iXBlue SeapiX User manual

SeapiX
Installation Manual

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 2
Revision History
Edition
Date
Comments
A
01/2020
Creation

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 3
Copyright
All rights reserved. No part of this manual may be reproduced or transmitted, in any form or
by any means, whether electronic, printed manual or otherwise, including but not limited to
photocopying, recording or information storage and retrieval systems, for any purpose
without prior written permission of iXblue.
Disclaimer
iXblue specifically disclaims all warranties, either expressed or implied, included but not
limited to implied warranties of merchantability and fitness for a particular purpose with
respect to this product and documentation. iXblue reserves the right to revise or make
changes or improvments to this product or documentation at any time without notify any
person of such revision or improvments.
In no event shall iXblue be liable for any consequential or incidental damages, including but
not limited to loss of business profits or any commercial damages, arising out of the use of
this product.
Trademarks
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
Intel and Pentium are registered trademarks and Celeron is a trademark of Intel
Corporation.
Delph is a registered trademark of ELICS.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 4
Warranty
iXblue provides a standard warranty of two (2) years covering this product against any
defect in materials or manufacture. The warranty starts from the date of the product received
at the customer’s location. In the event that a defect in materials or manufacture becomes
obvious during the stipulated warranty period, iXblue will undertake, at its sole discretion,
either to repair the defective product, bearing the cost of all parts and labor, or to replace it
with an identical product.
In order to avail itself of this warranty, Customer must notify iXblue of the defect before
expiry of the warranty period and take all steps necessary to enable iXblue to proceed.
Customer shall be responsible for the packaging and the shipment of the defective product
to the repair center notified by iXblue, the cost of such shipment being borne by Customer.
iXblue agrees to bear the cost of return freight, based on CPT (Cost Paid To) Customer’s
airport location, import tax-free.
This warranty shall not be construed as covering defects, malfunctions or damages caused
by improper use or inadequate maintenance of the product. Under no circumstances shall
iXblue be due to provide repair or replacement under this warranty in order a) to repair
damage caused by work done by any person not representing iXblue for the installation,
repair or maintenance of the product ; b) to repair damage caused by improper use or
connection to incompatible equipment, and specifically, the opening of the housing of the
equipment under warranty shall cause the warranty to be automatically cancelled ; c) to
maintain any product that has been modified or integrated into a larger configuration, if such
modification or integration increases the duration or difficulty of the maintenance of said
product ; d) the operating defect is caused by an intervention or as a result of a modification
that was performed without iXblue prior consent ; e) the failure was caused by normal
deterioration (wear and tear) of the product, or by negligence or by improper care on the
part of the Customer.
This warranty covers the product hereunder and is provided by iXblue in place of all and
any other warranty whether expressed or implied. iXblue does not guarantee the suitability
of the product under warranty for sale or any specific use. iXblue’s liability is limited to the
repair or replacement of defective products, this being the sole remedy open to Customer
in the event the warranty becomes applicable. iXblue cannot be held liable for indirect,
special, subsequent or consequential damage, irrespective of whether iXblue has or has
not received prior notification of the risk of occurrence of such damage. The repair,
replacement or re-performance of parts of defective product shall not cause the warranty
period mentioned above to be extended, to the exception of the said replaced, repaired or
re-performed parts for which a 3 month warranty period is granted from shipment to the
Customer of the replaced or repaired product part.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 5
Software License Agreement
PLEASE READ THIS SOFTWARE LICENSE AGREEMENT CAREFULLY BEFORE
INSTALLING OR USING THE SOFTWARE.
BY CLICKING ON THE "ACCEPT" BUTTON, INSTALLING THE SOFTWARE, OR USING
THE SOFTWARE, YOU ARE CONSENTING TO BE BOUND BY THIS AGREEMENT. IF
YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT, CLICK THE "DO
NOT ACCEPT" BUTTON AND THE INSTALLATION PROCESS WILL NOT CONTINUE,
RETURN THE PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.
iXblue grants you a non-exclusive and non-transferable license to use the enclosed iXblue
software in the manner provided below:
•the number of software users depends on the licenses agreed by iXblue. The user is
able to connect with a security key provided by iXblue for use on a single computer;
•you may couple multiple iXblue licenses on a single computer;
•you may make up to two (2) copies of the software for archival or backup purposes,
provided that you reproduce proprietary notices.
•You shall not share by any means, other than by agreement with iXblue, the software
licenses between multiple computers.
•You shall not copy the software except as set forth in the section above. Any copy of the
software that you make must contain the same copyright and other proprietary notices
that appear on or in the software.
•You shall not modify, adapt or translate the software. You shall not reverse engineer,
decompile, disassemble or otherwise attempt to modify or discover the source code of
the software.
•You shall not install, neither operate the software on virtual machines.
•You shall not, rent, lease, sublicense, assign or transfer your rights in the software
without prior written authorization from iXblue.
The software (including any images, animations and text incorporated into the software) is
owned by iXblue and protected by copyright laws and international treaty provisions
applicable.
iXblue offers software maintenance during the warranty period. This maintenance includes
the delivery of minor documentary and software licenses. The major or intermediary updates
are not included and shall be dealt with in a separate agreement. If the software supplied
under license is an updated version, the licensee will only be allowed to use the software in
order to replace versions of the same software previously and duly acquired under license.
Extended Maintenance Agreements –E.M.A. –may be purchased to extend the product
maintenance after the warranty period. An E.M.A. shall be applied to every software license
that will be maintained and upgraded.
Grant of license
Restrictions
Copyright
Maintenance /
Data update
Extended
Maintenance

