iWantit iCRIP12 User manual

clock radio with docking
for iPhone and iPod
iCRIP12
instruction manual
(iPod and iPhone not included)
iCRIP12_IB_120508_Zell.indd 1 08/05/2012 3:00 PM

Contents
unpacking .......................................................................................................................................... 3
product overview ............................................................................................................................ 4
- front view ........................................................................................................................................................................... 4
- top view .............................................................................................................................................................................. 4
- rear view ............................................................................................................................................................................. 4
power source..................................................................................................................................... 5
mains power ................................................................................................................................................................ 5
basic operation ................................................................................................................................. 5
powering ON/OFF...................................................................................................................................................... 5
setting the time ..........................................................................................................................................................5
time auto-synchronization ..................................................................................................................................... 5
selecting modes ......................................................................................................................................................... 5
memory ......................................................................................................................................................................... 5
snooze function.......................................................................................................................................................... 6
sleep timer function.................................................................................................................................................. 6
dimmer button............................................................................................................................................................ 6
adjusting the volume................................................................................................................................................ 6
setting the alarms ...................................................................................................................................................... 6
FM operation..................................................................................................................................... 7
selecting FM mode .................................................................................................................................................... 7
searching for a station automatically.................................................................................................................. 7
searching for a station manually .......................................................................................................................... 7
for better reception ................................................................................................................................................... 7
presetting stations..................................................................................................................................................... 7
recalling a preset station ......................................................................................................................................... 7
iPod / iPhone operation .................................................................................................................. 8
charging your iPod / iPhone................................................................................................................................... 9
AUX operation................................................................................................................................... 9
maintenance.................................................................................................................................... 10
hints and tips...................................................................................................................................10
specications................................................................................................................................... 10
safety warnings............................................................................................................................... 11
iCRIP12_IB_120508_Zell.indd 2 08/05/2012 3:00 PM

3
The Main Unit
Instruction Manual
(P.N.: PM-19153-15401-000)
iPod / iPhone Supporter
(P.N.: MP-18123-38Y41-000)
Mains Adapter
(P.N.: FR-AAB27-37002-000)
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new iWantit Clock Radio with Docking for iPhone and
iPod.
We recommend that you spend some time reading this instruction manual in order that you fully
understand all the operational features it oers. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
iCRIP12_IB_120508_Zell.indd 3 08/05/2012 3:00 PM

4
AUXANT DC IN
product overview
front view
top view
rear view
1. iPod / iPhone Supporter
2
1
4
6
7
3
5
9
11
8
10
13
2
4
SOURCE
RECALL STORE
1
1
2
2
1
2. LCD Display
1. Screw
2. iPod / iPhone Dock
3. RECALL Button
4. SOURCE Button
5. Button
6. Button
7. SNOOZE/DIMMER/SLEEP Button
8. STORE Button
9. / 1Button
10. Button
11. / 2Button
1. FM Aerial
2. AUX IN Socket
3. DC IN Socket
4. Speaker
iCRIP12_IB_120508_Zell.indd 4 08/05/2012 3:00 PM

5
power source
mains power
Before using the unit, connect the
supplied mains adapter to the DC 5V IN
socket at the rear of the unit and then to
the mains socket.
basic operation
powering ON/OFF
1. After connecting the mains adapter to the unit and the mains socket, the display will
turn on and the time will be shown. (You will need to set the time.)
2. The unit will enter STANDBY mode.
3. Press the SOURCE button to switch the unit between the dierent modes (AUX, FM,
iPod).
4. Press and hold the SOURCE button until the“OFF” show on the display. The unit will
turn to Standby mode, and the time will display.
setting the time
The clock can only be set in STANDBY mode
1. In standby mode, press and hold the STORE button to enter the clock setting mode.
2. When you see the hour digits ashing, press the buttons to select the hour,
then press the STORE button to set.
3. The minutes digits will ash next. Press the buttons to select the minutes, then
press the STORE button to set the time and return to reviewing the clock.
time auto-synchronization
Each time an iPod / iPhone is docked, the clock will automatically adjust to the time on the
iPod / iPhone.
An iPod / iPhone can only sync time up to the nearest minute; it’s possible to have up to 59
seconds dierence between the clock radio and the synced iPod / iPhone.
selecting modes
Press the SOURCE button repeatedly to switch between modes (FM, iPod or AUX).
FM
AUX iPod
AUXANT DC IN
Unplug the mains adapter will
erase all FM preset stations and
alarm settings.
iCRIP12_IB_120508_Zell.indd 5 08/05/2012 3:00 PM

