dji mavic User manual

MAVIC AIR

Aircraft
The DJITM MAVICTM Air features a new folding design and a fully stabilized 3-axis gimbal
camera capable of shooting 4K video and 12 megapixel photos. DJI signature
technologies such as Obstacle Avoidance and Intelligent Flight Modes like SmartCapture,
Panorama, Advanced Pilot Assistance Systems, QuickShot, ActiveTrackTM, and TapFlyTM,
make capturing complex shots effortless and easy. The Mavic Air boasts a maximum flight
speed of 42.5 mph (68.4 kph) and a maximum flight time* of 21 minutes.
1.Forward Vision System** 10. Battery Buckles
2.Propellers 11. Downward Vision System**
3.Motors 12. GPS Antennas
4.Gimbal and Camera 13. Vents
5.Front LEDs 14. USB -C Port
6.Landing Gears (Built-in antennas) 15. Camera Micro SD Card Slot
7.Power Button 16. Aircraft Status Indicator/Function Button
8.Battery Level LEDs 17. Backward Vision System**

9.Intelligent Flight Battery
* Maximum flight time was tested in 0 wind at a consistent 15.5 mph (25 kph). This value should be taken for
reference only.
** The Forward, Downward and Backward Vision Systems are affected bysurrounding conditions. Read the
Disclaimer and Safety Guidelines and watch the tutorial in the DJI GO 4 app or on the Official DJI website to
learn more. http://www.dji.com/mavic-air
Remote Controller
Built into the Remote Controller is the DJI enhanced Wi-Fi technology, offering a maximum
transmission range of 2.49 mi (4 km) and video from the aircraft to the DJI GOTM 4 app on
your mobile device at up to 1080p at close range, and 720p at longer ranges. The
detachable control sticks make the remote controller easier to store. The Mavic Air also
supports flying on your phone with Virtual Joysticks.

13. Gimbal Dial
1315 14. Record Button
1416 15. Customizable Button
16. Shutter Button
* The remote controller is able to reach its maximum transmission distance (FCC) in a wide open area with no
Electro-Magnetic Interference, and at an altitude of about 400feet (120meters).
The maximum run-time is tested under laboratory environment, only for your reference.
Specifications
●Aircraft
Weight
430 g
Max Speed
42.5 mph (68.4 kph) in Sport Mode without wind
Max Flight Time
21 minutes (0 wind at a consistent 15.5 mph (25 kph))
Operating Temperature
32° to 104°F (0° to 40°C)
JPEG, DNG
Video
MP4, MOV (MPEG-4 AVC / H.264)
GNSS
GPS / GLONASS
Operating Frequency
2.4-2.4835
GHz; 5.725-5.850 GHz
Transmitter Power
2.4
GHz: 28 dBm (FCC), 19 dBm (CE), 19 dBm (SRRC
)
EIRP
19
dBm (MIC
)
GHz: 31 dBm (FCC), 14 dBm (CE), 27 dBm (SRRC
)
5.8
Gimbal
Controllable Range
Pitch: -90° to +0° (Default settings)
-90° to +17° (Extended)
Camera
Sensor
CMOS
Max Image Size
4056×3040
Still Photography Modes
Single shot
HDR
Burst shooting: 3/5/7 frames
Auto Exposure Bracketing (AEB):
3
/5 bracketed frames at 0.7 EV Bias
Interval: 2/3/5/7/10/15/20/30/60 s
Panorama(3×1, 3×3, 3×7, Sphere)
4
K Ultra HD: 3840×2160 24 / 25 / 30p
Video Recording Modes
2.7K:
2720×1530 24 / 25 / 30 / 48 / 50 / 60p
FHD: 1920×1080 24 / 25 / 30 / 48 / 50 / 60 / 120p
Video Storage Bitrate
100
Mbps

Supported SD Cards
●Remote Controller
microSD. Class 10 or UHS-1 rating required.
Dimensions
143.9×78.3×61.2 mm (Folded)
Operating Frequency
2.4-2.4835 GHz; 5.725-5.850 GHz
Max Transmission Distance
2.4 GHz: FCC: 2.5 mi (4 km); CE/SRRC/MIC: 1.2 mi (2
km)
5.8 GHz: FCC: 2.5 mi (4 km); CE: 0.3 mi (0.5 km)
SRRC: 1.6 mi (2.5 km)
(Unobstructed and free of interference)
Operating Temperature
32° to 104° F (0° to 40° C)
Battery
2970 mAh
Transmitter Power
2.4 GHz: 26 dBm (FCC), 18 dBm (CE), 18 dBm
(SRRC)
(EIRP)
18 dBm (MIC)
5.8 GHz: 30 dBm (FCC), 14 dBm (CE), 26 dBm
(SRRC)
Operating Voltage
1000 mA @ 3.7 V
Supported Mobile Device Size Thickness supported: 6.5 - 8.5 mm, Max length: 160 mm
Supported USB port types: Lightning, Micro USB (Type-B)