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 6
Technical support is available free of charge during the warranty period:
•On iXblue website: http://www.ixblue.com/
•By dedicated e-mail box: [e-mail]
•24/7 hotline: [phone] (EMEA-LATAM), [phone] (NORAM), +65 6747
7027 (APAC)
The price comprises the main product together with accessories: grant of license and
accrued expenses (as referred to in the order, contract, or in the manufacturer or supplier
price list).
The user license is considered to be granted when iXblue acknowledges reception of the
whole price paid by the Buyer. Payment is made by means of a secure electronic payment
system or by any other means authorized by iXblue.
iXblue will notify reception of payment by electronic mail.
In case of non-payment and/or non-respect of the present terms, all rights of the license
and the use of software will be terminated, without prejudice to any legal action iXblue may
carry out against the defaulting party.
The Buyer will be obliged, at its own expense and risk, to return to iXblue all copies of the
software under license in its possession together with physical protection keys, or to confirm
in writing that all software copies under license in its possession have been destroyed.
iXblue reserves the right to proceed to all the necessary verifications in order to be assured
of the buyer’s observance of the aforementioned conditions.
This license agreement is governed by the laws of France. Both parties will do their utmost
to bring an end to disputes relative to the interpretation and/or the execution of this
document by settling an amicable agreement between their respective management. If an
amicable agreement has not been reached within three months, the dispute will be
submitted to the jurisdiction of the competent courts of Paris.
Technical support
Price
Termination
Applicable law
and Settlement of
disputes

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 7
Limited Warranty
iXblue guarantees that the software will perform substantially in accordance with the
accompanying written materials for a period of two (2) years from the date of shipment.
iXblue’s entire liability and your exclusive remedy shall be, at iXblue’s option, repair or
replacement of the software that does not meet iXblue’s Limited Warranty. Warranty service
is F.O.B. iXblue France. All shipping and insurance costs to iXblue are paid for by the Buyer;
shipping and insurance costs returning to the Buyer will be paid for by iXblue.
On-site Customer Service and Warranty Repair may be provided by iXblue, at its own
discretion. Travel and accommodation (including travel hours, transportation, lodging and
meals) will be charged by iXblue to the Buyer at cost plus ten (10) per cent. However, actual
labor hours to provide this service or repair will be free of charge to the Buyer. This Limited
Warranty is void if failure of the software or hardware has resulted from accident, abuse, or
misapplication. Any replacement software or hardware will be guaranteed for the remainder
of the original warranty period or thirty (30) days, whichever is longer.
iXblue makes no other warranties than the above limited warranties. iXblue makes no
warranties, expressed, implied, statutory, or in any communication with you, and iXblue
specifically disclaims any implied warranty of merchantability or fitness for a particular
purpose. iXblue does not warrant that the operation of the program will be uninterrupted or
error free. The Buyer agrees that the responsibility, based on contract or tort law, or the
responsibility related to the warranty, shall not exceed the price paid for the acquisition of
the product.
iXblue’s liability is excluded in case of misuse of the software or any use in contradiction
with iXblue’s instructions. This application program is only to be used in order to help
optimize fishing and shall not exempt the skipper of his responsibilities in terms of navigation
security and respect for law enforcement.
iXblue will not replace lost dongles free of charge, neither offer discounted pricing terms for
replacement dongles.
iXblue strongly recommends that you insure your iXblue products against loss, theft or
damage where applicable.
iXblue will propose the replacement of damaged dongles only for a limited fee, provided
that the damaged dongle units are returned to iXblue. All shipping and insurance costs are
paid for by the buyer.
Warranty period
Customer
Remedies
Limitations
Liability
Dongles