6
memory
When you power up the unit again, the unit enters the same mode and plays the same
station (FM, iPod or AUX) that it was left in when it was last turned o.
adjusting the volume
Press the or buttons to increase or decrease the volume level from 30 to 00.
setting the alarms
4. In standby mode, press and hold the 1or 2buttons to set the alarm 1 or 2. The hour
digits will ash.
5. Press the buttons to adjust the hour digits, then press the 1or 2buttons to
conrm.
6. The minute digits will ash. Press the buttons to adjust the minute digits, then
press the 1or 2buttons to conrm.
7. The alarm type will ash. Press the buttons to select the alarm type (Buzzer(B),
iPod / iPhone(I), FM Radio(F)). Press the 1or 2buttons to conrm.
8. The alarm volume will ash. Press the buttons to set the alarm volume. Press the
1or 2buttons to conrm.
snooze function
1. Press the SNOOZE/DIMMER/SLEEP button when the alarm sounds. The alarm will go
o and will sound again in approximately 9 minutes.
2. The snooze alarm will continue to go o every nine minutes. To turn the alarm o,
press the 1or 2buttons until SNOOZE disappears from the LED display.
sleep timer function
Use the sleep timer to turn the system o after a certain number of minutes in play mode.
By setting the sleep timer, you can fall asleep to music and know that your system will turn
o by itself rather than play all night.
1. To set the sleep timer press the SNOOZE/DIMMER/SLEEP button repeatedly to
view the dierent timer settings. The number of minutes shown will display in this
sequence:
10 mins 20 mins
90 mins
30 mins
80 mins
40 mins
70 mins
50 mins
60 mins
OFF
2. The system is now set to turn o after the number of minutes you have set. The display
will show “# mins”, e.g. “10 mins” means the unit will switch itself o after 10 minutes,
“15 mins” means the unit will switch itself o after 15 minutes, and so on.
3. Press the SNOOZE/DIMMER/SLEEP button to show the remaining time till the unit
switches o and return to previous screen.
4. To cancel the sleep timer press the SNOOZE/DIMMER/SLEEP button repeatedly until
“OFF” shows on the display.
dimmer button
In standby mode, press the SNOOZE/DIMMER/SLEEP button to select a brightness level.
iCRIP12_IB_120508_Zell.indd 6 08/05/2012 3:00 PM

7
FM operation
selecting FM mode
Press the SOURCE button repeatedly until you have switched to FM mode.
searching for a station automatically
To search for an FM station, press and hold the button. The unit will start scanning up
the frequency band. To scan down the frequency band, press and hold the button. Once
a station has been found, scanning will stop automatically.
If no station is found, then the tuning will stop once it has cycled through the entire FM
band (87.5-108MHz).
searching for a station manually
To search for FM stations manually, simply press the buttons repeatedly until your
desired frequency is reached.
for better reception
Fully unwind the FM aerial. Extend the FM aerial and place it in the position that oers the
best sound reception.
The unit will automatically switch between stereo and mono. This is helpful when signal
reception is poor.
presetting stations
You can store up to 20 of your favourite stations to the preset stations. This will enable you
to access your favourite stations quickly and easily.
1. To programme a preset station, you must rst be listening to the station that you
would like to save, then press and hold the STORE button.
2. Press the buttons to select your desired preset station number.
3. Press the STORE button once more to conrm the selection.
recalling a preset station
1. Once you have saved a station, you can recall it by pressing the RECALL button.
2. Press the buttons to select your desired preset station number.
Unplugging the mains adapter will erase the all preset memory.
iCRIP12_IB_120508_Zell.indd 7 08/05/2012 3:00 PM

8
iPod / iPhone operation
The unit can support the following iPod / iPhone models.
Type Support Model
iPhone • iPhone
• iPhone 3G/3GS
• iPhone 4/4S
iPod
(with 30-pin dock
connectors)
• iPod touch 1st/2nd/3rd/4th Generation
• iPod Classic
• iPod nano 1st/2nd/3rd/4th/5th/6th Generation
• iPod 4th Generation (with and without colour display)
• iPod 5th Generation (video)
• iPod mini
1. Press the SOURCE button repeatedly to switch to iPod / iPhone mode.
2. Slot the iPod / iPhone support into the iPod / iPhone dock until it sits rmly in place.
SOURCE
RECALL STORE
1
1
2
SOURCE
RECALL STORE
1
1
2
3. Slot your iPod / iPhone onto the dock.
4. If the iPod / iPhone is connected, the unit will start playback (it will take around 10
seconds for the unit to identify the iPod / iPhone). The iPod / iPhone battery will start
to charge automatically until it is fully charged.
iCRIP12_IB_120508_Zell.indd 8 08/05/2012 3:00 PM