USB-C
For more information, read the User Manual: http://www.dji.com/mavic-
air
Power Adapter
Voltage
13.2
V
Rated Power
50
W
Intelligent Flight Battery
Capacity
2375
mAh
Voltage
11.55
V, Max 13.2 V
Battery Type
LiPo 3S
Energy
27.43
Wh
Net Weight
Approx.140 g
Charging Temperature Range 41° to 104° F (5° to 40° C)
Max Charging Power
60
W

※This content is subject to change without prior notice.
1. Downloading the DJI GO 4 App and Watching Tutorial
Videos
Search for ‘DJI GO 4’ in the App Store or Google Play, or scan
the QR code to download the app on your mobile device.
DJI GO 4
protector from the arms and landing camera. gears.
It is recommended to mount the propeller guards when flying
in Beginner Mode or indoors to ensure better safety. Refer to
the Mavic Air Propeller Guards User Guide to learn more.
●It is recommended to have the gimbal protector
attached when the aircraft is not in use. Make sure the gimbal is horizontal when mounting or
removing the gimbal protector.

●Ensure the landing gear is properly unfolded before use. Otherwise, the built-in antenna may be
affected causing serious problems to the video link. Make sure you fold the landing gears first before
folding the aircraft arms.
3. Charging the Batteries
Use the provided charger to full charge the
Intelligent Flight Battery before first time use.

Press once to check the
battery level. Press once, then
again and hold to turn on/off.
Press the Power button once
to check the current battery
level. Press once, then again
and hold to turn on/off the
remote controller.
4. Preparing the Remote Controller
mobile device clamps, controller cable to the end of device within
the then attach the control sticks. the slot on the side of the clamps.

controller
Use your DJI account to activate the aircraft. Activation requires an internet connection.
Internet
6. Flight
Before taking off, make sure the Aircraft Status Ready to Go
(GPS) Bar in the DJI GO 4 app displays ‘Ready to Go’.

●Controlling flight with Virtual Joysticks on your mobile device via Wi-Fi

DJI GO 4
App
1. Power on the aircraft.
2. Press and hold the Function Button on the aircraft for four seconds until you
hear a double beep, switching to Wi-Fi control mode.
3. Launch the DJI GO 4 app and tap the icon in the top right corner of your
screen. Next, scan the Wi-Fi QR Code on the aircraft to start the connection.
Mavic_XXX
Turn on your mobile device's Wi-Fi and enter theWi-Fi password shown on the aircraft to connect to
the Mavic Air network if for any reason you cannot scan the QR code.
When using Wi-Fi in a wide open area with no Electro-Magnetic Interference, transmission distance
is approximately 262 ft (80 m) at an altitude of 164 ft (50 m).
Linking is required when switching back to Remote Control mode.
The Wi-Fi frequency of your
mobile device can be set to 2.4 GHz or 5 GHz. Set your Wi-Fi to 5 GHzfor less interference. Once
connected to the Mavic Air, you can change yourWi-Fi password or reset your Wi-Fi connection.
)
Refer to the User Manual for more information
(
In the DJI GO 4 App
. Tap Auto Takeoff.
4
. Now you can fly the aircraft with touch control via Virtual Joysticks.
5
Normal
QuickShot
ActiveTrack

TapFly Tripod SmartCapture
●Watch the tutorial in the DJI GO 4 app or on the Official DJI website to learn more.
●Always set an appropriate RTH altitude before takeoff. When the aircraft is
returning to the Home Point, you should guide it with the control sticks.
7. Fly Safe
Fly in Open Strong GPS Maintain Line Fly Below 400 Feet
Areas Signal of Sight (120 m)
Avoid flying over or near obstacles, crowds, high voltage power lines,
trees or bodies of water.
DO NOT fly near strong electromagnetic sources such as power lines
and base stations as it may affect the onboard compass.
DO NOT use the aircraft in adverse weather conditions such as rain,
snow, fog and wind speeds exceeding 10 m/s or 22 mph.
≥

No Fly Zone
Stay away from the rotating propellers Learn more at:
and motors. http://flysafe.dji.com/no-fly
It’s important to understand basic flight guidelines, for the safety of both you
and those around you. Don't forget to read the Disclaimer and Safety
Guidelines.
MAVIC is a trademark of DJI.
Copyright © 2018 DJI All Rights Reserved. Designed by DJI. Printed in China.