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 8
Export Regulation
Export of the products and services described in this document may be subject to different
national rules and regulations related to export control.
iXblue products and services shall not be exported, re-exported or used in the following
countries (including their territorial waters): Cuba, Iraq, Iran, North Korea, Sudan and Syria.
The following export control guidelines shall apply as related to French rules and
regulations.
This product or service can be freely exported.
Free export

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 9
Manual Overview
This manual is the Installation Manual for SeapiX manufactured by iXblue. It is intended for
qualified installing technicians. It must be read and understood prior to using SeapiX. The
manufacturer shall in no case be held liable for any application or use that does not comply
with the stipulations in this manual.
It is divided into several chapters:
•Part 1: Introduction
This part contains a general descrition of SeapiX and provides information about the theory
of operation.
•Part 2: Technical Characteristics
This part gives details on mechanical, acoustic and electrical characteristics of the SeapiX
components.
•Part 3: SeapiX Pack
This part details a typical SeapiX pack and its contents; it also gives some
recommendations.
•Part 4: Installation Process
This part details SeapiX installation process.
•Part 5: SeapiX Commissioning
This part details how to set up SeapiX for the first time.
•Part 6: SeapiX Configuration
This part details which parameters to set prior to using SeapiX.
•Part 7: Shutdown Procedure
This part explains how to shut down SeapiX system properly.
•Part 8: Software Upgrade
This part explains how to upgrade SeapiX programs.
•Part 9: Preventive Maintenance
This part describes the preventive maintenance tasks.
•Part 10: Troubleshooting
This part provides a table helping to solve minor problems encoutered while using SeapiX.
•Part 11: Support through TeamViewer
This part provides support contacting information through TeamViewer.
•Appendices
It contains the detailed drawings and diagrams.
Warning: SeapiX is NOT a navigation tool. SeapiX is a fishing tool and it must be used as
such.
The abbreviations and acronyms used in this manual are listed hereafter.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 10
Abbreviations and Acronyms
BFU Beam Former Processor Unit
CSV Plain text format file
ETA Estimated Time of Arrival
FEBL Tool showing the Range Bearing Line
GUI Graphical Interface Unit
ITU Interface Unit
GNSS Global Navigation Satellite System (including GPS, ...)
MRU Motion Reference Unit
RX Reception
SAT Sonar Axial Tiltable mode
SATA Data transfer format
SAU Sonar Antenna Unit
SAV Sonar Axial Volumetric mode
SED Single Echo Detection
SLI Sonar Lateral Imaging mode
STT Sonar Transverse Tiltable mode
STV Sonar Transverse Vertical mode
SV Scattered Volume; in acoustics, fish shoal measurement mode (in dB)
TS Target Strength; in acoustics, single fish measurement mode (in dB)
TX Transmission
VPU Viewer Processor Unit

