardware and software
projects. Warranty information is listed and included separately with Develop Air.
Standard Specifications
Flight Controller (FC) / Processor:" " Holybro Pixhawk 4
"Flying with the Pixhawk 4, Develop Air can operate autonomously and control
electrical or electromechanical payloads.
Power Distribution Board (PDB):"""Holybro PM06 v2
"Facilitating 7V - 42V input and 5V/3A output, the Holybro PM06 v2 ensures
Develop Air and connected projects are supplied with reliable, continuous power.
Battery Eliminator Circuit (BEC):"""iFlight Micro 2-8S BEC
"Able to step down an input voltage of up to 36V, the two iFlight Micro BECs
ensures Develop Air and connected projects have access to 12V 2A or 5V 3A currents.
GPS:"""""""Pixhawk 4 GPS Module
"Built with a Ublox Neo-M8N module and IST8310 compass, the Pixhawk 4 GPS
enables Develop Air to navigate autonomously.
Brushless Motors:"""""KDE2315XF-885
Page of2 8

iVue Robotics LLC
"Rated to operate at up to 240°C continuous (340°C maximum) temperatures, the
KDE 2315XF-885 motors enable comfortable operation in tropical or arid climates.
Electronic Speed Controllers (ESCs): ! ! KDEXF-UAS20LV
!The KDEXF-UAS20LV ESCs are tuned with Dynamic PWM and Motor Advance
Timing algorithms to deliver highly efficient performance for stable operations.
Receiver:""""""FrSky RX6R
"Using the FrSky RX6R receiver, Develop Air is compatible with many transmitters
for manual remotely controlled operations within a 1.5mi (2.41km) range.
Telemetry Radio:!!!!!HolyBro 915 Mhz 500 mW
"With a 915 Mhz 500mW HolyBro telemetry radio, Develop Air is capable of
autonomous remotely controlled operations within a nearly 2mi (3.2km) range.
Skateboard / Airframe:""""Nylon-12SLS
"Develop Air was designed by iVue Robotics to be weather resistant, lightweight,
and rugged with a SLS printed Nylon-12 skateboard and EPDM Rubber Foam gasket.
Propellers:""""""9.4” Master Airscrew MR Series
"Including a built-in nut for ease of installation, the 9.4” Master Airscrew MR
Series propellers are designed to maximize performance while also minimizing noise.
Battery:!!!!!!MaxAmps LiPo 6000XL 3S 11.1v
"The Max Amps LiPo 6000XL 3S 11.v boasts a 100C rating for quickly and safely
discharging the waterproof, high capacity battery.
Side Plates: """"""Blank
"The blank side plates can be replaced with Dual Power, DB9, and Signal side
plates for data and power pass through to mounted sensors and electronic payloads.
Quick Release Payload Rail: """Zinc Plated Steel Mini DIN Rail
"Payloads like sensors and deployment mechanisms can be conveniently
mounted on Develop Air with the Quick Release Project Rail designed by iVue Robotics.
Position & Status Indicator Lights: "" 4Position&5StatusLEDs
"Quickly check the orientation, status, and position of Develop Air before, during,
and after flight operations with the onboard position and status LEDs.
Page of3 8

iVue Robotics LLC
Options Included
Radio Controller / Transmitter: !!!Eachine TX16S 16CH Radio Transmitter
!Pre-bound to Develop Air, the Eachine TX16S transmitter enables control of
Develop Air and connected payloads via joystick, dial, and switch inputs.
Buck Boost Converter: ! ! ! ! DROK DC-DC Buck Boost Converter
!With an input voltage range of DC 5-30V, the DROK DC-DC Buck Boost Converter
will provide a constant 12V output for use with the Dual Power side plate.
Side Plates: """"""Dual Power
"Develop Air can be configured with a Dual Power side plate for providing 5V and
12V power pass through to mounted sensors and electronic payloads.
Part 1
Off the Ground with Develop Air
Getting Started
Out of the box, Develop Air is fully assembled, tested, and ready to fly. To operate
Develop Air autonomously, a ground control device like a phone, tablet, or PC running
Windows, Linux, MacOS, Android, or iOS with QGroundControl is highly recommended.
While Develop Air can be used with other ground control software, QGroundControl is
recommended due to its compatibility across devices, open source architecture, and
operator friendly interface.
Once QGroundControl is downloaded and installed on a compatible ground control
device of choice, QGroundControl can be opened and the HolyBro telemetry radio can
be plugged into a USB port on the ground control device. Please note that iOS devices
are not natively compatible with USB telemetry radios, so connectivity via a bluetooth
serial port or a non-iOS device capable of running QGroundControl may be required.
Alternatively, Develop Air can also be flown and operated via manual user input with
ACCST D16 and ACCESS transmitters like the RadioMaster/Eachine TX16s or the FrSky
Page of4 8