9
• If you charge the iPod / iPhone while playing music, it may take longer than normal.
• You can play / pause and select the previous / next track from the controls on the unit. All
other functions can only be controlled from your iPod / iPhone.
• 1st, 2nd & 3rd generation iPods cannot be charged.
• On some iPod / iPhone models, if your battery has completely discharged, the unit may
not charge the iPod / iPhone. If this occurs, we suggest charging through your PC or your
iPod / iPhone mains charger.
5. Select your desired music, or video, etc., and play the connected iPod / iPhone as usual.
You can do this on either the iPod / iPhone or the unit.
To Press
Start Playback
Pause Playback
Resume Playback
Previous Track
Next Track
Increase Volume
Decrease Volume
AUX operation
1. Before connecting to the mains socket, use a 3.5mm LINE IN cable (not included) to
connect your audio device through the AUX IN socket at the rear of the unit.
2. Connect the mains adapter to the unit, then the mains socket. The unit will enter
Standby mode.
3. Press the SOURCE button repeatedly until you have switched to AUX mode
4. In AUX mode, you may operate your audio device directly for playback features.
charging your iPod / iPhone
1. Your iPod / iPhone has an internal non-removable battery, the battery may need to be
charged if it has not been used for a while.
2. You can automatically charge the iPod / iPhone through the unit when in all modes.
The unit cannot show any music information on your iPod / iPhone.
Please view the music information on your iPod’s / iPhone’s display.
iCRIP12_IB_120508_Zell.indd 9 08/05/2012 3:00 PM

10
maintenance
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray an aerosol at or near the unit.
hints and tips
problem cause / solution
No Sound Adjust the volume control, it may not be turned up.
Static Sound Poor reception. Adjust the aerial or move the unit to a stronger signal
location.
Sound is distorted Volume is too high. Adjust the volume.
Desired station not found Weak signal. Use the manual tune function.
No sound in AUX-IN mode Ensure that the audio plug is fully inserted and the unit is in AUX-IN
mode.
specications
mains supply Mains adapter Input 100-240V ~ 50/60 Hz 0.4A
Mains adapter Output DC 5V 2.5A
output power 2 X 2.5W
radio frequency range FM87.5 – 108 MHz
Features and specications are subject to change without prior notice.
Ensure the unit is fully unplugged from the mains socket before cleaning.
iCRIP12_IB_120508_Zell.indd 10 08/05/2012 3:00 PM

safety warnings
• Read all the instructions carefully before using
the unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a
third party make sure to include this manual.
• Check that the voltage marked on the rating
label matches your mains voltage.
damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you are
in any doubt about it working normally, or if it
is damaged in any way - switch o, withdraw
the mains adapter and consult your dealer.
location of unit
• The unit must be placed on a at stable surface
and not subjected to vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the unit
and should be easily accessible.
• This unit is designed for indoor, domestic use only.
temperature
• Avoid extreme degrees of temperature, either
hot or cold. Place the unit well away from heat
sources such as radiators or gas/ electric res.
• Do not expose the battery to direct sunlight or
sources of excessive heat.
naked ames
• Never place any type of candle or naked ame
on the top of or near the unit.
moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases, should
be placed on the unit.
• If you spill any liquid into the unit, it can cause
serious damage. Switch it o at the mains
immediately. Withdraw the mains plug and
consult your dealer.
ventilation
• To prevent the risk of electric shock or re
hazard due to overheating, ensure that
curtains and other materials do not obstruct
the ventilation vents.
• Do not install or place this unit in a bookcase,
built-in cabinet or in another conned space.
Ensure the unit is well ventilated.
safety
• Always disconnect the unit from the mains
supply before connecting/disconnecting other
devices or moving the unit.
• Unplug the unit from the mains socket during
a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption, never leave
the unit switched on while unattended for
long periods of time, e.g. overnight, while on
holiday or while out of the house. Switch it o
and disconnect the mains adapter from the
mains socket.
mains adapter cable
• Make sure the unit or unit stand is not resting
on top of the mains adapter cable, as the
weight of the unit may damage the mains
adapter and create a safety hazard.
interference
• Do not place the unit on or near appliances
which may cause electromagnetic interference.
If you do, it may adversely aect the working of
the unit, and cause a distorted sound.
supervision
• Children should be supervised to ensure that
they do not play with the unit.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a fatal
electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure that
may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
maintenance
• Ensure to unplug the unit from the mains
socket before cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the
unit’s surface.
• Do not use liquids to clean the unit.
iCRIP12_IB_120508_Zell.indd 11 08/05/2012 3:00 PM

DSGRetailLtd•MaylandsAvenue•HemelHempstead
Herts•HP27TG•England
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its
life separately from your household waste. There are separate collection
systems for recycling in the EU.
For more information, please contact the local authority or your retailer
where you purchased the product.
NOTE: If you require a replacement for any of the items listed below, please quote their
corresponding part numbers:
replacement part part number
Mains Adapter FR-AAB27-37002-000
iPod / iPhone Support MP-18123-38Y41-000
(P.N. PM-19153-15401-000)
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million spares
and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK customers only)
Calls charged at National Rate.
All trademarks are the property of their respective owners and all rights are acknowledged.
iPhone and iPod are trademarks of Apple Inc.,
registered in the U.S. and other countries.
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been
designed to connect specically to iPod or iPhone respectively, and has been certied by
the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and
regulatory standards.
iCRIP12_IB_120508_Zell.indd 12 08/05/2012 3:00 PM