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 11
Text Usage
Bold
Bold text is used for items you must select or click in the software.
It is also used for the field names used into the dialog box.
Courier
Text in this font denotes text or characters that you should enter
from the keyboard, the proper names of disk Drives, paths,
directories, programs, functions, filenames and extensions.
Italic
Italic text is the result of an action in the procedures. It is also
used for referencing to other document titles.
Icons
The Note icon indicates that the following information is of particular interest and should be
read with care.
Important
The Important mention indicates that the following information should be read to forbid or
prevent a product dysfunction or a faulty operation of the equipment.
The Caution icon indicates that the following information should be read to forbid or
prevent product damage.
The Warning icon indicates that possible personal injury or death could result from failure
to follow the provided recommendation.
The Advanced/Expert icon indicates that the described procedure/action is reserved to
advanced level of operation.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 12
Table of Contents
1INTRODUCTION............................................................................................................ 14
1.1 SEAPIXSYSTEM OVERVIEW.......................................................................................................14
1.2 SEAPIXPRINCIPLE....................................................................................................................15
1.2.1 Downward-Looking Swath.................................................................................................16
1.2.2 Forward-Looking Swath.....................................................................................................16
1.2.3 Side-Looking Swath...........................................................................................................16
2TECHNICAL CHARACTERISTICS.................................................................................... 17
2.1 SEAPIX-F .................................................................................................................................17
2.2 SEAPIX-R.................................................................................................................................18
2.3 SEAPIX-L .................................................................................................................................19
3SEAPIXPACK ............................................................................................................. 20
3.1 PACK CONTENTS ......................................................................................................................20
3.2 DESCRIPTION OF THE PACK ITEMS .............................................................................................21
4INSTALLATION PROCESS ............................................................................................. 23
4.1 INSTALLATION CHECKLIST.........................................................................................................24
4.2 CABLING AND WIRING ...............................................................................................................27
4.2.1 Transducer Cable (SAU↔ITU) ..........................................................................................27
4.2.1.1 Bending Radius..................................................................................................................28
4.2.1.2 Connectors.........................................................................................................................28
4.2.2 Ethernet Cables (ITU↔BFU and BFU↔VPU)...................................................................30
4.2.3 Control Command Cable (ITU↔BFU) ...............................................................................31
4.3 CHECKING THE SYSTEM BEFORE INSTALLING .............................................................................32
4.4 INSTALLING SEAPIXANTENNA UNIT (SAU)................................................................................33
4.4.1 Considering the Slamming.................................................................................................33
4.4.2 Cooling Down the SAU......................................................................................................33
4.4.3 Corrosion Protection of the SAU........................................................................................33
4.4.4 Hull-Mounting an SAU Step by Step..................................................................................34
4.4.4.1 Views of Hull-Mounted Antennas......................................................................................37
4.4.5 Pole-Mounting an SAU Step by Step.................................................................................39
4.4.5.1 Views of Pole-Mounted Antennas......................................................................................40
4.5 INSTALLING THE INTERFACE UNIT (ITU) .....................................................................................41
4.6 INSTALLING THE BEAM FORMER UNIT (BFU)..............................................................................42
4.7 INSTALLING THE VIEWER PROCESSOR UNIT (VPU).....................................................................43
4.7.1 SeapiX Software installation..............................................................................................44
4.7.2 SeapiX Software reinstallation...........................................................................................44
5SEAPIXCOMMISSIONING ............................................................................................. 45
6SEAPIXCONFIGURATION............................................................................................. 47
6.1 SETTING THE OFFSETS..............................................................................................................47
6.1.1 Offset Conventions ............................................................................................................47
6.1.2 Offsets Menu......................................................................................................................47
6.2 SETTING THE INPUTS.................................................................................................................48

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 13
6.3 SETTING THE OUTPUTS .............................................................................................................53
6.4 CHECKING STATUS THROUGH MAIN CONTROLS..........................................................................54
6.5 SOFTWARE VERSION &UNITS ...................................................................................................55
7SHUTDOWN PROCEDURE .............................................................................................56
8SOFTWARE UPGRADES................................................................................................57
9PREVENTIVE MAINTENANCE.........................................................................................58
10 TROUBLESHOOTING ....................................................................................................62
11 SUPPORT THROUGH TEAMVIEWER ...............................................................................66
11.1 USING TEAMVIEWER .................................................................................................................66
11.2 REINSTALLING TEAMVIEWER.....................................................................................................68
AMECHANICAL AND ELECTRICAL DRAWINGS................................................................................72

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 14
1Introduction
1.1 SeapiX System Overview
SeapiX is a volumetric 3D Sonar dedicated to the fishing industry. It provides a realistic fish
evaluation together with a full ecosystem description. Composed of a dual Mills Cross
multibeam sonar array, this compact system is able to generate one or more scan swaths
along or across a vessel axis. The result is a total three-dimensional coverage of the water
column; it also provides a bathymetric profile of the seabed and the identification of the
sediment type.
SeapiX is connected to the vessel navigation system for real-time geo-referenced data
generation. it is used with SeapiX Surface Software for configuration, control and
visualization of data.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 15
1.2 SeapiX Principle
SeapiX is a volumetric multibeam echosounder which can operate:
•downward-looking,
•forward-looking,
•side-looking.
Each multibeam swath is proposed along and across the vessel track (is either “axial” or
“transverse”). Swaths are tiltable to control the biomass all around the vessel. For each
swath, 3 echogram sectors are formed from 1° to 120° beam aperture.
On board a fishery vessel, the skipper watches the shoal behavior and steers the vessel to
perform catches.
Warning: SeapiX is NOT a navigation tool. SeapiX is a fishing tool and it must be
used as such.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 16
1.2.1 DOWNWARD-LOOKING SWATH
Downward-looking swath (axial & transverse)
1.2.2 FORWARD-LOOKING SWATH
Forward-looking swath (axial & transverse)
1.2.3 SIDE-LOOKING SWATH
Side-looking swath (axial & transverse)
Axial swaths correspond to SAT or SAV sonar modes.
Transverse swaths correspond to STT or STV sonar modes.