iVue Robotics LLC
QX7. If Develop Air is purchased with a transmitter, Develop Air is pre-bound and ready
to fly as soon as the transmitter is turned on and Develop Air has power from its battery.
Binding a Transmitter
If using a transmitter not purchased with Develop Air, bind it to the FrSky RX6R receiver
in Develop Air by turning on the transmitter and setting it to the binding mode according
to the transmitter’s user manual. Following the transmitter being set to bind mode, turn
on the receiver by holding down the F/S button. The red LED light on the receiver will
then flash to indicate the binding process has been completed. Once the binding has
been completed, the transmitter can be taken out of the binding mode, turned off, and
then Develop Air is ready to fly next time the transmitter is turned on and setup with the
desired joystick, switch, and dial input channels.
Preparing for Takeoff
In preparation of flying Develop Air, the battery should be secured by using the battery
brackets and battery straps underneath Develop Air. Once the battery is properly
secured and orientated so the XT60 battery connector on Develop Air’s fuselage and the
battery is aligned on the same side, the propellers can be connected to each motor by
spinning them clockwise or counterclockwise until they are snug and will not tighten
any further without noticeable force.
For the operator’s safety, the transmitter should be turned on before plugging the
battery in, arming, and initializing manual control of Develop Air. Similarly, be sure
QGroundControl is open on the phone, tablet, or PC prior to powering on and arming
Develop Air when operating it autonomously.
Using QGroundControl for autonomous flight, Develop Air takes off to the preset altitude
specified by the operator with a swipe of the finger on a touchscreen device or a click
and drag with a PC trackpad or mouse.
Operation in Flight
In flight, Develop Air can operate in three different modes:
Mission Mode - In mission mode, Develop Air can autonomously fly a preset flight plan
using QGroundControl or another compatible ground control software. While Develop
Air is primarily controlled by GPS waypoints set in the autonomous flight plan when in
Page of5 8

iVue Robotics LLC
mission mode, Develop Air’s flight can also be overridden with operator input on a
transmitter.
Position Mode - In position mode, Develop Air can fly using GPS positioning and be
remotely controlled with operator input on a transmitter. With GPS positioning being
used in position mode, Develop Air is able to hover in a location without the operator
providing input on a transmitter.
Manual Mode - In manual mode, Develop Air can fly and be controlled with operator
input on a transmitter. No GPS positioning is used when operating in manual mode,
therefore, the operator must constantly provide direction to Develop Air for sustaining a
hover position or movement.
Part 2
Develop Air, Inside & Out
Removing the Cover
The electronics enabling Develop Air to fly and operate autonomously are inside
Develop Air’s skateboard. Operators may access the inside of Develop Air by removing
the eight screws on the top cover with a Phillips head screw driver. When removing the
cover, operators will find the GPS assembly is connected from the dome on the top
cover. Operators should not disconnect the GPS or any other wiring within Develop Air’s
airframe/skateboard and also be careful to not over tighten the screws when
reattaching the top cover.
Position & Status Lights
Position Lights - On the bottom side of each motor mount, a NeoPixel light will be found
to make operators and spectators on the ground aware of Develop Air’s orientation in
flight. Arranged like the position lights on a manned aircraft, Develop Air has a red light
on the front left motor mount, a green light on the front right motor mount, and two
white lights on the rear motor mounts.
Status Lights - Develop Air has a total of five status lights, two located near the rear
boom arms and three located on the GPS dome fixed to the top cover.
Page of6 8

iVue Robotics LLC
The status lights near the rear boom arms indicate the battery status, with a green light
to indicate the battery has enough charge for flight and an amber light to indicate the
battery is low and needs to be changed before carrying on flight operations.
The status lights on the GPS dome indicate the motor arming and GPS connectivity
statuses. A solid blue light indicates Develop Air is armed with no GPS connectivity. A
solid green light indicates Develop Air is armed with GPS connectivity. A blinking blue
light indicates Develop Air is ready to be armed with no GPS connectivity. A blinking
green light indicates Develop Air is ready to be armed with GPS connectivity. A blinking
red light indicates Develop Air has encountered an error when trying to arm.
Viewing Flight Logs
On the rear left side of Develop Air, the USB-C port can be used for uploading flight logs
from the Pixhawk to a PC without needing to remove the microSD card from the
Pixhawk and entering it into a computer. Flight Logs can be uploaded for review here:
https://logs.px4.io/
Part 3
Build, Create, and Develop to Modify Develop Air
Expanding Develop Air
Once familiar with flying Develop Air and an understanding of its internal electronics is
achieved, the operator can expand the capabilities of Develop Air. Rated to continuously
carry external payloads of up to 3lbs, Develop Air is outfitted with swappable side plates
and a quick release project rail to connect and mount electromechanical payloads.
Quick Release Rail System
Operators can conveniently and securely mount payloads underneath Develop Air using
the quick release rail system. Payloads are only limited by the operator’s imagination to
create a payload, the size so it fits between the landing gear, and 3lb carrying capacity.
Replacing Parts
iVue Robotics has made the following replaceable parts available for purchase to make
Develop Air the ultimate ready to fly and modify drone with ease of repair in mind:
Page of7 8

iVue Robotics LLC
Page of8 8
Brushless Motor
Side Plate
Foot
Battery
Boom Arm Assembly
Top Cover
Telemetry Antenna
Landing Gear Assembly
Battery Bracket
Quick Release Payload Bracket
Quick Release Rail
Fuselage
Replaceable Parts