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 17
2Technical Characteristics
Seapix is available in 3 versions:
•SeapiX-F for fishery
•SeapiX-R for fishery research
•SeapiX-L for marine science and fish farming
2.1 SeapiX-F
SeapiX-F is dedicated to the fish industry and is installed on fishery vessels.
SeapiX-F SAU
Applications
Fishery
Frequency
150 kHz
Modulation
CW and Chirp
Across-track multibeam swath
64 channels, stabilized
Along-track multibeam swath
64 channels, stabilized
Beam stabilization
TX + RX, built-in MRU
Beam resolution
1.6° angular / 7.5 cm radial
Triple echograms from all swaths
Adjustable from 1° to 120° each
Typical range
Biomass 400m, Bathymetry 600 m
Volume resolution
0,6 m3@100 m
Volume coverage
120° X 120°
Signal processing
SV, TS, NORMALIZED
SED fish extraction
Up to 200.000 single fish detection
Transmission power
2 kW (4 kW as an option)
Scientific pack
(option)
Sonar Antenna Unit (SAU) cable
20 m
SAU weight
61.5 kg

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 18
2.2 SeapiX-R
SeapiX-R is dedicated to fishery research and is installed on large fishery research vessels.
SeapiX-R SAU
Applications
Fishery research
Frequency
150 kHz
Modulation
CW and Chirp
Across-track multibeam swath
64 channels, stabilized
Along-track multibeam swath
64 channels, stabilized
Beam stabilization
TX + RX, built-in MRU
Beam resolution
1.6° angular / 7.5 cm radial
Triple echograms from all swaths
Adjustable from 1° to 120° each
Typical range
Biomass 400 m, Bathymetry 600 m
Volume resolution
0,6 m3@100 m
Volume coverage
120° X 120°
Signal processing
SV, TS, NORMALIZED
SED fish extraction
Up to 200.000 single fish detection
Transmission power
4 kW
Scientific pack
yes
Sonar Antenna Unit (SAU) cable
20 m
SAU weight
61.5 kg

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 19
2.3 SeapiX-L
SeapiX-L is a mobile research version dedicated to marine Science and fish Farming; it can
be mounted on a pole and used on an “opportunity vessel”.
SeapiX-L SAU
Applications
Marine science and fish farming
Frequency
150 kHz
Modulation
CW and Chirp
Across-track multibeam swath
64 channels, stabilized
Along-track multibeam swath
64 channels, stabilized
Beam stabilization
TX + RX, built-in MRU
Beam resolution
1.6° angular / 7.5 cm radial
Triple echograms from all swaths
Adjustable from 1° to 120° each
Typical range
Biomass 400m, Bathymetry 600 m
Volume resolution
0,6 m3@100 m
Volume coverage
120° X 120°
Signal processing
SV, TS, NORMALIZED
SED fish extraction
Up to 200.000 single fish detection
Transmission power
2 kW (4 kW as an option)
Scientific pack
yes
Sonar Antenna Unit (SAU) cable
20 m
SAU weight
24 kg, floating

SeapiX –Installation Manual
SSD-C-1306 Ed. A –01/2020 20
3SeapiX Pack
3.1 Pack Contents
The shipping pack contains a Packing List detailing all delivered items. This Packing List
has been completed and checked for by iXblue shortly before shipment and should match
the content of the pack that you have received.
CAUTION: PACK NON-CONFORMITY OR DAMAGE
It is recommended to check the content of the pack and all equipment items immediately
after reception. Specifically, you should check that all items referred to in the Packing List
are present and that none has sustained damage.
If you observe any non-conformity or damage, please inform the carrier and iXblue
without delay by certified mail describing in detail the problem encoutered.
Example of a SeapiX Packing List
